OPC/UA

A native Go implementation of the OPC/UA Binary Protocol.

You need go1.13 or higher. We test with the current and previous Go version. See below for a list of Tested Platforms and Supported Features.

GitHub Go Reference License Version

Note

v0.2.4 and v0.2.5 are broken and should not be used. Please upgrade to v0.2.6 or later. See #538 for details.

Quickstart

# make sure you have go1.17 or higher

# install library
go get -u github.com/gopcua/opcua

# get current date and time 'ns=0;i=2258'
go run examples/datetime/datetime.go -endpoint opc.tcp://localhost:4840

# read the server version
go run examples/read/read.go -endpoint opc.tcp://localhost:4840 -node 'ns=0;i=2261'

# get the current date time using different security and authentication modes
go run examples/crypto/*.go -endpoint opc.tcp://localhost:4840 -cert path/to/cert.pem -key path/to/key.pem -sec-policy Basic256 -sec-mode SignAndEncrypt

# checkout examples/ for more examples...

Sponsors

The gopcua project is sponsored by the following organizations by supporting the active committers to the project:

Northvolt evosoft Intelecy AS

Users

We would also like to list organizations which use gopcua in production. Please open a PR to include your logo below.

strtaeos

Disclaimer

We are still actively working on this project and the APIs will change.

We have started to tag the code to support go modules and reproducible builds but there is still no guarantee of API stability.

However, you can safely assume that we are aiming to make the APIs as stable as possible. :)

The Current State was moved to the Wiki.

Your Help is Appreciated

If you are looking for ways to contribute you can

  • test the high-level client against real OPC/UA servers
  • add functions to the client or tell us which functions you need for gopcua to be useful
  • work on the security layer, server and other components
  • and last but not least, file issues, review code and write/update documentation

Also, if the library is already useful please spread the word as a motivation.

Tested Platforms

gopcua is run in production by several companies and with different equipment. The table below is an incomplete list of where and how gopcua is used to provide some guidance on the level of testing.

We would be happy if you can add your equipment to the list. Just open a PR :)

Device gopcua version Environment By
Siemens S7-1500 v0.1.x..latest production Northvolt
Beckhoff C6015-0010,C6030-0060 on OPC/UA server 4.3.x v0.1.x..latest production Northvolt
Kepware 6.x v0.1.x..latest production Northvolt
Kepware 6.x v0.1.x, v0.2.x production Intelecy
Cogent DataHub 9.x v0.1.x, v0.2.x production Intelecy
ABB Ability EdgeInsight 1.8.X v0.1.x, v0.2.x production Intelecy
GE Digital Historian 2022 HDA Server v0.3.x production Intelecy
InfluxDB Telegraf plugin v0.3.x ? Community

Supported Features

The current focus is on the OPC UA Binary protocol over TCP. No other protocols are supported at this point.

Categories Features Supported Notes
Encoding OPC UA Binary Yes
OPC UA JSON not planned
OPC UA XML not planned
Transport UA-TCP UA-SC UA Binary Yes
OPC UA HTTPS not planned
SOAP-HTTP WS-SC UA Binary not planned
SOAP-HTTP WS-SC UA XML not planned
SOAP-HTTP WS-SC UA XML-UA Binary not planned
Encryption None Yes
Basic128Rsa15 Yes
Basic256 Yes
Basic256Sha256 Yes
Authentication Anonymous Yes
User Name Password Yes
X509 Certificate Yes

Services

The current set of supported services is only for the high-level client.

Service Set Service Supported Notes
Discovery Service Set FindServers
FindServersOnNetwork
GetEndpoints Yes
RegisterServer
RegisterServer2
Secure Channel Service Set OpenSecureChannel Yes
CloseSecureChannel Yes
Session Service Set CreateSession Yes
CloseSession Yes
ActivateSession Yes
Cancel
Node Management Service Set AddNodes
AddReferences
DeleteNodes
DeleteReferences
View Service Set Browse Yes
BrowseNext Yes
TranslateBrowsePathsToNodeIds
RegisterNodes Yes
UnregisterNodes Yes
Query Service Set QueryFirst
QueryNext
Attribute Service Set Read Yes
Write Yes
HistoryRead Yes
HistoryUpdate
Method Service Set Call Yes
MonitoredItems Service Set CreateMonitoredItems Yes
DeleteMonitoredItems Yes
ModifyMonitoredItems Yes
SetMonitoringMode
SetTriggering
Subscription Service Set CreateSubscription Yes
ModifySubscription
SetPublishingMode
Publish Yes
Republish
DeleteSubscriptions Yes
TransferSubscriptions

Authors

The Gopcua Team.

If you need to get in touch with us directly you may find us on Keybase.io but try to create an issue first.

License

MIT
