Nautilus w/ CARAT CAKE

Nautilus is an example of an Aerokernel, a very thin kernel-layer exposed (much like Unikernel) directly to a runtime system and/or application. An Aerokernel does not, by default, have a user-mode! There are several reasons for this, simplicity and performance among the most important. Furthermore, there are no heavy-weight processes---only threads, all of which share an address space. Therefore, Nautilus is also an example of a single address-space OS (SASOS). The runtime can implement user-mode features or address space isolation if this is required for its execution model.

This version of Nautilus has been modified to accommodate running with a CARAT address space abstraction (CARAT CAKE). CARAT CAKE is an extension of work found in PLDI '20 with the paper describing this work appearing in ASPLOS '22.

The concept of CARAT CAKE is to replace paging with a system that can operate using only physical addresses. Doing this enables the underlying system to have significant energy savings as well as allow new performance minded optimizations in both the micro-architecture and in software.

Table of Contents

• Background
• Prerequisites
• Hardware Support
• Building
• Using QEMU
• Using BOCHS
• Resources
• Maintainers
• License
• Acknowledgements

Background

We call the combination of an Aerokernel and the runtime/application using it a Hybrid Runtime (HRT), in that it is both a runtime and a kernel, especially regarding its ability to use the full machine and determine the proper abstractions to the raw hardware (if the runtime developer sees a mismatch with his/her needs and the Aerokernel mechanisms, they can be overridden).

If stronger isolation or more complete POSIX/Linux compatibility is required, it is useful to run the HRT in the context of a Hybrid Virtual Machine. An HVM allows a virtual machine to split the (virtual) hardware resources among a regular OS (ROS) and an HRT. The HRT portion of the HVM can then be seen as a kind of software accelerator. Note that because of the simplicity of the hardware abstractions in a typical HRT, virtualization overheads are much, much less significant than in, e.g. a Linux guest.

Prerequisites

• clang/llvm 9.0+ (https://releases.llvm.org/download.html)
• grub version >= ~2.02
• xorriso (for creating ISO images)
• qemu or bochs (for testing and debugging)
• NOELLE (https://github.com/scampanoni/noelle)
• wllvm or gclang (https://github.com/travitch/whole-program-llvm) (https://github.com/SRI-CSL/gllvm)

Hardware Support

Nautilus w/ CARAT CAKE works with the following hardware:

• x86_64 machines (AMD and Intel)
• Intel Xeon Phi, both KNC and KNL using Philix for easy booting
• As a Hybrid Virtual Machine (HVM) in the Palacios VMM

Nautilus can also run as a virtual machine under QEMU, BOCHS, KVM, and in a simulated environment using Gem5

Building

First, configure Nautilus by running either make menuconfig or make defconfig. The latter generates a default configuration for you. The former allows you to customize your kernel build.

For running CARAT CAKE, a pre-made configuration file has been created and is located in ./configs/karat.config The user can simply run the following command to be set up for a CARATized version of Nautilus from the root directory: $> cp $./configs/karat.config ./.config

Before running the next command, ensure that you have downloaded/installed/enabled the prerequisites (mainly clang, wllvm, and NOELLE). To compile a CARATized Nautilus, from the root directory run:

$> ./kernel_build_with_llvm_and_noelle.sh

Additional Artifact Availability Information for CARAT CAKE

For artifact availability purposes, we have also included the benchmark suites, scripts, and and an empty file system image -- all of which were used to build and test CARAT CAKE.

The benchmark suites are:

• NAS, located in ./src/test/NAS
• Parsec, located in ./src/test/parsec-3.0

Please see the README files in both directories that log the minor changes required to the benchmarks so they are compatible with the CARAT CAKE/Nautilus compilation pipeline.

Scripts used to build the benchmarks (with and without instrumentation from the CARAT CAKE compiler) are located in ./parsec_and_nas_build_scripts.

Finally, an additional "run" script is included that runs Nautilus under QEMU with KVM enabled, serial output enabled, and debug output enabled. This script is in run_nautilus_qemu_kvm.sh.

