Component graph and text featurizer: preserve user-specified woodwork types by dsherry · Pull Request #2297 · alteryx/evalml

dsherry · 2021-05-21T01:06:52Z

Repro and root cause are on the issue.

There was more to the problem than I had originally thought. In addition to the text featurizer not passing along user-specified woodwork types to the LSA component (which is used inside the text featurizer), our component graph also wasn't preserving custom types during fit. I shored up our unit test coverage of this case a bit.

@freddyaboulton I bet the component graph changes will cause conflicts with your woodwork accessor feature branch. but hopefully they will be minor. I tried to write the tests in a way which meant you could avoid huge conflicts there at least.

dsherry · 2021-05-21T01:10:30Z

evalml/pipelines/component_graph.py

            y (ww.DataColumn, pd.Series): The target training data of length [n_samples]
        """
        X = infer_feature_types(X)
-        X = _convert_woodwork_types_wrapper(X.to_dataframe())


There's no need to convert to pandas here. That's all handled in _compute_features. In fact, calling this here is a bug.

Symptom: calls to pipeline fit always use whatever types woodwork infers for all the columns, overriding all user-specified values.

Explanation: the first thing we do in _compute_features is call X = infer_feature_types(X). So, by converting to pandas here and then immediately converting back to woodwork first thing in _compute_features, we were effectively resetting the input to whatever woodwork infers by default.

@dsherry this is very interesting and I wonder if it's part of what I was seeing in my investigation with Chris.

dsherry · 2021-05-21T01:18:58Z

evalml/pipelines/components/transformers/preprocessing/text_featurizer.py

            X_nlp_primitives.fillna(0, inplace=True)

-        X_lsa = self._lsa.transform(X[self._text_columns]).to_dataframe()
+        X_lsa = self._lsa.transform(X_ww[self._text_columns]).to_dataframe()


This was the first fix required for this bug. We need to pass the woodwork type info to the LSA component, otherwise it will run woodwork inference again from scratch and the newly reset types will be used by all the downstream components!

dsherry · 2021-05-21T01:19:21Z

evalml/tests/pipeline_tests/test_component_graph.py

-    X = pd.DataFrame({'column_1': ['a', 'b', 'c', 'd', 'a', 'a', 'b', 'c', 'b'],
-                      'column_2': [1, 2, 3, 4, 5, 6, 5, 4, 3]})
+    X = pd.DataFrame({'column_1': ['a', 'a', 'a', 'b', 'b', 'b', 'c', 'c', 'd'],
+                      'column_2': [1, 2, 3, 3, 4, 4, 5, 5, 6]})


No functional change, just reordered to make this test easier to understand

dsherry · 2021-05-21T01:23:27Z

evalml/tests/pipeline_tests/test_component_graph.py

-                                                    'column_2_1', 'column_2_2', 'column_2_3', 'column_2_4', 'column_2_5', 'column_2_6']
-    assert input_feature_names['Elastic Net'] == ['column_3', 'column_1_a', 'column_1_b', 'column_1_c', 'column_1_d',
-                                                  'column_2_1', 'column_2_2', 'column_2_3', 'column_2_4', 'column_2_5', 'column_2_6']
+    assert input_feature_names['Text'] == ['column_3', 'column_5', 'column_1_a', 'column_1_b', 'column_1_c', 'column_1_d',


Woodwork would infer the data in "column_5" to be datetime, but I set it to natural language above. We check here that it passes through the datetime featurizer untouched and enters the text featurizer. On the next assert, we check that it gets transformed into natural language features.

dsherry · 2021-05-21T01:31:51Z

evalml/tests/pipeline_tests/test_component_graph.py

+    X['column_4'] = [str((datetime(2021, 5, 21, 12, 0, 0) + timedelta(minutes=5 * x))) for x in range(len(X))]
+    X['column_5'] = X['column_4']
    y = pd.Series([1, 0, 1, 0, 1, 1, 0, 0, 0])
-    X = infer_feature_types(X, {"column_2": "categorical"})


