cv4pve-autosnap

License Release GitHub All Releases Nuget

Proxmox VE automatic snapshot tool

More information about cv4pve-autosnap

More information about Qemu guest agent

    ______                _                      __
   / ____/___  __________(_)___ _   _____  _____/ /_
  / /   / __ \/ ___/ ___/ / __ \ | / / _ \/ ___/ __/
 / /___/ /_/ / /  (__  ) / / / / |/ /  __(__  ) /_
 \____/\____/_/  /____/_/_/ /_/|___/\___/____/\__/

 Corsinvest for Proxmox VE Auto Snapshot    (Made in Italy)

Usage: cv4pve-autosnap [options] [command]

Options:
  -?|-h|--help        Show help information
  --version           Show version information
  --host              The host name host[:port],host1[:port],host2[:port]
  --api-token         Api token format 'USER@REALM!TOKENID=UUID'. Require Proxmox VE 6.2 or later
  --username          User name <username>@<realm>
  --password          The password. Specify 'file:path_file' to store password in file.
  --vmid              The id or name VM/CT comma separated (eg. 100,101,102,TestDebian)
                      -vmid or -name exclude (e.g. -200,-TestUbuntu)
                      '@pool-???' for all VM/CT in specific pool (e.g. @pool-customer1),
                      '@all-???' for all VM/CT in specific host (e.g. @all-pve1, @all-\$(hostname)),
                      '@all' for all VM/CT in cluster
  --timeout           Timeout operation in seconds
  --timestamp-format  Specify different timestamp format. Default: yyMMddHHmmss
  --max-perc-storage  Max percentage storage (default 95%)

Commands:
  app-check-update    Check update application
  app-upgrade         Upgrade application
  clean               Remove auto snapshots
  snap                Will snap one time
  status              Get list of all auto snapshots

Run 'cv4pve-autosnap [command] --help' for more information about a command.

cv4pve-autosnap is a part of suite cv4pve-tools.
For more information visit https://www.cv4pve-tools.com

Copyright and License

Copyright: Corsinvest Srl For licensing details please visit LICENSE.md

Commercial Support

This software is part of a suite of tools called cv4pve-tools. If you want commercial support, visit the site

Tutorial

Tutorial

GUI Version Toolbox

Tutorial

Introduction

Automatic snapshot for Proxmox VE with retention.

In this version the tool works outside the Proxmox VE host using the API. The reasons are:

  • if the host does not work the tool does not work
  • using the API, future changes are guaranteed
  • Root access is not required, a user is required to perform the operation
  • use of standard https / https json technology

Main features

  • Completely written in C#
  • Use native Api REST Proxmox VE (library C#)
  • Independent os (Windows, Linux, Macosx)
  • Installation rapid, unzip file extract binary
  • Not require installation in Proxmox VE
  • Execute out side Proxmox VE
  • For KVM and LXC
  • Work for single node or cluster, automatically resolve VM/CT id/name
  • Use id or name with --vmid parameter
  • Can keep multiple snapshots --keep
  • Clean all snapshots
  • Multiple schedule VM/CT using --label (es. daily,monthly)
  • Hook script
  • Multiple VM/CT (100,102,ubuVm,debVm,pipperoVm,fagianoVm or all or pool) in a single execution
  • Exclusion specific VM/CT using minus e.g --vmid=all,-100
  • Exclusion template from snapshot
  • Waiting for the snapshot process to finish
  • Alerting in QEMU, agent not enabled.
  • Save memory VM Qemu in snap using parameter --state.
  • No stop on error
  • Script hook for metrics
  • Timeout remove/create snapshot in --timeout parameter specify in second
  • Support multiple host for HA in --host parameter es. host[:port],host1[:port],host2[:port]
  • Multiple output text,unicode,unicodeAlt,markdown,html
  • Check-Update and Upgrade application
  • Use Api token --api-token parameter
  • Support range vmid 100:103,134,200:204,-102
  • Support different timestamp format with parameter --timestamp-format
  • Check the storage space used by the disks in the VM / CT is available by default (95%) parameter --max-perc-storage

Permission

For execution is required permission: VM.Audit, VM.Snapshot, Datastore.Audit, Pool.Allocate.

Api token

From version 6.2 of Proxmox VE is possible to use Api token. This feature permit execute Api without using user and password. If using Privilege Separation when create api token remember specify in permission.

Custom timestamp format

Timestamp format is based on C# date and time format string.

Configuration and use

E.g. install on linux 64

Download last package e.g. Debian cv4pve-autosnap-linux-x64.zip, on your os and install:

root@debian:~# unzip cv4pve-autosnap-linux-x64.zip

This tool need basically no configuration.

