This document contains developer documentation for BioImage Suite Web. Follow this link for the end-user documentation/manual.

A web page version (as opposed to browsing the source) of this page can be found at this link.


Introduction

BioImage Suite Web (BisWeb) is a web-based medical image analysis tool geared towards processing neural images. We gratefully acknowledge support from the NIH Brain Initiative under grant R24 MH114805 (Papademetris X. and Scheinost D. PIs). A good overview of the software can be found in slides from a presentation at the 2018 NIH Brain Initiative Meeting, which was the first public introduction of the software.

The architecture of BioImage Suite Web is shown below:

BioImage Suite Web Software Architecture

BioImage Suite Web uses a mixture of JavaScript for the user interfaces and C++ for the image processing with optional Python and Matlab wrappers. Additional information about aspects of the software can be found in other files in this directory, such as:

  • Some background material on why JavaScript is the primary language for Biomage Suite Web in WhyJS.md.
  • Aspects of JavaScript that are particularly relevant to the project in AspectsofJS.md.
  • How to program using the base BioImage Suite Web Libraries in JS in BisWebJS.md.
  • The interface from JavaScript to WebAssembly in JStoWASM.md.
  • Using the base BioImage Suite Web libraries from Python in BisWebPython.md.
  • Using the base BioImage Suite Web libraries from Matlab inBisWebMatlab.md. This code is primitive compared to the rest of the code base and more importantly is unsupported. Use at your own risk!
  • Descriptions of the module architecture in two separate documents
  • Details about how the Electron desktop applications are constructed in DesktopAppsWithElectron.md.

Setting up your Development Environment

The goal of this section is to help the reader set up a proper software development environment. BioImage Suite Web uses the following tools:

  • Git : A popular version control system.
  • Node.js : The command line JavaScript interpreter. Packaged with npm which is the package manager that comes with node.js.
  • Gulp: An automation tool designed to ease JavaScript build tasks.
  • webpack: A packaging tool that enables Node.js style modules in browser applications.
  • Mocha: A scripting library designed to automate regression testing.
  • JSHint: "A tool that helps to detect errors and potential problems in your JavaScript code" (from the webpage).
  • JSDoc: A parsing tool that generates documentation from comments in code.
  • Electron: A tool that uses the HTML/CSS/JS that makes up a webpage to create a desktop application.

Editing code also requires a text editor. Users with no prior experience may want to try Microsoft's Visual Code editor. Sublime and Atom are also fine choices. Emacs or Vim may be considered for the truly dedicated/crazy, but users of such esoterica tend to know who they are already.

More information about each of these tools may be found in the links contained in this section.

Aside: If you are using Microsoft Windows

The instructions in this documents are primarily for Linux (Ubuntu) and secondarily MacOS. These are Unix-y operating systems with a common set of commandline tools and package managers which make life a little easier.

If you are developing on a Windows machine, it is strongly recommended to compile/build BioImage Suite Web using the Ubuntu distribution available from the Windows Store as of 2016. This is part of the Windows Subsystem for Linux (WSL) and will simplify your life immensely. See also https://github.com/QMonkey/wsl-tutorial and also the section Microsoft Windows and WSL at the end of the document for more details.


Installing Git

Git may already be installed on Linux and Mac. which git will return the path for Git if it is installed, or an error message otherwise. For MS-Windows please see this page. This will also install a bash command line shell which can be used in the same way as a standard bash shell (the shell that ships with MacOS and Linux).

To test that git is correctly installed type:

git --version

If it returns a descriptive answer (e.g. git version ...) then Git is properly installed.

Installing Node.js

It it recommended the install the latest version of Node.js from the Node.js webpage (download the latest stable version which should be 8.9.x or newer). The node and npm binary may need to be added to PATH.

To test a correct installation type

node -v

If it returns a descriptive answer, e.g. v8.9.0, then Node is correctly installed.

Setting up

Once both Git and Node are set up, install the rest of the tools as follows: on MacOS or Linux open a terminal and type

sudo npm install -g gulp mocha jsdoc jshint webpack webpack-cli uglify-es eslint

or on Windows type

npm install -g gulp mocha jsdoc jshint webpack webpack-cli uglify-es

This will install the core tools. Please note that the '-g' flag stands for 'global', which means these modules are installed in the global package directory (e.g. /usr/local/node_modules) instead of the local package directory. If there is an error or the server times out, simply re-run the same command until it is complete.

Next install Electron and its associated tools. As of April 2018 there is bug in the electron installer which requires a more complex command:

 sudo npm install -g electron --unsafe-perm=true --allow-root
 sudo npm install -g electron-packager

The JS development environment is now complete.

Building and Running BioImage Suite Web

BioImage Suite Web is currently compiled/packaged in directories inside the source tree. The contents are as follows:

  • node_modules — The location of dependent node_modules. This will be populated by npm.

  • build — The core build directory.

    • build/wasm — The build directory for the WebAssembly code. You can move this out if your prefer; however, the key output files will be redirected to the build directory so that webpack can find them.
    • build/dist — The output directory for .zip files or packaged Electron applications.
    • build/cpp — (optional) This is where the native libraries for accessing the C++ code from Python and Matlab will be built.
    • build/web — The output directory for creating the final web-applications and associated .css, .html files etc.
  • compiletools — Scripts and configuration files to help with compiling.

  • config — Configuration files for webpack, JSDoc etc.

  • cpp — C++ code.

  • doc — Directory containing this and other documentation files.

  • js — Directory containing all js code

  • lib — Directory containing js external libraries and some css/html that are either not distributed via npm or are customized in some way.

  • matlab — Directory containing the primitive Matlab wrapper code.

  • python — Directory containing the Python code.

  • test — Directory containing the regression tests and data.

  • various — Miscellaneous files.

    • various/download — Versions of Emscripten (this is a skeleton version) and Eigen for installation.
    • various/wasm — Pre-built version of the Wasm-related JS files to expedite getting started. These can be copied to build/wasm to eliminate the need to compile C++ to Web Assembly. These are updated periodically though so to use up-to-date code they will have to be recompiled.
    • various/config — Configuration files for Emacs, Bash and Visual Studio Code that may be useful.
  • web — The directory containing the .html /.css files for the web and desktop applications. This also contains the configuration files for Electron desktop applications.

In addition there are two key files that live in the main directory

  • package.json — The package description file for npm that lists the dependencies of our software. Generates a companion file, package-lock.json
  • gulpfile.js — The configuration file for Gulp.

Getting the BioImage Suite Web code

First create an empty director. Avoid paths that have spaces in them; a folder named 'bisweb' or something similar in the home directory will work well.

cd ~
mkdir bisweb
git clone https://github.com/bioimagesuiteweb/bisweb bisweb

The source code for the project may be found on Github.


Building the JS Code

Assuming the steps above, the BioImageSuite Web code should be inside a folder named bisweb. This will be used as the name of the root directory for the project, but you can name it whatever you'd like so long as you're consistent.

cd bisweb

Note the presence of package.json. This contains references to the dependencies required by BioImageSuite Web. Ensure that these are up to date by typing:

npm update

or, for more verbose output:

npm update -d

Note: Dependencies may change over time. If Bisweb does not perform as expected try checking if there are updates to the dependencies.

To create the WebAssembly binaries and build folder structure from the source files, see createbuild.sh (instructions can be found in Installing Emscripten and Eigen and Configuring your Build Directories). Otherwise, Bisweb comes with a prebaked version of the wasm binaries:

chmod +x config/createjsbuild.sh
./config/createjsbuild.sh

This will create three directories, build/web, build/wasm, and build/dist and copy the wasm binary in various/wasm to the build folders. This will perform the same function as making the WebAssembly binaries from the C++ code, though the prebaked binaries may not be fully up-to-date in every version of the software.

Important: The build tools (Gulp, webpack, etc.) will look for the files in exactly these locations, so moving them elsewhere may cause build steps to fail. The curious may want to look at the configuration files config/webpack_config.js, config/app_config.js and config/bisweb_pathconfig.js.

The last step is to build the entire application:

gulp build

This will copy core files to build/web, the destination for the both the web and Electron builds.

Open the Web Applications

To do this type:

gulp serve

This does three things:

  • It creates a light-weight web server.
  • It runs JSHint that performs syntax checking on all the JS files
  • It runs webpack which packages all the .js files into a single web-compatible JS output

Open a web-browser and go to http://localhost:8080/web. If it all works the main screen should pop up.

Note: The observant reader may notice that the .html files live in the web directory. Executing gulp build modifies these and places them in build/web for eventual distribution/packaging. This does some re-writing of the HTML header to change paths etc.

Running Regression Tests

The regression tests should function by this point. These should be executed to test proper integration of the WebAssembly code. To do so, type:

mocha test

This will take a few minutes to finish. The results will be stored in .js files under tests. If not all tests are reported as successful, there may be a problem with the WebAssembly code.

At this point the JS-development directory should be fully functional.


Building the C++ Code as a WebAssembly Library

The previous sections used prebaked versions of the WebAssembly binaries. This section will describe how to build this final part of the software, the C++/WebAssembly binaries. These instructions are for Unix-style operating systems, e.g. Linux, MacOS and the WSL version of Ubuntu Linux that can be installed from the MS-Windows Store.

This process requires three tools:

  • CMake : The cross-platform make tool originally created for the needs of the Insight Toolkit (ITK).
  • Emscripten: A project from Mozilla that can be used to compile C++ to WebAssembly
  • Eigen : A numerical linear algebra library. This is the only external library used by BioImage Suite Web.

Installing CMake

Ubuntu/Debian

Ubuntu and Debian support CMake through their built-in package manager, apt. Enter the following:

sudo apt-get install cmake cmake-curses-gui

MacOS

On MacOS install CMake from their website and then from the GUI follow the instructions under Tools | How to Install for CommandLine Use to install it for command line use. The easiest option is propabably to create symbolic links in /usr/local as follows:

sudo "/Applications/CMake.app/Contents/bin/cmake-gui" --install

Installing Python v3.5 or later

Emscripten needs a modern version of Python, i.e. v3.5 or later, and will fail to install without one.

On Ubuntu type:

sudo apt-get install python3

MacOS has its own package manager, brew, that maintains versions of Python. If brew is installed, the latest version of python can be installed using:

brew install python3

Ensure that python3 is in your path. If it is, then

which python3

should return a response that looks like /usr/bin/python3 or /usr/local/bin/python3.

Python Packages

Please install the packages numpy and nibabel using the pip package manager as follows:

sudo pip3 install numpy nibabel

These are used by the Python regression tests.

Installing Emscripten and Eigen and Configuring your Build Directories

The C++ BisWeb code has a single external library dependency — Eigen. We also need to install Emscripten to compile the C++ code to Web Assembly. Both the installation of these tools and the creation of the correct development directories is automated using the createbuild.sh script from the config directory as follows:

First go to your source directory

cd SOURCE_DIR

Ensure createbuild.sh is executable

chmod +x config/createbuild.sh

Run the script:

./config/createbuild.sh

This will install Eigen v3, the latest cut of Emscripten and then create the build directories and a bunch of scripts all inside a directory called build in your source tree. For the curious, a detailed description of createbuild can be found at the end of this document.

Configuring and Building

This requires some understanding of CMake. There is lots of info online on this.

You will need to run cmake to configure the project as a "cross-compiled" application. The easiest way to do this (if you follow our instructions completely) is as follows:

cd build
source setpaths.sh
cd wasm

Note: You should always source setpaths.sh before any make/cmake operations in the future as well.

Then to accept all defaults type

../cmake.sh .

Note: If you would like to customize things replace cmake.sh with ccmake.sh. to use the ccame GUI version of cmake. The core settings are

  • BIS_A_EMSCRIPTED -- if ON cross compile using Emscripten else build native library using native compilers (this is how the Python libraries are compiled)
  • BIS_WEB_OPT -- this is the optimization flags for the compiler (-O2 is default)
  • BUILDNAME -- this is the automatically generated build name
  • BUILD_TESTING -- set this to ON to enable ctest-style testing (in addition to mocha). CTest calls mocha.
  • EXECUTABLE_OUTPUT_PATH -- Make sure this goes to build/wasm as this is where webpack and the node.js will look for the final libraries.
  • EIGEN3_DIR -- set this to the location of the eigen cmake directory -- it should be set automatically for you.

This cmake.sh/ccmake.sh scripts simply sets some environment variables and runs cmake with the necessary flags. You can can do this manually and set the flags inside cmake but this is not for the faint-hearted.

One CMake is done, on the console simply type

make

or better use the -j flag to set multiple parallel jobs

make -j2

If it all goes well you will have a fresh set of files in your build/wasm directory:

  • libbiswasm_wrapper.js -- the JS wrapper code (more on this in another document)
  • libbiswasm.wasm -- the actual web assembly output file (which we do not use directly)
  • libbiswasm.js -- the Emscripten Module that packages the web assembly library
  • libbiswasm_wasm.js -- a custom script that embeds the WASM file.

Note: In the future, if you make any changes to the C++ code (or inherit some via git pull), source setpaths.sh before typing make as this may invoke cmake which will not find (by default) the paths to Emscripten.

In addition you will have created the command line tools in build/wasm/lib

This is a set of bash and batch files plus two large-ish js files bisweb.js and bisweb-test.js that are the webpack-packaged versions of the command line code. You can install and package these in the usual cmake way using make install and make package if you know what to set up the proper configuration in CMake.

If you are feeling brave you can at this point type:

make test

This will run the regression tests. It will take a while but hopefully everything passes.


Building the C++ Code as a Native Shared Library for Python/Matlab

You will need to install Python 3.5 or higher for this to work.

This is simpler than the WebAssembly build BUT you need to have the WebAssembly libraries compiled first as the Python module descriptions (more on this in ModulesInPython.md) are created from the JS Code.

If you followed the steps above you will have a directory called build/native. Then cd to this and run the script cmake_native.sh as follows:

cd build/native
../cmake_native .

(Again if you would like to customize things replace cmake_native.sh with ccmake_native.sh.)

Once you are done type:

make -j2

and then

make test

as before.


Creating the Code Documentation

For the JS code simply type

gulp jsdoc

This will create a set of html files in build/doc.

For the C++ code you will need to install doxygen and dot.l On Ubuntu this can be done as:

sudo apt-get install doxygen graphviz

On Mac OS (using brew) you can similarly get these using:

brew install doxygen graphviz

Then simply type

gulp cdoc

The final output will go in the directory build/doc/doxygen/html.


Installing and Packaging

Web Applications

The first is for the webpage itself. To do this type

gulp build -m 1
gulp zip

The setting -m 1 turns on minification of the JS code and turns off debug statements. The final result should be a zip file in build/dist that can simply be uploaded to a web server.

Electron Application

To package bisweb as a desktop application for electron simply type

gulp package

You will find the resulting file (.app,.exe,.zip depending on the platform) in build/dist.

Command Line Tools

For either Python tools or WASM commandline tools you can install these using

make install

This will send the files to the directory CMAKE_INSTALL_PREFIX/bisweb. You can set the value of CMAKE_INSTALL_PREFIX in cmake, the default is /usr/local.

You can also configure packaging using cpack within CMake. Then type:

make package

This will create the appropriate .tar.gz, .sh, .zip (depending on options selected) file for you to share.

A cool little trick is to make install both the WASM and the Python tools to the same directory. Then simply zip this and you will have a single JS/Python command line installation!


Detailed description of createbuild.sh

We discuss below the internals of config\createbuild.sh for any one who is curious. What follows is an annotated simplified version of this script (with the print statements removed to shorten it). If you prefer, you can invoke the steps below one at a time instead of the script. In that case set the environment variable DIR to point to the location of the build directory.

  1. Find the location of this script and the build directory

     DIR="$( cd "$( dirname "${BASH_SOURCE[0]}" )" && pwd )"
     DIR="${DIR}/../build"

  2. Create the build directory if needed

     mkdir -p ${DIR}
     cd ${DIR}

  3. Install Eigen 3

     mkdir -p ${DIR}/eigen3
     cd ${DIR}/eigen3
     unzip ${DIR}/../various/download/Eigen.zip

  4. Install Emscripten

     cd ${DIR}
     tar xvfz ${DIR}/../various/download/emsdk-portable.tar.gz
     cd emsdk_portable
     chmod +x emsdk
     ${DIR}/emsdk_portable/emsdk update
     ${DIR}/emsdk_portable/emsdk install latest
     ${DIR}/emsdk_portable/emsdk activate latest

  5. Create the remaining build directories

     mkdir -p ${DIR}/web
     mkdir -p ${DIR}/wasm
     mkdir -p ${DIR}/cpp
     mkdir -p ${DIR}/dist