The confusing thing about this test is that it was passing before my changes. That's weird because here we set an integer column "column_2" to have categorical type, and saw that as expected one-hot encoded features based off of "column_2" show up in the datetime component's input.

dsherry · 2021-05-21T01:36:35Z

evalml/tests/pipeline_tests/test_component_graph.py

    y = pd.Series(y)
    graph = {'Imputer': [Imputer], 'OHE': [OneHotEncoder, 'Imputer.x', 'Imputer.y']}
-    expected_x = ww.DataTable(pd.DataFrame(index=X.index, columns=X.index).fillna(1))
+    expected_x = ww.DataTable(pd.DataFrame(index=X.index, columns=X.columns).fillna(1))


This isn't a "bug" per se, but the imputer will return one column for each input column, not more which is what this was doing

dsherry · 2021-05-21T01:37:52Z

evalml/tests/pipeline_tests/test_component_graph.py

    component_graph = ComponentGraph(graph).instantiate({})
    component_graph.fit(X, y)
-    expected_x_df = expected_x.to_dataframe().astype("Int64")
+    expected_x_df = expected_x.to_dataframe().astype("float64")


If you look at X_y_binary, all 20 columns in X have type float64.

dsherry · 2021-05-21T02:07:15Z

evalml/pipelines/component_graph.py

        if y_input is not None:
            return_y = y_input
-        return_x = infer_feature_types(return_x)
+        return_x = _retain_custom_types_and_initalize_woodwork(X, return_x)


This method _consolidate_inputs currently only gets called inside _compute_features. If you look at the call site, you'll see the x_inputs is always a list of pandas dataframes. Therefore, after concatenating those pandas dataframes representing input features from the parent components in the graph, we need to call _retain_custom_types_and_initalize_woodwork to preserve any columns which appeared in the original woodwork input.

I added test_component_graph_types_multi_input_1 and test_component_graph_types_multi_input_2 to check this is working properly. Both fail without this change.

I think the limitation we still face is that the types that are specified during the pipeline evaluation are not necessarily preserved. Only the types that are specified before pipeline evaluation. We don't make much use of this yet but we may want to do so in the future (one thing that comes to mind is preserving semantic tags). I was initially worried about how the OHE sets boolean types but we're ok for now because there's a one-to-one mapping between the boolean physical type and the boolean logical type so the inference will always work out in our favor.

I don't think this should block your pr because I'm not sure there's a way to prevent this from happening until alteryx/woodwork#884 is released but just want to call out we're still not 100% there.

from evalml.pipelines.components import Transformer from evalml.pipelines import RegressionPipeline from evalml.utils import infer_feature_types, _retain_custom_types_and_initalize_woodwork import woodwork as ww import pandas as pd import pytest class ZipCodeExtractor(Transformer): name = "Zip Code Extractor" def fit(self, X, y): return self def transform(self, X, y): X = infer_feature_types(X) X = X.select(["address"]) X_df = X.to_dataframe() X_df['zip_code'] = pd.Series(["02101", "02139", "02152"]) X_df.drop(columns=X.columns, inplace=True) new_X = _retain_custom_types_and_initalize_woodwork(X, X_df) new_X = new_X.set_types({'zip_code': "ZipCode"}) return new_X class ZipCodeToAveragePrice(Transformer): name = "Check Zip Code Preserved" def fit(self, X, y): return self def transform(self, X, y): X = infer_feature_types(X) X = X.select(["ZipCode"]) assert len(X.columns) > 0, "No Zip Code!" X_df = X.to_dataframe() X_df['average_apartment_price'] = pd.Series([1000, 2000, 3000]) new_X = _retain_custom_types_and_initalize_woodwork(X, X_df) return new_X X = pd.DataFrame({"postal_address": ["address-1", "address-2", "address-3"]}) X = ww.DataTable(X, semantic_tags={"postal_address": ['address']}) y = pd.Series([1500, 2500, 35000]) apartment_price_predictor = RegressionPipeline([ZipCodeExtractor, ZipCodeToAveragePrice, "Random Forest Regressor"]) with pytest.raises(AssertionError, match="No Zip Code!"): apartment_price_predictor.fit(X, y)

