Digital Decoupling Layer for Cloud Modernization using Cloud Pak for Data

Cloud Modernization at scale can be disruptive and clients prefer to start the journey that incrementally transition them to reach them to required digital maturity. This can be made possible by developing a co-existing layer that operates alongside core business application and database. Digital decoupling can also be seen as a coexistence layer that helps clients to incrementally transition to the future state with minimal or no disruption to the existing technology stack. There are numerous usecases that can be made possible using the decoupling layer, one such is the customer empowerment and smart front office application.

In this code pattern, we will take the scenario of a telecom company that provides mobile network services. The company has a legacy application with a number of functional modules for customer information management, mobile plans management, inventory management and billing. The telecom company now wants to build a new system of engagement with an interactive chatbot for the customers. In the new chatbot the customers can query for billing information, data usage and also get plan recommendations. It is proposed to build this new chatbot using new technologies and capabilities of Cloud Pak for Data (CP4D) but without disrupting the existing legacy system. The legacy system uses a DB2 database and is the system of record. The new chatbot system uses a Postgresql database. A subset of data needed by the chatbot system is replicated to the PostgreSQL database using IBM DataStage.

When you have completed this code pattern, you will understand how to:

  • Create DataStage flows for data replication using Cloud Pak for Data (CP4D)
  • Create a chatbot using Watson Assistant
  • Create Cloud functions in Watson Assistant to query databases

Flow

arch

  1. The employee performs one of many actions like create new mobile plan, enter new customer information or generate billing for customers.
  2. The data is stored in the DB2 database.
  3. Datastage reads data from DB2 database.
  4. Datastage replicates the data in the PostgreSQL database.
  5. A customer queries for billing information, data usage and recommendations through chatbot.
  6. Watson Assistant chatbot invokes Cloud Functions for the queries.
  7. Cloud functions queries PostgreSQL for data, processes the data and returns the response to Watson Assistant.

Watch the video

Demo

Prerequisites

  1. IBM Cloud Account
  2. IBM Cloud CLI
  3. Java
  4. Maven
  5. Git Client

Steps

  1. Create an instance of DB2 database
  2. Clone the repo
  3. Build and deploy the legacy application
  4. Set up legacy database
  5. View sample data
  6. Login to CP4D SaaS and Create Services
  7. Get Credentials of PostgreSQL database
  8. Setup PostgreSQL database
  9. Import project in CP4D
  10. Setup chatbot application
  11. Analyze the results
  12. Summary

1. Create an instance of DB2 database

As explained before, the legacy application uses a DB2 database. This code pattern uses DB2 service on IBM Cloud for easy demonstration in this code pattern. Follow the below steps to create DB2 instance on IBM Cloud.

Login to IBM Cloud:

ibmcloud login [--sso]

Run the below command to create an instance of DB2:

ibmcloud resource service-instance-create db2-legacy dashdb-for-transactions free us-south

The DB2 instance is created and the output appears as shown below:

Creating service instance db2-legacy in resource group default of account Balaji Kadambi's Account as bkadambi@in.ibm.com...
OK
Service instance db2-legacy was created.

Name:             db2-legacy
ID:               crn:v1:bluemix:public:dashdb-for-transactions:us-south:a/9xxxxb::
GUID:             xxxx
Location:         us-south
State:            active
Type:             service_instance
Sub Type:
Allow Cleanup:    false
Locked:           false
Created at:       2021-06-03T04:52:38Z
Updated at:       2021-06-03T04:52:38Z
Last Operation:
                  Status    create succeeded
                  Message   Completed create instance operation

Make a note of the GUID. It is needed in the next step.

Run the below command to create service credentials. The service credentials will be used later.

ibmcloud resource service-key-create skey --instance-id [GUID of DB2]

2. Clone the repo

Run the below command to clone the repo:

git clone https://github.com/IBM/app-modernization-coexistence-layer.git

3. Build and deploy the legacy application

Open IBM Cloud Dashboard. Go to the db2-legacy database instance you created earlier. Select Service credentials on the menu. Copy the DB2 credentials by clicking on the Copy to clipboard icon. This needs to be added to the credentials-db2.json file.

creds

In the cloned Github repo, go to the resources folder:

cd app-modernization-coexistence-layer/sources/legacyapp/src/main/resources/

Open the credentials-db2.json file and paste the DB2 credentials you copied earlier.

