A high performance and compression ratio compressor, powered by GTXLab of Genetalks.
Clone or download
Latest commit 4a3cf17 Oct 19, 2018
Permalink
Failed to load latest commit information.
License.md GTX.Zip professional V1.1 Oct 11, 2018
README.md Update README.md Oct 19, 2018
README_chs.md Update README_chs.md Oct 19, 2018
gtz_latest.run GTX.Zip professional V1.1 Oct 19, 2018

README.md

GTX.Zip Professional Version

Powered by GTXLab of Genetalks.

  • One-click installation:
    sudo curl -sSL https://gtz.io/gtz_latest.run -o /tmp/gtz.run && sudo sh /tmp/gtz.run

  • GTX.Zip Professional download URL:https://gtz.io/gtz_latest.run

中文说明.

System Overview

GTX.Zip is a professional fastq/bam compressor and also can be used as a universal data compression software, developed by GTXLab of Genetalks Inc. GTX.Zip can rapidly compress any DNA sequencing files and directories with very high compression rate, and generate a single compressed data files, thus facilitating the data storage, distribution and transmission. Different from other compression tools, GTX.Zip system focuses on high compression rate, high speed, and convenient data extraction.

There are three different versions of GTX.Zip for different users:

  • GTX.Zip Professional:Companies, Institutions and individual users that with large local sequencing data
  • GTX.Zip Enterprise:Large-scale enterprises and data centers that with PB-level sequencing data and require distributed compression by their own computing clusters
  • GTX.Zip Cloud:Companies that with low efficiency of sequencing data distribution and storage

System Highlights

GTX.Zip compressor system features:

  • High Compression Ratio: The system implements Context Model compression technology, with a variety of optimized predicting model, and balancing the system concurrent and memory resources consumption, thus achieving a extreme high compression rate. For FASTQ files, GTX.Zip is capable to compress the original fastq file to 2.53%. The compression rate of GTX.Zip is about 3-6 times of gzip compressor which could save up to 80% storage space and transfer costs.
Data List Compression rate of GTX.Zip Compression rate of Fastq.gz
Nova_wes_1.fq 2.53% 17.15%
Nova_wes_2.fq 3.45% 18.34%
nova_wgs_1.fq 3.18% 17.55%
nova_wgs_2.fq 3.93% 18.66%
nova_rna_1.fq 4.56% 17.70%
nova_rna_2.fq 5.39% 18.94%
  • High Performance: GTX.Zip fully exploits the concurrency of the CPU, the new Haswell CPU architecture, and the computing power of the new instructions such as AVX2, BMI2, which makes GTX.Zip gain high compression speed even on a ordinary computing server, with the throughput of 1100MB/s for a single compression node. GTX.Zip Enterprise supports large-scale distributed compression.

  • Safety Guarantee: Thanks to its high speed, during the process of GTX.Zip compression, the data decompression and restore test is performed. The compression process will be done only after the data has been confirmed exactly the same as the source data. MD5 validation is performed to ensure data integrity as well.

  • Software Ecology: GTX.Zip provides command line and GUI decompression software for Linux, Mac OSX and Windows. It also provides SDK interfaces in languages such as Python, C, C++, etc. which is convenient for third-party developers to read and write gtz file (GTX.Zip compression format) directly. For example, gtz version of bcl2fastq, fastp and BWA are supported by community now. More software will be released soon.

Nirvana Plan

As an enterprise-level software, GTX.Zip has developed a nirvana program for high-availability requirements to ensure that users can decompress compressed data into original data under the extreme condition. The nirvana plan's dual availability protection strategy is as follows:

  • GTX.Zip is multi-site hosted. http://gtz.io website, GitHub and other sites will permanently host all versions of GTX.Zip, to make sure that it is available to the entire network all the time and free of charge at any time.
  • To ensure that compressed data can be restored to original file under any conditions, pre-embedded micro decompression programs could be extract from compressed data first, and then be used to decompress the file.

GTX.Zip Professional

  • GTX.Zip Professional is a stand-alone version which supports local compression service. GTX.Zip Professional runs by command lines for compression and decompression of local genomic data.

System Environment Requirements

  • 64-bit Linux system (CentOS 6.5 or above, or Ubuntu 12.04 or above)
  • To achieve good performance, the computing server with 32-core 64GB memory is recommended (at least 4-core and 8GB memory), or that has the same configuration with the AWS C4.8xlarge machine)

Quick Start

  1. Install GTX.Zip

    • Method 1(recommended)

    sudo curl -sSL https://gtz.io/gtz_latest.run -o /tmp/gtz.run && sudo sh /tmp/gtz.run

    • Method 2:

    Download from:

     https://gtz.io/gtz_latest.run


    Change permissions:

     chmod +x ./gtz_latest.run


    Install:

     ./gtz_latest.run

  2. Make index to enable high rate compression Take the human sample species as an example, make the index file (bin file) required for GTX.Zip high rate compression