Thanks for this @freddyaboulton . I'll try to file something for this before we merge this PR. Its a great point, and yep something we'll run into eventually.

dsherry · 2021-05-21T02:26:48Z

evalml/pipelines/component_graph.py

        """
        X = infer_feature_types(X)
-        X = _convert_woodwork_types_wrapper(X.to_dataframe())
+        y = infer_feature_types(y)


This, and the similar change in _compute_features are important. Otherwise, if the input provided to fit is not a woodwork structure, fit will fail!

dsherry · 2021-05-21T02:27:46Z

evalml/pipelines/component_graph.py

        """
        if len(x_inputs) == 0:
-            return_x = X
+            return_x = X.to_dataframe()


Since we're now expecting _compute_features will be normalizing input to woodwork up the stack, we need to convert to pandas here. You can see that this X input is guaranteed to be woodwork by the code in _compute_features.

Ah, woodwork conversions

Haha yep. This is necessary because there's no concatenate feature in woodwork 0.0.11. I'm pretty sure this is handled on @freddyaboulton 's accessor feature branch

Yep, in the ww update branch we just do return_x = X hehe but fyi there still isn't a concatenate feature in ww

codecov · 2021-05-21T02:28:39Z

Codecov Report

Merging #2297 (7fdae8a) into main (a318afa) will increase coverage by 10.5%.
The diff coverage is 100.0%.

@@           Coverage Diff            @@
##            main   #2297      +/-   ##
========================================
+ Coverage   89.4%   99.9%   +10.5%
========================================
  Files        281     281
  Lines      24671   24760      +89
========================================
+ Hits       22054   24731    +2677
+ Misses      2617      29    -2588

Impacted Files	Coverage Δ
...del_understanding_tests/test_partial_dependence.py	`100.0% <ø> (+42.8%)`	⬆️
evalml/pipelines/component_graph.py	`100.0% <100.0%> (+5.6%)`	⬆️
...ents/transformers/preprocessing/text_featurizer.py	`100.0% <100.0%> (ø)`
evalml/tests/automl_tests/test_dask_engine.py	`100.0% <100.0%> (ø)`
...alml/tests/component_tests/test_text_featurizer.py	`100.0% <100.0%> (ø)`
...valml/tests/pipeline_tests/test_component_graph.py	`100.0% <100.0%> (+3.5%)`	⬆️
evalml/automl/automl_search.py	`99.9% <0.0%> (+0.2%)`	⬆️
evalml/tests/utils_tests/test_logger.py	`100.0% <0.0%> (+0.6%)`	⬆️
evalml/pipelines/utils.py	`100.0% <0.0%> (+1.0%)`	⬆️
evalml/tests/conftest.py	`100.0% <0.0%> (+1.1%)`	⬆️
... and 46 more

Continue to review full report at Codecov.

Legend - Click here to learn more
Δ = absolute <relative> (impact), ø = not affected, ? = missing data
Powered by Codecov. Last update a318afa...7fdae8a. Read the comment docs.

dsherry · 2021-05-21T13:50:19Z

evalml/tests/automl_tests/test_dask_engine.py

        assert all([s._is_fitted for s in par_pipelines])

        # Ensure the scores in parallel and sequence are same
-        assert set(par_scores) == set(seq_scores)


This test was flaking on me in the 17th decimal place, but only for linux/windows python 3.8 😆 not sure why exactly this PR would trigger that.

chukarsten · 2021-05-21T14:31:23Z

evalml/pipelines/component_graph.py

        """
        if len(x_inputs) == 0:
-            return_x = X
+            return_x = X.to_dataframe()


Ah, woodwork conversions

evalml/tests/component_tests/test_text_featurizer.py

evalml/tests/pipeline_tests/test_component_graph.py

dsherry · 2021-05-24T14:37:09Z

For those following along, this is still ready for review, but I'm waiting for #2181 to merge (woodwork accessor), then I'll rebase this and get it in.

bchen1116

Nice! The tests look pretty thorough!

freddyaboulton · 2021-06-03T22:30:58Z

evalml/tests/model_understanding_tests/test_partial_dependence.py

-        0.1666874487986626: 1,
-        0.13357573073236878: 1,
-        0.06778096366056789: 1,
+        0.19149451286750388: 154,


I had posted a previous comment explaining why this change is necessary but it got wiped from the diff view with the black pr.

