ExoPlayer DRM (AndroidX Media3)

Sample Android app that plays DASH with Widevine and ClearKey using AndroidX Media3 1.11.1 (androidx.media3:media3-exoplayer, media3-exoplayer-dash, media3-ui).

ExoPlayer 2 (com.google.android.exoplayer) is not used. DRM is configured with the current Media3 APIs: MediaItem.DrmConfiguration, DefaultDrmSessionManager, HttpMediaDrmCallback, and (for developer-supplied ClearKey JSON) LocalMediaDrmCallback. Player failures in the DRM range are shown as PlaybackException.ERROR_CODE_DRM_*.

What works out of the box vs what you must supply

Piece	Out of the box	You must supply
Media3 player + DASH	Yes	—
Clear DASH (Tears of Steel)	Yes	—
Widevine Google test DASH + UAT license proxy	Yes (labeled as test)	Nothing, but the proxy is not a production license server; it can fail, rate-limit, or disappear
Custom Widevine (drm.widevine.licenseUri)	UI state MISSING LICENSE URL until set	A real license server URL that matches your content (optional manifest + license request headers)
MediaItem.DrmConfiguration / DefaultDrmSessionManager	Yes (code)	Matching license URI for your content
Widevine CDM	Device-dependent	Google Play system images usually include it; many AOSP emulators do not (MediaDrm.isCryptoSchemeSupported)
ClearKey HTTP license	API + empty Gradle placeholders	ClearKey-protected manifest and drm.clearkey.licenseUri
ClearKey local keys	API + LocalMediaDrmCallback	Your own W3C ClearKey JSON via drm.clearkey.keysFile (gitignored). No keys are hardcoded
Production DRM / PlayReady on a phone	No	PlayReady SL2000 is documented for Android TV, not this sample

This sample does not invent license servers, wrap keys, or fake MediaDrm.

UI states

The label above the status text is one of:

• CLEAR — unencrypted Google test DASH
• WIDEVINE · GOOGLE TEST — Media3 demo Tears of Steel + proxy.uat.widevine.com
• WIDEVINE · CUSTOM LICENSE — Gradle drm.widevine.licenseUri is set
• MISSING LICENSE URL — custom Widevine or ClearKey selected without a license URL or keys JSON; playback is not started
• CLEARKEY — developer-supplied license URL or local keys JSON
• CDM UNSUPPORTED — MediaDrm.isCryptoSchemeSupported is false (no fake fallback)
• DRM ERROR — ERROR_CODE_DRM_* from the player
• PLAYBACK ERROR — other Media3 PlaybackException codes

Extra DRM diagnostics (this branch)

These extras sit on top of the Media3 sample. They do not add a license server.

Extra	What it does	Honest limit
DrmSessionEventListener	Session acquire / keys loaded / manager error / release, shown in the UI and via EventLogger on logcat	Events never include license keys. Wired through AnalyticsListener because ExoPlayer does not expose addDrmSessionEventListener.
UUID + CDM properties	Prints Widevine / ClearKey UUID and MediaDrm strings securityLevel, hdcpLevel, maxHdcpLevel, version, systemId	Properties are vendor-optional. Missing values show as n/a. PlayReady is not opened on phones.
forceDefaultLicenseUri	Checkbox: keep license HTTP on the app URI even if a DASH period lists LicenseUrl. MediaItem path uses DrmConfiguration.setForceDefaultLicenseUri; session-manager path uses HttpMediaDrmCallback(..., forceDefaultLicenseUrl). Media3 1.11.1 has no DefaultDrmSessionManager.Builder setter for this.	The default Google Tears of Steel MPD is typically one period, so the flag is a no-op until you load a multi-period (or in-band license URL) asset.
License HTTP retries	LoadErrorHandlingPolicy with 4 DRM load attempts	Installed only on the DefaultDrmSessionManager radio. The MediaItem.DrmConfiguration path still uses ExoPlayer’s built-in DRM load policy.

