LinkedOut - Cloudflare Data Stack Demo

📼 https://youtu.be/pkS1ccQBoqg

LinkedOut is an educational demo application that showcases Cloudflare's modern data stack for building real-time analytics applications with authenticated multi-user collaboration.

What This Demo Teaches

This project demonstrates a complete data pipeline using:

• Workers - Serverless compute for handling HTTP requests
• D1 - Serverless SQL database for relational data
• Pipelines - Stream ingestion for real-time event data
• R2 Data Catalog - Apache Iceberg tables for structured analytics data
• R2 SQL - Query analytics data with standard SQL
• Cloudflare Access - Zero Trust authentication with GitHub OAuth

Use Case: Link Sharing with Analytics

LinkedOut allows educators and presenters to share links after talks and track engagement:

1. Create markdown pages with links to share
2. Collaborate with co-presenters via multi-maintainer system
3. Customize with beautiful pre-built themes
4. Share via URL or QR code
5. Track page views, link clicks, and QR scans
6. Analyze engagement data with SQL queries

Architecture

┌─────────────────────────────────────────────────────────────────┐
│                         User Actions                             │
│  - Visits /out/my-talk                                          │
│  - Clicks link to external site                                 │
│  - Scans QR code                                                │
└────────────────┬────────────────────────────────────────────────┘
                 │
                 v
┌─────────────────────────────────────────────────────────────────┐
│                      Cloudflare Worker                          │
│  - Authenticates via Cloudflare Access (GitHub)                 │
│  - Serves pages from D1 database                                │
│  - Receives tracking events via sendBeacon                      │
│  - Writes events to Pipeline stream                             │
└────────────────┬────────────────────────────────────────────────┘
                 │
                 v
┌─────────────────────────────────────────────────────────────────┐
│                    Pipelines (Stream)                           │
│  - Batches events for efficient writes                          │
│  - Applies SQL transformations (SELECT * FROM stream)           │
└────────────────┬────────────────────────────────────────────────┘
                 │
                 v
┌─────────────────────────────────────────────────────────────────┐
│              R2 Data Catalog (Sink)                             │
│  - Writes to Apache Iceberg table                               │
│  - Stores as Parquet files in R2                                │
│  - Maintains Iceberg metadata for queries                       │
└────────────────┬────────────────────────────────────────────────┘
                 │
                 v
┌─────────────────────────────────────────────────────────────────┐
│                        R2 SQL                                   │
│  - Query data with standard SQL                                 │
│  - Aggregations, filters, time-series analysis                  │
│  - Powers analytics dashboard                                   │
└─────────────────────────────────────────────────────────────────┘

Key Features

Authentication & Security

• Cloudflare Access - GitHub OAuth authentication
• Zero Trust - JWT-based auth, no passwords to manage
• Admin Panel - User management and promotion system
• Multi-User - Role-based access control

Collaboration

• Multi-Maintainer - Share link ownership with co-presenters
• Equal Permissions - All maintainers can edit and manage links
• Team Links - Perfect for conference talks with multiple speakers

Customization

• 6 Pre-built Themes - Default, Dark, Minimal, Colorful, Conference, Retro
• CSS Variables - 10 customizable variables per theme
• Theme Selection - Choose different themes for different links
• Public/Private Themes - Share themes or keep them private

Analytics

• Real-Time Tracking - Page views, clicks, QR scans
• Geographic Data - Country, city, region from Cloudflare
• Interactive Map - Global visualization of page views
• Link Performance - Click-through rates, destination URLs, link text
• Filterable - View all activity or filter by specific links

Sharing

• QR Code Generation - Automatic QR codes for each page
• Hotkeys - Press 'Q' to toggle QR modal
• Download - Export QR codes as PNG
• Tracking - Separate QR scan tracking

Getting Started

See QUICKSTART.md for a quick guide, or follow the detailed setup below.

