A Flock of Swifts

We are a group of people excited by the Swift language. We meet each Saturday morning to share and discuss Swift-related topics.

All people and all skill levels are welcome to join.


Join us next Saturday:


Force Directed Graph

Ray blew the dust off the old SwiftUI project from a couple of years ago that featured a force directed graph simulation. We walked through building the project that can be found here:

Possible improvements might include using the new CanvasView and TimelineView. You could delay the transform until the very end during rendering which would be more efficient for rendering large graphs. (The way the timer is currently setup is rather resource wasteful.)

Another improvement suggested by Josh in the chat. This code:

  init(jsonData: Data) throws {
     let decoder = JSONDecoder()
     let decoded = try decoder.decode(Self.self, from: jsonData)
     self.init(nodes: decoded.nodes, links: decoded.links)

Can be simplified to this:

  init(jsonData: Data) throws {
     self = try JSONDecoder().decode(Self.self, from: jsonData)


Mark had some questions about how to filter snoozed events. Maybe this can be done with the ns-predicate?


We are on break this week and will resume next week.


We discussed how to bridge from delegates / callbacks to AsyncStream and how to bridge from AsyncSequence to Publisher:

import Combine
import GameController
import SpriteKit

final class GameScene: SKScene {
    private var player = SKNode()
    private var thumbStick: Double = .zero
    private var controller: GCVirtualController?
    private var canJump = true
    private var isIdle = true
    private var lastUpdate: Date?
    private var subscription: AnyCancellable?
    override func sceneDidLoad() {
        player = childNode(withName: "Player") ?? player CharacterAnimation.idle)))

        let virtualConfiguration = GCVirtualController.Configuration()
        virtualConfiguration.elements = [GCInputLeftThumbstick, GCInputButtonA]
        let controller = GCVirtualController(configuration: virtualConfiguration)
        self.controller = controller

        physicsWorld.contactDelegate = self

        controller.controller?.extendedGamepad?.leftThumbstick.valueChangedHandler = { [weak self] _, x, y in
            guard let self = self else { return }
            self.thumbStick = Double(x)

        let (onTap, taps) = AsyncStream<Bool>.pipe()

        controller.controller?.extendedGamepad?.buttonA.valueChangedHandler = { _, _, pressed in

        subscription = taps
            .filter { $0 }
            .throttle(for: .seconds(0.1), scheduler: DispatchQueue.main, latest: true)
            .sink(receiveValue: { [weak self] _ in
                guard let self = self else { return }
                guard self.canJump else { return }
                self.canJump = false
                DispatchQueue.main.async {
                        .applyImpulse(.init(dx: 0, dy: 60), duration: 0.1),
                        .animation(for: CharacterAnimation.jump),
                        .repeatForever(.animation(for: CharacterAnimation.idle))

    override func didFinishUpdate() {
        let now =
        let elapsed = ?? 0
        lastUpdate = now
        guard canJump else { return }
        if abs(thumbStick) < 0.1 {
            if !isIdle {
            isIdle = true
        } else {
            if isIdle {
            isIdle = false
            player.position.x += thumbStick * elapsed * 500.0
            player.xScale = thumbStick > 0 ? 1 : -1

extension GameScene: SKPhysicsContactDelegate {
    func didBegin(_ contact: SKPhysicsContact) {
        if contact.bodyA.node === player || contact.bodyB.node === player {
            canJump = true

extension AsyncStream {
    static func pipe() -> ((Element) -> Void, Self) {
        var input: (Element) -> Void = { _ in }
        let output = Self { continuation in
            input = { element in
        return (input, output)

extension AsyncSequence {
    func bind(to subject: PassthroughSubject<Element, Never>, priority: TaskPriority? = nil) -> Task<Void, Error> {
        Task(priority: priority) {
            try await withTaskCancellationHandler(handler: {
                subject.send(completion: .finished)
            }, operation: {
                for try await element in self {
                subject.send(completion: .finished)

    var publisher: AnyPublisher<Element, Never> {
        let subject = PassthroughSubject<Element, Never>()
        let task = bind(to: subject, priority: nil)
        return subject
            .handleEvents(receiveCancel: task.cancel)

extension SKAction {
    static func animation(named name: String, frames:  ClosedRange<Int>, frameDuration: TimeInterval) -> SKAction {
        let textures = frames
            .map { "\(name)\($0)"}
        return .animate(with: textures, timePerFrame: frameDuration, resize: false, restore: false)
    static func animation(for spriteAnimation: SpriteAnimation) -> SKAction {
        animation(named:, frames: spriteAnimation.frames, frameDuration: spriteAnimation.frameDuration)

protocol SpriteAnimation {
    var name: String { get }
    var frames: ClosedRange<Int> { get }
    var frameDuration: TimeInterval { get }
    var totalDuration: TimeInterval { get }

enum CharacterAnimation: String, SpriteAnimation, RawRepresentable {
    case idle, walk, jump
    var name: String {
    var frames: ClosedRange<Int> {
        switch self {
        case .idle: return 1...14
        case .walk: return 1...6
        case .jump: return 1...7
    var frameDuration: TimeInterval {
        switch self {
        case .idle: return 0.175
        case .walk: return 0.175
        case .jump: return 0.1
    var totalDuration: TimeInterval {
        TimeInterval(frames.count) * frameDuration


Josh talked about how to bridge from imperative delegates/callbacks to Combine by using a PublishSubject and how to bridge from a Publisher to an AsyncSequence by using the values property on a Publisher.

final class ViewModel {

    struct Item: Hashable, Identifiable {
        var id: Int

    @Published private(set) var items: [Item] = []
    @Published private(set) var selectedItem: Item?

    var didSelect: (IndexPath) -> Void = { _ in }

    init() {
        items = (0..<100).map(Item.init(id:))

        let didSelectSubject = PassthroughSubject<IndexPath, Never>()

        didSelect = didSelectSubject.send

        let values = didSelectSubject

        Task { [weak self] in
            for await value in values {
                self?.selectedItem = value

final class ViewController: UIViewController {

    private enum Section: Hashable, CaseIterable {
        case main
    private typealias DataSource = UICollectionViewDiffableDataSource<Section, ViewModel.Item>
    private typealias Snapshot = NSDiffableDataSourceSnapshot<Section, ViewModel.Item>
    private typealias Item = ViewModel.Item

    private var subscriptions = Set<AnyCancellable>()
    private let viewModel: ViewModel

    init(viewModel: ViewModel) {
        self.viewModel = viewModel
        super.init(nibName: nil, bundle: nil)
        view.backgroundColor = .systemBackground
        let layoutConfig = UICollectionLayoutListConfiguration(appearance: .plain)
        let listLayout = UICollectionViewCompositionalLayout.list(using: layoutConfig)

        let collectionView = UICollectionView(frame: .zero, collectionViewLayout: listLayout)
        collectionView.delegate = self
        collectionView.translatesAutoresizingMaskIntoConstraints = false
            collectionView.topAnchor.constraint(equalTo: view.safeAreaLayoutGuide.topAnchor),
            collectionView.bottomAnchor.constraint(equalTo: view.bottomAnchor),
            collectionView.leadingAnchor.constraint(equalTo: view.leadingAnchor),
            collectionView.trailingAnchor.constraint(equalTo: view.trailingAnchor),

        let cellRegistration = UICollectionView.CellRegistration<UICollectionViewListCell, Item> { (cell, indexPath, item) in
            var content = cell.defaultContentConfiguration()
            content.text = "\("
            cell.contentConfiguration = content

        let dataSource = DataSource(
            collectionView: collectionView,
            cellProvider: { (collectionView, indexPath, item) in
                    using: cellRegistration,
                    for: indexPath,
                    item: item

            .sink(receiveValue: { items in
                var snapshot = Snapshot()
                snapshot.appendItems(items, toSection: .main)
                dataSource.apply(snapshot, animatingDifferences: true)
            .store(in: &subscriptions)

            .compactMap { $0 }
            .sink(receiveValue: { [weak self] item in
                let alert = UIAlertController(title: "Selected Item", message: "\(item)", preferredStyle: .alert)
                alert.addAction(.init(title: "Ok", style: .default, handler: nil))
                self?.present(alert, animated: true)
            .store(in: &subscriptions)

    @available(*, unavailable)
    required init?(coder: NSCoder) {
        fatalError("init(coder:) has not been implemented")

extension ViewController: UICollectionViewDelegate {
    func collectionView(_ collectionView: UICollectionView, didSelectItemAt indexPath: IndexPath) {


Emil found that he could not access the camera roll from an App clip Carlyn asked about image storage (Coredata vs Documents) and cloud storage with Cloudkit Mark had some questions about tuples and the scan function using CoreMotion example from a few weeks ago Peter had some questions about debugging @IBInspectable & @IBDesignable

Bridging the Worlds of Completion Handlers, Combine, and Concurrency

Josh talked about how to bridge Combine, structured concurrency and completion handlers.

Here is a method that gives you a result after a delay.

import Combine
import Foundation

func eventual<Value>(
    result: Result<Value, Error>,
    after delay: TimeInterval,
    completion: @escaping (Result<Value, Error>) -> Void
) {
    DispatchQueue.main.asyncAfter(deadline: .now() + delay) {

An equivalent in async/away would looks something like this. (Written in full syntax to show what is happening.)

func awaitEventual<Value>(
    result: Result<Value, Error>,
    after delay: TimeInterval
) async throws -> Value {
    try await Task {
        await Task.sleep(UInt64(1e9 * delay))
        switch result {
        case let .success(value):
            return value
        case let .failure(error):
            throw error

We can use a combine future which is a reference type that runs immediately even if there are no observers. It stores the result that can be accessed later. Fire and store.

In the completion handler world:

let future = Future<Int, Error> { promise in
    eventual(result: .success(1), after: 1) { result in
        switch result {
        case let .success(value):
        case let .failure(error):

In the new concurrency world, you could do the same thing like this:

let future2 = Future<Int, Error> { promise in
    Task {
        do {
            let value = try await awaitEventual(result: .success(1), after: 1)
        } catch {

The above is pretty verbose. With a little up-front engineering we can do this:

extension Future where Failure == Error {
    convenience init(awaiting operation: @escaping () async throws -> Output) {
        self.init { promise in
            Task {
                do {
                    let value = try await operation()
                } catch {

Now it is easy to make a future.

let future3 = Future {
    try await awaitEventual(result: .success(1), after: 1)

We can make our own version of Future for the concurrency world using continuations and effectful read-only properties.

final class AsyncFuture<Value> {
    var value: Value  {
        get async throws {
            try await task.value

    private let task: Task<Value, Error>

        completion: @escaping ( ( (Result<Value, Error>) -> Void ) -> Void )
    ) {
        task = Task {
            try await withCheckedThrowingContinuation { continuation in



Performance tip from Jake. He found that setting the proxy in View initializer led to the lag. Instead, setting it in onAppear was much faster. He also used made TextField layout like he wanted by putting TextField and Text in a ZStack and then giving the Text an opacity of 0.

Effectful, Readonly Properties

We talked about this proposal

You can define throws and async in the getter like this:

struct User {
  var name: String {
    get throws {
      return "Name"

And call it like this:

let user = User()
let name = try

You only need a try at the outer most level. So:

func process(_ name: String) throws -> String {

try process(try // long way
try process(     // short way

We also had an impromptu discussion about actors. The above proposal probably came about because actors need to have async properties. Peter provided this link to background material.

