Z2P: Instant Visualization of Point Clouds

Eurographics 2022 [Paper] [Demo]

by Gal Metzer, Rana Hanocka, Raja Giryes, Niloy J. Mitra and Daniel Cohen-Or

Getting Started

Installation

The code relies on PyTorch version 1.8.1 and other packages specified in requirements.txt

Setup Conda Environment

• Change cuda version in install.sh
• Run install.sh to create a conda environment and install everything

Running

Data

The datasets used for the paper can be downloaded from google drive.
Both links contain scripts to .zip files that contain the datasets, please extract before training.
Each set should take up about 16GB or disk space. If you wish to use the cache option at train time please space for around 350GB of disk space.
This will save the 2D point cloud z-buffers to disk and allow for faster training.

Simple dataset

Train, Test

This dataset only allows control over the color and light direction, and uses a simple diffuse material.

Metal-Roughness dataset

Train, Test

This dataset also augments the metallic and roughness of the shape, and allows control over them as well.

Training

First make sure the datasets are downloaded and extracted to disk.

There are two training scripts train_regular.sh and train_metal_roughness.sh, corresponding to the dataset that should be used for training.
Both scripts can be found in the scripts folder and require three inputs: trainset dir, testset dir, export dir.

For example:

train_regular.sh /home/gal/datasets/renders_shade_abs /home/gal/datasets/renders_shade_abs_test /home/gal/exports/train_regular

train_metal_roughness.sh /home/gal/datasets/renders_mr /home/gal/datasets/renders_mr_test /home/gal/exports/train_mr

Inference

Inference with the pre-trained demos is available in an interactive demo app, as well as with demo scripts in this repo.
The scripts folder containes two inference scripts:

• inference_goat.sh
• inference_chair.sh

The scripts require an export dir output, for example:

scripts/inference_goat.sh /home/gal/exports/goat_results

The scripts use inference_pc.py which allows for more inference options like:

• --show_results enables showing the results with matplotlib instead of exporting them
• --checkpoint enables loading a trained checkpoint instead of the pretrained models pulled from drive
• --model_type toggle between regular and metal_roughness models
• --rx, --ry, --rz rotate the pc before projecting
• --rgb control over the color parameter
• --light control over the lights parameters
• --metal, --roughness control over the metal and roughness parameters

and more options accessible through python inference_pc.py --help

Citation

If you find this code useful, please consider citing our paper

@article{metzer2021z2p,
author={Metzer, Gal and Hanocka, Rana and Giryes, Raja and Mitra, Niloy J and Cohen-Or, Daniel},
title = {Z2P: Instant Visualization of Point Clouds},
journal = {Computer Graphics Forum},
volume = {41},
number = {2},
pages = {461-471},
doi = {https://doi.org/10.1111/cgf.14487},
url = {https://onlinelibrary.wiley.com/doi/abs/10.1111/cgf.14487},
year = {2022}
}

Questions / Issues

If you have questions or issues running this code, please open an issue.
