diff --git a/docs/streams-and-ampersandjs.md b/docs/streams-and-ampersandjs.md new file mode 100644 index 00000000000..ff7941d88c1 --- /dev/null +++ b/docs/streams-and-ampersandjs.md @@ -0,0 +1,261 @@ +# Streams and Ampersand.js + +1. Start mongodb in a background window. +2. Open a new terminal window and run the following to start up scout-server: `cd ~/scout/scout-server; npm start;` +3. Open scout-ui in your editor of choice: `cd ~/scout/scout-ui; subl -a ./;` + +```javascript +// It all starts with requiring some libraries. +// +// scout-brain is currently a dumping ground and will be broken up into +// several smaller modules as soon as we can. +var brain = require('../../../scout-brain'); + +// scout-client provides us with a nice wrapper around the scout-server +// REST and socket.io API's. +var client = require('../../../scout-client')(); + +// mongodb-schema provides us with a very convenient `Schema` model +// we can extend from that means we have a nice and simple implementation: +// we just need to fill out the method for providing it data. +var Schema = require('mongodb-schema').Schema; + +// Our debugging philosophy is the same as node.js core, chromium and unix: +// when it comes to logging there are no levels, only `debug()` and it should +// be nice and only output messages when you want them. If there is an error, +// you should throw an error. More info: http://npm.im/debug +var debug = require('debug')('scout-streams-example'); + +var SampledSchema = Schema.extend({ + fetch: function() { + // Create a new readable stream that will feed us documents sampled from + // the namespace `this.ns`. Under the hood, scout-client implements this + // as a socket.io stream. This way as soon as a document is available from + // the sample it will be on it's way to being analyzed. + var docs = client.sample(this.ns, {size: 5, query: {}, fields: null}); + + // mongodb-schema provides us with a convenient `stream()` method + // that provides a [transform](https://github.com/substack/stream-handbook#transform) + // that will update `this.fields` as new documents are delivered to it. + var transformer = this.stream(); + + // Streams don't do anything until they're told to. Calling `.sample()` + // just prepares the state and won't start using the network until + // another stream is connected to it, most often via `.pipe()`: + docs.pipe(transformer); + + // Finally, when we've finished analyzing the sample, we trigger a `sync` + // event so anyone watching us will know we're finished loading data. + transformer.on('end', this.trigger.bind(this, 'sync', this)); + } +}); + +var schema = new SampledSchema({ + ns: 'local.startup_log' +}); +schema.on('sync', function() { + debug('schema analyzed! It has %d fields', schema.fields.length); + schema.fields.map(function(field, i) { + debug('%d. %s', i, field._id); + }); + client.close(); +}); +schema.fetch(); +``` + +Because of the way scout and ampersand are built, we can try this out +right in the terminal instead of mucking about in the browser. Save the above +under `~/scout/scout-ui/src/models/streams-01.js` and run the following in a +terminal window: `DEBUG=scout-* node src/models/streams-01.js`. You should see +something like the following https://gist.github.com/imlucas/83da48b4b05745fcfef2 + +Let's add some debugging to get a better look under the hood. + +```javascript +var client = require('../../../scout-client')(); +var Schema = require('mongodb-schema').Schema; +var debug = require('debug')('scout-streams-example'); +var es = require('event-stream'); + +var SampledSchema = Schema.extend({ + fetch: function() { + var docs = client.sample(this.ns, { + size: 5, + query: {}, + fields: null + }); + var transformer = this.stream(); + + docs.pipe(es.map(function(doc, done) { + debug('got sampled document with _id `%j`', doc._id); + done(null, doc); + })) + .pipe(transformer) + .pipe(es.map(function(field, done) { + debug('created or updated field `%s`', field._id); + done(null, field); + })); + + transformer.on('end', this.trigger.bind(this, 'sync', this)); + } +}); + +var schema = new SampledSchema({ + ns: 'local.startup_log' +}); +schema.on('sync', function() { + debug('schema analyzed! It has %d fields', schema.fields.length); + client.close(); +}); +schema.fetch(); +``` + +Save the above under `~/scout/scout-ui/src/models/streams-02.js` and run the +following in a terminal window: `DEBUG=scout-* node src/models/streams-02.js`. +You should see something like the following https://gist.github.com/imlucas/8baf67b46035bc1ae6d9 + +Let's make some UI! Now that we know how to weild streams, let's add a +new panel to the collection view that shows a list of sampled documents +with nice syntax highlighting. + +To do the highlighting, we'll use the [html-stringify](http://npm.im/html-stringify) +module: `cd ~/scout/scout-ui; npm install --save html-stringify;` + +Modify our schema model above to look like the below and save it as +`scout/scout-ui/src/models/sampled-schema.js`: + +```javascript +// scout/scout-ui/src/models/sampled-schema.js +var brain = require('../../../scout-brain'); +var client = require('../../../scout-client')(); +var Schema = require('mongodb-schema').Schema; +var es = require('event-stream'); + +var SampledSchema = Schema.extend({ + collections: { + documents: brain.models.DocumentCollection + }, + fetch: function() { + var docs = client.sample(this.ns, { + size: 5, + query: {}, + fields: null + }); + var transformer = this.stream(); + var schema = this; + + docs.pipe(es.map(function(doc, done) { + schema.documents.add(doc); + done(null, doc); + })) + .pipe(transformer); + transformer.on('end', this.trigger.bind(this, 'sync', this)); + } +}); + +module.exports = SampledSchema; +``` + +Next, lets write some views that use our new model and do the wiring +into the main `CollectionView`. + +```javascript +// scout/scout-ui/src/home/index.js +// add as a subview to CollectionView +var htmlStringify = require('html-stringify'); + +var DocumentListItemView = AmpersandView.extend({ + derived: { + document_html: { + deps: ['model'], + fn: function() { + return htmlStringify(this.model.serialize()); + } + } + }, + bindings: { + document_html: { + hook: 'document_html', + type: 'innerHTML' + } + }, + template: '
' +}); + +var DocumentListView = AmpersandView.extend({ + template: '', + render: function() { + this.renderWithTemplate(); + this.renderCollection(this.collection, DocumentListItemView, this.queryByHook('documents')); + } +}); + +var CollectionView = AmpersandView.extend({ + bindings: { + 'model._id': { + hook: 'name' + } + }, + children: { + model: models.Collection, + schema: require('../models/sampled-schema') + }, + initialize: function() { + app.statusbar.watch(this, this.schema); + + this.schema.ns = this.model._id; + this.schema.fetch(); + }, + template: require('./collection.jade'), + subviews: { + documents: { + waitFor: 'schema.documents', + hook: 'documents-container', + prepareView: function(el) { + return new DocumentListView({ + el: el, + parent: this, + collection: this.schema.documents + }); + } + }, + fields: { + waitFor: 'schema.fields', + hook: 'fields-container', + prepareView: function(el) { + return new FieldListView({ + el: el, + parent: this, + collection: this.schema.fields + }); + } + } + } +}); +``` + +Finally, modify the template `scout/scout-ui/src/home/index.jade` +to position our new subview. + +```jade +// scout/scout-ui/src/home/index.jade +.panel-group + .contextbar(style='width: 400px;position: absolute; right: 0;') + .panel.panel-default + .panel-heading + .panel-title Sampled documents + div(data-hook='documents-container') + + .panel.panel-default(style='margin-right: 420px;') + .panel-heading + .panel-title + i.fa.fa-fw.fa-bars + span(data-hook='name') + div(data-hook='fields-container') + .clearfix +``` + +Start up scout with `cd ~/scout && npm start` and you should see your +new panel that looks something like the below: + +