Peter provided this link.

We talked about how actors give you islands of concurrency, and write a lot of the boilerplate code for you.


Formatting numbers

Though it has been covered before for dates, Swift 5.5 brings some nice foundation changes for formatting number.


let x = 3.100001

We also looked at a bunch of other formatting options. Consider making an internal or private extension if you use a complex formatted configuration:


extension BinaryFloatingPoint {
  var usdCurrency: String {
    formatted(.currency(code: "usd"))

The implementation does a lot of internal caching so you don't have to worry about making a static formatter.

Codable and Enumerations with Associated values

Yes, this works now in Swift 5.5.

enum Vehicle: Equatable {
  case airplane(String)
  case car(Int, String)
  case bicycle([Int])
  case gocart(maker: String)
  case boat

let vehicles: [Vehicle] = [
    .car(42, "Hi"),
    .gocart(maker: "w"),

extension Vehicle: Codable {}

A handy extension from Josh lets your pretty printing encodables:

private extension Encodable {
    var prettyPrinted: String {
        let encoder = JSONEncoder()
        encoder.outputFormatting = [.prettyPrinted, .sortedKeys]
        return (try? encoder.encode(self))
            .flatMap { String(data: $0, encoding: .utf8) } ?? "\(self)"


This gives you:

    "airplane" : {
      "_0" : "Hello"
    "car" : {
      "_0" : 42,
      "_1" : "Hi"
    "gocart" : {
      "maker" : "w"
    "boat" : {



Josh covered logging with Logger and OSLogStore in iOS 15:



final class ViewModel: ObservableObject {

    @Published private(set) var recent = 0.0
    @Published private(set) var maximum = 0.0
    private let motionManager: CMMotionManager

    init() {
        let motionManager = CMMotionManager()
        self.motionManager = motionManager

            .publish(every: 0.1, on: .main, in: .common)
            .map { _ -> Double in
                guard let vector = motionManager.accelerometerData?.acceleration else { return 0.0 }
                return sqrt(vector.x * vector.x + vector.y * vector.y + vector.z * vector.z)
            .scan([0]) { accumulated, next in
                (accumulated + [next]).suffix(50)
            .map { $0.max() ?? 0.0 }
            .assign(to: &$recent)

            .scan(0) { maximum, next in
                max(maximum, next)
            .assign(to: &$maximum)

    func onAppear() {

    func onDisappear() {

struct ContentView: View {
    @StateObject private var viewModel = ViewModel()
    var body: some View {
        VStack {
            Text("Max: \(viewModel.maximum.formatted(.number.precision(.fractionLength(3))))g")
        .onAppear { viewModel.onAppear() }
        .onDisappear { viewModel.onDisappear() }


Good Learning Sources

Jake asked about good Swift learning sources. Here are ones that came up in no particular order. I added a couple more at the end:

Analytics & Social media

We talked about anaylytics and crash reporting.

Emil mentioned that Facebook has been in the news. He gave us a couple links to look at:


FocusState is a new property wrapper in iOS 15 that is the declarative version of UIResponder. It has some limitations about having to live in the view. Based on a Free video we explored how to use this new property wrapper with a proper view model.

Jake posed a problem about putting focus on the login right when the view appears.

Ultimately we needed to put in a delay.

    .onAppear {
      DispatchQueue.main.asyncAfter(deadline: .now() + 0.5) {

John James sent some resources:

It looks like Form now works. We could use onAppear instead of just task


Emily was asking about basic performance measurement. We demoed using gauges in Xcode and launching Instruments. Josh also mentioned using signposts in the logging system to drill down on a specific performance related problem.

Ed told us about a powerful performance measurement (misnamed video optimizer):

That's all. See you next week!


Signal Lab

Peter released his first mac app to the App store. You can download it for free (here)[]

Custom viewcontroller animations

We discussed using (UIViewControllerAnimatedTransitioning)[] to animated the transition between actionsheets. Josh has an old example from a pervious meetup (here)[]

Testable Architecture with MVVM + Coordinator

We discussed the motivation for writing tests. Watch these videos for additional context:

protocol Coordinator {
    associatedtype Action
    func handle(_ action: Action)

extension Coordinator {
    func eraseToAnyCoordinator() -> AnyCoordinator<Action> {

struct AnyCoordinator<Action>: Coordinator {
    private let _handle: (Action) -> Void
    init<SomeCoordinator: Coordinator>(_ coordinator: SomeCoordinator) where SomeCoordinator.Action == Action {
        _handle = coordinator.handle(_:)
    func handle(_ action: Action) {

We then looked at how this enables us to write a mock coordinator that simply records all of its actions:

final class RecordingCoordinator<Action>: Coordinator {
    var actions: [Action] = []
    func handle(_ action: Action) {

We talked about the adding a test target to your app and how to @testable import your module and setup your tests:

import XCTest
@testable import ImperativeCoordinator

final class ListViewModelTest: XCTestCase {

    var coordinator: RecordingCoordinator<ListCoordinator.Action>!
    var consumablesService: ConsumablesService!
    var viewModel: ListViewModel!

    override func setUpWithError() throws {
        coordinator = .init()
        consumablesService = .init()
        viewModel = .init(coordinator: coordinator, consumablesService: consumablesService)

    override func tearDownWithError() throws {
        coordinator = nil
        consumablesService = nil
        viewModel = nil

Using the mock, we can write tests and assert that the actions we expect are captured by the mock:

    func test_ViewModel_OnSelect_SomeConsumables() throws {
        let indexToSelect = 5
        consumablesService.ordinalNumberConsumable = 1
        XCTAssertTrue(coordinator.actions.contains {
            switch $0 {
            case let .showDetail(number):
                return number == viewModel.items[indexToSelect].number
                return false
        XCTAssertEqual(1, coordinator.actions.count)
    func test_ViewModel_OnSelect_NoConsumables() throws {
        let indexToSelect = 5
        consumablesService.ordinalNumberConsumable = 0
        XCTAssertTrue(coordinator.actions.contains { action in
            switch action {
            case .show:
                return true
                return false
        XCTAssertEqual(1, coordinator.actions.count)


Auto Rotation Problems

Ed wants to restrict an app to portait only mode except for one screen. He is having trouble doing this.

Josh thought this might help

It doesn't appear to re-evaluate the traits as hoped so still not working. Follow up next week.

Working toward a Machine Learning Model

Ray talked about his quiz project and how he plans to incorporate machine learning into a spaced repetition system. Lots of ideas about how to best gamify the system. Is ML really necessary in this case.

The project is being developed here:

SOLID Design principles

We reviewed SOLID design principles. Josh recommends you watch:

Imperative Coordinator

We took a look at the original imperative coordinator pattern and some of the issues it was designed to solve:


An optimal algorithm for bounded random integers

State of the art work is being done in Swift.

"Everyone knows that generating an unbiased random integer in a range 0 ..< upperBound, where upperBound is not a power of two, requires rejection sampling. What if I told you that Big Random Number has lied to us for decades, and we have been played for absolute fools?"

On Randomness

Ed talked about floating pins on only Atari 2600s.

Carlyn told us about this:

Felipe Cardoso to Everyone (10:07 AM) A really cool video about the nature of randomness. Vsauce - What is random?

Quiz Machine (version 1)

Ray did code overview of a SwiftUI quiz app.

The repo is here:

We talked about the overall architecture which uses a state machine. A good talk about making state machines can be found here (via Josh): Cory Benfield - Building State Machines in Swift

It would be nice if Swift had better ways to deal with enum types:

One library is case paths:

Backward capability

We talked an approach for supporting older OSes. We used the M25 apps BurndownView as an example:

import SwiftUI

// MARK: - Common Method

private func rectangle(started: Date, current: Date, totalWidth: Double, totalTime: TimeInterval) -> some View {
  let width = totalWidth - (min(current.timeIntervalSince(started), totalTime) / totalTime * totalWidth)
  return Rectangle().frame(width: width, height: 10, alignment: .leading)

// MARK: - iOS 14 version

private struct BurndownView14: View {
  let totalTime: TimeInterval
  @State private var started: Date?
  @State private var current: Date?
  let timer = Timer.publish(every: 0.01, on: .main, in: .common).autoconnect()

  var body: some View {
    GeometryReader { proxy in
        if let started = started, let current = current {
          rectangle(started: started, current: current,
                    totalWidth: proxy.size.width, totalTime: totalTime)
    .onAppear {
      started = Date()
    .onReceive(timer) { input in
      self.current = input

// MARK: - iOS 15 version

@available(iOS 15, *)
private struct BurndownView15: View {

  let totalTime: TimeInterval
  @State private var started: Date?

  var body: some View {
    GeometryReader { proxy in
        TimelineView(.animation) { context in
          if let started = started {
            rectangle(started: started, current: .now,
                      totalWidth: proxy.size.width, totalTime: totalTime)
    }.onAppear {
      started = Date()

// MARK: -- Common view

struct BurndownView: View {
  let totalTime: TimeInterval
  var body: some View {
    if #available(iOS 15, *) {
      AnyView(BurndownView15(totalTime: totalTime))
    } else {
      AnyView(BurndownView14(totalTime: totalTime))


Asteroids in SwiftUI using TimeLineView Canvas and GCVirtualController

//  ContentView.swift
//  Asteroids
//  Created by Joshua Homann on 8/28/21.

import Combine
import GameController
import SwiftUI

// MARK: - ViewModel
final class ViewModel: ObservableObject {

    // MARK: - Entity
    struct Entity {
        var orientation: Double = 0
        var position: CGPoint = .zero
        var velocity: CGVector = .zero

    // MARK: - Instance
    private(set) var player = Entity()
    private(set) var bullets: [Entity] = []

    // MARK: - Private
    private var subscriptions: Set<AnyCancellable> = []
    private let controller: GCVirtualController
    private var thumbStick: UnitPoint = .zero
    private var lastBounds: CGRect = .zero
    private var lastUpdateTime: Date?

