react-native-drawpad


Basic useful feature list:

  • Let users draw anything they want!
  • change color of input easily
  • change thickness of input easily
  • default penal to change color, thickness and undo
  • get base64 encoding callback

Still developing, any PR is welcome!

##How to install

npm install react-native-drawpad --save
rnpm link react-native-webview-bridge

And here's some code! 👍

import ReactNativeDrawPad from 'react-native-drawpad';
...


render(){
  return (
    <ReactNativeDrawPad
        ref="drawpad"
        padWidth={300}
        padHeight={300}
        padColor={"#efefef"}
        onPadUpdated={this.catchImageEncode}
    />
   )
 }

changePenColor(color){
	this.refs.drawpad.changeColor(color)
}

undo(){
  this.refs.drawpad.undo(coor)
}

changePenColor(thickness){
	this.refs.drawpad.changethickness(thickness)
}

catchImageEncode(base64EncodingImage){
	//do anything with the image here
}

...

Props

Prop Description Default
showColorSelectors Boolean, if true, show the color selector true
showErasor Boolean, if true, show the erasor button true
showUndoButton Boolean, if true, show the undo button true
showThicknessSlider Boolean, if true, show the thickness slider true
selectedColor Sring, color for text in button when selected #dd7777
padColor Sring, color of the drawpad #eee
padWidth Number, width of the drawpad 300
padHeight Number, height of the drawpad 300
initColor Sring, color of the pen initially #dd7777
colors Array, a set of color used in color selector ['#dd7777','#222','#FE5722', '#FEEA3B', '#4CAE50', '#2196F2','purple']
onPadUpdated Function, the function to listen to the change of the drawpad a function log the base64 encoding image data

Reference:
