ASCIIBIRD v3 — The World's Best IRC ASCII Art Editor

⚠️ v3 is currently in TESTING. Expect bugs. For the stable version, visit classic.birdnest.live.

ASCIIBIRD is a browser-based IRC ASCII art editor for creating and editing mIRC art. It's 100% client-side — everything runs in your browser and persists to IndexedDB. No server, no accounts, no API keys.

Try it live: asciibird.birdnest.live

Support ASCIIBIRD and birdnest streaming by jumping on our Patreon!

---

What's New in v3

v3 is a complete modernization — new build system, new framework, new language, and a pile of new features.

Core Modernization

Before (v2)	After (v3)
Vue 2.6 + Options API	Vue 3.5 + Composition API (<script setup>)
Vuex 3	Pinia 3
vue-cli (Webpack)	Vite 8
JavaScript	TypeScript
Jest	Vitest 4
ESLint 6	ESLint 9 + typescript-eslint
Tailwind CSS 2	Tailwind CSS 3
localStorage (~5MB)	IndexedDB (unlimited)
7 npm dependencies for UI primitives	Headless UI + VueUse

New Features

• 18 brush shapes — circle, square, cross, diamond, ring, star, diagonal, checkerboard, frame, edge, and more (was 4)
• Half-block editing mode — full brush, eraser, mirror, select, and UI constraints for half-block art (▀▄█)
• Shape tool — draw lines, rectangles, and ellipses on the canvas (press L)
• Gradient fill — pick two colors, click two corners, get a smooth gradient
• Border/frame generator — 8 box-drawing styles (single, double, rounded, thick, dashed, dotted, etc.)
• Find & Replace — search and replace characters, colors, or patterns across the canvas or selection
• Color replace tool — click to pick source color, click to replace everywhere (press R)
• Recent colors strip — LRU of last 12 used colors, persisted across sessions
• IRC line length warning — status bar indicator shows byte count per line, yellow >400 bytes, red >500 bytes
• Undo/redo count — status bar shows ⟲ N | ⟳ M for undo/redo steps
• Selection transforms — copy, cut, paste, delete selection with ghost preview
• Shift+Arrow nudge — move selection by 1 block with Shift+Arrow keys
• Export to ANSI — convert mIRC art to ANSI terminal format (256-color)
• Export to HTML — styled HTML with entity escaping
• Plain text export — strip color codes, clipboard or file
• ANSI import — import ANSI art files
• Crop to content — trim canvas to actual art bounds
• Merge layer down / Duplicate layer — with keyboard shortcuts
• Tab inline rename — double-click tab title to rename
• Panel-specific icons — each floating panel has its own icon
• Smart panel positions — panels and canvas start in proper positions
• Middle-click panel minimize — middle-click title bar to collapse

Bugs Fixed

• Flood fill recursion limit on large ASCIIs → iterative fill with explicit stack
• Hidden layers don't auto-select next visible layer → findNextVisibleLayer()
• Half-block import background persistence → import/export round-trip verified
• Panel dragging stuck after right-click → PointerEvent safety nets
• Brush tool line gaps → Bresenham interpolation
• Mirror mode undo corruption → duplicate-position guard
• Page scrollbar visible → fullscreen fixed layout
• Modals behind floating panels → z-index stacking fix
• Menu bar dropdowns behind panels → z-index stacking fix
• Font inconsistency across UI → JetBrains Mono everywhere, Hack canvas only

---

Feature Overview

• Tabbed ASCII editing — multiple documents open at once
• Layers — show/hide, reorder, rename (double-click), merge down, duplicate
• 99 mIRC colors — full extended color palette
• Brush tool — 18 shapes, adjustable size, rotate/flip, mirror X/Y
• Select tool — copy, cut, paste, delete, nudge (Shift+Arrow), transform
• Text tool — click and type, arrow key support
• Fill tool — fill by fg/bg/char with filter checkboxes
• Eraser — per-property erase (fg only, bg only, char only)
• Color picker — eyedropper to grab fg/bg/char from any block
• Image overlay — trace images on the canvas (URL-based)
• Import — mIRC from clipboard, file, URL, ANSI files
• Export — mIRC clipboard/file/POST, ANSI file, HTML, plain text
• Brush Library & History — save, reuse, and organize brushes
• Brush Preview — editable preview panel with tool support
• Context menus — right-click on canvas, brushes, tabs, layers
• Undo/Redo — configurable history limit, diff-based for performance
• Grid mode — Alt+G to toggle grid overlay
• Mirror X/Y — draw symmetrically
• State persistence — everything saved to IndexedDB automatically
• Export/import state file — backup and restore full workspace

---

Tech Stack

Layer	Technology
Framework	Vue 3.5 (Composition API, <script setup>)
State	Pinia 3 + pinia-plugin-persistedstate
Build	Vite 8
Styling	Tailwind CSS 3, SCSS
Language	TypeScript
Testing	Vitest 4 (1400+ tests)
Linting	ESLint 9 + typescript-eslint + plugin:vue
UI Primitives	Headless UI, VueUse
Storage	IndexedDB via idb-keyval
Compression	LZ-String
CI/CD	GitHub Actions → Bunny.net

---

Project Setup

yarn install          # Install dependencies
yarn dev              # Dev server (localhost:5180)
yarn build            # Production build → dist/
yarn lint             # ESLint check
yarn test             # Vitest unit tests
yarn test --coverage  # Tests with coverage report
npx tsc --noEmit      # TypeScript type check

---

Big Shout Outs to Patrons

shrew, octopus, j-hex, nes, mouse, dingo, eraser, pancakes

special thanks to slime aka botmaster slime for the wonderful bot integration with asciibird

What Chatters are Saying

<ralph> ascii bird is so easy a drunk LQ chatter like myself can use, and does use it
<ralph> asciibird is to chatters what the ak-47 is to kids in Sierra Leone
<ralph> POWERFUL STUF

<kayos> man asciibird is legit revolutionary shit

<acidvegas> ngl ive seen asciibird on github
<acidvegas> first time using it rn
<acidvegas> this is v impressive jewbird
<acidvegas> props
<acidvegas> beautiful design
<acidvegas> looks very iOS circa 2015

<higgs> asciibird changed my life.

ASCII Art Created with ASCIIBIRD

References

• http://anti.teamidiot.de/static/nei/*/extended_mirc_color_proposal.html — 99 colours info
• https://modern.ircdocs.horse/formatting.html#color — mIRC formatting
• https://www.mirc.com/colors.html — mIRC colour standard
• https://www.oocities.org/spunk1111/history.htm — History of ASCII art by Joan Stark (jgs)

ASCII Resources

• https://mircart.org/ — IRC ASCII art
• https://asdf.us/asciiblaster/ — Asciiblaster (ASCIIBIRD is loosely based on this)
• https://acid.vegas/asciimaker — ASCII Creator from acidvegas
• https://github.com/ircart/resources — IRC ASCII resources
• http://wepump.in/ascii/ — Classic IRC ASCII art
• https://irc.watch/ascii/ — IRC ASCIIs you can load into ASCIIBIRD