Snapshot a VM/CT one time

root@debian:~# cv4pve-autosnap --host=192.168.0.100 --username=root@pam --password=fagiano --vmid=111 snap --label=daily --keep=2

This command snap VM 111.

root@debian:~# cv4pve-autosnap --host=192.168.0.100 --username=root@pam --password=fagiano --vmid="all,-111" snap --label=daily --keep=2
ACTION Snap
VMs:              all,-111
Label:            daily
Keep:             2
State:            False
Timeout:          30000
Timestamp format: yyMMddHHmmss
Max % Storage :   95%
----------------------------------------------------------------------------
| Storage          | Type    | Valid | Used %  | Max Disk (GB) | Disk (GB) |
----------------------------------------------------------------------------
| cv-pve01/hddpool | zfspool | Ok    | 58.2    | 1797          | 1046      |
| cv-pve01/nfs-arc | nfs     | Ok    | 21.1    | 3269          | 689       |
| cv-pve01/ssdpool | zfspool | Ok    | 24.4    | 859           | 209       |
| cv-pve02/hddpool | zfspool | Ok    | 71.7    | 1797          | 1288      |
| cv-pve02/nfs-arc | nfs     | Ok    | 21.1    | 3269          | 689       |
| cv-pve02/ssdpool | zfspool | Ok    | 5.5     | 898           | 49        |
----------------------------------------------------------------------------
----- VM 103 Qemu -----
VM 103 consider enabling QEMU agent see https://pve.proxmox.com/wiki/Qemu-guest-agent
Create snapshot: autodaily211203164953
Remove snapshot: autodaily211202164953
VM execution 00:00:02.3060904
----- VM 105 Qemu -----
Create snapshot: autodaily211203164955
Remove snapshot: autodaily211202164955
....

This command snap all VMs except 111.

The --keep tells that it should be kept 2 snapshots, if there are more than 2 snapshots, the 3 one will be erased (sorted by creation time). The --state save memory VM. The --timeout specify the timeout remove/creation snapshot.

When create a snapshot the software add "auto" prefix of the name the snapshot.

On the VM it is checked if "QEMU agent" is enabled, otherwise an alert is displayed.

Clean a VM/CT one time

root@debian:~# cv4pve-autosnap --host=192.168.0.100 --username=root@pam --password=fagiano --vmid=111 clean --label=4hours --keep=2
----- VM 100 QEMU -----
Remove snapshot: auto4hours190617080002
Remove snapshot: auto4hours190617120002
Remove snapshot: auto4hours190617160002
Remove snapshot: auto4hours190617200002

Status snapshots

root@debian:~# cv4pve-autosnap --host=192.168.0.100 --username=root@pam --password=fagiano --vmid=100 status

┌──────┬─────┬───────────────────┬──────────────────────────────┬──────────────────────────────┬─────────────────┬─────┐
│ NODE │ VM  │ TIME              │ PARENT                       │ NAME                         │ DESCRIPTION     │ RAM │
├──────┼─────┼───────────────────┼──────────────────────────────┼──────────────────────────────┼─────────────────┼─────┤
│ pve1 │ 100 │ 19/08/28 09:21:35 │ no-parent                    │ auto4hours190828112133       │ cv4pve-autosnap │     │
│ pve1 │ 100 │ 19/08/28 12:23:09 │ auto4hours190828112133       │ auto4hours190828142307       │ cv4pve-autosnap │     │
│ pve1 │ 100 │ 19/08/29 06:50:23 │ auto4hours190828142307       │ auto4hours190829085021       │ cv4pve-autosnap │     │
│ pve1 │ 100 │ 19/08/29 07:32:15 │ auto4hours190829085021       │ auto4hours190829093214       │ cv4pve-autosnap │     │
└──────┴─────┴───────────────────┴──────────────────────────────┴──────────────────────────────┴─────────────────┴─────┘

Output type:

-o|--output   Type output (default: text) Text,Json,JsonPretty

Hook script

Before run hook script, program create environment variable:

CV4PVE_AUTOSNAP_PHASE
CV4PVE_AUTOSNAP_VMID
CV4PVE_AUTOSNAP_VMNAME
CV4PVE_AUTOSNAP_VMTYPE
CV4PVE_AUTOSNAP_LABEL
CV4PVE_AUTOSNAP_KEEP
CV4PVE_AUTOSNAP_SNAP_NAME
CV4PVE_AUTOSNAP_VMSTATE     #1/0
CV4PVE_AUTOSNAP_DEBUG       #1/0
CV4PVE_AUTOSNAP_DRY_RUN     #1/0
CV4PVE_AUTOSNAP_DURATION
CV4PVE_AUTOSNAP_STATE       #1/0

See example hook file script-hook.bat, script-hook.sh

Some words about Snapshot consistency and what qemu-guest-agent can do for you

Bear in mind, that when taking a snapshot of a running VM, it's basically like if you have a server which gets pulled away from the Power. Often this is not cathastrophic as the next fsck will try to fix Filesystem Issues, but in the worst case this could leave you with a severely damaged Filesystem, or even worse, half written Inodes which were in-flight when the power failed lead to silent data corruption. To overcome these things, we have the qemu-guest-agent to improve the consistency of the Filesystem while taking a snapshot. It won't leave you a clean filesystem, but it sync()'s outstanding writes and halts all i/o until the snapshot is complete. Still, there might me issues on the Application layer. Databases processes might have unwritten data in memory, which is the most common case. Here you have the opportunity to do additional tuning, and use hooks to tell your vital processes things to do prio and post freezes.