Go to the legacypp folder:

cd ../../..

Run the below command to build the application:

mvn clean install

Deploy the legacy application to IBM Cloud:

ibmcloud cf push

Note: In a real world situation, the legacy application runs on-premise. The application is deployed to IBM Cloud so that it is accessible for demonstrating the code pattern.

You will see the below ouput at the end when the application starts fine:

Waiting for app to start...

name:              app-legacy
requested state:   started
routes:            app-legacy-xxxx.mybluemix.net
last uploaded:     Thu 03 Jun 09:44:06 IST 2021
stack:             cflinuxfs3
buildpacks:        Liberty for Java(TM) (WAR, liberty-21.0.0_3,
                   buildpack-v3.57-20210512-1446, ibmjdk-1.8.0_sr6fp26-20210216,
                   env)

type:            web
instances:       1/1
memory usage:    512M
start command:   .liberty/initial_startup.rb
     state     since                  cpu     memory           disk         details
#0   running   2021-06-03T04:15:35Z   92.7%   176.3M of 512M   332M of 1G

Make a note of the route(app-legacy-xxxx.mybluemix.net) in the output.

Please check if the application is accessible at http://app-legacy-xxxx.mybluemix.net/telecom.

4. Set up legacy database

Invoke the URL http://app-legacy-xxxx.mybluemix.net/telecom/apis/setup-legacy-db from the browser to create tables in the DB2 database and populate sample data.

5. View sample data

You can now view the sample data.

sample_data

6. Login to CP4D SaaS and Create Services

Access this URL to access CP4D SaaS offering. Select a region preferrably Dallas as DataStage service exists only in Dallas and Frankfurt region at the time of writing this code pattern. You must be having an active IBM Cloud account by now, so click on Log in with your IBMid.

CP4D-login

After login to your cloud account, it sets up the core services of Cloud Pak for you. Launch the SaaS offering by clicking Go to IBM Cloud Pak for Data. It takes you to the integrated dashboard where you can create projects and work with your data.

On the dashboard, click on the hamburger menu and navigate to Services Catalog under Services.

CP4D-service-catalog

It shows the list of integrated services. You need to create the following services to execute this code pattern:

  • Databases for PostgreSQL

    Note: This code pattern uses PostgreSQL DB for the modernized application. You can setup your own PostgreSQL DB and provide connection details or use the service provided on IBM Public Cloud as shown here.

    On the services catalog page, select Databases in Category, it will show list of available databases of which instance can be created on IBM Cloud. Choose Database for PostgreSQL. Provide the required values like region, service name, resource group. Rest all values are optional. You can proceed with the default values and click Create. Post this, it will create service instance on IBM Cloud and allows you to add more services. Click on Add Service and perform the steps as exaplined in next section.

  • Cloud Object Storage (COS)

    On the services catalog page, select Storage in Category and choose Cloud Object Storage. Choose the pricing plan, resource group and provide the service name, then click Create. Note that you can use Lite plan of this service for this code pattern. COS is required to save your assets and project details which we will be creating in later steps. Click on Add Service to add more services.

  • DataStage

    On the services catalog page, select Analytics in Category and choose DataStage. Select the region, resource group and provide the service name of your choice, then click Create. You can use Lite plan of this service for this code pattern. This instance will be used to create DataStage flows for data replication. Click on Add Service to add next service.

  • Watson Assistant

    On the services catalog page, select AI/Machine Learning in Category and choose Watson Assistant. Select the region, resource group and provide the service name, then click Create. Note that you can use Lite plan of this service for this code pattern.

You have created all the required services of CP4D for this code pattern. You can read more about CP4D SaaS offering here.

7. Get Credentials of PostgreSQL database

On the CP4D dashboard, click on the hamburger menu and navigate to Service Instances under Services. Choose the PostgreSQL instance. In left side panel, click Service Credentials and New Credential. Provide credentials name and click Add. The credentials will be created now. Make a note of the following values from the credential, these are required to create data connection for DataStage flows.

"hostname": "56cf0e7b-4xxx.databases.appdomain.cloud"
"port": xxx
"instance_id": "crn:v1:xxx16e::"
"database": "xxx"
"password": "9fd671xxxx0f"
"username": "ibm_cloud_xxxx2"

8. Setup PostgreSQL database

Use a client either pgAdmin4 or psql to connect to the PostgreSQL database using the credentials created in previous step. Here, the steps are provided using psql CLI.