    // MARK: - Init
    init() {
        let virtualConfiguration = GCVirtualController.Configuration()
        virtualConfiguration.elements = [GCInputLeftThumbstick, GCInputButtonA]
        let controller = GCVirtualController(configuration: virtualConfiguration)
        self.controller = controller
        controller.controller?.extendedGamepad?.leftThumbstick.valueChangedHandler = { [weak self] _, x, y in
            self?.thumbStick = .init(x: Double(x), y: Double(y))

        let buttonPresses = PassthroughSubject<Bool, Never>()
        controller.controller?.extendedGamepad?.buttonA.valueChangedHandler = { _, _, pressed in

            .throttle(for: .seconds(0.25), scheduler: DispatchQueue.main, latest: false)
            .map { pressed in
                    ? Timer
                        .publish(every: 0.33, on: .main, in: .common)
                        .map { _ in () }
                    : Empty(completeImmediately: true).eraseToAnyPublisher()
            .sink(receiveValue: { [weak self] _ in
                guard let self = self else { return }
                    orientation: self.player.orientation,
                    position: self.player.position,
                    velocity: .init(
                        dx: self.player.velocity.dx + cos(self.player.orientation - .τ / 4) * 5,
                        dy: self.player.velocity.dy + sin(self.player.orientation - .τ / 4) * 5
            .store(in: &subscriptions)


    func update(for time: Date, in bounds: CGRect) {
        let dt = ?? 0
        lastUpdateTime = time
        if bounds != lastBounds {
            lastBounds = bounds
            player.position = .init(x: bounds.midX, y: bounds.midY)
        player.orientation += thumbStick.x * .τ * dt
        let acceleration: Double = thumbStick.y * 4.0
        player.velocity = .init(
            dx: player.velocity.dx + cos(player.orientation - .τ / 4) * acceleration * dt,
            dy: player.velocity.dy + sin(player.orientation - .τ / 4) * acceleration * dt
        player.velocity.clamp(to: 250 * dt)
        player.position = .init(
            x: fmod(player.position.x + player.velocity.dx + bounds.width, bounds.width),
            y: fmod(player.position.y + player.velocity.dy + bounds.height, bounds.height)

        for index in bullets.indices {
            bullets[index].position.x += bullets[index].velocity.dx * dt * 50
            bullets[index].position.y += bullets[index].velocity.dy * dt * 50

        bullets = bullets.filter { bounds.contains($0.position) }

extension CGVector {
    var magnitude: Double {
        sqrt(dx * dx + dy * dy)

    mutating func clamp(to limit: Double) {
        let m = magnitude
        guard limit < magnitude else { return }
        dx /= m
        dy /= m
        dx *= limit
        dy *= limit

// MARK: - ContentViewView
struct ContentView: View {
    // MARK: - Instance
    @StateObject private var viewModel = ViewModel()
    private enum Graphic: Hashable {
        case ship, bullet, alien
    // MARK: - View
    var body: some View {
        TimelineView(.animation()) { time in
                opaque: true,
                colorMode: .linear,
                rendersAsynchronously: true,
                renderer: { context, size in
                    let bounds = CGRect(origin: .zero, size: size)
                    viewModel.update(for:, in: bounds)
                        Rectangle().path(in: bounds),
                        with: .color(.black)
                    if let resolvedBullet = context.resolveSymbol(id: Graphic.bullet) {
                        for bullet in viewModel.bullets {
                            var context = context
                            context.translateBy(x: bullet.position.x, y: bullet.position.y)
                            context.rotate(by: .init(radians: bullet.orientation))
                            context.draw(resolvedBullet, at: .zero)
                    if let ship = context.resolveSymbol(id: Graphic.ship) {
                        var context = context
                        context.translateBy(x: viewModel.player.position.x, y:  viewModel.player.position.y)
                        context.rotate(by: .init(radians: viewModel.player.orientation))
                        context.draw(ship, at: .zero)
                symbols: {
                    Text("🚀").font(.system(size: 48)).rotationEffect(.radians(-.τ / 8)).hueRotation(.init(radians: .τ / 2.0)).tag(Graphic.ship)
                    Text("🔥").font(.system(size: 24)).rotationEffect(.radians(.τ / 2)).tag(Graphic.bullet)
                    Text("👾").font(.system(size: 64)).tag(Graphic.alien)

extension Double {
    static let τ: Self = .pi * 2



Carlyn showed us some code that she was experimenting with wrt regex in Swift.

She also discovered this resource during the meeting:

Josh suggested that she might want to explore Apple's natural language offerings.

TimelineView Example

Ray gave an example on how to use the new timeline view:

struct ContentView: View {

    @State var dates: [Date] = []

    func timeSince(now: Date, input: Date) -> String {
        let formatter = RelativeDateTimeFormatter()
        return formatter.localizedString(for: input, relativeTo: now.addingTimeInterval(1))

    var body: some View {
        NavigationView {
            VStack {
                TimelineView(.periodic(from: .now, by: 1)) { _ in
                    List(dates, id: \.self) { date in
                        Text(timeSince(now: .now, input: date))
                Button("Add") {
                    withAnimation {

Sequences, AsyncSequences and AsyncStreams

Josh gave a review how sequences and iterators work and showed how they are a basis for the new AsyncSequence. He also showed how the sequence(first:next:) and sequence(state:next) are similar to AsyncStreams. If you are creating a async stream from traditional callback-style code, you can use the continuation builder initializer. If you have proper async you can use another initializer.

import UIKit

struct Fibonnacci: Sequence, IteratorProtocol {
    private var penultimate = 1
    private var last = 0
    mutating func next() -> Int? {
        let next = penultimate + last
        penultimate = last
        last = next
        return last < Int.max >> 1 ? next : nil
    func makeIterator() -> some IteratorProtocol {

extension Sequence {
    func printPrefix(_ count: Int) {
        print(self.prefix(count).map { "\($0)" }.joined(separator: " "))


let zeros = sequence(first: 0) { previous in previous }

let odds = sequence(first: 1) { $0 + 2 }

let fib = sequence(state: (penultimate: 1, last: 0)) { state -> Int? in
    let next = state.penultimate + state.last
    state.penultimate = state.last
    state.last = next
    return next


enum List<Element>: Sequence, ExpressibleByArrayLiteral {
    case end
    indirect case node(value: Element, next: List<Element>)

    private struct ListIterator: IteratorProtocol {
        var current: List<Element>
        mutating func next() -> Element? {
            switch current {
            case .end:
                return nil
            case let .node(value, next):
                current = next
                return value
    func makeIterator() -> some IteratorProtocol {
        ListIterator(current: self)

    mutating func push(front: Element) {
        self = .node(value: front, next: self)

    init(arrayLiteral elements: Element...) {
        self = .end
        elements.reversed().forEach { self.push(front: $0) }

var list: List = [1,2,3,4,5]
let list2 = list
list.push(front: 0)

struct Delayed<SomeElement>: AsyncSequence {
    typealias AsyncIterator = DelayIterator
    typealias Element = SomeElement
    private let delay: TimeInterval
    private let sequence: AnySequence<SomeElement>
    init<SomeSequence: Sequence>(
        sequence: SomeSequence,
        delay: TimeInterval
    ) where SomeSequence.Element == SomeElement {
        self.sequence = AnySequence(sequence)
        self.delay = delay
    struct DelayIterator: AsyncIteratorProtocol {
        private let delay: UInt64
        private let iterator: AnySequence<SomeElement>.Iterator
            delay: TimeInterval,
            sequence: AnySequence<SomeElement>
        ) {
            self.delay = UInt64(delay * 1e9)
            iterator = sequence.makeIterator()
        mutating func next() async throws -> SomeElement? {
            await Task.sleep(delay)

    func makeAsyncIterator() -> DelayIterator {
        DelayIterator(delay: delay, sequence: sequence)

let delayed = Delayed(sequence: fib, delay: 1)

Task.detached {
    var iterator = delayed.makeAsyncIterator()
    while let next = try await {
extension NSNotification.Name {
    static let josh = NSNotification.Name("josh")

let c = Timer
    .publish(every: 1, tolerance: nil, on: .main, in: .common, options: nil)
    .sink(receiveValue: { _ in .josh, object: nil, userInfo: ["date":]))

let stream = AsyncStream<Date> { continuation in
    NotificationCenter.default.addObserver(forName: NSNotification.Name.josh, object: nil, queue: nil) { notification in
        guard let date = notification.userInfo?["date"] as? Date else { return }

let stream2 = AsyncStream<Date>.init(unfolding: {
    await NotificationCenter.default.notifications(named: .josh, object: nil)
        .compactMap { $0.userInfo?["date"] as? Date }
        .first { _ in true }!

Task.detached {
    for await element in stream2 {


We discussed:

  • Storyboards vs Nib file vs Code
  • GPU vs CPU rendering
  • The cost of passing value types back and forth between queue's vs using references
  • Swift.Mirror and various loggin solutions.

Ed showed his watch running app and solicited feedback. He is lookf or beta testers next week.

Josh covered creata generic retry method for structure concurrency. We discussed a few concepts along the way:

  • Using Task.detached to spawn an asynchonous context from a synchronous context
  • Expressing retry as a loop and as a recursive function
  • naive, interval and exponential rety
  • Using Task.sleep to suspent the current task
  • static member llokup
  • private extensions
  • lazy repeated sequences with repeatElement
  • unfold sequences with sequence
  • lazy sequences with .lazy
protocol RetryStrategyProtocol {
    func delay() -> UInt64?

final class RetryStrategy: RetryStrategyProtocol {

    private var generator: AnySequence<UInt64>
    private var iterator: AnySequence<UInt64>.Iterator

    init<SomeSequence: Sequence>(sequence generator: SomeSequence) where SomeSequence.Element == UInt64 {
        self.generator = AnySequence(generator)
        iterator = self.generator.makeIterator()

    func delay() -> UInt64? {

private extension Double {
    static func nanoSeconds(_ value: Self) -> UInt64 {
        .init(max(value, 0) * 1e9)

extension RetryStrategyProtocol where Self == RetryStrategy {
    static func forever(delay: TimeInterval = 0) -> RetryStrategyProtocol {
        RetryStrategy(sequence: sequence(first: Double.nanoSeconds(delay)) { $0 })
    static func count(_ count: Int, delay: TimeInterval = 0) -> RetryStrategyProtocol {
        RetryStrategy(sequence: repeatElement(Double.nanoSeconds(delay), count: count))
    static func exponential(count: Int, initial: TimeInterval, multiplier: TimeInterval = 2) -> RetryStrategyProtocol {
        let exponential = sequence(first: initial) { next in
            next * multiplier
        return RetryStrategy(sequence: exponential.prefix(count)

final class Service {
    struct 💩: Error { }
    private var state = 1
    func getValue() async throws -> Int {
        defer { state += 1 }
        guard state.isMultiple(of: 4) else {
            print("Service failed \(state) at \(")
            throw 💩()
        print("Service succeeded \(state) at \(")
        return state

let service = Service()

func retry<Value>(_ strategy: RetryStrategyProtocol, awaiting task: @escaping () async throws -> Value) async throws -> Value {
    func onRetry(iteration: Int, task: @escaping () async throws -> Value) async throws -> Value {
        do {
            return try await task()
        } catch {
            guard let delay = strategy.delay() else { throw error }
            await Task.sleep(delay)
            return try await onRetry(iteration: iteration + 1, task: task)
    return try await onRetry(iteration: 0, task: task)

let t = Task.detached {
    let value = try await retry(.exponential(count: 3, initial: 1.0)) { try await service.getValue() }


This meeting was a smorgasbord of topics by group participants.

Ed had a couple of questions about building his watch app in SwiftUI.

  1. How to make a piece of text scale up. Using a geometry reader is one solution to the problem. Josh H. had a better solution. Make font size extra large and then scale it down by setting the minimum scale factor to something really small.
Text("Hello, world!")
   .font(.system(size: 400))
  1. How to implement double tap in SwiftUI. The best solution we could come up with was to use a ZStack-ed UIHostingView with a UIGestureRecognizer.

Don't use touchesBegan and friends from UIResponder. It is the old, ugly way of doing it.

We talked about syncing solutions. You can't force an iCloud sync.

There are other solutions:

Probably the best way is to do the iCloud sync separately.

Firebase is a low latency solution but Ed doesn't like it because it is a large dependency with a lot of extra baggage that your app probably doesn't need.

A commercial solution noted was Pusher but none seems to have had actual experience with it.

Tim showed us an app that he was making (QuickStuff) but needed to change the orientation of the video stream for Mac and iOS.

// Set the video orientation mode for Mac only
        // NOT needed when Mac Target is added!
        #if os(OSX)
            print("---> macOS")
        #elseif os(watchOS)
            print("---> watchOS")
        #elseif os(tvOS)
            print("---> tvOS")
        #elseif os(iOS)
            #if targetEnvironment(macCatalyst)
                print("---> macOS - Catalyst")
                print("---> iOS")
            // Without a Mac Target, running on Mac lands here
            //preview.connection?.videoOrientation = .landscapeLeft

Ray talked about a recent evolution pitch that will allow opaque return types to be structural types.