Using QEMU

Here's an example:

Recommended:

$> qemu-system-x86_64 -cdrom nautilus.iso -m 2048

Nautilus has multicore support, so this will also work just fine:

$> qemu-system-x86_64 -cdrom nautilus.iso -m 2048 -smp 4

You should see Nautilus boot up on all 4 cores.

Nautilus is a NUMA-aware Aerokernel. To see this in action, try (with a sufficiently new version of QEMU):

$> qemu-system-x86_64 -cdrom nautilus.iso \
                      -m 8G \
                      -numa node,nodeid=0,cpus=0-1 \
                      -numa node,nodeid=1,cpus=2-3 \
                      -smp 4,sockets=2,cores=2,threads=1

Nautilus supports debugging over the serial port. This is useful if you want to debug a physical machine remotely. All prints after the serial port has been initialized will be redirected to COM1. To use this, find the SERIAL_REDIRECT entry and enable it in make menuconfig. You can now run like this:

$> qemu-system-x86_64 -cdrom nautilus.iso -m 2G -serial stdio

Sometimes it is useful to interact with the Nautilus root shell via serial port, e.g. when you're running under QEMU on a system that does not have a windowing system. You'll want to first put a character device on the serial port by rebuilding Nautilus after selecting the Place a virtual console interface on a character device option. Then, after Nautilus boots (making sure you enabled the -serial stdio option in QEMU) you'll see a virtual console at your terminal. You can get to the root shell by getting to the terminal list with \``3. You can then select the root shell, and you will be able to run shell commands and see output. If you want to see more kernel output, you can use serial redirection and serial mirroring in your config.

If you'd like to use Nautilus networking with QEMU, you should use a TUN/TAP interface. First, you can run the following on your host machine:

$> sudo tunctl -d tap0
$> sudo tunctl -t tap0
$> sudo ifconfig tap0 up 10.10.10.2 netmask 255.255.255.0

Then you can use the tap interface with QEMU as follows. This particular invocation attaches both a virtual e1000 fast ethernet card and a virtio network interface:

$> sudo qemu-system-x86_64 -smp 2 \
                           -m 2048 \
                           -vga std \
                           -serial stdio \
                           -cdrom nautilus.iso \
                           -netdev tap,ifname=tap0,script=no,id=net0 \
                               -device virtio-net,netdev=net0 \
                           -netdev user,id=net1 \
                               -device e1000,netdev=net1 \
                           -drive if=none,id=hd0,format=raw,file=nautilus.iso \
                               -device virtio-blk,drive=hd0

Using BOCHS

While we recommend using QEMU, sometimes it is nice to use the native debugging support in BOCHS. We've used BOCHS successfully with version 2.6.8. You must have a version of BOCHS that is built with x86_64 support, which does not seem to be the default in a lot of package repos. We had to build it manually. You probably also want to enable the native debugger.

Here is a BOCHS config file (~/.bochsrc) that we used successfully:

ata0-master: type=cdrom, path=nautilus.iso, status=inserted
boot: cdrom
com1: enabled=1, mode=file, dev=serial.out
cpu: count=2
cpuid: level=6, mmx=1, level=6, x86_64=1, 1g_pages=1
megs: 2048

Resources

You can find publications related to Nautilus and HRTs/HVMs at http://halek.co, http://pdinda.org, http://interweaving.org, and the lab websites below.

Our labs:

HExSA Lab at IIT

Prescience Lab at Northwestern

Maintainers

CARAT CAKE

Primary development done by: Brian Suchy, Souradip Ghosh, Drew Kersnar, Siyuan Chai, Aaron Nelson, Zhen Huang, Michael Cuevas, Alex Bernat, Gaurav Chaudhary, Nikos Hardavellas, Simone Campanoni, and Peter Dinda

Nautilus

Primary development is done by Kyle Hale and Peter Dinda.

However, many people contribute to the development and maintenance of Nautilus. Please see this page as well as comments in the headers and the commit logs for details.
