README.md

StatusBarUtil

Android Arsenal

Download

A util for setting status bar style on Android App. It can work above API 19(KitKat 4.4).

中文版点我

Sample

Download StatusBarUtil-Demo

ChangeLog

CLICK ME

Usage

  1. Add the dependencies to your build.gradle file, StatusBarUtil is avaiable in JCenter:

    compile 'com.jaeger.statusbarutil:library:1.5.1'

    I fixed typo, change "statusbaruitl" to "statusbarutil", please notice this.

  2. Call method you need after setContentView(), such as :

    setContentView(R.layout.main_activity);
    ...
    StatusBarUtil.setColor(MainActivity.this, mColor);
  3. If you use this util in a page which containing a DrawerLayout, you need add android:fitsSystemWindows="true" for DrawerLayout in your layout XML:

    <android.support.v4.widget.DrawerLayout
        xmlns:android="http://schemas.android.com/apk/res/android"
        xmlns:app="http://schemas.android.com/apk/res-auto"
        android:id="@+id/drawer_layout"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:fitsSystemWindows="true">

        ...

    </android.support.v4.widget.DrawerLayout>
  4. Set color for swipe back page

    Recommend using with bingoogolapple/BGASwipeBackLayout-Android: Android Activity 滑动返回

    StatusBarUtil.setColorForSwipeBack(Activity activity, @ColorInt int color, int statusBarAlpha)
  5. All statusBarAlpha value you set should between 0 ~ 255

  6. How to use in Fragment, please read UseInFragmentActivity.java

    Handle all Fragments in ViewPager as ImageViewFragment, add a fake View in your Fragment layout as StatusBar :

    <?xml version="1.0" encoding="utf-8"?>
    <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:orientation="vertical">

        <View
            android:id="@+id/fake_statusbar_view"
            android:layout_width="match_parent"
            android:layout_height="@dimen/statusbar_view_height"
            android:background="@color/colorPrimary"/>

        <TextView
            android:id="@+id/tv_title"
            android:layout_width="match_parent"
            android:layout_height="56dp"
            android:background="@color/colorPrimary"
            android:gravity="center"
            android:text="@string/app_name"
            android:textColor="@color/white"
            android:textSize="24sp"/>
    </LinearLayout>

    The fake StatusBar View height value statusbar_view_height defined in dimens.xml

    ~ values-v19/dimens.xml

    <dimen name="statusbar_view_height">25dp</dimen>

    ~ values/dimens.xml

    <dimen name="statusbar_view_height">0dp</dimen>

    When you change StatusBarColor :

    mFakeStatusBar.setBackgroundColor(color);

    Then in the Activity which contains ViewPage, just invoke

    StatusBarUtil.setTranslucentForImageViewInFragment(UseInFragmentActivity.this, null);

    Please read UseInFragmentActivity.java

Features

  • Set status bar color

    StatusBarUtil.setColor(Activity activity, int color)

  • Set status bar translucent

    StatusBarUtil.setTranslucent(Activity activity, int statusBarAlpha)

  • Set status bar transparent

    StatusBarUtil.setTransparent(Activity activity)

  • Set status bar color for DrawerLayout

    StatusBarUtil.setColorForDrawerLayout(Activity activity, DrawerLayout drawerLayout, int color)

  • Set translucent status bar for using ImageView as head view page

      StatusBarUtil.setTranslucentForImageView(Activity activity, int statusBarAlpha, View needOffsetView)

  • Set Light or Dark mode

      StatusBarUtil.setLightMode(Activity activity)
      StatusBarUtil.setDarkMode(Activity activity)


  • Use in fragment

  • Set color for swipe back page

      StatusBarUtil.setColorForSwipeBack(Activity activity, @ColorInt int color, int statusBarAlpha)

  • Pass statusBarAlpha param when necessary to change your status bar alpha, which is 112 by default.

License

Copyright 2016 Jaeger Chen

Licensed under the Apache License, Version 2.0 (the "License");	you may not use this file except in compliance with the License.
You may obtain a copy of the License at

	http://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