In this meeting, Josh created a generic property wrapper for transforming values. He also made the property wrapper conform to Dynamic Property which is useful in SwiftUI to make sure the body property of a view gets recomputed upon mutation. Among other tricks, he showed how to use nonmutating set with a reference type.

See previous meetings (April) for more information about property wrappers.

import Combine
import SwiftUI
import PlaygroundSupport
import Foundation

protocol TransformerProtcol {
    associatedtype Value
    var transform: (Value) -> Value { get }

struct AnyTransformer<Value>: TransformerProtcol {
    let transform: (Value) -> Value

enum CharacterCase { case lower, upper, capitalized }

extension TransformerProtcol {
    static func identity<Value>() -> AnyTransformer<Value> {
        .init { $0 }
    static func clamp<Value: Comparable>(_ range: ClosedRange<Value>) -> AnyTransformer<Value> {
        .init { min(max($0, range.lowerBound), range.upperBound) }
    static func rounded<Value: BinaryFloatingPoint>(_ rule: FloatingPointRoundingRule = .up) -> AnyTransformer<Value> {
        .init { $0.rounded(rule) }
    static func normalized<Value: BinaryFloatingPoint>(magnitude: Value) -> AnyTransformer<Value> {
        .init { $0 / magnitude }
    static func trimmed(_ characterSet: CharacterSet = .whitespacesAndNewlines) -> AnyTransformer<String> {
        .init { $0.trimmingCharacters(in: characterSet) }
    static func cased(_ characterCase: CharacterCase) -> AnyTransformer<String> {
        .init {
            switch characterCase {
            case .lower: return $0.lowercased()
            case .upper: return $0.uppercased()
            case .capitalized: return $0.capitalized

struct Transform<Value>: DynamicProperty {
    final class Wrapper: ObservableObject {
        @Published var value: Value
        @Published var untransformedValue: Value
        private let setter: (Value) -> Value
            untransformedValue: Value,
            setter: @escaping (Value) -> Value
        ) {
            self.untransformedValue = untransformedValue
            self.setter = setter
            value = setter(untransformedValue)
        func set(_ newValue: Value) {
            untransformedValue = newValue
            value = setter(newValue)
    @ObservedObject private var wrapped: Wrapper
    var wrappedValue: Value {
        get { wrapped.value }
        nonmutating set { wrapped.set(newValue) }

    var projectedValue: Wrapper {

        wrappedValue: Value,
        _ setter: AnyTransformer<Value>
    ) {
        let wrapper = Wrapper(untransformedValue: wrappedValue, setter: setter.transform)
        _wrapped = .init(wrappedValue: wrapper)

final class B: ObservableObject {
    @Transform(.clamp(0...1.0)) var a = 1.5
    @Transform(.rounded()) var b = 2.7
    @Transform(.trimmed()) var c = " sdsf "
let b = B()

extension NSNotification.Name {
    static let persistedDidChange = NSNotification.Name(rawValue: "PersistedDidChange")

struct Persisted<Value: Codable>: DynamicProperty {
    final class Wrapper: ObservableObject {
        @Published var value: Value
        private let defaults: UserDefaults
        private let suiteName: String?
        private let key: String
            value: Value,
            suiteName: String? = nil,
            key: String
        ) {
            defaults = suiteName.flatMap(UserDefaults.init(suiteName:)) ?? .standard
            self.key = key
            self.suiteName = suiteName
            self.value = defaults
                .data(forKey: key)
                .flatMap { try? JSONDecoder().decode(Value.self, from: $0) } ?? value

                .publisher(for: .persistedDidChange)
                .compactMap { notification in
                    guard (notification.object as? String) == suiteName else { return nil }
                    return notification.userInfo?[key] as? Value
                .assign(to: &$value)
        func setAndSave(_ newValue: Value) {
            guard let data = try? JSONEncoder().encode(newValue) else { return }
            value = newValue
            defaults.set(data, forKey: key)
   .persistedDidChange, object: suiteName, userInfo: [key: newValue]))
    @ObservedObject private var wrapped: Wrapper
    var wrappedValue: Value {
        get { wrapped.value }
        nonmutating set { wrapped.setAndSave(newValue) }

    var projectedValue: Published<Value>.Publisher {


Overheating MacBook Pro

We started off the meeting talking about Ray's computer problems with macOS 11.4 - macOS 11.5, Zoom, Google meetup and overheating. Update: After getting the pentalop driver to disassemble and clean the dust the 2019 MBP, the problem appears to be resolved! There was a lot of dust stuck in the fan blades.

Capturing Video Frames

Tim asked about the state of the art for capturing video.

Colors with themes

There was a question about how to handle colors with light and dark themes. Josh talked about how to specify multiple colors per theme in an asset catalog as well as resolved colors:


Ed gave us a demo of GeoCoding and reverse geocoding.

He uses this in his app TouchRoute. Five star reviews welcome!


New in foundation is the ability to specify formatters. These formatters are better typed than before.

let date = Date()
date.formatted(date: .abbreviated, time: .omitted)

let stuff = [1,2,3,4,5].map(String.init)
print(stuff.formatted(.list(type: .and)))

Usability Feedback

Tim Colson let us know about a group that offers free advice on user experience.

Extensible Options

Static member lookup in Swift 5.5 gives us the syntactic elegance and code completion of enums while making things extensible.

Imagine a library method:

protocol ItemSorting {
    func sort(_ items: [Item]) -> [Item]

extension Array where Element == Item {
    func sort<Method: ItemSorting>(method: Method) -> [Item] {

The library can define methods:

struct NoneItemSorting: ItemSorting {
    func sort(_ items: [Item]) -> [Item] {

extension ItemSorting where Self == NoneItemSorting {
    static var none: NoneItemSorting {

But clients outside the library can also define methods.

struct CrazyItemSorting: ItemSorting {
    func sort(_ items: [Item]) -> [Item] {
        return items

extension ItemSorting where Self == CrazyItemSorting {
    static var crazy: CrazyItemSorting {

How beautiful it looks at the call site:

[Item(name: "Hello", date: .now)].sort(method: .none)



@ViewBuilder SwiftUI API Conventions

We walked through a blog post on the Five Stars blog that talked about how SwiftUI has changed API over the last couple years with regards to ViewBuilders and trailing closures.

  • Instead of a single generic view, SwiftUI now prefers @ViewBuilders
  • Main content comes first and labels and secondary views second
  • Takes advantage of trailing closure syntax
  • @escaping closures for actions come last, after the view builders

Although not covered in this blog post, the latest beta has enabled these new APIs back to iOS13.

TimelineView and CanvasView

Josh reviewed the new TimelineView and Canvas in iOS 15. We discussed animation scheduling and the graphics context.

struct ContentView: View {
    @StateObject private var viewModel = ViewModel()
    var body: some View {
        TimelineView(.animation()) { time in
            Canvas { context, size in
                let minimumDimension = size.minimumDimension
                let delta = minimumDimension * 0.1 * sin( + minimumDimension * 0.1
                let rect = CGRect(origin: .zero, size: .init(width: minimumDimension, height: minimumDimension))
                        dx: (size.width - minimumDimension) / 2,
                        dy: (size.height - minimumDimension) / 2
                    .insetBy(dx: delta, dy: delta)
                    Path(ellipseIn: rect),
                    with: .color(.red)

extension CGSize {
    var minimumDimension: Double {
        min(width, height)

The animation schedule is analogous to CADisplayLink and executes on every frame available. This is great for animation.

The GraphicsContext has a bunch of features including grabbing resolved images and text so that duplicates can be draw very quickly. See the documentation for details.


R-Style Boolean Sequences in Swift

Ray presented some extensions on Sequences and Collection to make Swift work more like the statistical programming language R. (PS: After reinstalling Big Sur 11.4, things worked a lot better. The playground that was having problems in the demo suddenly just worked. Hah.)


Nasa Astronomy Image of the Day

Josh showed a code along project designed to show how to use async / await with SwiftUI in iOS 15 beta.

We dicussed:

  • The Nasa Astronomy Picture of the Day API:
  • decoding the response with Quicktype:
  • cleaning up the type to remove optional elements, use strong typing for URL, and make the resulting struct Identifiable so it works in a SwiftUI.List
  • build a URL with URLComponents
  • making an async initializer for Result
  • making an async network request and decoding the response
  • switching over the images enum to handle loading, error and loaded states
  • Using the new AsyncImage API
  • Using the new .task modifier to start an async task that is automatically scoped to the lifetime of the view
  • using the new .refreshable modifier to implement pull to refresh



Met Museum Gallery

We continued the Met Museum app. Fixes:

  • Fixed the problem with search results not updating by using the new OrderedSet in the swift-collections package. We all discussed package lists and the new IDE changes for packages in XCode 13.
  • Fix the parallel download issue by using withThrowingTaskGroup and hoisted this logic into its own generic function:
extension Sequence {
    func asyncUnorderedMap<Value>(awaiting transform: @escaping (Element) async throws -> Value) async rethrows -> [Value] {
        try await withThrowingTaskGroup(of: [Value].self) { group in
            forEach { element in
                group.async {
                    [try await transform(element)]
            return try await group.reduce(into: [Value]()) { total, next in
                total.append(contentsOf: next)
  • discussed the .listStyle and .listRowSeparator modifiers
  • created a DetailView and discussed when to use an ObservableObject vs when to use a struct for a viewModel
  • discussed AttributedString from markdown, new iOS 15 Date formatter and List Formatter
  • discussed new .safeAreaInset modifier
  • discussed new .foregroundStyle label styles
  • discussed new Material styles Project:



Command line dice roll app

Peter showed his command line dice rolling app and we discussed some problems he was having compiling the app from the command line when including a swift package:

Met Museum Gallery

Josh demoed an app using the Met API . We discussed:

  • Code generating the response with and manually cleaning up the generated code
  • A generic networking layer using the new try await API
  • Using an actor for the service layer of the app
  • The new AsyncImage View in iOS 15
  • The new .searchable, .searchCompletion and .onSubmit modifiers in iOS 15
  • The new @MainActor annotation
  • Reviewed the @AppStorage property wrapper from iOS 14
  • discussed chaining await calls and a problem with using withThrowingTaskGroup(of: inside a async The partial project is here: We will finish it next week.

Bridging await to Combine

We dicussed the differences push (Combine) vs pull (async/await), strong error typing (combine) vs weak error typing (async/await), cold publishers (the Combine structs) vs hot publishers (the Combine references and async/await), and how to bridge async functions to Combine by leveraging Future, a hot publisher.

extension Future where Failure == Error {
    convenience init(awaiting asyncTask: @escaping () async throws -> Output) {
        self.init { promise in
            async {
                do {
                    promise(.success(try await asyncTask()))
                } catch {


Izzi Pics App Feedback

Emil Safier asked our opinion on his screenshots for marketing his Izzi Pics app.

He also has a TestFlight version available.

Slow Watch Reminders Updates

Mark not getting good performance. Perhaps his iCloud data store needs to be reset? It is a scary operation so caution is advised.

John James needs to get a new watch or replace his battery. Discussion about "right to repair".

Existential and Universal Types in Swift

A presentation from Josh about the difference between existential protocol types, generics, type erased Any*, and some types.


