What does OMGene do?

OMGene (Optimise My Gene) aims to improve simultaneously sets of gene models on an orthogroup-by-orthogroup basis. It leverages genetic information from multiple orthologs across multiple genomes to find the most evolutionary consistent set of gene models for a given gene.

Given an input set of gene models and a set of genomes, it will seek to find the gene model variants for each gene which collectively optimise the coherence of the multiple sequence alignment, thus maximising the likelihood that a gene model is correct in the absence of extrinsic data. OMGene requires only a set of single-entry GTF gene model files and a set of input FASTA genome files.

Github link: https://github.com/mpdunne/OMGene

Usage

Default usage

OMGene is written in Python 2.7 and is designed to be run on Linux systems. Note OMGene is not currently being maintained.

OMGene runs as a single command that takes as input a tabulated text file containing locations of genomes and GTF files in the following format:

#gtf                                  genome
/path/to/gtf_species1_gene1.gtf       /path/to/genome_species1.fasta
/path/to/gtf_species2_gene1.gtf       /path/to/genome_species2.fasta
/path/to/gtf_species3_gene1.gtf       /path/to/genome_species3.fasta
etc.

Each GTF file should contain the coordinates of a single gene. OMGene is then run using:

python omgene.py -i path/to/gene_info_file.tdv -o output_folder

If no output folder is specified then OMGene will create one with a generic name. Currently OMGene is only configured to run on a single core.

Example files

An example file is given in the "samples" directory included in this repository. This contains actual published gene models and truncated FASTA genome sections. To run the example, navigate to the samples directory and execute the following command:

python ../omgene.py -i in.tdv -o out

Once this has run, the "out" directory will contain the results. To compare the original and new results, compare the files working/or.aln and results/all.aln. To view this quickly in the terminal, you may wish to use the Alan alignment viewer. If you have alan installed, you can type

cat working/or.aln results/all.aln > compare.aln; alan compare.aln

Alternate start and splice sites

You may wish to use non-canonical nucleotide combinations for start and splice sites, for example GU--GG splicing or CUG start codons. These can be specified using the -do, -ac, and -sc options for donor sites, acceptor sites, and start codons respectively. Site lists must be comma-separated. If you wish to include the canonical codon or splice site in the search, you must also specify it here. For example:

python ../omgene.py -i in.tdv -o out -do "gc,gu" -ac "gg,ag" -sc "aug,cug".

Cysteine and uracil (C and U) will be interpreted identically. If these options are omitted, the default will be used: GU,GC donor sites, AG acceptor sites, and AUG start codons. The more options that are inputted here, the more variants will be probed by OMGene, potentially considerably increasing its runtime. Therefore we recommend some degree of restraint here when choosing your start and splice sites.

Search margins

By default, OMGene searches the region 600bp either side of the termini of each inputted gene. This buffer margin can be expanded or contracted as desired using the -b option, e.g.

python omgene.py -i path/to/gene_info_file.tdv -o output_folder -b 1000

Serving suggestion

It is recommended that orthogroups be obtained using OrthoFinder, implemented on primary transcripts only.

The results from OrthoFinder are outputted as a large, tab-delimited table of gene IDs. You will need to use these IDs to extract genomic GTF coordinates from your species GTF file, and produce a TDV input file as described above.

Reference species

If you do not wish to change all of the gene models in your species group, you may divide them into target and reference species. Target species are specified in a file given by the -i option, and reference species are specified in the file given by the -r option.

python omgene.py -i path/to/target_species.tdv -r path/to/reference_species.tdv -o output_folder

The target_species.tdv file should only contain the species whose genomes you would like to search, and the reference_species.tdv file should contain only species which you do not wish to search.

OMGene likes clean FASTA files.

The current iteration of OMGene requires that chromosome names in the genome FASTA files consist of unspaced IDs only (i.e. no description lines or information other than the name). This will be fixed in future versions. In the meantime, you may wish simply to modify the names of your chromosome entries using:

sed -r "s/>([^ ]+*) .*/>\1/g" genome.fa > genome_clean.fa

Obtaining GTFs from GFF3 files

OMGene uses GTF files for both its input and output, due to the superior uniformity of GTF naming and attribute conventions. To convert files from GFF3 to GTF format, we recommend using the simple tool fml_gff3togtf, from the Galaxy Tool Shed. This can be found at https://toolshed.g2.bx.psu.edu/repository?repository_id=afcb6456d8e300ed, and is implemented using python:

python gff_to_gtf.py infile.gff3 > outfile.gtf

Users should note that this tool truncates chromsome names to 15 characters. If this is going to be an issue, a wrapper for this script can be found in the utils directory in this repository (https://github.com/mpdunne/orthofiller/blob/master/utils/gff_to_gtf_safe.py). The above Galaxy tool should be downloaded first, and the path to its directory should be included in the appropriate place at the top of the gff_to_gtf_safe.py file. The full script can then be run as

python gff_to_gtf_safe.py infile.gff3 outfile.gtf

Note that, in order to function properly, the above conversion script requires that entries in the GFF3 input file are well-formed: that is they contina gene, mRNA, CDS, and exon entries for each gene. Ideally ensure that each GFF3 entry has each of these attributes before proceeding. Alternatively, if you simply wish to remove incomplete entries from your GFF3 file, you can use the clean_gff.py script, also included in the utils directory of this repository. The usage for this script is:

python clean_gff.py infile.gff3 infile_clean.gff3

Output File Format

OMGene output can be found in the results folder of the specified output directory. For each inputted gene, each of a CDS and amino acid FASTA file are produced, as well as a GTF file containing the genomic coordinates of the relevant gene.

Installing Dependencies

OMGene is written to run on linux and requires the following to be installed and in the system path:

  1. Python 2.7 together with the scipy, numpy, pyfaidx, networkx and BioPython libraries

  2. BedTools Suite

  3. Exonerate

python and scipy

Up-to-date and clear instructions are provided here: http://www.scipy.org/install.html, be sure to chose a version using python 2.7. As websites can change, an alternative is to search online for "install scipy".

BedTools

The BedTools suite can be downloaded from https://github.com/arq5x/bedtools2/releases

Exonerate

Exonerate can be downloaded from the EBI website, https://www.ebi.ac.uk/about/vertebrate-genomics/software/exonerate

Example results

alt text

Other useful software

OrthoFiller

OrthoFiller is a pipeline designed to help "fill in" gaps in the proteomes of a set of species, by searching for absent members of orthogroups.

https://github.com/mpdunne/orthofiller

Alan

Alan is an in-terminal command-line tool for viewing alignments without the need for a GUI.

https://github.com/mpdunne/alan

About

Mutual optimisation of gene models through gene orthology