  6. Copy the scripts

     cp ${DIR}/../config/setpaths_build.sh ${DIR}/setpaths.sh
     cp ${DIR}/../compiletools/cmake.sh ${DIR}/cmake.sh
     cp ${DIR}/../compiletools/ccmake.sh ${DIR}/ccmake.sh
     cp ${DIR}/../compiletools/cmake_native.sh ${DIR}/cmake_native.sh
     cp ${DIR}/../compiletools/ccmake_native.sh ${DIR}/ccmake_native.sh

  7. Make the cmake scripts executable

     chmod +x ${DIR}/cmake*.sh
     chmod +x ${DIR}/ccmake*.sh


This will create a set of directories (if they are not already there)

  • build/web -- for bundling the web-app code
  • build/wasm -- for building the Web Assembly code
  • build/native -- for building the native C++ libraries (for Python)
  • build/dist -- for outputing desktop applications

Next it will install emscripten in build/emsk_portable and Eigen v3 in build/eigen3. The Emscripten installation might take a while depending on your internet connection. See also the instructions on the WebAssembly Developer's Guide if you want to understand what is going on under the hood..

Next it will create five scripts in the build directory.

  • setpaths.sh -- a bash file for setting your paths when compiling Web Assembly. Simply source build/setpaths.sh to set this up
  • cmake.sh -- a wrapper around cmake for building the Web Assembly code.
  • ccmake.sh -- a wrapper around ccmake for the same purpose
  • cmake_native.sh - a wrapper around cmake for building the native libraries for Python
  • ccmake_native.sh - a wrapper around ccmake for building the native libraries for Python

Dropbox and Google Drive Keys

The only source file that is not publicly supplied is the file containing keys for Google Drive and Dropbox access. A skeleton files is provided in js/nointernal/bis_keystore.js. If you intend to include this code in your own application you will need to register it with Dropbox/Google Drive as needed and obtain your own keys and add them to this file (which you should also keep private). The easiest way to do this in the current source setup is to:

  • Create a directory structure that contains two folders

    • bisweb (or anything you want) -- clone the BioImage Suite Web repository inside this directory.
    • internal (this must be called internal) -- this is for your own private code.
  • In internal create a subdirectory called js

  • Copy the files from bisweb/js/nointernal to internal/js directory and edit them to set the correct keys.

  • Run the build using

      cd bisweb
      gulp --internal 1


The parameter "--internal 1" instructs webpack to include the code from the internal directory and not include the boilerplate from js/nointernal -- see config/webpack.config.js if you are curious as to how this happens.


Microsoft Windows and WSL

The one weakness of compiing BisWeb under the Windows Subsystem for Linux (WSL) is that Electron does not run under WSL at this point (it does run but lacks the WebGL integration we need for the viewers.) If you need to work with both C++ code and Electron, here is a recipe that works:

  1. Checkout the bisweb source tree under both WSL (e.g. /home/user/bisweb) and under "Native" Windows (e.g. c:\users\user\bisweb)

  2. Configure the Windows version to just build the JS distribution (i.e. no WebAssembly)

  3. Configure the WSL (Ubuntu effectively) version to build the full version (including Web Assembly)

Under WSL (Ubuntu) in CMake set the two variables (under advanced)

  • BIS_WASMLIB_COPY : ON
  • BIS_EXTRAPATH : /c/users/user/bisweb/build/wasm

This will instruct CMake to copy the output of the WebAssembly compilation (the three files libbiswasm.js, libbiswasm_wasm.js and libbiswasm_wrapper.js to 'c:\users\user\bisweb\build\wasm' each time they are regenerated. This is done automatically as a post-build rule within CMake. This takes advantage of the fact that WASM results in completely platform-independent bytecode, hence we can compile it one one platform and use it everywhere. The advent of WSL means that one does not need to fight with Windows tools and paths anymore. (Though it has been done, but the WSL solution is so much nicer!) Much of the initial testing of the Electron version of BioImage Suite Web was performed in exactly this dual platform setup.

If you are not planning to modify the C++ code then you can simply build this once under WSL and just copy the three files above manually.


Web-based Tests (experimental)

Browser:

To run tests in the browser (this applies only to the module tests) type

  gulp serve

Then navigate to:

  http://localhost:8080/web/biswebtest.html

Then select the tests to run and click Run Tests to execute.

Electron:

To run tests in Electron (this applies only to the module tests) type

  gulp build

Then (assuming you are in the src directory) type:

  electron web biswebtest

Then select the tests to run and click Run Tests to execute.