  • Generic functions
  • Any
  • AnyObject, AnyClass
  • Concrete generic type erasers: Any* AnySequence, AnyView, AnyPublisher Existentials:
  • existentials (SE-309): let a: CustomStringConvertible = 1. Dynamically implemented by witness table.
  • some: let a: some CustomStringConvertible = 1. Statically known at compile time. A question from Josh A in the chat we didn't notice. (We'll discuss the answer next week):

Hope this isn't a silly question, but why do we need "some", couldn't we do something like T, like just a normal generic? Is it because we want the compiler to know the type? Or is it because there are so many different ways to satisfy the "View protocol" having a normal generic wouldn't work?

The "some type" is called a "reverse generic" because the implementation body determines the implementation. With normal generics the caller determines the concrete type which would not work for "some View".

Apple Logo

Looking at the details of this code from Jordan Singer.

Fighting Xcode, Zoom, macOS

Ray had significant problems sharing his screen today. Somehow hopes to fix this for next week.


WWDC Discussion

You are probably best off using the developer app to watch the videos. Get started here:

Josh talked about some of the major themes and surprises from this year.

  • Continued improvement to bring parity to all platforms but not do something like run Mac apps on iPad.
  • Markdown support for Text
  • No developments on Combine. Pushes the FRP story out by another year.

Other discussion:

  • Frank's pick was Demystifying SwiftUI
  • Column breakpoints!
  • ARC observed lifetime vs guaranteed lifetime

We will be talking a lot more about these things in the coming weeks.


  • Ray will be live on the Raywenderlich podcast after WWDC. Signup here:

  • Emily asked about showing a different viewcontroller at startup depending on Userdefaults. We discussed using childViewControllers and setting the rootViewController programatically from the Appdelegate or the SceneDelegate

    func scene(_ scene: UIScene, willConnectTo session: UISceneSession, options connectionOptions: UIScene.ConnectionOptions) {
        let contentView = ContentView()
        if let windowScene = scene as? UIWindowScene {
            let window = UIWindow(windowScene: windowScene)
            window.rootViewController = figureOutWhichVCGoesHere()
            self.window = window
  • Dan's app is available on the app store. Check it out here:

  • Ed demoed his brother hackathon entry for buying/renting AR rendered NFT's.

  • Josh demoed the problem with classes and shared mutable state that actors are designed to solve. For example this code is not thread safe:

final class Poop {
    private var count: Int = 0
    private let serialQueue = DispatchQueue(label: String(reflecting: Poop.self))
    func poo() {
        count += 1
        print(count == 1 ?  "💩 is good" : "\(count) bad 💩 happened!!!!")
        count -= 1

let poop = Poop()
for _ in 0..<10 { .background).async {

It can be made thread safe by adding locks or a serial DispatchQueue, but this results in a programmer guarantee and not a compiler guarantee:

final class Poop {
    private var count: Int = 0
    private let serialQueue = DispatchQueue(label: String(reflecting: Poop.self))
    func poo() {
        serialQueue.async { [weak self] in
            guard let self = self else { return }
            self.count += 1
            print(self.count == 1 ?  "💩 is good" : "\(self.count) bad 💩 happened!!!!")
            self.count -= 1

let poop = Poop()
for _ in 0..<10 { .background).async {
  • We discussed the types in Swift and when to use them:
    • enum
      • Is your type heterogeneous?
      • Does your type represent discretely many states?
      • enum is a value unless you use the indirect keyword
    • struct
      • structs have value semantics
      • Copy on write for types that are implemented as references
      • Sendable thread safe by default
    • tuple
      • tuple have value semantics
      • anonymous
      • Sendable thread safe by default
    • class
      • class has reference semantics
      • Implies shared ownership
      • Allows inheritance (don’t use it for non obj C code)
      • Not thread safe unless its immutable or you guarantee safety
      • Have lifetime with init and deinit
    • actor
      • actor has reference semantics
      • Implies shared ownership
      • No inheritance
      • Thread safe and Sendable but you pay a performance cost
    • func
      • func is a reference type
      • Not thread safe; you make the guarantee with @Sendable
    • Protocol
      • protocol is abstract type
      • Prefer to using inheritance

Josh's shorthand rule for class vs actor: Use an actor for all of the service level objects in your app (networking, caching, location etc.) but continue to use classes for types that are owned by UI thread objects (ie viewModels) and wherever you need to inherit from Objective C or can guarantee single threaded access or immutability.


We talked about getting the most out of the WWDC.

  • Download the developer app
  • Make sure to watch the Platforms state of the Union
  • Watch what's new in Swift

We spent most of the meeting working through this article by Paul Hudson:

The newsletter mentioned some videos that might also be useful to watch:

Apple needs to get caught up on graphics technology.



  • The new book Expert Swift is out. You can read the first four chapters for free and Ray Fix wrote two of those. Any feedback you have toward the next edition would be useful!

  • Paul Hegarty's famous CS193p iOS Stanford class for 2021 is out. He does an amazing job of teaching SwiftUI from the ground up. Worth watching.

Router Pattern

Tim Colson helped us explore a navigational pattern related someone to coordinators.

  • Protip: To reset user defaults quickly you can just delete the app in the simulator.

Building C++

Ed was working through some tricky build issues. One issue which we were able to solve was related to ensuring that there one definition of a symbol in C++ so the linker doesn't get duplicates. You must declare things "extern" in shared headers. Also, special care needs to be taken for C:

#ifdef __cplusplus
extern "C" {

// C code here

#ifdef __cplusplus

Coredata, Dependency Injection, Inversion of Dependencies

Josh reworked Apple's sample CoreData project to facade CoreData behind a value and function only interface, sequesting the CoreData specific logic, types and delegates behind a protocol and decoupling the rest of the app from the dependency on Coredata. See last weeks discussiong for dependency inversionf or more details.



Fluent SQLite

In previous weeks we have talked about using a variety of data backends for iOS models. I demonstrated how you can use the Fluent ORM from the Vapor project to back your SwiftUI app. Here is the writeup:

Inversion of Dependecies

We discussed the D in SOLID: dependency inversion and how it can we be used to facade your database implementation so that you can swap out the implementation of your caching or storage layer without affecting the rest of your app (ie swap Coredata for Fluent).

Transforming a while loop into an asynchronous Publisher

Josh showed how we can take a while loop for a series of asynchronous tasks and reimagine it as a generic recursive asynchrounous function. This is useful for tasks such as making repeated sequential network requests until the response satisfies some predicate.

import PlaygroundSupport
import Combine

extension Publishers {
  static func publishLatest<Output, Failure>(
    while predicate: @escaping (Output) -> Bool,
    make publisherFactory: @escaping (Output?) -> AnyPublisher<Output, Failure>
  ) -> AnyPublisher<Output, Failure> {
    func makeNextPublisher(from output:Output?) -> AnyPublisher<Output, Failure> {
      publisherFactory(output).map { result -> AnyPublisher<Output, Failure> in
          ? Publishers.Concatenate(
              prefix: Just(result).setFailureType(to: Failure.self),
              suffix: makeNextPublisher(from: result)
          : Empty(
              completeImmediately: true,
              outputType: Output.self,
              failureType: Failure.self
    return makeNextPublisher(from: nil)

let c = Publishers.publishLatest(
  while: { $0 < 3 },
  make: { previous in Just( { $0 + 1 } ?? 0).eraseToAnyPublisher() }
.sink(receiveValue: {


Swift 5.5

We discussed the current status of the Swift 5.5 with many of the proposals approved ahead of WWDC:

Swift Package index

Ray showed the Swift package index and the apbility to download and test a package in a playground: He also showed the collections package and the Dequeue:

Rendering cell gradients

Josh A showed his project to create a messaging UI framework. We discussed possible ways to render a gradient overlay for the entire scrollview in UIKit and in Swift UI. Josh H suggested using a blend mode on a gradient to tint the cells like this:

MVC, Diffable DataSources and MVVM in UIKit and SwiftUI

Josh H continued his demo on modern app architecture in UIKit and SwiftUI. We recapped what a basica imperative MVC TableView VC looks like in UIKit, what the analogous declarative version looks like by using DiffableDataSources, Combine and UIAction. We noted that we were able to delete all of the instance variables in the declartive version because all the mutable state is now private to the init function.

We then created a futher refinement by lifting out the busness logic to a SwiftUI inspired viewModel, and saw that we can use the same viewModel to drive both the UIKit and SwiftUI versions of this screen, giving us a single reactive declarative and immutable architecture for both UIKit and SwiftUI that is especially useful for hybrid apps that need to use both UI layers:



Emil asked about the requirements for decrypting and inspecting the receipt payload for Storekit in app purchases. We discussed that the official Apple solution is to have your server validate the receipts against the Apple servers to avoid a possible man in the middle attack, although you can do this on device if you don't have a server and are willing to ignore Apple's security concerns.

Parsing command line arguments

We looked at the Swift argument parser library. This was developed, among other reasons, to provide argument parsing for the Swift compiler. While most of Swift is written in C++, parts are being re-written now in Swift.

We created a simple SwiftUI app and passed arguments to it. You can find the example, and more information on this blog post:


Curits asked about how to perform deeplinking from a local notification in his app. We discussed the MVC architecture and noted that it lacks a separate component for routing. This problem also exists for MVVM applications in SwiftUI where the view tree is a function of the viewmodel state. We discussed the possibility of solving this with a separate Router/Coordinator component that can be imperative for UIKit code and reactive for SwiftUI, allowing for a single unified routing architecture in a mixed app. We looked at how you can handle deeplinks imperatively by handling 3 functions in the app delegate (didLaunch, open url, and didRecieveRemoteNotification) and funneling the results to one function that can inspect the application's keywindow rootViewController to decide how to route the link. We dicussed the possible pitfalls of changing the navigation stack when the user is not logged in, when the user is in the middle of some content creation (typing a message for instance), or when the user does not have permission or is not authenticated. We will explore this concept in the future as part of a broader discussion on modern ios app architecture.


Product and Rumor Talk

We talked about the new product Apple made. Ray and John pre-ordered AirTags. Ray is excited to buy an M1 iPad when it becomes available.

We discussed the quanta leaks:

UITextField vs UITextView

Josh notes UITextField is generally easier to work with because it has the target action behavior of UIControl.

Demonstration of Yi's apps

He showed a cool desktop picture app that uses the Unsplash API.

He showed his finance app which compared with big competitors is (1) easy to use (2) protects your privacy (3) is not a subscription model. Asked for market.

Sync solution used


We discussed market positioning and marketing and possibly using a press release as a better value proposition than advertising:

Josh's picks

Benchmarking Swift

One language to rule them all?

Josh suggested watching this Uncle Bob video where Bob proposes that new programming paradigms are about subtraction and not adding features and that we may have discovered all of the programming paradigms because there is nothing else left to subtract. The most interesting discussion is at the 13:20 mark.

Lots of changes coming in Swift 5.5


New Swift Evolution Proposals, Repos and Tools

We talked about some of the new evolution proposals and repositories available.

Evolution Proposals

Swift Repositories

Other repos to think about using:

User Experience Resources

Read the Human Interface Guidelines (HIG). There are also websites that explore different user interfaces

Corner Rounding

Mira had a question about label corner rounding. The discovery was that if corner rounding is added to the init of a custom collection view cell it works but if added to layoutSubviews, it does not. It is somewhat a mystery as to why this is the case

Core Data vs ...

