src















Description

Planby is a React based component for a quick implementation of Epg, schedules, live streaming, music events, timelines and many more ideas. It uses a custom virtual view which allows you to operate on a really big number of data. The component has a simple API that you can easily integrate with other third party UI libraries. The component theme is customised to the needs of the application design.

Codesandbox example

Live example - Codesandbox

Live example - website with control panel

🚀 Become a Sponsor! 🚀

Support our activity and help us continue our development -> Open Collective.

Getting Started

Installation

  • yarn
yarn add planby
  • npm
npm install planby

Usage

import { useEpg, Epg, Layout } from 'planby';

const channels = React.useMemo(
  () => [
    {
      logo: 'https://via.placeholder.com',
      uuid: '10339a4b-7c48-40ab-abad-f3bcaf95d9fa',
      ...
    },
  ],
  []
);

const epg = React.useMemo(
  () => [
    {
      channelUuid: '30f5ff1c-1346-480a-8047-a999dd908c1e',
      description:
        'Ut anim nisi consequat minim deserunt...',
      id: 'b67ccaa3-3dd2-4121-8256-33dbddc7f0e6',
      image: 'https://via.placeholder.com',
      since: "2022-02-02T23:50:00",
      till: "2022-02-02T00:55:00",
      title: 'Title',
      ...
    },
  ],
  []
);

const {
  getEpgProps,
  getLayoutProps,
  onScrollToNow,
  onScrollLeft,
  onScrollRight,
} = useEpg({
  epg,
  channels,
  startDate: '2022/02/02', // or 2022-02-02T00:00:00
});

return (
  <div>
    <div style={{ height: '600px', width: '1200px' }}>
      <Epg {...getEpgProps()}>
        <Layout
          {...getLayoutProps()}
        />
      </Epg>
    </div>
  </div>
);

or

Custom width and height

const {
  getEpgProps,
  getLayoutProps,
  ...
} = useEpg({
  epg,
  channels,
 startDate: '2022/02/02', // or 2022-02-02T00:00:00
  width: 1200,
  height: 600
});

return (
  <div>
     <Epg {...getEpgProps()}>
        <Layout
          {...getLayoutProps()}
        />
      </Epg>
  </div>

or

Time range

const {
  getEpgProps,
  getLayoutProps,
  ...
} = useEpg({
  epg,
  channels,
  startDate: '2022-02-02T10:00:00',
  endDate: '2022-02-02T20:00:00',
  width: 1200,
  height: 600
});

return (
  <div>
     <Epg {...getEpgProps()}>
        <Layout
          {...getLayoutProps()}
        />
      </Epg>
  </div>

API

useEpg

Options

Available options in useEpg

Property Type Status Description
channels array required Array with channels data
epg array required Array with epg data
width number optional Epg width
height number optional Epg height
sidebarWidth number optional Width of the sidebar with channels
itemHeight number optional Height of channels and programs in the EPG. Default value is 80
dayWidth number optional Width of the day. Default value is 7200. Calculation to set up day width with own hour width value eg. 24h * 300px(your custom hour width) = 7200px -> dayWidth
startDate string optional Date format 2022/02/02 or 2022-02-02T00:00:00. You can set your own start time eg. 2022-02-02T10:00:00, 2022-02-02T14:00:00 etc. Full clock hours only.
endtDate string optional Date format 2022-02-02T00:00:00. You can set your own end time eg. 2022-02-02T15:00:00, 2022-02-02T:20:00 etc. Full clock hours only.
isBaseTimeFormat boolean optional Convert to 12 hours format eg. 2:00am, 4:00pm etc. Default value is false.
isSidebar boolean optional Show/hide sidebar
isTimeline boolean optional Show/hide timeline
isLine boolean optional Show/hide line
theme object optional Object with theme schema

Note about width and height props

Without declaring the width and length properties, the component takes the dimensions of the parent element.

Instance Properties

Properties returned from useEpg

Property Type Description
scrollY number Current scroll y value
scrollX number Current scroll x value
onScrollLeft function(value: number) Default value is 300
onScrollRight function(value: number) Default value is 300
onScrollToNow function() Scroll to current time/live programs
onScrollTop function(value: number) Default value is 300

Channel schema

Property Type Status
logo string required
uuid string required

Epg schema

Property Type Status
channelUuid string required
id string required
image string required
since string required
till string required
title string required

Epg

Base props

Available props in Epg

Property Type Description Status
isLoading boolean Loader state optional
loader Component Loader custom cpomponent optional

Layout

Base props

Available props in Layout.