    • Download the 1th rbin file (1 is the number of the human RBIN file in the appendix list) and gtz_index will save it to the default path (~/.config/gtz):

      gtz_index download 1

      or

      You can download rbin file from here ( Homo_sapiens rbin file )

    • Make the index bin file ( may need 100GB free disk space, and >28GB memory, and 10 sec)

      gtz_index makeindex ~/.config/gtz/Homo_sapiens_bcacac9064331276504f27c6cf40e580.rbin

  3. Compress sample fastq file

    gtz sample.fq -o sample.fq.gtz --bin-file ~/.config/gtz/Homo_sapiens_bcacac9064331276504f27c6cf40e580.bin

    sample.fq can be downloaded from https://gtz.io/sample.fq. (1GB fastq file, extracted from a real WES data produced by Novaseq)

    [^] Notice: gtz can also directly compress fastq.gz file.

Installation Instruction

  • Method 1 (recommended):
    sudo curl -sSL https://gtz.io/gtz_latest.run -o /tmp/gtz.run && sudo sh /tmp/gtz.run

  • Method 2:
    Download the gtz_latest.run, and then execute the it.

Guidelines Of gtz:

usage: gtz [-h] [-o OUT] [-b INDEX_BIN] [-d DECOMPRESS] [-O OUT_DIR]

-h, --help                                      show this help message and exit
-o OUT, --out OUT                               specify the GTZ file name after compression
-b BIN_FILE, --bin-file BIN_FILE                specify the bin file name for high compression
-d DECOMPRESS, --decompress DECOMPRESS          decompress
-O OUT_DIR, --out-dir OUT_DIR                   specify the save path of the extracted file
-c, --stdout                                    decompress to terminal
-gz, --fastq-to-fastq-gz                        decompress fastq to fastq.gz, it's valid only for FASTQ
-r RBIN_PATH, --rbin-path RBIN_PATH             specify the path where the rbin file resides
-p PARALLEL_NUM,--parallel			specify parallel number for compression or decompression,
						default equal CPU logical cores
-f, --force                                     force overwrite of output file
-e, --no-keep                                   don't keep input files
-v, --version                                   display version number

Guidelines Of gtz_index:

gtz_index <command> [options]
-	list					show species which current support
-	download <index> <path_to>		download species reference sequence rbin file , path_to is not necessary.
-	makeindex <rbin_path>			making reference sequence

For Example:

Compress

1:Compress the sample.fq to the current directory.Without the specified bin file, GTZ will automatically recognize the species to compress.
gtz sample.fq -o sample.fq.gtz

2:Compress the file sample.fq into the out folder of the current directory.Without the specified bin file, GTZ will automatically recognize the species to compress.
gtz sample.fq -o ./out/sample.fq.gtz

3.GTZ performs high compression by specifying bin files in the Homo folder under the current directory.
gtz sample.fq -o sample.fq.gtz --index-bin ./Homo/Homo_sapiens_bcacac9064331276504f27c6cf40e580.bin

Decompress

1.Deompress the file sample.fq to the current directory.If there is no species rbin file under "~/.config/ gtz/", GTZ will be automatically downloaded from the Cloud to "~/.config/ gtz /".
gtz -d sample.fq.gtz

2.Specify the directory of the rbin path “~/Homo” for decompress sample.fq.gtz.
gtz -d sample.fq.gtz --index-path ~/Homo

3.Decompress sample.fq.gtz to the Homo folder in the current path
gtz -d sample.fq.gtz --out-dir ./Homo

gtz_index

Interaction mode:
gtz_index
Show supported species and you can gradually create bin files through human-machine interaction mode.

Manual mode
1:Show supported species list,the index number is the input of the gtz_index download command.
gtz_index list
2:Download the rbin file in the species list with No.1 index
gtz_index download 1
3:Make BIN,rec file by specifying the rbin file". /Homo/Homo_sapiens_bcacac9064331276504f27c6cf40e580.rbin "
gtz_index makeindex ./Homo/Homo_sapiens_bcacac9064331276504f27c6cf40e580.rbin

Nirvana Plan

Let’s start Nirvana plan!At first, we have a gtz file named sample.fq.gtz.
Step 1:
Run the following command to extract the embeded programe gtz_reborn to current directory:
sed -e 's/\[GTZ_REBORN_BEGIN\]/\n&/;' sample.fq.gtz | sed -n '/\[GTZ_REBORN_BEGIN\]/,/\[GTZ_REBORN_END\]/p' | sed -e 's/.*\[GTZ_REBORN_BEGIN\]//g' -e 's/\[GTZ_REBORN_END\].*//g' | tar -zxvf -

Step2:
If sample.fq.gtz is a high compression file, download the corresponding fasta file according to the prompt, and then extract the file.
If sample.fq.gtz is not a high compression file, the FASTQ file can be extracted directly
./gtz_reborn -d sample.fq.gtz

Note:

  • bin files:Genome reference index files which used for compression.The default file storage path is "~/.config/gtz/"
  • rbin files:Compact genome reference files which used for decompression.The default file storage path is "~/.config/gtz/"
  • gtz_index:An installation tool of GTX.Zip Professional which used to view species list, download rbin files and generate bin files.