Curtis was wonding about as a wrapper for data. A simpler approach may be to just store everything in a file that is saved to the documents directory.

If you are learning about CoreData you might want to check this out:

Also you might want to read this:

Josh A. reminded us that parse which is alive and well (and uses Mongo under the hood)

Previews for UIKit

Josh created a package that lets you preview UIKit views and view controllers using the SwiftUI preview mechanism.

Table View Data Sources

Ask three questions?

  1. How does it work? (coding concern)
  2. Why does it work that way? (software engineering concern)
  3. Should it work that way? (deeper software engineering concern)

Josh gave a presentation about table view data sources. His first example used standard MVC to show pokeman characters loaded in from a JSON document. It had a searchbar to narrow down search terms. It worked but performed expensive filter work on the main thread, had to have mutable shared state properties, and didn't animate changes.

Next, he used the diffable data source to solve the same problem. This is a more declarative form put everything in the initializer (except for the observing publisher subscription). It applies snapshots as the data source to achieve animation when search is activated. The structures look more like SwiftUI.

Next week he will take this example further and show an MVVM implementation that looks a lot more like SwiftUI.


Touch Route

Ed has a new app in the App Store called Touch Route. Several participated in the TestFlight. Time to get it and give him a five star review! :)

Swift Packages with Binary Frameworks

Ed also gave us a quick tour about how to use frameworks from SwiftPM. Important: you need to convert a .framework to an .xcframework to be usable. The package definition DSL is just Swift code.

We also talked about various Brother printers - Brother QL-820NWB

Review of Property Wrappers

We worked through this example:

struct Clamped<Value: Comparable> {
    var range: ClosedRange<Value>
    private var value: Value
    var wrappedValue: Value {
        get { value.clamped(to: range) }
        set { value = newValue }
    var projectedValue: Value {
        get { value }
        set { value = newValue }
    init(wrappedValue: Value, range: ClosedRange<Value>) {
        value = wrappedValue
        self.range = range

extension Comparable {
    func clamped(to range: ClosedRange<Self>) -> Self {
        min(max(range.lowerBound, self), range.upperBound)

Josh Homann has covered this in previous meetups.

Also, Josh recommends using Snippets in Xcode as a way to expose the entire surface area of a function in one shot.

struct <#Name#> {
  private var value: <#Wrapped#>
  var wrappedValue: <#Wrapped#> {
    get { value }
    set { value = newValue }
  var projectedValue: <#Projected#> {
    get { value }
    set { value = newValue }
  init(wrappedValue: <#Wrapped#>) {
    value = wrappedValue

A new Swift evolution proposal 0293 has been accepted and will be in Swift 5.5. Expect to see a lot more @ symbols at next WWDC.


Review of Mutable Value Semantics

Ray did a review of what mutable value semantics are in Swift using the iPad note app to draw with. Languages like Java and Python use reference semantics for performance. Languages like Haskell have value semantics but achieve it through immutability. Swift gets the best of both worlds by using reference semantics privately but then doing copy-on-write to achieve value semantics.

Tim wrote some playground code to work through the ideas:

// Value Semantics
let a = [1,2,3]
// b just "points" to same memory as "a"
let b = a
// c just points to a
var c = a
print(a,b,c) // [1,2,3][1,2,3][1,2,3]
    // Standard Swift Types support "Mutable Value Semantics" - i.e. Copy on Write (aka "COW paradigm")
    // Uh Oh - this is a var that changes... so COW!
print(a,b,c) // [1,2,3][1,2,3][1,2,3,4]

// Example with Classes (Person)
class Person {
    var name : String
    init(name: String) { = name
var p1 = Person(name:"Josh1")
let p2 = Person(name:"Josh2")
let p3 = Person(name:"Josh3")
print("p1 unique=\(isKnownUniquelyReferenced(&p1))")
var people : [Person] = [p1, p2, p3]
//  print("people unique=\(isKnownUniquelyReferenced(&people))")
print("p1 unique=\(isKnownUniquelyReferenced(&p1))")
//  let tallPeople = people
//  let smartPeople = people

We looked at the problem with SwiftUI and CoW types. The property wrappers @State and @Published make a local copy which prevents the copy optimization. Instead, you can use objectWillChange on ObservableObject directly.

Swift on Tap

Tim showed us Apple-like documentation but with examples.

Frank: Swift on Tap is the work of Alex Fine.

Some SwiftUI resources worth a look:

Importing a binary framework and vending it from SwiftPM

Ed talked about a problem he is still trying to solve. We think he will need to import the library through a bridging header of a modulemap file.

Rumors and Discussion

Video app pitch

Yi pitched his video app that he is just beginning with.


John showed the beginning of his app: which he would like to make into an interactive coding exercise. If you'd like to contribute, propose a feature and you can present it during the meetup and crowd source the solution.

Ray demoed an issue with a CowWrapper type where it was causing unexpected allocations. The solution will be presented in the next meeting!

Josh showed a solution to making a UIStackView in UIScrollView scroll only when the content exceeds the scrollView's height, and making the stackview equal the scrollview's height in all other cases. This involves 10 constraints:

  • 4 position constraints on the scrollView's frameLayoutGuide to its parent view to position the scrollview.
  • 4 position constraints on the stackview to the scrollView's contentLayoutGuide to position the stackView inside the scrollview
  • 2 dimension constraints to imply the size of the stackView
    • A cross axis (horizontal for a vertical scroll) constraint that constrains the stackView's width to the scrollView's width, causing the scrollView to not scroll horizontally
    • An axis constraint (height for a vertical scrollView) that provides a minimum dimension for the stackView's axis that is equal to or greater than the scrollView's scrolling axis. This constraint must not be required (the priority must be less than .required which has a rawValue of 1000).

Finally, at least one view in the stack needs to be expandable. In this example it is the spacer view. Expandability is accomplished by setting the contentHuggingPiority of the expandable view(s) to a value lower than all of the other views in the stack for the scrolling axis (vertical).

class ViewController: UIViewController {

  override func viewDidLoad() {
    let title = UILabel()
    title.text = "Title"
    let subtitle = UILabel()
    subtitle.numberOfLines = 0
    subtitle.text = "Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum."
    let imageView = UIImageView(image: UIImage(systemName: "star.fill") ?? UIImage())
    imageView.contentMode = .scaleAspectFill
    imageView.heightAnchor.constraint(equalToConstant: 300).isActive = true
    let button = UIButton()
    button.backgroundColor = .black
    button.setTitle("Test", for: .normal)
    button.heightAnchor.constraint(equalToConstant: 50).isActive = true
    button.widthAnchor.constraint(equalToConstant: 100).isActive = true
    button.layer.cornerRadius = 8
    let spacer = UIView()
    spacer.translatesAutoresizingMaskIntoConstraints = false
    spacer.heightAnchor.constraint(greaterThanOrEqualToConstant: 50).isActive = true
    spacer.setContentHuggingPriority(.init(rawValue: 0), for: .vertical)
    let stack = UIStackView.init(arrangedSubviews: [
    stack.translatesAutoresizingMaskIntoConstraints = false
    stack.axis = .vertical
    stack.alignment = .center
    let scrollView = UIScrollView()
    scrollView.translatesAutoresizingMaskIntoConstraints = false
      scrollView.frameLayoutGuide.topAnchor.constraint(equalTo: view.safeAreaLayoutGuide.topAnchor),
      scrollView.frameLayoutGuide.bottomAnchor.constraint(equalTo: view.safeAreaLayoutGuide.bottomAnchor),
      scrollView.frameLayoutGuide.leadingAnchor.constraint(equalTo: view.safeAreaLayoutGuide.leadingAnchor),
      scrollView.frameLayoutGuide.trailingAnchor.constraint(equalTo: view.safeAreaLayoutGuide.trailingAnchor),
      scrollView.contentLayoutGuide.topAnchor.constraint(equalTo: stack.topAnchor),
      scrollView.contentLayoutGuide.bottomAnchor.constraint(equalTo: stack.bottomAnchor),
      scrollView.contentLayoutGuide.leadingAnchor.constraint(equalTo: stack.leadingAnchor),
      scrollView.contentLayoutGuide.trailingAnchor.constraint(equalTo: stack.trailingAnchor),
      scrollView.widthAnchor.constraint(equalTo: stack.widthAnchor),
    let height = scrollView.heightAnchor.constraint(greaterThanOrEqualTo: stack.heightAnchor)
    height.priority = .defaultLow
    height.isActive = true


Breakout sessions

Had fun with breakout sessions. I can see how we can use these in the future.

Setting Autolayout Constraints and whitespace

Constraints need to set the xy position and width and height of a view. Sometimes the size has an implicit content size and you don't need to set the width and height. You want to avoid under constraining or specifying conflicting contraints.

How to make whitespace at the bottom?

  1. Make a constraint >= 1
  2. Set vertical hugging priority to the lowest possible value (1)

String Performance Cliff

If you load in a string with:

let value = try String(contentsOf: url)

You might load a string that is UTF16 or non-contiguous. That causes a 10x slowdown. This might be noticeable if you have a string processing app or a lot of concurrent users on a server app.

There are two functions you might want to be aware of:

    value.isContiguousUTF8  // can this string use the fast path algorithms?
    value.makeContiguousUTF8() // makes it O(1) to access the storage

Also, there are two overloads: String(contentsOf: url) and String(contentsOf: url, encoding: .utf8) The first does autodetection the second assumes the encoding. Prefer specifying it when you can as it may guarantee contiguous storage in the future.


Codable and code synthesis

A lot of forum discussions happening right now with relation to Codable because of the associated type proposal.

We talked about this one:

Swizzling and associated storage to track view controller leaks

Josh walked through the different types of dispatch available to Swift: static dispatch, virtual table (closely related to witness table) dispatch, and full Objective-C message dispatch. The last is the most flexible to a frightening extent. It allows you to swizzle (replace) system methods like viewDidLoad of UIViewController types. Using assocated storage you can track stuff about the object including an object with a custom deinit.


extension UIViewController {

  final class OnDealloc {
    var closure: () -> Void
    init(_ closure: @escaping () -> Void) {
      self.closure = closure
    deinit {
  private static var associatedObjectAddress = String(reflecting: OnDealloc.self)

  @objc private func swizzledViewDidLoad() {
    let onDealloc = OnDealloc {
      print("Dealloc \(Self.self)")
    objc_setAssociatedObject(self, &Self.associatedObjectAddress, onDealloc, .OBJC_ASSOCIATION_RETAIN_NONATOMIC)
    print("ViewDidLoad \(Self.self)")
    swizzledViewDidLoad()  //ViewDidLoad
  private static let swizzleImplementation: Void = {
    let originalSelector = #selector(UIViewController.viewDidLoad)
    let swizzledSelector = #selector(UIViewController.swizzledViewDidLoad)

    guard let originalMethod = class_getInstanceMethod(UIViewController.self, originalSelector),
          let swizzledMethod = class_getInstanceMethod(UIViewController.self, swizzledSelector) else {

    method_exchangeImplementations(originalMethod, swizzledMethod)

  static func swizzle() {
    _ = swizzleImplementation



What's new in Swift evolution?

CGFloat <-> Double

Great if this sharp edge were fixed. A good April 1st version of this would be to introduce CGDouble 🤣


Some chatter about the pattern in general:

It is available in many languages. (I first encountered it a decade ago in C++ Boost asio.)

