Could not load image metadata. #21168

Open
cycwll opened this Issue Oct 4, 2018 · 5 comments

Comments

Projects
None yet
5 participants
@cycwll

cycwll commented Oct 4, 2018

Description

I installed openshift cluster by ansible(version 3.10), one master, two compute node, one infra node.

I configured HTTP_PROXY and HTTPS_PROXY for docker in /etc/sysconfig/docker file(not in the ansible inventory file ), and I am sure that every node can be download the image by docker pull nginx.


Problem

I have a problem, when I Deploy Image to my project by OpenShift web console:

Could not load image metadata.
Internal error occurred: Get https://registry-1.docker.io/v2/: net/http: request canceled while waiting for connection (Client.Timeout exceeded while awaiting headers)


The same problem happened, when I by Image Stream Tag

#### [root@master ~]# oc get pod -n default
NAME                       READY     STATUS    RESTARTS   AGE
docker-registry-3-cwxfm    1/1       Running   0          19m
registry-console-1-2gjvz   1/1       Running   0          5h
router-4-c8kr7             1/1       Running   0          19m

#### [root@master ~]# oc get is -n openshift
NAME             DOCKER REPO                                                 TAGS                         UPDATED
dotnet           docker-registry.default.svc:5000/openshift/dotnet           2.0
dotnet-runtime   docker-registry.default.svc:5000/openshift/dotnet-runtime   2.0
httpd            docker-registry.default.svc:5000/openshift/httpd            2.4
jenkins          docker-registry.default.svc:5000/openshift/jenkins          1,2
mariadb          docker-registry.default.svc:5000/openshift/mariadb          10.1,10.2
mongodb          docker-registry.default.svc:5000/openshift/mongodb          3.2,3.4,2.4 + 1 more...
mysql            docker-registry.default.svc:5000/openshift/mysql            5.5,5.6,5.7
nginx            docker-registry.default.svc:5000/openshift/nginx            1.12,1.8,1.10
nodejs           docker-registry.default.svc:5000/openshift/nodejs           0.10,4,6 + 1 more...
perl             docker-registry.default.svc:5000/openshift/perl             5.24,5.16,5.20
php              docker-registry.default.svc:5000/openshift/php              5.5,5.6,7.0 + 1 more...
postgresql       docker-registry.default.svc:5000/openshift/postgresql       9.4,9.5,9.6 + 1 more...
python           docker-registry.default.svc:5000/openshift/python           3.3,3.4,3.5 + 2 more...
redis            docker-registry.default.svc:5000/openshift/redis            3.2
ruby             docker-registry.default.svc:5000/openshift/ruby             2.4,2.5,2.0 + 2 more...
wildfly          docker-registry.default.svc:5000/openshift/wildfly          10.0,10.1,11.0 + 3 more...
@jwforres

This comment has been minimized.

Show comment
Hide comment
Member

jwforres commented Oct 11, 2018

@bparees

This comment has been minimized.

Show comment
Hide comment
@bparees

bparees Oct 11, 2018

Contributor

@openshift/sig-user-interface I don't know what calls you guys are making in these flows, so i need details on that before i can help.

Contributor

bparees commented Oct 11, 2018

@openshift/sig-user-interface I don't know what calls you guys are making in these flows, so i need details on that before i can help.

@spadgett

This comment has been minimized.

Show comment
Hide comment
@spadgett

spadgett Oct 11, 2018

Member

For image name, we are using ImageStreamImport:

https://github.com/openshift/origin-web-console/blob/master/app/scripts/services/images.js#L23-L40

For image stream tag, we get the ImageStreamImage.

Member

spadgett commented Oct 11, 2018

For image name, we are using ImageStreamImport:

https://github.com/openshift/origin-web-console/blob/master/app/scripts/services/images.js#L23-L40

For image stream tag, we get the ImageStreamImage.

@bparees

This comment has been minimized.

Show comment
Hide comment
@bparees

bparees Oct 11, 2018

Contributor

@cycwll please run:

$ oc get istag nginx:1.10 -n openshift
NAME         IMAGE REF                                                                                                                  UPDATED
nginx:1.10   docker-registry.default.svc:5000/openshift/nginx@sha256:67a1757a7f4e4185b72dcac2a19efdfc82d59f574c3352d25c215c900653ea58   About a minute ago

then based on the output, run:

$ oc get imagestreamimage nginx@sha256:67a1757a7f4e4185b72dcac2a19efdfc82d59f574c3352d25c215c900653ea58 -n openshift

where you replace "sha256:xxxxxxxxxxxxxx" with the value you get from the first command (you can see I used the value from my output in my invocation)

I would expect you to see an output like:

NAME                                                                            UPDATED
nginx@sha256:67a1757a7f4e4185b72dcac2a19efdfc82d59f574c3352d25c215c900653ea58   About a minute ago
Contributor

bparees commented Oct 11, 2018

@cycwll please run:

$ oc get istag nginx:1.10 -n openshift
NAME         IMAGE REF                                                                                                                  UPDATED
nginx:1.10   docker-registry.default.svc:5000/openshift/nginx@sha256:67a1757a7f4e4185b72dcac2a19efdfc82d59f574c3352d25c215c900653ea58   About a minute ago

then based on the output, run:

$ oc get imagestreamimage nginx@sha256:67a1757a7f4e4185b72dcac2a19efdfc82d59f574c3352d25c215c900653ea58 -n openshift

where you replace "sha256:xxxxxxxxxxxxxx" with the value you get from the first command (you can see I used the value from my output in my invocation)

I would expect you to see an output like:

NAME                                                                            UPDATED
nginx@sha256:67a1757a7f4e4185b72dcac2a19efdfc82d59f574c3352d25c215c900653ea58   About a minute ago
@bparees

This comment has been minimized.

Show comment
Hide comment
@bparees

bparees Oct 11, 2018

Contributor

regarding this error:

Could not load image metadata.
Internal error occurred: Get https://registry-1.docker.io/v2/: net/http: request canceled while waiting for connection (Client.Timeout exceeded while awaiting headers)

That would point to your openshift apiserver being unable to talk to docker.io for some reason (possibly temporary).

Contributor

bparees commented Oct 11, 2018

regarding this error:

Could not load image metadata.
Internal error occurred: Get https://registry-1.docker.io/v2/: net/http: request canceled while waiting for connection (Client.Timeout exceeded while awaiting headers)

That would point to your openshift apiserver being unable to talk to docker.io for some reason (possibly temporary).