Rbin files Download

No. Species Official Url
---- ---- --------
1 Homo sapiens https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Homo_sapiens_bcacac9064331276504f27c6cf40e580.rbin
2 Triticum aestivum Https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Triticum_aestivum_8e2da4d2c18d5fadd1d3cd0c15e918d0.rbin
3 Arabidopsis thaliana https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Arabidopsis_thaliana_3dcb9b7a5a8b46c8ebbdbbdb3e0fa233.rbin
4 Mus musculus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Mus_musculus_def651daa3884affc85be8a74f7ba67e.rbin
5 Rattus norvegicus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Rattus_norvegicus_6cb6204aeddde515414059bcc3f048af.rbin
6 Oryza sativa Japonica Group https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Oryza_sativa_Japonica_Group_90b8919fd938ce2eb40a83da674d8b3f.rbin
7 Zea mays https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Zea_mays_898a827cde37664a7c0ac710d79b333f.rbin
8 Ailuropoda melanoleuca https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Ailuropoda_melanoleuca_9d59370cb06760b671353b20224ec2de.rbin
9 Apis mellifera https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Apis_mellifera_10a768025aad33307a53bc077b60e4c8.rbin
10 Bombyx mori https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Bombyx_mori_3ad2e80daa1d88f3339ac968e97f72eb.rbin
11 Bos taurus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Bos_taurus_2726c844c35a2576a513a0b578955a70.rbin
12 Brassica napus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Brassica_napus_39b086ee1025ab9d96e59639c4ce87f7.rbin
13 Caenorhabditis elegans https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Caenorhabditis_elegans_2fa2b1575d9e722f076bafcf3b755fed.rbin
14 Canis lupus familiaris https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Canis_lupus_familiaris_ddd3c39e58079f740ae2d21613f923ba.rbin
15 Capra hircus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Capra_hircus_d58b5bac5ee5baf3cb4873be119d86fe.rbin
16 Capsicum annuum https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Capsicum_annuum_9d1dac11540dbee75ea81868a5c52cc3.rbin
17 Chlorocebus sabaeus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Chlorocebus_sabaeus_6c0f80b3ca9404dc83ddffdad72c206b.rbin
18 Citrus sinensis https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Citrus_sinensis_704f1f26af39ba2e78d562e85ce974c4.rbin
19 Danio rerio https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Danio_rerio_7b1f24b449248a08ddab86d19b686818.rbin
20 Drosophila elegans https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Drosophila_elegans_ac9318016d83e7234b35aee177545225.rbin
21 Felis catus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Felis_catus_9af1182789a93a7b7c00eb657928a270.rbin
22 Glycine max https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Glycine_max_8761f4855d9396ff38f5a6201edc6080.rbin
23 Gossypium hirsutum https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Gossypium_hirsutum_3f2a7ca4b7cc58f57022c24f1cc24094.rbin
24 Macaca mulatta https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Macaca_mulatta_e75fcb8d26d9a316f1da1983b584b142.rbin
25 Manihot esculenta https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Manihot_esculenta_45e8f4480f267cf82f51f08af5dd1fa8.rbin
26 Medicago truncatula https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Medicago_truncatula_4b0ad793b3a8a7bcc1c1bcb0dee5c3c9.rbin
27 Momordica charantia https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Momordica_charantia_30f2c8beae3bb8d7beb990c522ae454d.rbin
28 Nicotiana tabacum https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Nicotiana_tabacum_c8d4659974cfc88753b60684aadb9ca3.rbin
29 Oryctolagus cuniculus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Oryctolagus_cuniculus_2d37f28080f4caff68fd164c567f18be.rbin
3 Populus trichocarpa https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Populus_trichocarpa_72f0a29abc20570aa3691445160b584c.rbin
3 Prunus persica https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Prunus_persica_cb65aac20158fa3e8075963e8ff45cfa.rbin
32 Raphanus sativus https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Raphanus_sativus_fc9dc14c13511a3cd8ed2377d2c8f472.rbin
33 Sesamum indicum https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Sesamum_indicum_18e9ca5868589ab3851ee39536577784.rbin
34 Solanum tuberosum https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Solanum_tuberosum_11117f289d350ac2727d5136941986f0.rbin
35 Sorghum bicolor https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Sorghum_bicolor_ad3fb597e71a3d3cc1a50606865207a5.rbin
36 Sus scrofa https://gtzdata.oss-cn-hangzhou.aliyuncs.com/Sus_scrofa_fa17a95f7b8532dfb932210977bebc77.rbin

Change Log

v1.0

base revision

v1.1

add function:

-c/--stdout decompress to terminal

-gz/--fastq-to-fastq-gz decompress fastq to fastq.gz, it's valid only for FASTQ

Contact Us

If you have any questions, feel free to contact: contact@gtz.io, or commit an issus on Github.
