Qt: Network Watch tool #9849

Open
wants to merge 3 commits into
from
+1,127 −1

Conversation

Reviewers

@jonasschnelli jonasschnelli

@paveljanik paveljanik

Assignees
No one assigned
Labels
GUI
Projects
None yet
Milestone
No milestone
4 participants
@luke-jr @paveljanik @jonasschnelli @fanquake
@luke-jr
Member

luke-jr commented Feb 24, 2017

Simple realtime log of p2p network activity (blocks and transactions only)

  • Doesn't begin logging until opened; limited to 0x400 entries (outputs)
  • Automatically scrolls if left at the bottom of the log; maintains position if left elsewhere
  • Memory-efficient circular buffer; CTransaction references become weak after they're 0x200 entries back in the log
  • Search function that selects all matching log entries, including ongoing

@fanquake fanquake added the GUI label Feb 24, 2017

src/qt/netwatch.cpp
+ }
+ ++rows_used;
+ if (rows_used > max_nonweak_txouts) {
+ LogEntry& le = getLogEntryRow(rows_used - max_nonweak_txouts - 1);
@paveljanik

paveljanik Feb 24, 2017

Contributor

le is the same name as the first argument here, it will bring shadow warning.

@paveljanik
Contributor

paveljanik commented Feb 24, 2017

This is how it looks like here on testnet:

screen shot 2017-02-24 at 08 22 39
@jonasschnelli
Member

jonasschnelli commented Feb 24, 2017 •
Edited 1 time

Thanks. Will review.
I just played a bit with it and had massive locking issues on mainnet during catch-up of 2-3 weeks.
@jonasschnelli
Member

jonasschnelli commented Mar 17, 2017

Running this PR (built over gitian: https://bitcoin.jonasschnelli.ch/build/54) makes Bitcoin-Qt and also the rest of my apps almost unusable. Had to force kill the process.
src/qt/netwatch.cpp
+void NetWatchLogModel::LogBlock(const CBlockIndex* pblockindex)
+{
+ CBlock block;
+ if (!ReadBlockFromDisk(block, pblockindex, Params().GetConsensus())) {
@jonasschnelli

jonasschnelli Mar 17, 2017

Member

IMO reading each block will cause a massive slow down during IBD / catchup.

@luke-jr

luke-jr Mar 17, 2017

Member

The OS should have the data cached already?

src/qt/netwatch.cpp
+ // Indicate error somehow?
+ return;
+ }
+ assert(block.vtx.size());
@jonasschnelli

jonasschnelli Mar 17, 2017

Member

What we probably should do is adding each blocks size and vtx.size() to CBlockIndex* (would require to alter the block index, migration, etc. yes).

@luke-jr

luke-jr Mar 17, 2017

Member

That wouldn't change anything here...?

luke-jr added some commits Feb 24, 2017

@luke-jr
Qt: Store network style on BitcoinGUI object
5beea7d
@luke-jr
CValidationInterface: ValidationInterfaceUnregistering, called when b…
…eing unregistered
6091bf1
@luke-jr
Qt: Network Watch tool
Simple realtime log of p2p network activity (blocks and transactions only)

- Doesn't begin logging until opened; limited to 0x400 entries (outputs)
- Automatically scrolls if left at the bottom of the log; maintains position if left elsewhere
- Memory-efficient circular buffer; CTransaction references become weak after they're 0x200 entries back in the log
- Search function that selects all matching log entries, including ongoing
bbbef18