Alignment Guides

There are many ways of performing the alignment in Swift. We looked at several ways using alignment guides. Here was a basic example we explored.

extension HorizontalAlignment {
    enum Custom: AlignmentID {
        static func defaultValue(in context: ViewDimensions) -> CGFloat {
    static var custom: HorizontalAlignment = HorizontalAlignment(Custom.self)

 struct ContentView: View {
        var body: some View {
            VStack(alignment: .custom) {
                HStack {
                    TextField("John J.", text: .constant(""))
                        .alignmentGuide(.custom) { context in
                HStack {
                    TextField("1234 Main Drive", text: .constant(""))
                        .alignmentGuide(.custom) { context in

Adding Measurement Units

The Measurement facility in Foundation lets you add different units of the same dimension in a type safe way. Be careful with temperature, though. If you add C and F together it will convert to the base unit (K) and add those which might not be expected. Stay in the same units to keep the implicit conversion from happening.

import Foundation
let a = Measurement(value: 70, unit: UnitTemperature.fahrenheit)
let b = Measurement(value: 20, unit: UnitTemperature.celsius)
a + b // really hot!

a.converted(to: .kelvin) + b.converted(to: .kelvin)  // same as a + b

a + b.converted(to: .fahrenheit)  // probably what you meant, not as hot

Better NSAttributedString API with Result Builder

Josh created a cool custom result builder for creating composable NSAttributedString without all of the type loss of its Objective-C / NSDictionary based API.

Package and example project: image


Demo Time

Caleb and Emily showed a new version of their app. They had some questions about handling multipart posts and general app architecture.

Josh gave us a brief survey of various app architectures.

Is SwiftUI ready for production? The answer depends on the user base you need to support. (They are currently requiring iOS 13 because they are using Combine.)

Some links from Tim Colson

The story about how Uber almost had a disaster when they switched to Swift:

Push Notifications

What is the state of the art for push notifications?

Many services out there. You probably don't want to roll your own unless you have to.

Network Sniffing

Aside: Serial 2 is a great tool for sniffing USB/serial devices on macOS

LaTeX and MathML

A cool project would be to write a LaTeX parser that rendered using MathML and WKWebView.

Units and Codable

import Foundation
let mile = Measurement(value: 1, unit: UnitLength.miles)
let encoder = JSONEncoder()
let data = try encoder.encode(mile)
print(String(data: data, encoding: .utf8)!)
let decoded = try JSONDecoder().decode(Measurement<UnitLength>.self,
                                       from: data)
decoded.converted(to: .fathoms)

The archive looks like this:


Capture Lists

Capture lists are a way of extending lifetime. The capture occurs at the point of declaration so be careful about capturing values. They can also be used to break reference cycles, but they tend to be rare. Try to capture the minimum set of things that you need to. If you are doing MVC, you probably don't need to inject in and capture your services. Instead, you can use a singleton. If you are doing MVVM or others you probably need to use the capture list.

Getting Started

We all agree that is a great course. The prerequisites are OOP, data structures and algorithms but you might be able to fake it even without some of those things.


John demo'ed a cool tool for using symbols that outputs code.


LA Swift Coders has a Slack channel.



Josh had a link for Ray as a follow up on his mandlebrot plot:

John showed a math project manually laying out equations in SwiftUI. Asked if there is another way to do it. Frank suggested MathML which is supported by WKWebView. Others mentioned LaTeX.

Clarissa had a question on her flipping animation. Josh suggested interactively flipping each card as a function of how far a touch has traveled by using the UIView.transform property: and then animating the transform back to .identity when the gesture ends. although Josh just realized that this is wrong and you need the y-axis (uiview only rotates about z) so you have to actually use CALayer's transform instead of the view's transform for this particular animation. For instance:

import PlaygroundSupport
import UIKit

final class V: UIViewController {
  override func viewDidLoad() {
    let square = UIView()
    square.translatesAutoresizingMaskIntoConstraints = false
    square.backgroundColor = .red
      square.centerXAnchor.constraint(equalTo: view.centerXAnchor),
      square.centerYAnchor.constraint(equalTo: view.centerYAnchor),
      square.widthAnchor.constraint(equalToConstant: 100),
      square.heightAnchor.constraint(equalTo: square.widthAnchor)

    let rotation: CABasicAnimation = CABasicAnimation(keyPath: "transform")

    rotation.duration = 5
    rotation.fromValue = CATransform3D()
    rotation.toValue = CATransform3DMakeRotation(.pi, 0, 1, 0)
    square.layer.add(rotation, forKey: "scale")

PlaygroundPage.current.liveView = V()

Intro to Measurement

TimC gave a brief intro to Foundation Measurements in an XCode playground. Asked for help with Apple's broken Custmo Unit example. Josh suggested running in Mac Playgrounds app - showed the true error.

// Brief intro to Measurements
// Creation, Conversion, Custom

import Foundation

// Create a Measurement
var mile = Measurement(value: 1, unit: UnitLength.miles)

// Convert to another unit
var dMiles = mile.converted(to: .meters)
mile.converted(to: .yards)

// Extend UnitLength to include pool-laps conversions:
extension UnitLength {
    static let lap50m = UnitLength(symbol: "laps", converter: UnitConverterLinear(coefficient: 50))
    static let lap50y = UnitLength(symbol: "laps", converter: UnitConverterLinear(coefficient: 45.72))
    static let lap25y = UnitLength(symbol: "laps", converter: UnitConverterLinear(coefficient: 45.72/2))

// How many laps
var lapCount = mile.converted(to: UnitLength.lap50m)

// Make Measurement init less verbose
extension Measurement {
    init(_ v: Double, _ u: UnitType) {
        self.init(value:v, unit:u)

// Swimmers consider 1650 yards or 1500 meters a "mile"
// These distances are shorter than an actual mile
var mileSwimY = Measurement(1650, UnitLength.yards)
var mileSwimM = Measurement(1500, UnitLength.meters)
mileSwimY.converted(to: .miles)
mileSwimM.converted(to: .miles)

// How many laps do you need to swim in different pools?

// 1500 meters in a 50 meter pool (Olympic) -> 30 laps
mileSwimM.converted(to: .lap50m)

// 1500 meters in a 50 yard pool -> ~33 laps
mileSwimM.converted(to: .lap50y)

// 1500 meters in a 25 yard pool -> ~66 laps
mileSwimM.converted(to: .lap25y)

// Actual Mile in a 25 yard pool -> ~71 laps (Tim swims 72 to end where he started)
mile.converted(to: .lap25y)

/* Create a Custom Dimension
 Apple example code for RadioactivityUnits does NOT compile;
    after some updates, it compiles, throws a runtime error.

 class CustomRadioactivityUnit: Dimension {
    //init needs converter: argument name
    static let becquerel = CustomRadioactivityUnit(symbol: "Bq", UnitConverterLinear(coefficient: 1.0))
    static let curie = CustomRadioactivityUnit(symbol: "Ci", UnitConverterLinear(coefficient: 3.7e10))

    static let baseUnit = self.becquerel // replace with "becquerel" to compile

 **THANKS JoshHomann** for suggesting Mac Playgrounds app which shows the run-time error.
 Error: Crashing on exception: *** You must override baseUnit in your class
      Page_Contents.CustomRadioactivityUnit to define its base unit.

 Note -- obviously the static let isn't doing the job, but TimC found below works:

// Working Custom Unit Dimension!
class CustomRadioactivityUnit: Dimension {
    static let becquerel = CustomRadioactivityUnit(
        symbol: "Bq", converter: UnitConverterLinear(coefficient: 1.0))
    static let curie = CustomRadioactivityUnit(
        symbol: "Ci", converter: UnitConverterLinear(coefficient: 3.7e10))
    override class func baseUnit() -> Self {
        becquerel as! Self // expects a *Dimension* as Self

var rads = Measurement(1, CustomRadioactivityUnit.becquerel)
var radsC = rads.converted(to: .curie)

print("Rads=\(rads) -> curie= \(radsC) ")

Intro to @propertyWrappers - JoshH

We looked at the basics of proertyWrappers and their three characteristics: 1) a required wrappedValue, 2) an optional projectedValue 3) an optional init(wrappedValue:). The only thing a propertyWrapper provides is renaming for the wrappedValue (name), the underlying struct (_name) and the projectedValue ($name) it is otherwise entirely equivalent to the unsugared struct, as this playground demonstrates:

import Foundation
import PlaygroundSupport

struct Uppercased {
  private var value: String = ""
  var wrappedValue: String {
    get { value.uppercased() }
    set { value = newValue }
  var projectedValue: String {
  init(wrappedValue: String) {
    self.wrappedValue = wrappedValue

final class Person {
  @Uppercased var name = "josh"
  var name2 = Uppercased(wrappedValue: "peter")
  func output() {
    // name.wrappedValue
    // name
    // name.projectedValue


let p = Person()

Custom DynamicProperty implementations

We looked at Apple's DynamicProperty documentations and noted that the only required function has a default implmenation and that call of the propertyWrappers that implment the protocol are listed at the bottom of the page:

Josh walked through the code for this project on how to build your own custom DynamicProperty. The readme for the project has more details:

We saw the structs in swift cannot be mutated inside of a function that is not flagged as mutating. We further saw that Apple skirts this restriction with @State by using the nonmutating keyword for its setter, and that we can do the same thing an achieve the same behavior by using a reference type to store our variable: the reference never changes, but the pointee can change. If we want to communicate information about the pointee changing, we can use the ObservedObject protocol.



This is a good system to produce animations made by designers.

What are some good SwiftUI starter resources?

Debug session: problem with gestures in a collection view

We did a group debug of Clarissa's code. The tap selector for the tap selector wasn't being called. Josh spoted the problem: the gesture was being added to the cell's root view instead of the contentView. Remember that table view cells and collection view cells have a contentView that you need to add your custom views and gestures to.

Problem with Collection Views in iOS 14.4

Jumping to a particular cell seems to be broken. Mira provided a discussion link:

How do you make an app that uses landscape but only in one view

One way is to make a class derived from UIViewController that is a NonRotatingView and overrides supported orientations. All the views that don't rotate derive from that.

How do you make an enable button and a slider

We used onAppear and onChange to sync state and a binding.

We hit a disable styling problem. Jo mentioned this:


Tricks and tips

John shared Xcode tips from 24 Quick Xcode Tipes article by Paul Hudson

Notable shortcuts:

  • Command-option-control g - Run the last unit test.
  • Command-option / - Automatic doc comment template.
  • Command-control-shift A - Author's view (git blame)

M1 Rumors

Bill is interested in M1 rumors, especially this one about a Mac Mini Pro version in space grey!

SwiftUI Composition

Tim Colson presented strategies for SwiftUI Composition, i.e. breaking views down into components. SwiftUI composition exercises were inspired by strategies from articles/code/videos by Joseph Pacheco and Paul Hudson.

The code-along session style was inspired by Tim's year teaching and David Laing's Grand Unified Theory of Documentation (Divio) which itself decomposes documentation into four types. Intent was a hands-on learning oriented tutorial, applying composition techniques to a task reminders view. (Unfortunately, Zoom sharing + Xcode + (2 x 4K monitors) crippled Tim's 2015 MBP 13" i7/16GB. He needs an M1x MBP 14"!

See Tim's GitHub repo has for links and sample code: -- start with tag v1 git co tags/v1

If interested in working thru the code together, reach out to Tim.

Breakout rooms

We will try this next week.


Xcode Tricks and Tips

Rainer presented a list of tricks and Tips in Xcode and macOS.