In summary, since we're preserving types we were previously not preserving (bool/int) the predicted probabilities are different which means the partial dependence is different.

Disregard this and the previous comment! This was actually a symptom of a bug hehe

freddyaboulton · 2021-06-04T15:32:47Z

Perf tests here

Our linear estimators are doing worse so I think we should hold off on merging until we know why.

freddyaboulton · 2021-06-04T19:42:44Z

evalml/pipelines/component_graph.py

+        # Because of that, the for-loop below is sufficient.
+
+        logical_types = {}
+        logical_types.update(X.ww.logical_types)


Before we would do this before the for-loop which was causing the performance regression in linear estimators

freddyaboulton · 2021-06-04T19:43:48Z

evalml/tests/pipeline_tests/test_component_graph.py

+        ["column_2", "column_1_a", "column_1_b", "column_1_c", "column_1_d", "column_3"]
+    )
+    assert mock_rf_fit.call_args[0][0].ww.logical_types["column_3"] == Integer
+    assert mock_rf_fit.call_args[0][0].ww.logical_types["column_2"] == Double


Adding this to make sure we don't overwrite the types created by the standard scaler.

freddyaboulton · 2021-06-04T20:53:05Z

I've updated the performance tests here!

I was able to trace the issue to a bug where we were overriding the types set by the standard scaler. I updated the implementation so this should be good for review now!

freddyaboulton · 2021-06-04T20:54:43Z

@dsherry I can't add you as a reviewer 😂 But your feedback would be appreciated!

dsherry

@freddyaboulton well done on this! Tricky stuff, particularly those scaler types. The tests look comprehensive. GH isn't letting me "approve" because I am still listed as the PR author, haha. But let's do it! ✅

dsherry · 2021-06-04T21:55:30Z

evalml/pipelines/component_graph.py

+        # update them with the types created by components (if they are different).
+        # Components are not expected to create features with the same names
+        # so the only possible clash is between the types selected by the user and the types selected by a component.
+        # Because of that, the for-loop below is sufficient.


@freddyaboulton thanks for this comment, I think its warranted given the complexity of preserving types here.

I wonder if woodwork could help manage this for us. I guess adding a concatenate ability would do it.

@dsherry I think you're right that ww.concat would definitely make this easier! Looks like it'll be in the next release so I'm really excited to try it out!

alteryx/woodwork#932

dsherry · 2021-06-04T22:09:25Z

evalml/pipelines/components/transformers/preprocessing/text_featurizer.py

-
-        X_lsa = self._lsa.transform(X_ww[self._text_columns])
        X_nlp_primitives.set_index(X_ww.index, inplace=True)
+        X_lsa = self._lsa.transform(X_ww.ww[self._text_columns])


Does this change matter? Or could we back it out?

Ohhhh. @freddyaboulton explained offline. Woodwork schema won't be copied by default pandas indexing operator, have to use woodwork namespace. Thanks @freddyaboulton !

dsherry · 2021-06-04T22:10:17Z

evalml/tests/component_tests/test_text_featurizer.py

+        "LSA(col_1)[0]": Double,
+        "LSA(col_1)[1]": Double,
+    }
+    assert X_t.ww.logical_types == expected_logical_types


This is great.

dsherry · 2021-06-04T22:12:33Z

evalml/tests/pipeline_tests/test_component_graph.py

+    check_feature_names(component_graph.input_feature_names)
+    component_graph.input_feature_names = {}
+    component_graph.predict(X)
+    check_feature_names(component_graph.input_feature_names)


Wow, good call adding this, pretty slick. I forgot that predict would set input_feature_names, because I guess it always gets set in fit first.