Property Type Description Status
renderProgram function({ program: { data: object, position: object}) data object contains all properties related to the program, position object includes all position styles optional
renderChannel function({ channel: { ..., position: object}) channel object contains all properties related to the channel, position object includes all position styles optional
renderTimeline function({sidebarWidth: number}) sidebarWidth value of the channel's sidebar width optional

Render functions

You can use Plaby's style components to develop main features. Moreover, you can integrate with third party UI library eg. Chakra UI, Material UI etc or make custom styles.

renderProgram

Below is an example that allows you to render your custom Program component using Plaby's style components.

import {
  useEpg,
  Epg,
  Layout,
  ProgramBox,
  ProgramContent,
  ProgramFlex,
  ProgramStack,
  ProgramTitle,
  ProgramText,
  ProgramImage,
  useProgram,
  Program,
  ProgramItem
} from "planby";


const Item = ({ program,...rest }: ProgramItem) => {
  const { styles, formatTime, isLive, isMinWidth } = useProgram({ program,...rest });

  const { data } = program;
  const { image, title, since, till } = data;

  const sinceTime = formatTime(since);
  const tillTime = formatTime(till);

  return (
    <ProgramBox width={styles.width} style={styles.position}>
      <ProgramContent
        width={styles.width}
        isLive={isLive}
      >
        <ProgramFlex>
          {isLive && isMinWidth && <ProgramImage src={image} alt="Preview" />}
          <ProgramStack>
            <ProgramTitle>{title}</ProgramTitle>
            <ProgramText>
              {sinceTime} - {tillTime}
            </ProgramText>
          </ProgramStack>
        </ProgramFlex>
      </ProgramContent>
    </ProgramBox>
  );
};

function App() {

  ...

 const {
  getEpgProps,
  getLayoutProps,
} = useEpg({
  epg,
  channels,
  startDate: '2022/02/02', // or 2022-02-02T00:00:00
});

return (
  <div>
    <div style={{ height: '600px', width: '1200px' }}>
      <Epg {...getEpgProps()}>
        <Layout
            {...getLayoutProps()}
            renderProgram={({ program,...rest }) => (
              <Item key={program.data.id} program={program} {...rest} />
            )}
          />
      </Epg>
    </div>
  </div>
);
}

export default App;

renderProgram - 12 hours time format

Below is an example that allows you to render your custom Program component with 12 hours time format using Plaby's style components.

...
const Item = ({ program, ...rest }: ProgramItem) => {
  const {
    styles,
    formatTime,
    set12HoursTimeFormat,
    isLive,
    isMinWidth,
  } = useProgram({
    program,
    ...rest
  });

  const { data } = program;
  const { image, title, since, till } = data;

  const sinceTime = formatTime(since, set12HoursTimeFormat()).toLowerCase();
  const tillTime = formatTime(till, set12HoursTimeFormat()).toLowerCase();

  return (
    <ProgramBox width={styles.width} style={styles.position}>
      <ProgramContent
        width={styles.width}
        isLive={isLive}
      >
        <ProgramFlex>
          {isLive && isMinWidth && <ProgramImage src={image} alt="Preview" />}
          <ProgramStack>
            <ProgramTitle>{title}</ProgramTitle>
            <ProgramText>
              {sinceTime} - {tillTime}
            </ProgramText>
          </ProgramStack>
        </ProgramFlex>
      </ProgramContent>
    </ProgramBox>
  );
};

function App() {

  ...

 const {
  getEpgProps,
  getLayoutProps,
} = useEpg({
  epg,
  channels,
  isBaseTimeFormat: true,
  startDate: '2022/02/02', // or 2022-02-02T00:00:00
});

...
}

export default App;

renderChannel

Below is an example that allows you to render your custom Channel component using Plaby's style components.

import { useEpg, Epg, Layout, ChannelBox, ChannelLogo, Channel } from 'planby';

interface ChannelItemProps {
  channel: Channel;
}

const ChannelItem = ({ channel }: ChannelItemProps) => {
  const { position, logo } = channel;
  return (
    <ChannelBox {...position}>
      <ChannelLogo
        onClick={() => console.log('channel', channel)}
        src={logo}
        alt="Logo"
      />
    </ChannelBox>
  );
};


function App() {

  ...