  • Click the "jump bar"; then start typing to do a fuzzy match.
  • Command click the jump bar to get an alphabetical listing by scope.
  • Command-option square brackets to move the entire line of text under the cursor up & down. This also works for partially selected lines of text.
  • Define a shortcut in Xcode's key bindings to delete the line under the cursor (or partially selected lines): Command-Backsapce (Pay attention to collisions with system shortcuts ⚠️.
  • Control-left/right arrow to move from captial to capital in CamelCase words
  • Option-left/right arrows to move to word boundaries, command-left/right arrows to go to head and tail of the line. Hold SHIFT to also select. (Works also in all Apple text editors, i.e. TextEdit & Pages)
  • Select text, Command-K to add a URL/web link in Apple text editors.
  • Control-Command left/right arrows to go back & forth in file 'browser' history (Shout-out to Caleb!)
  • Command Shift J reveals where a file is located in the file navigator.
  • Command Shift A exposes actions on a selected piece of text
  • Comment // MARK: - Note creates a note in the jump bar. Also FIXME: and TODO:. The colon makes it show up in the list of jump bar items, and the - makes a horizontal divider line in the menu.
  • Command-option square brackets moves a line or a group of lines up and down.
  • Multi-cursor support: Control-Shift-click or arrow up/down
  • Click the blue 'change' ribbon to see an action menu. Command-click to automatically show/hide the changes

Other tricks:


Frank introduced us to the world of xcconfig files. You can specify these files to use in your build. They handle comments, key values such as:

MY_SETTING = "this is debug mode"

  • You can cut and past from the build configuration of Xcode.
  • It understands include files to support common settings.
  • You can use include? for optional includes used for local configuration not checked into version control.


Ray demo'ed SHA256 hash generation. Using CryptoKit makes it easy.

import UIKit
import CryptoKit

var str = "Hello, playground!"

let data = .utf8)!
let digest = SHA256.hash(data: data)
print(String(describing: digest))

extension Digest {
    var hexString: String {
        map { String(format: "%02x", $0) }.joined()

let d2 = SHA512.hash(data: data)

URL Publishing Chain Revisited

By request, Josh walked us step-by-step thru the Combine URL publishing chain in his TeslaOwnerAPI.swift


Josh presented his Tesla Owner app.

(Note as of 2021.02-13 app is broken due to Tesla changing the authentication process; however, the concepts are still notable!)

FYI - Josh presenting at SwiftLA meetup - Creation of Local Packages

Some high level notes:

  • Uses a Shared URL session
  • Models data quickly with
  • Maps generic Errors to specific server error types
  • Returns

We looked at making a struct to encapsulate the unique information about an endpoint:

struct EndPoint {
  enum HTTPMethod: String {
    case post = "POST", get = "GET"
  enum Parameters {
    case url([String: String]), body(Data)
  var path: String
  var method: HTTPMethod
  var parameters: Parameters? = nil
  var requiresAuthentication = true
  var headers: [String: String] = Self.jsonHeaders


static func getVehicleData(id: Int) -> Self {
    .init(path: "/api/1/vehicles/\(id)/vehicle_data", method: .get)

Noted that Moya is a more robust general solution; however, a lot can be done with plain URLSessions, as Josh expertly demo'd.

We discussed using to code gen conformance to Codable and making server errors Codable:

public struct ErrorMessage: Codable {
  public var message: String
  public enum CodingKeys: String, CodingKey {
    case message = "error"

We discussed the value of strongly typed errors and name shadowing Swift.Error:

  public enum Error: Swift.Error {
    case invalidURL, networkError(Swift.Error), decodingError(Swift.Error), unauthenticated, server(message: String)
    public var message: String {
      switch self {
      case let .server(message): return message
      case let .networkError(error): return error.localizedDescription
      case let .decodingError(error): return error.localizedDescription
      case .invalidURL: return "Invalid URL"
      case .unauthenticated: return "Unauthenticated"
    public var isVehicleUnavailableError: Bool {
      if case let .server(message) = self {
        return message.starts(with: "vehicle unavailable")
      return false

We building a URL request from URLComponents, URLQueryItems and body data:

  private func makeRequest(from endPoint: EndPoint) throws -> URLRequest {
    var components = URLComponents()
    components.scheme = Constant.scheme =
    components.path = endPoint.path
    if case let .url(parameters) = endPoint.parameters {
      components.queryItems = { key, value in
        .init(name: key, value: value)
    guard let url = components.url else {
      throw Error.invalidURL
    var request = URLRequest(url: url)
    request.httpMethod = endPoint.method.rawValue
    endPoint.headers.forEach { key, value in
      request.setValue(value, forHTTPHeaderField: key)
    if case let .body(data) = endPoint.parameters {
      print(String(data: data, encoding: .utf8))
      request.httpBody = data
    return request

We discussed a generic request function:

  private func request<SomeDecodable: Decodable, Output>(
    _ decoded: SomeDecodable.Type,
    from endPoint: EndPoint,
    transform: @escaping (SomeDecodable) -> Output
  ) -> AnyPublisher<Output, Error> {
    guard var request = try? makeRequest(from: endPoint) else {
      return Fail(error: .invalidURL).eraseToAnyPublisher()
    if endPoint.requiresAuthentication {
      guard let token = token?.accessToken else {
        return Fail(error: .unauthenticated).eraseToAnyPublisher()
      EndPoint.authenticatedHeaders(from: token).forEach { key, value in
        request.addValue(value, forHTTPHeaderField: key)
    return URLSession
      .dataTaskPublisher(for: request)
      .handleEvents(receiveOutput: { data in
        print(String(data: data, encoding: .utf8) ?? "")
      }, receiveCompletion: { completion in
        switch completion {
        case .finished: return
        case let .failure(error):
      .decode(type: Either<SomeDecodable, ErrorMessage>.self, decoder: Self.jsonDecoder)
      .map { either -> AnyPublisher<SomeDecodable, Error> in
        switch either {
        case let .left(someDecodable): return Just(someDecodable).setFailureType(to: Error.self).eraseToAnyPublisher()
        case let .right(errorMessage): return Fail(error: Error.server(message: errorMessage.message)).eraseToAnyPublisher()

We discussed :

  • how side effects should be handled by handleEvents
  • errors can be made strongly typed with mapError.
  • using a generic Either enum to decode heterogenous types from our response (either the decodable type we are looking for or a server error):
enum Either<Left, Right> {
  case left(Left), right(Right)

extension Either: Decodable where Left: Decodable, Right: Decodable {
  init(from decoder: Decoder) throws {
    let container = try decoder.singleValueContainer()
    if let value = try? container.decode(Left.self) {
      self = .left(value)
    } else if let value = try? container.decode(Right.self) {
      self = .right(value)
    } else {
      throw DecodingError.typeMismatch(Self.self, DecodingError.Context(codingPath: decoder.codingPath, debugDescription: "Wrong type for \(String(describing:Self.self))"))



Discussed network security and SSL pinning. Potential topic for future meetup. You can try it out:

Swift Fiddle

It let's you play with the Swift compiler (and different versions) online.


We talked about how equality checking for enums do not consider argument labels. The same thing goes for comparison and hash values coming in a future version of Swift when [tuples will become Equatable, Comparable and Hashable[( if all of the element types are Equatable, Comparable and Hashable respectively.

Regarding comparison of floating point, question about zero was raised. IEEE-754 specifies a sign bit so there are multiple representations of zero.

Your Demo Here

If you have a trick or tip and want to show the group, remember to write it down. - - font for terminal and Xcode that includes ligatures for common two-char symbols How to draw bounding boxes with SwiftUI (Medium) - useful for scanning-related project ideas, ex: draw a box around a QR code in a video capture.

Demo SwiftUI Picker

We explored Picker with a simple example.

Names in the app store

Needs to be a real name or company name (LLC, Corporation, etc). Apple doesn't allow DBAs.

Demo Exquisite Corpse

Got a quick demo of a game that Jo is building. And talked about debugging Firebase cloud functions. It is taking minutes to spin up an instance and something seems wrong.


Discussion of Corporate Dev Account vs Personal Account

Be careful of LLC (with a single person) or even a corporation. If you don't do everything to the letter, chances are the corporate veil can be pierced. When you are just starting out, it is probably easiest to use a personal account. While there was agreement that it can be changed later there was some disagreement about how hard it is to do.

Emil's TikTok App Tutorial Recommendation

iCloud sync

What folder should you use to sync with?

  • Library - saved, not directly accessible
  • Document - save, user access
  • Cache - purgeable not directly accessible

Sync is surprisingly hard so it makes sense to use a third party library. Several exist:

Refactoring to Combine

Emily gave us a presentation on Caleb and her experience refactoring to Combine.

  • The code is nicer than nested callbacks.
  • Discussion on weak captures to prevent extension of lifetime (capture self, or just capture exactly what is needed in the callback closure).
  • How can the number of error states be reduced?

Josh reminded us of a previous project that abstracts loading state and error / empty response handling.

Josh also recommends a single access point for doing requests. Link TBD. (Next week?)

Proposal for Visualization Toolkit

The idea is to have a library to allow you to read in a CSV file and then render as a plot.

Can we make something comparable to D3

Tesla Watch App: Modules

Josh showed an in-progress watch app that uses the Tesla API to unlock the car. We will look at it in greater detail in a future meetup.

This week he showed how to factor out watch and iOS code into a common Swift Package Manager module.


We discussed the new asynchronous sequence proposal

We discussed reduce (fold) and its inverse (unfold) sequence

let a = (0..<20).reduce(0, +)

let b = sequence(state: (total: a, counter: 0)) { state -> Int? in
  guard > 0 else { return nil } -= state.counter
  defer { state.counter += 1}
  return state.counter


We then explored the limitations of sequence ie (its inability to remove a element once its been produced) and derived a new unfold operator:

@discardableResult func unfold<State>(into value: State, next: @escaping (inout State) -> State?) -> State {
  var localState = value
  var unfolded = sequence(state: localState) { _ -> State? in
  while != nil { }
  return localState

and we used it to replace an imperative version of reversi:

  private func flipsForAdding(_ targetColor: Piece.Color, at coordinate: Coordinate) -> [Coordinate] {
    guard coordinate.isValidForBoard && board[coordinate].color == nil else { return [] }
    var total = [Coordinate]()
    for offset in Constant.adjacentOffsets {
      var subtotal = [Coordinate]()
      var next = coordinate + offset
      while next.isValidForBoard {
        guard let color = board[next].color else {
        if color == targetColor {
        next = next + offset
      total.append(contentsOf: subtotal)
    return total

with a functional version:

 private func flipsForAdding(_ targetColor: Piece.Color, at coordinate: Coordinate) -> [Coordinate] {
    guard coordinate.isValidForBoard && board[coordinate].color == nil else { return [] }
    return Constant.adjacentOffsets.flatMap { [board] offset -> [Coordinate]  in
      unfold(into: (coordinate: coordinate, accumulated: [Coordinate]())) { [board] state in
        state.coordinate = state.coordinate + offset
        guard state.coordinate.isValidForBoard, let color = board[state.coordinate].color else {
          return nil
        if color == targetColor {
          return nil
        return state

Full project: Reversi


Happy New Year!

Josh created an animated SwiftUI RingChart view that he plans to integrate into the Tides app.




Meeting minutes and learnings from the physical space meeting.



No releases published


No packages published

Contributors 4