Prerequisites

• Node.js 18+
• Cloudflare account
• Wrangler CLI: npm install -g wrangler

Installation

# Clone repository
git clone https://github.com/yourusername/linkedout-pipelines
cd linkedout-pipelines

# Install dependencies
npm install

# Login to Cloudflare
npx wrangler login

Database Setup

# Create D1 database (if not exists)
npx wrangler d1 create linkedout-db

# Apply migrations
npx wrangler d1 migrations apply linkedout-db --remote

# Create your first admin user
npx wrangler d1 execute linkedout-db --remote \
  --command "INSERT INTO users (email, is_admin, created_at) VALUES ('your@email.com', 1, datetime('now'))"

Cloudflare Access Setup

1. Go to Zero Trust Dashboard → Access → Applications
2. Click Add an Application → Self-hosted
3. Configure:
   • Application domain: your-worker.workers.dev (or custom domain)
   • Path: /dashboard (or /dashboard/* for subpaths)
4. Add GitHub as an identity provider
5. Create a policy to allow authenticated users
6. Important: Enable "Send Cf-Access-JWT-Assertion header"

Pipeline Setup

# Set your R2 API token
export R2_API_TOKEN="your_token_here"

# Create stream
npx wrangler pipelines streams create click_events_v6 \
  --schema-file schema.json \
  --http-enabled true \
  --http-auth false

# Create sink
npx wrangler pipelines sinks create click_events_sink_v6 \
  --type r2-data-catalog \
  --bucket linkedout-data-catalog \
  --namespace default \
  --table click_events_v6 \
  --catalog-token "$R2_API_TOKEN" \
  --compression zstd \
  --roll-size 100 \
  --roll-interval 300

# Create pipeline
npx wrangler pipelines create click_events_pipeline_v6 \
  --sql "INSERT INTO click_events_sink_v6 SELECT * FROM click_events_v6"

# Note the pipeline ID and update wrangler.jsonc

Development

npm run dev         # Start dev server at localhost:8787
npm test            # Run tests
npm run deploy      # Deploy to production

Project Structure

linkedout-pipelines/
├── src/
│   ├── index.tsx                 # Main Worker (Hono framework)
│   ├── types.ts                  # TypeScript interfaces
│   ├── middleware/
│   │   └── auth.ts              # Cloudflare Access auth middleware
│   ├── routes/
│   │   ├── dashboard.ts         # Dashboard & link management
│   │   ├── auth.ts              # Login/logout routes
│   │   └── tracking.ts          # Click tracking API
│   ├── utils/
│   │   ├── auth.ts              # Auth helpers
│   │   ├── db.ts                # D1 data access layer
│   │   ├── cloudflare-access.ts # JWT decoding
│   │   ├── helpers.ts           # Utility functions
│   │   └── map-data.ts          # World map data fetching
│   └── views/
│       ├── layouts.tsx          # Page layouts
│       └── leaflet-map.tsx      # Interactive map component
├── public/
│   ├── track.js                 # Client-side tracking
│   ├── qr.js                    # QR code functionality
│   └── theme-customizer.js      # Live preview for themes
├── migrations/
│   ├── 0001_initial_schema.sql  # Database schema
│   └── 0002_seed_themes.sql     # Default themes
├── truth-window/                # Development session logs
├── schema.json                  # Pipeline event schema
├── wrangler.jsonc              # Worker configuration
├── AGENTS.md                   # AI agent guidelines
└── README.md                   # This file

Key Concepts Demonstrated

1. Event Streaming with Pipelines

Pipelines ingest high-volume event data without overwhelming downstream systems:

// Write event to stream
await env.EVENT_STREAM.send([{
  timestamp: new Date().toISOString(),
  event_type: 'click',
  slug: 'my-talk',
  out: 'https://clicked-link.com',
  link_text: 'Read More',
  city: 'San Francisco',
  country: 'US'
}]);

2. Apache Iceberg for Analytics

R2 Data Catalog uses Apache Iceberg for:

• Schema evolution - Add columns without breaking existing queries
• Time travel - Query historical data snapshots
• ACID transactions - Consistent reads and writes
• Efficient queries - Columnar format (Parquet) for fast aggregations

3. SQL Analytics on Object Storage

R2 SQL lets you query data in R2 directly:

SELECT
  slug,
  event_type,
  COUNT(*) as event_count,
  city,
  country
FROM default.click_events_v6
WHERE event_type = 'click'
  AND slug IN ('talk-1', 'talk-2')
GROUP BY slug, event_type, city, country
ORDER BY event_count DESC