  const {
    getEpgProps,
    getLayoutProps,
  } = useEpg({
    epg,
    channels,
    startDate: '2022/02/02', // or 2022-02-02T00:00:00
  });

  return (
    <div>
      <div style={{ height: '600px', width: '1200px' }}>
        <Epg {...getEpgProps()}>
          <Layout
              {...getLayoutProps()}
              renderChannel={({ channel }) => (
              <ChannelItem key={channel.uuid} channel={channel} />
            )}
            />
        </Epg>
      </div>
    </div>
  );
}

renderTimeline

Below is an example that allows you to render your custom Timeline component using Plaby's style components.

import {
  TimelineWrapper,
  TimelineBox,
  TimelineTime,
  TimelineDivider,
  TimelineDividers,
  useTimeline,
} from 'planby';

interface TimelineProps {
  isBaseTimeFormat: boolean;
  isSidebar: boolean;
  dayWidth: number;
  hourWidth: number;
  numberOfHoursInDay: number;
  offsetStartHoursRange: number;
  sidebarWidth: number;
}

export function Timeline({
  isBaseTimeFormat,
  isSidebar,
  dayWidth,
  hourWidth,
  numberOfHoursInDay,
  offsetStartHoursRange,
  sidebarWidth,
}: TimelineProps) {
  const { time, dividers, formatTime } = useTimeline(
    numberOfHoursInDay,
    isBaseTimeFormat
  );

  const renderTime = (index: number) => (
    <TimelineBox key={index} width={hourWidth}>
      <TimelineTime>
        {formatTime(index + offsetStartHoursRange).toLowerCase()}
      </TimelineTime>
      <TimelineDividers>{renderDividers()}</TimelineDividers>
    </TimelineBox>
  );

  const renderDividers = () =>
    dividers.map((_, index) => (
      <TimelineDivider key={index} width={hourWidth} />
    ));

  return (
    <TimelineWrapper
      dayWidth={dayWidth}
      sidebarWidth={sidebarWidth}
      isSidebar={isSidebar}
    >
      {time.map((_, index) => renderTime(index))}
    </TimelineWrapper>
  );
}

function App() {

  ...

  const {
    getEpgProps,
    getLayoutProps,
  } = useEpg({
    epg,
    channels,
    startDate: '2022/02/02', // or 2022-02-02T00:00:00
  });

  return (
    <div>
      <div style={{ height: '600px', width: '1200px' }}>
        <Epg {...getEpgProps()}>
          <Layout
              {...getLayoutProps()}
              renderTimeline={(props) => <Timeline {...props} />}
            />
        </Epg>
      </div>
    </div>
  );
}

export default App;

Theme

Schema

Make your theme custom. Below is theme schema that you can pass as one of the options to useEpg hook.

const theme = {
  primary: {
    600: '#1a202c',
    900: '#171923',
  },
  grey: { 300: '#d1d1d1' },
  white: '#fff',
  green: {
    300: '#2C7A7B',
  },
  loader: {
    teal: '#5DDADB',
    purple: '#3437A2',
    pink: '#F78EB6',
    bg: '#171923db',
  },
  scrollbar: {
    border: '#ffffff',
    thumb: {
      bg: '#e1e1e1',
    },
  },
  gradient: {
    blue: {
      300: '#002eb3',
      600: '#002360',
      900: '#051937',
    },
  },
  text: {
    grey: {
      300: '#a0aec0',
      500: '#718096',
    },
  },
  timeline: {
    divider: {
      bg: '#718096',
    },
  },
};

All import options

import {
  Epg,
  Layout,
  ChannelBox,
  ChannelLogo,
  ProgramBox,
  ProgramContent,
  ProgramFlex,
  ProgramStack,
  ProgramTitle,
  ProgramText,
  ProgramImage,
  TimelineWrapper,
  TimelineBox,
  TimelineTime,
  TimelineDividers,
  useEpg,
  useProgram,
  useTimeline,
  Program, // Interface
  Channel, // Interface
  ProgramItem, // Interface for program render
  Theme, // Interface
} from 'planby';

License

Distributed under the MIT License. See LICENSE for more information.

Contact

Karol Kozer - @kozerkarol_twitter

Project Link: https://github.com/karolkozer/planby