First, you want to make sure that your guest has the qemu-guest-agent running and is working properly. Now we use custom hooks to tell your services with volatile data, to flush all unwritten data to disk. On debian based linux systems the hook file can be set in /etc/default/qemu-guest-agent and could simply contain this line:

DAEMON_ARGS="-F/etc/qemu/fsfreeze-hook"

Create /etc/qemu/fsfreeze-hook and make ist look like:

#!/bin/sh

# This script is executed when a guest agent receives fsfreeze-freeze and
# fsfreeze-thaw command, if it is specified in --fsfreeze-hook (-F)
# option of qemu-ga or placed in default path (/etc/qemu/fsfreeze-hook).
# When the agent receives fsfreeze-freeze request, this script is issued with
# "freeze" argument before the filesystem is frozen. And for fsfreeze-thaw
# request, it is issued with "thaw" argument after filesystem is thawed.

LOGFILE=/var/log/qga-fsfreeze-hook.log
FSFREEZE_D=$(dirname -- "$0")/fsfreeze-hook.d

# Check whether file $1 is a backup or rpm-generated file and should be ignored
is_ignored_file() {
    case "$1" in
        *~ | *.bak | *.orig | *.rpmnew | *.rpmorig | *.rpmsave | *.sample | *.dpkg-old | *.dpkg-new | *.dpkg-tmp | *.dpkg-dist |
*.dpkg-bak | *.dpkg-backup | *.dpkg-remove)
            return 0 ;;
    esac
    return 1
}

# Iterate executables in directory "fsfreeze-hook.d" with the specified args
[ ! -d "$FSFREEZE_D" ] && exit 0
for file in "$FSFREEZE_D"/* ; do
    is_ignored_file "$file" && continue
    [ -x "$file" ] || continue
    printf "$(date): execute $file $@\n" >>$LOGFILE
    "$file" "$@" >>$LOGFILE 2>&1
    STATUS=$?
    printf "$(date): $file finished with status=$STATUS\n" >>$LOGFILE
done

exit 0

For testing purposes place this into /etc/qemu/fsfreeze-hook.d/10-info:

#!/bin/bash
dt=$(date +%s)

case "$1" in
    freeze)
        echo "frozen on $dt" | tee >(cat >/tmp/fsfreeze)
    ;;
    thaw)
        echo "thawed on $dt" | tee >(cat >>/tmp/fsfreeze)
    ;;
esac

Now you can place files for different Services in /etc/qemu/fsfreeze-hook.d/ that tell those services what to to prior and post snapshots. A very common example is mysql. Create a file /etc/qemu/fsfreeze-hook.d/20-mysql containing

#!/bin/sh

# Flush MySQL tables to the disk before the filesystem is frozen.
# At the same time, this keeps a read lock in order to avoid write accesses
# from the other clients until the filesystem is thawed.

MYSQL="/usr/bin/mysql"
#MYSQL_OPTS="-uroot" #"-prootpassword"
MYSQL_OPTS="--defaults-extra-file=/etc/mysql/debian.cnf"
FIFO=/var/run/mysql-flush.fifo

# Check mysql is installed and the server running
[ -x "$MYSQL" ] && "$MYSQL" $MYSQL_OPTS < /dev/null || exit 0

flush_and_wait() {
    printf "FLUSH TABLES WITH READ LOCK \\G\n"
    trap 'printf "$(date): $0 is killed\n">&2' HUP INT QUIT ALRM TERM
    read < $FIFO
    printf "UNLOCK TABLES \\G\n"
    rm -f $FIFO
}

case "$1" in
    freeze)
        mkfifo $FIFO || exit 1
        flush_and_wait | "$MYSQL" $MYSQL_OPTS &
        # wait until every block is flushed
        while [ "$(echo 'SHOW STATUS LIKE "Key_blocks_not_flushed"' |\
                 "$MYSQL" $MYSQL_OPTS | tail -1 | cut -f 2)" -gt 0 ]; do
            sleep 1
        done
        # for InnoDB, wait until every log is flushed
        INNODB_STATUS=$(mktemp /tmp/mysql-flush.XXXXXX)
        [ $? -ne 0 ] && exit 2
        trap "rm -f $INNODB_STATUS; exit 1" HUP INT QUIT ALRM TERM
        while :; do
            printf "SHOW ENGINE INNODB STATUS \\G" |\
                "$MYSQL" $MYSQL_OPTS > $INNODB_STATUS
            LOG_CURRENT=$(grep 'Log sequence number' $INNODB_STATUS |\
                          tr -s ' ' | cut -d' ' -f4)
            LOG_FLUSHED=$(grep 'Log flushed up to' $INNODB_STATUS |\
                          tr -s ' ' | cut -d' ' -f5)
            [ "$LOG_CURRENT" = "$LOG_FLUSHED" ] && break
            sleep 1
        done
        rm -f $INNODB_STATUS
        ;;

    thaw)
        [ ! -p $FIFO ] && exit 1
        echo > $FIFO
        ;;

    *)
        exit 1
        ;;
esac
