Nibbler

nibbler

Parse MIDI Messages

Install

gem install midi-nibbler

or using Bundler, add this to your Gemfile

gem "midi-nibbler"

Usage

require 'nibbler'

nibbler = Nibbler.new

Enter a message piece by piece

nibbler.parse("90")
  => nil

nibbler.parse("40")
  => nil

nibbler.parse("40")
  => #<MIDIMessage::NoteOn:0x98c9818
       @channel=0,
       @data=[64, 100],
       @name="C3",
       @note=64,
       @status=[9, 0],
       @velocity=100,
       @verbose_name="Note On: C3">

Enter a message all at once

nibbler.parse("904040")

  => #<MIDIMessage::NoteOn:0x98c9818
        @channel=0,
        @data=[64, 100],
        @name="C3",
        @note=64,
        @status=[9, 0],
        @velocity=100,
        @verbose_name="Note On: C3">

Use bytes

nibbler.parse(0x90, 0x40, 0x40)
  => #<MIDIMessage::NoteOn:0x98c9818 ...>

You can use nibbles in string format

nibbler.parse("9", "0", "4", "0", "4", "0")
  => #<MIDIMessage::NoteOn:0x98c9818 ...>

Interchange the different types

nibbler.parse("9", "0", 0x40, 64)
  => #<MIDIMessage::NoteOn:0x98c9818 ...>

Use running status

nibbler.parse(0x40, 64)
  => #<MIDIMessage::NoteOn:0x98c9818 ...>

Look at the messages we've parsed

nibbler.messages
  => [#<MIDIMessage::NoteOn:0x98c9804 ...>
      #<MIDIMessage::NoteOn:0x98c9811 ...>]

Add an incomplete message

nibbler.parse("9")
nibbler.parse("40")

See progress

nibbler.buffer
  => ["9", "4", "0"]

nibbler.buffer_s
  => "940"

Pass in a timestamp

nibbler.parse("904040", :timestamp => Time.now.to_i)
  => { :messages=> #<MIDIMessage::NoteOn:0x92f4564 ..>, :timestamp=>1304488440 }

Nibbler defaults to generate midi-message objects, but it is also possible to use midilib

Nibbler.new(:message_lib => :midilib)

nibbler.parse("9", "0", 0x40, "40")
  => "0: ch 00 on 40 40"

Also see

  • midi-eye, a MIDI event listener based on nibbler

Author

License

Apache 2.0, See the file LICENSE

Copyright (c) 2011-2015 Ari Russo
