datepicker memory leak #17896

rudzikdawid · 2019-12-07T17:21:16Z

Reproduction

Steps to reproduce:

go to https://material.angular.io/components/datepicker/examples
open datepicker and close multiple times
each open and close action generate 135KB memory leak.

The more times we open and close datepicker, the more memory are allocated.
Garbage collector does not clear all allocated memory.

Expected Behavior

datepicker without memory leaks

Actual Behavior

memory leaks

Environment

Angular: 8.2.14, 9.0.0-rc.5
CDK/Material: 8.2.3, 9.0.0-rc.5
Browser(s): Chrome 78.0.3904.108
Operating System: Fedora 31

rudzikdawid · 2019-12-08T21:36:12Z

related issue: angular/angular#25744

it looks like the biggest leak comes from @angular/animations module
after remove matDatepickerAnimations and rest of "animations" code from datepicker
each open and close action generate only 1.3KB of memory leak.

crisbeto · 2019-12-16T20:58:23Z

The animations leak is fixed by angular/angular#34409.

jelbourn · 2019-12-17T01:45:32Z

Closing since this was caused by the framework and because the fix has been merged there.

rudzikdawid · 2019-12-27T23:56:53Z

it's look like the memory leak still exists.
I built and launched dev-app from 9.0.0-rc.6 tag.
inside DOM the dev-app element has attibute ng-version="9.0.0-rc.7"
Also inside animations-browser.umd.js i see changes from fix angular/angular#34409.
So theoretically fix should work, but still each open and close action generate 130KB memory leak.

crisbeto · 2019-12-28T08:03:53Z

I can see the memory leak as well so the root cause probably wasn't angular/angular#34409. I spent some more time looking into it and I'm not sure exactly why it's happening, but here are some observations:

It only happens for datepickers in popup mode. There's still a smaller leak in dialog mode, but it only ends up leaking one datepicker worth of elements and it doesn't stack up like the current leak.
It seems to happen, because in popup mode we detach the overlay and we only dispose of it on destroy, but by that time the elements have leaked out already. If I switch to disposing it on every close, it starts behaving like dialog mode, but this isn't ideal because it breaks the closing animation.
The leak seems to be due to the fact that we remove the DOM nodes once the animation has finished here. If I switch it to remove the element immediately, it stops leaking. This is confusing, because I can verify that the callback always fires at the proper time and the elements do get cleaned up. There might be something further down the line that expects the elements to have been removed immediately.

Fixes the datepicker leaking memory when it is opened and closed in popup mode. The leak seems to come from the fact that we're detaching, rather than disposing of, the overlay when it is closed. We did this in the past to support an animation while closing the calendar, but it seems to cause the animations engine further down the line to retain the elements memory since they aren't being removed immediately. These changes resolve the issue by triggering the exit animation, waiting for it to finish and disposing of the overlay. We weren't gaining too much by reusing the overlay from the previous approach, because the calendar was being removed and re-created every time anyway. Fixes angular#17896.

Fixes the datepicker leaking memory when it is opened and closed in popup mode. The leak seems to come from the fact that we're detaching, rather than disposing of, the overlay when it is closed. We did this in the past to support an animation while closing the calendar, but it seems to cause the animations engine further down the line to retain the elements memory since they aren't being removed immediately. These changes resolve the issue by triggering the exit animation, waiting for it to finish and disposing of the overlay. We weren't gaining too much by reusing the overlay from the previous approach, because the calendar was being removed and re-created every time anyway. Fixes #17896.

Fixes the datepicker leaking memory when it is opened and closed in popup mode. The leak seems to come from the fact that we're detaching, rather than disposing of, the overlay when it is closed. We did this in the past to support an animation while closing the calendar, but it seems to cause the animations engine further down the line to retain the elements memory since they aren't being removed immediately. These changes resolve the issue by triggering the exit animation, waiting for it to finish and disposing of the overlay. We weren't gaining too much by reusing the overlay from the previous approach, because the calendar was being removed and re-created every time anyway. Fixes angular#17896.

