Ndvi2Gif is a Python library for multi-temporal remote sensing analysis with Google Earth Engine. It provides seasonal compositing, 40+ vegetation and environmental indices, SAR preprocessing, time series analytics, land cover classification, and hydroperiod analysis — all server-side, without downloading raw data.
Built on top of Google Earth Engine and geemap. Adapted and extended through its use in the eLTER and SUMHAL projects.
https://digdgeo.github.io/Ndvi2Gif/
⚠️ Every Sentinel-3 index changes, and NDVI changed sign.COPERNICUS/S3/OLCIis top-of-atmosphere radiance and was being read as if it were reflectance. Solar irradiance falls with wavelength at roughly the rate a vegetation spectrum rises, so the radiances came out nearly flat across bands and S3 NDVI sat near zero whatever the surface: one Doñana scene gave −0.022 on radiance against +0.208 on reflectance, reading vegetation as bare ground. The collection is now converted to TOA reflectance with per-band, per-spacecraft solar irradiance. Anything computed from Sentinel-3 indices should be recomputed. Note this is TOA, not surface reflectance: over water the signal is dominated by Rayleigh scattering.
Water masking is now a parameter, not an improvisation — get_water_mask() offers
'dynamic', 'permanent', 'maximum', the JRC Global Surface Water layer, or a zone you
supply. Over Iznájar in 2022 the same reservoir measures 6.47 km² permanent against 10.95 at
maximum extent: a factor of 1.7 in the surface a chlorophyll mean is taken over. The masked
area per period is recorded alongside, because with a dynamic mask each period is averaged
over a different population of pixels.
The peak month is a circular variable — get_peak_statistics() returns the circular mean
and the concentration R instead of an ordinary average, which would place December and January
in June. R is what says whether the mean means anything.
One nighttime lights record, 1992 to today — calibrate_nighttime_lights() fits the
DMSP-to-VIIRS conversion on your own ROI. On the Andalusian coast it takes the artificial step
at the sensor change from −64% down to −12%.
Previously, in v1.6.0:
⚠️ Values change for some indices — please read before upgrading. A review of every index against its publication found that Sentinel-2 and MODIS bands were used as integers × 10000 instead of reflectance: band ratios such as NDVI were unaffected, but SAVI, EVI, LAI, AVI, WI2015, CRI and a few others came out wrong on those sensors (EVI 2–3 times too high). Sentinel-1 was processed and indexed in dB instead of linear power, and its terrain correction had no effect because the DEM lost its projection. Several formulas were also wrong (aweinsh,wi2015,nmi,rfdi,dpsvi). All are fixed and tested; results computed with the affected indices should be recomputed. The CHANGELOG lists every index and how much it changes.
Multi-sensor classification — LandCoverClassifier([s2, s1]) combines indices from several sensors in one feature stack, e.g. indices={'S2': ['ndvi', 'ndmi'], 'S1': ['vv', 'vh']}. When resolutions differ you choose how to reconcile them (resample='coarser', 'finer' or a pixel size in meters). In the new Tawau Hills tutorial — natural forest versus oil palm under Borneo's clouds — Sentinel-2 + Sentinel-1 reach 0.76 overall accuracy against 0.73 and 0.58 for each sensor alone.
Reproducible classifications — export_model() saves the full configuration, every random-forest tree, the accuracy and the training samples with their coordinates, ready to refit the model in scikit-learn or R. Train/validation splits are now seeded and identical across feature stacks, so classifiers can be compared fairly.
An indices catalogue you can trust — the indices reference is rebuilt from the code: 111 variables, each with the formula as implemented and a verified reference. Each sensor now only accepts the indices it can actually compute.
Previously, in v1.5.0: raw reflectance bands as index= ('blue' … 'swir2', plus 'red_edge1-3' on S2) and key='count', the number of valid observations per pixel; v1.5.1 fixed band names shifting when a period had no images.