Supported DRM schemes (Media3 / Android)

From Media3 DRM documentation:

Scheme	Typical API level	Formats
Widevine cenc	19+	DASH, HLS (FMP4)
Widevine cbcs	25+	DASH, HLS (FMP4)
ClearKey cenc	21+	DASH
PlayReady SL2000	Android TV	DASH, SmoothStreaming, HLS (FMP4)

PlayReady is not implemented here; phones do not expose that stack the way Android TV does.

Default test content

The Widevine and clear DASH URLs are the Tears of Steel assets published for the AndroidX Media3 demo:

• Encrypted: https://storage.googleapis.com/wvmedia/cenc/h264/tears/tears.mpd
• Clear: https://storage.googleapis.com/wvmedia/clear/h264/tears/tears.mpd
• Widevine license (Google UAT test proxy):
  https://proxy.uat.widevine.com/proxy?video_id=2015_tears&provider=widevine_test

Those URLs are used only by the two “Google test” radios. Custom Widevine does not silently fall back to the UAT proxy.

Build and run

Requirements:

• Android Studio Ladybug / AGP 8.11-compatible IDE, or JDK 17+
• compileSdk 36 (required by Media3 1.11.1 AARs) and Kotlin 2.2.10
• Android device or emulator, API 24+
• For Widevine: a device/emulator image that includes Widevine (Google Play system images are more likely than AOSP)

./gradlew :app:assembleDebug
./gradlew :app:testDebugUnitTest

In the app:

1. Widevine DASH — Google test (MediaItem.DrmConfiguration) — recommended Media3 path.
2. Widevine DASH — Google test (DefaultDrmSessionManager) — same stream with HttpMediaDrmCallback installed on DefaultMediaSourceFactory.
3. Custom Widevine DASH — requires drm.widevine.licenseUri; otherwise MISSING LICENSE URL.
4. Clear DASH — same title without DRM.
5. ClearKey DASH — requires your license URL or keys JSON.
6. Force app license URI — optional. When checked, MediaItem.DrmConfiguration.setForceDefaultLicenseUri(true) (and the matching HttpMediaDrmCallback flag on the session-manager radio) ignores a per-period LicenseUrl. Leave it off for the Google test MPD.

The status line, CDM property dump, and DRM session log are diagnostics only. They do not request extra licenses.

Supplying your own license server or ClearKey keys

Add properties to gradle.properties (or pass -P on the Gradle command line) and rebuild:

drm.widevine.manifestUri=https://your-cdn.example/stream.mpd
drm.widevine.licenseUri=https://your-widevine-license.example/license
drm.widevine.licenseRequestHeaders=Authorization=Bearer your-token

drm.clearkey.manifestUri=https://your-cdn.example/clearkey.mpd
drm.clearkey.licenseUri=https://your-clearkey-license.example/license

For ClearKey without a license HTTP server, put a W3C ClearKey response in a local file (already gitignored as local-clearkey.json) and point Gradle at it:

drm.clearkey.manifestUri=https://your-cdn.example/clearkey.mpd
drm.clearkey.keysFile=local-clearkey.json

Expected JSON shape (fill in your k / kid values; do not commit production keys):

{"keys":[{"kty":"oct","k":"<base64url-key>","kid":"<base64url-kid>"}]}

License request headers also belong on MediaItem.DrmConfiguration.Builder.setLicenseRequestHeaders or HttpMediaDrmCallback.setKeyRequestProperty. This sample does not add fake auth.

Media3 version

Module	Version	Maven
androidx.media3:media3-exoplayer	1.11.1	Google Maven
androidx.media3:media3-exoplayer-dash	1.11.1	same group
androidx.media3:media3-ui	1.11.1	same group

Declared in gradle/libs.versions.toml.

Docs

• Media3 DRM
• Media3 releases
• Media3 migration
