Use standard json naming convention

[stuartnelson3]

This would probably require changes to every project, but I think it'd be nice to use standard JSON naming for the api, so instead of

{Type: "matrix",
 Value: [
  Metric: {},
  Values: [{Value: 1, Timestamp:1234428}]
}

it would be

{type: "matrix",
 value: [
  metric: {},
  values: [{values: 1, timestamp:1234428}]
}

thoughts?

[juliusv]

In general, 👍 and we should do this at some point, but copy from my email:

Hey,

Thanks. I agree that lower-case is the way to go in general, but as they say...

The problem is that we have a bunch of known and possibly unknown places using the existing JSON query API already, besides PromDash. [redacted]. We'll need to map those out and synchronize a bunch of stuff before rolling out an API change. Shouldn't be too hard, but it's not high enough on the priorities list right now to spend time on it. In general, it would be cool to think of a way to version APIs in the future. One possibility is putting the version in the path names, another could be using header-based version negotiation...

[brian-brazil]

If we change this, we should also change the format to be more compact. Rather than having a map per sample, a two item array would require transmitting fewer bytes over the wire.

[juliusv]

👍 - though I think compressed encodings should take care pretty well of maps per sample? Anyways, I'm for two-item arrays.

If we want to change this, we'd need to do it kind of now-ish. But from our side, it would require quite some careful change management to not break things in production.

[brian-brazil]

I'd suggest adding a url parameter that selects the output format, defaulting to the old format. At some point we can flip the default, and ultimately delete the old format.

[juliusv]

Actually it might be easier to change the query clients to support both formats for a while. Putting conditional switches into the nested JSON-marshaled types in the server would get complicated/inefficient.

This is a change which updates the format that the server produces:

https://github.com/prometheus/prometheus/compare/change-json?expand=1

For vectors, it looks like this:

{
   "version": 1,
   "type" : "vector",
   "value" : [
      {
         "timestamp" : 1421765411.045,
         "value" : "65.475000",
         "metric" : {
            "quantile" : "0.5",
            "instance" : "http://localhost:9090/metrics",
            "job" : "prometheus",
            "__name__" : "http_request_duration_microseconds",
            "handler" : "/static/",
            "method" : "get",
            "code" : "304"
         }
      },
      {
         "timestamp" : 1421765411.045,
         "value" : "5826.339000",
         "metric" : {
            "quantile" : "0.9",
            "instance" : "http://localhost:9090/metrics",
            "job" : "prometheus",
            "__name__" : "http_request_duration_microseconds",
            "handler" : "prometheus",
            "method" : "get",
            "code" : "200"
         }
      },
      /* ... */
   ]
}

For matrices, it looks like this:

{
   "version": 1,
   "type" : "matrix",
   "value" : [
      {
         "metric" : {
            "quantile" : "0.99",
            "instance" : "http://localhost:9090/metrics",
            "job" : "prometheus",
            "__name__" : "http_request_duration_microseconds",
            "handler" : "/static/",
            "method" : "get",
            "code" : "200"
         },
         "values" : [
            [
               1421765547.659,
               "29162.953000"
            ],
            [
               1421765548.659,
               "29162.953000"
            ],
            [
               1421765549.659,
               "29162.953000"
            ],
            /* ... */
         ]
      }
   ]
}

Does that look sane? I'll let it sit there in any case for a while because it needs some changes in the other components to be compatible with it.

[brian-brazil]

That looks sane to me.

[juliusv]

Updated to have a version number.