Execute the following steps to create a database and tables schema that is required before the data replication. The .sql files have been provided in this repository at app-modernization-coexistence-layer/postgre-scripts to create tables and its schema, to check data and to clean-up the database. Run the following command to create new db demodb, its schema and tables.

$ psql postgres://< username >:< password >@< db-hostname >:< port >/< database > -f cp-postgre-ddl.sql
CREATE DATABASE
psql (13.3, server 12.5)
SSL connection (protocol: TLSv1.3, cipher: TLS_AES_256_GCM_SHA384, bits: 256, compression: off)
You are now connected to database "demodb" as user "ibm_cloud_5e71779b_bab3_4cda_b460_82838f00a1a2".
psql:cp-postgre-ddl.sql:3: NOTICE:  schema "public" already exists, skipping
CREATE SCHEMA
SET
CREATE TABLE
CREATE TABLE
CREATE TABLE
CREATE TABLE

The tables created and its data(if any) can be checked using the following command:

psql postgres://< username >:< password >@< db-hostname >:< port >/< database > -f cp-postgre-getData.sql

After creating schema in PostgreSQL database, you are all set to create DataStage flows that is explained in next section.

9. Import project in CP4D

To design a DataStage flow, need to create a project, add data connections in project and then create DataStage flow. The following four DataStage flows are required for this code pattern.

  • customer-data-replication-flow: It replicates few columns from the customer table of DB2 database.
  • customer_plan-data-replication-flow: It replicates only those rows which gives information about the current plan is being used by a customer.
  • plans-data-replication-flow: It transform the plans related data as-is from DB2 to PostgreSQL.
  • billing-data-replication-flow: It replicates the customer billing data of last three months.

This code pattern provides you a project to import that has data assets and DataStage flows already created for you. Let's import the project.

On the CP4D dashboard, click on the hamburger menu, navigate to Home.

  • Click on Projects under Quick Navigation section and then New Project +.
  • Choose to create a project from a sample or file.
  • Upload the .zip file located at app-modernization-coexistence-layer/datastage.
  • Provide the name of the project (say demo) and define storage. For storage, use the COS instance created in step6.
  • Then click on Create.

import-project

Wait until import gets completed. Once completed, navigate to Assets tab. It will show two database connections under Data Assets and four flows under DataStage Flows section.

imported-project

Next, you need to update data assets with your databases connection details.

Update Data Assets

  • db2-conn: Click on db2-conn under Data Assets. Provide your database connection details and credentials which was created in step1. Then Test connection. Save it once the connection is successful.

  • postgre-conn: Click on postgre-conn under Data Assets. Use database name as demodb. Provide your database connection details and credentials as noted in step7. Then Test connection. Save it once the connection is successful.

Note: Port is SSL-enabled option is selected in provided connections. If your database does not support that option, please unselect that and test.

Run DataStage Flows

To start replication of the data in PostgreSQL DB, you need to run DataStage Flows. Click on a flow and then run the flow as shown below. Perform the same step for all four flows.

DS-Flow

Once all flows ran successfully, then the data in PostgreSQL DB tables can be verified using client. If you want to schedule the flows to run, that can be achieved using Project > Jobs > Choose a Job to be scheduled > Edit Configuration > Schedule. As a next step, we will work on chatbot.

10. Setup chatbot application

Until now you have setup a legacy application and have replicated the legacy database to a modern database, PostgreSQL. Next we will build a chatbot application, using Watson Assistant and IBM Cloud Functions, to fetch data from the modern database.

Capture service credentials of PostgreSQL database

The cloud functions fetch data from PostgreSQL database. You will need to provide PostgreSQL service credentials to cloud functions.

Login to your IBM Cloud account. Navigate to resources list. Click on the PostgreSQL service that was created earlier. On the top left side of the page, click on Service credentials. Copy the existing service credentials by clicking on the Copy to clipboard icon and save it in a text file.

The default database in this credentials could be different than the one that is used for this code pattern. In this credentials, under postgres->composed->postgres field update the database name as demodb, the database name used in PostgreSQL.

Update DB name

This credentials will be used in the next section.

Create Cloud Functions Action

Login to your IBM Cloud account. On the dashboard, click on the hamburger menu and navigate to Functions and click on Actions.

Click the Create button to create a new action. Select the tile with heading Action.