4. Zero Trust Authentication

Cloudflare Access provides seamless authentication:

// Middleware extracts JWT from Cf-Access-Jwt-Assertion header
const userInfo = getUserFromAccessJWT(jwtHeader);

// Auto-create user on first login
if (!await getUser(userInfo.email)) {
  await createUser(userInfo.email, false);
}

// Set context for routes
c.set("userEmail", userInfo.email);
c.set("userName", userInfo.name);
c.set("isAdmin", user.is_admin);

5. Multi-Maintainer Collaboration

Junction table enables flexible permissions:

-- Add maintainer to link
INSERT INTO link_maintainers (link_slug, user_email, added_by)
VALUES ('my-talk', 'coworker@example.com', 'me@example.com');

-- Check if user can access link
SELECT COUNT(*) FROM link_maintainers
WHERE link_slug = 'my-talk' AND user_email = 'coworker@example.com';

Why Cloudflare's Data Stack?

Traditional data pipelines require:

• Database servers to manage
• ETL jobs to maintain
• Message queues to configure
• Analytics databases to scale
• Authentication servers to secure

Cloudflare's approach:

• ✅ Serverless - No servers to manage
• ✅ Scalable - Handles millions of events
• ✅ Cost-effective - Pay only for what you use
• ✅ Simple - Standard SQL, familiar patterns
• ✅ Fast - Global edge network, low latency
• ✅ Secure - Built-in Zero Trust authentication

Technical Notes

Pipeline Schema (v6)

Events are written with a defined schema ensuring proper column structure:

• timestamp (STRING) - Event timestamp
• event_type (STRING) - Type: page_view, click, qr_scan
• slug (STRING) - Outie slug
• url (STRING) - Page URL
• out (STRING) - Clicked link destination
• link_text (STRING) - Anchor text clicked
• visitor_id (STRING) - Anonymous visitor ID
• user_agent (STRING) - Browser user agent
• referer (STRING) - HTTP referer
• country (STRING) - Country code
• city (STRING) - City name
• region (STRING) - State/province
• colo (STRING) - Cloudflare data center
• latitude (STRING) - Geographic latitude
• longitude (STRING) - Geographic longitude
• timezone (STRING) - Timezone

R2 SQL Limitations

• ⚠️ No AS aliases - use row['count(*)'] instead of row.count
• ⚠️ ORDER BY only on partition keys - use __ingest_ts, not timestamp
• ⚠️ Limited LIKE patterns - no multiple %, must escape _ as \_

Authentication Flow

1. User visits /dashboard (protected by Access)
2. Cloudflare Access intercepts, shows GitHub OAuth
3. User authenticates with GitHub
4. Access issues JWT, adds Cf-Access-Jwt-Assertion header
5. Worker middleware decodes JWT, extracts email
6. Check D1 for user, create if first login
7. Set context variables for routes
8. Render dashboard

Educational Use

This project is perfect for teaching:

• Serverless Architecture - Building apps without servers
• Data Pipeline Design - Streaming, batching, querying
• Web Analytics - How tracking actually works
• Modern Data Stack - Apache Iceberg, Parquet, SQL on object storage
• Zero Trust Security - Authentication without passwords
• Collaborative Systems - Multi-user permissions

Deployment

# Deploy Worker
npm run deploy

# Your app will be at:
https://your-worker-name.workers.dev

Documentation

• QUICKSTART.md - Quick setup guide
• AGENTS.md - AI agent development guidelines
• truth-window/ - Development session logs
  • 09-cloudflare-access-github-auth.md - Latest session (GitHub auth migration)
  • 08-d1-migration-progress.md - D1 database migration
  • And more...

Learn More

• Cloudflare Workers
• D1 Database
• Cloudflare Access
• Pipelines Documentation
• R2 Data Catalog
• R2 SQL
• Apache Iceberg
• Hono Framework

Contributing

This is an educational demo project. Feel free to fork and modify for your own learning!

License

MIT - Feel free to use this for educational purposes!

---

Built with 🧡 using Cloudflare's serverless data stack