In v1.4.0: dispersion reducers — key='std', 'variance', 'range', 'cv' — and downloadable water masks from HydroperiodAnalyzer.
And in v1.3.0: SpatialPhenologyAnalyzer, GEE-native per-pixel phenology rasters (SOS/POS/EOS) with threshold, derivative and harmonic methods. See CHANGELOG for details.
| Module | Description |
|---|---|
NdviSeasonality |
Core engine: seasonal compositing, 40+ indices, 7 sensors, flexible ROI input |
HydroperiodAnalyzer |
Wetland flood duration analysis (days/year) with multi-year anomaly detection |
TimeSeriesAnalyzer |
Trend detection (Mann-Kendall, Sen's slope), phenology metrics, dashboards |
SpatialPhenologyAnalyzer |
Per-pixel phenology rasters (SOS/POS/EOS) via threshold, derivative or harmonic methods |
S1ARDProcessor |
Sentinel-1 SAR preprocessing: terrain correction, speckle filtering |
LandCoverClassifier |
Supervised (RF, SVM, CART) and unsupervised (K-means, LDA) classification, multi-sensor feature stacks, exportable models |
pip install ndvi2gifconda install -c conda-forge ndvi2gifimport ee
from ndvi2gif import NdviSeasonality
ee.Authenticate()
ee.Initialize(project='your-project-id')
# Monthly NDVI composites from Sentinel-2 (2018–2024)
ndvi = NdviSeasonality(
roi=your_roi, sat='S2', periods=12,
start_year=2018, end_year=2024,
key='percentile', percentile=85, index='ndvi'
)
ndvi.get_gif(name='ndvi_evolution.gif')Yes, it makes nice GIFs — but it's much more than that.
- Compute pixel-wise statistics over any region and time span — seasonal medians, percentiles, multi-year aggregations, or dispersion (std, variance, range, CV) to map variability instead of level
- Monitor 40+ indices across Sentinel-1/2/3, Landsat (4–9), MODIS, ERA5-Land, CHIRPS, and nighttime lights (VIIRS, DMSP-OLS)
- Map the timing of a maximum with
get_peak_period()— the month of peak greenness, of deepest flooding, of brightest nighttime light - Analyse wetland hydroperiod and multi-year flood anomalies with
HydroperiodAnalyzer - Detect trends and phenology (SOS, EOS, POS, Length of Season) with
TimeSeriesAnalyzer - Classify land cover with multi-temporal feature stacks and Random Forest, SVM, or K-means
- Preprocess Sentinel-1 SAR with terrain correction and speckle filtering
- Export to GeoTIFF, Google Drive, or Earth Engine Assets
- Use any ROI: shapefile, GeoJSON, drawn geometry, eLTER DEIMS ID, Sentinel-2 tile, or Landsat path/row
Sentinel-1 (SAR) · Sentinel-2 SR · Sentinel-3 OLCI · Landsat 4–9 SR · MODIS MOD09A1 · ERA5-Land · CHIRPS · VIIRS (monthly and daily) · DMSP-OLS
Bug reports and feature requests: GitHub Issues
Pull requests are welcome. See CONTRIBUTING.md for guidelines — it includes step-by-step instructions for adding new indices and datasets.
If you use Ndvi2Gif in your research, please cite the JOSS paper:
@article{GarciaDiaz2026,
author = {García Díaz, Diego},
title = {Ndvi2Gif: A Python Package for Multi-Seasonal Remote Sensing Analysis with Google Earth Engine},
journal = {Journal of Open Source Software},
year = {2026},
volume = {11},
number = {124},
pages = {10654},
publisher = {The Open Journal},
doi = {10.21105/joss.10654},
url = {https://doi.org/10.21105/joss.10654}
}Special thanks to Qiusheng Wu for his invaluable work in developing and promoting open-source geospatial software, to the Google Earth Engine team, and to the broader open-source geospatial community.
MIT — see LICENSE.txt