Enter a name for action under Action Name. Leave Enclosing Package as (Default Package) itself. Under Runtime select option for Node.js.

Create Action

Click on Create button. You are presented with actions code editor. Replace the existing code with the javascript code here.

This code connects to PostgreSQL database as well as Legacy application's Update Plan api. You will need to update code with the right credentials. In the function getVCAPLocal (towards the end of the javascript file), provide PostgreSQL credentials copied and edited, in the above section, in the variable vcapLocal (replace the existing double quotes). It will look something like this -

function getVCAPLocal() {
  let vcapLocal = {
    "connection": {
      "cli": {
        "arguments": ..,
        "bin": "psql",
        "certificate": {
          ..
        },
        .
        .
      },
      "postgres": {
        "authentication": {
          "method": "direct",
          "password": "xxxx",
          "username": "xxxx"
        },
        "certificate": {
          ..
        },
        "composed": [
          "postgres://xxxxx:xxxxx@xxxx:xxxxx/demodb?sslmode=verify-full"
        ],
        .
        .
      }
    },
    .
    .
  }
  return vcapLocal;
}

Next, in the javascript code, update the value of variable legacy_app_url (you will find it in the beginning of the file) to the changeplan url. The changeplan url will be http://app-legacy-xxxx.mybluemix.net/telecom/apis/changeplan.

Note: the base url http://app-legacy-xxxx.mybluemix.net was noted in the legacy application setup

Click Save button on the top right of the code editor.

Enable cloud function action as web action

For the action just created, click Endpoints on the left side navigation menu. Select the checkbox Enable as Web Action. Click the Save button on the right top corner. When saved, Copy web action url icon, under Web Action section is enabled. Click the icon to copy the webhook url. This URL will be used in Watson Assistant for it to call the actions in Cloud Functions.

Webhook URL

Setup Watson Assistant Chatbot

Login to IBM Cloud. On the dashboard, click on the hamburger menu and click Resource List. Click on the Watson Assistant instance that you created earlier. Then click on Launch Watson Assistant button to launch Watson Assistant dashboard.

On the Watson Assistant dashboard, on the left side of the screen click on skills icon. Click Create skill button. Select Dialog skill and click Next.

Select Upload skill tab. The skill file is available if your cloned GitHub repo in the path app-modernization-coexistence-layer/sources/chatbot/dialog.json. Click Drag and drop file here or click to select a file and select the skill file. Click Upload.

The dialog skill should be imported now. Next, click Options on left navigation menu for the skill. Webhooks under Options is selected by default. On this page under URL, enter the Webhook url you copied in the above section and append the URL with .json. Note: Append the url with .json extension. Without the extension, functions won't be called The entered details are saved automatically.

Next, click Assistants option available on the top left side of the Watson Assistant dashboard. Click Create assistant. In Create Assistant window, under Name enter a name for the assistant. Optionally enter a description and click the Create assistant button.

In the next window, click Add an action or dialog skill. In Add Actions or Dialog skill click on the skill that you created earlier.

11. Analyze the results

Now that all the components are ready, we can launch the chatbot and check the behavior of the application. If you have moved away to any other page on IBM Cloud dashbboard, then launch Watson Assistant and click on Assistants icon on top left of the screen. Click on the assistant you created earlier. Click the Preview button on top right to launch default application provided by Watson Assistant.

Chatbot App

You can share the preview link with others to run the chabot application. You can start chatting with the chatbot to fetch telecom customer information.

Authentication of mobile numbers is not implemented in this code pattern to keep things simple. If you are interested in authenticating user mobile numbers, check this code pattern

Sample flow of chatbot is as shown in the below video.

wa-demo.mp4

If you submit a request to change the plan then that request goes to the legacy application. To make that change in modern database, replication has to happen i.e. you need to run DataStage flows manually if not scheduled. Post that if you query through chatbot, it will show the latest updated plan. The same is shown in the video.

As a next step, you can add a new user using legacy application interface. Replicate the data using DataStage flow and query using your number in chatbot. If previous two steps are successful then chatbot should respond with your name else it will say Mobile number is not correct and then accordingly you can check plan, its usage etc. Like this you can verify an end-to-end working flow.

12. Summary

In this code pattern, DataStage was used to replicate the data from the legacy DB2 database to the Postgresql database. This enabled a decoupling between the legacy application and the modernized part of the application. This approach ensures that there is no disruption of current operations during modernization.