Fixes the datepicker leaking memory when it is opened and closed in popup mode. The leak seems to come from the fact that we're detaching, rather than disposing of, the overlay when it is closed. We did this in the past to support an animation while closing the calendar, but it seems to cause the animations engine further down the line to retain the elements memory since they aren't being removed immediately. These changes resolve the issue by triggering the exit animation, waiting for it to finish and disposing of the overlay. We weren't gaining too much by reusing the overlay from the previous approach, because the calendar was being removed and re-created every time anyway. Fixes #17896.

rudzikdawid · 2020-01-17T09:07:35Z

bad news: memory leak is a little bit smaller (120KB instead 130KB) but still exists.
I built and launched dev-app from 9.0.0-rc.8 tag.
Devtools Source panel, inside /src/material/datepicker/datepicker.js i see changes from #18102.

But still each open and close action generate ~120KB memory leak.

crisbeto · 2020-01-17T09:31:53Z

The 40x leak is what I was referring to above when I said "There's still a smaller leak in dialog mode", but do you see the HTMLTableCell count increase if you keep opening and closing it? That's the part that my fix addressed.

rudzikdawid · 2020-01-17T19:48:15Z

even if the leak comes from the dialog, calling it "small" is a lot of abuse.
This issue should be closed after the leak has been repaired.

crisbeto · 2020-01-17T19:50:26Z

It's not small, but it's smaller since it doesn't leak for every open. I haven't been able to track down exactly where the other leak comes from, but it looks like it could be from the framework.

Fixes the datepicker leaking memory when it is opened and closed in popup mode. The leak seems to come from the fact that we're detaching, rather than disposing of, the overlay when it is closed. We did this in the past to support an animation while closing the calendar, but it seems to cause the animations engine further down the line to retain the elements memory since they aren't being removed immediately. These changes resolve the issue by triggering the exit animation, waiting for it to finish and disposing of the overlay. We weren't gaining too much by reusing the overlay from the previous approach, because the calendar was being removed and re-created every time anyway. Fixes angular#17896.

rudzikdawid · 2020-02-05T21:25:57Z

it looks like it's getting worse with every version of angular and components.

Angular 7.1.4
Components 7.3.7
Leak: 11.8 KB

Angular 8.2.10
Components 8.2.3
Leak: 59.5 KB

Angular 9.0.0-rc.13
Components 9.0.0-rc.9
Leak: 122 KB

manklu · 2020-02-05T23:16:32Z

This may be part of the leak angular/angular#35148

jelbourn · 2020-02-06T01:30:24Z

I would also suspect something in the framework, since we haven't made any major changes to overlays or datepicker lately.

rudzikdawid · 2020-02-19T21:37:48Z

angular@9.0.2 provides significant improvement in memory profile

rudzikdawid · 2020-02-24T21:50:50Z

@angular/material 9.1.0solve memory leak in datepicker component

angular-automatic-lock-bot · 2020-03-26T00:02:37Z

This issue has been automatically locked due to inactivity.
Please file a new issue if you are encountering a similar or related problem.

Read more about our automatic conversation locking policy.

_{This action has been performed automatically by a bot.}

Splaktar added P1 Impacts a large percentage of users; if a workaround exists it is partial or overly painful animation This issue is related to Angular animations or CSS animations perf This issue is related to performance labels Dec 13, 2019

Splaktar assigned mmalerba Dec 13, 2019

jelbourn closed this as completed Dec 17, 2019

mmalerba reopened this Dec 28, 2019

crisbeto self-assigned this Jan 4, 2020

crisbeto added has pr P2 The issue is important to a large percentage of users, with a workaround and removed P1 Impacts a large percentage of users; if a workaround exists it is partial or overly painful labels Jan 4, 2020

crisbeto mentioned this issue Jan 4, 2020

fix(datepicker): memory leak in popup mode #18102

Merged

mmalerba closed this as completed in #18102 Jan 10, 2020

crisbeto reopened this Jan 17, 2020

rudzikdawid closed this as completed Feb 24, 2020
