AdVeil Prototype

Dependencies

• Microsoft SEAL 3.2.0
• GMP Library
• CMake
• Go 1.13 or higher

Getting everything to run (tested on Ubuntu 20.04.2 LTS)

0) Install dependencies (Ubuntu):	0) Install dependencies (CentOS):
sudo apt-get install build-essential	sudo yum groupinstall 'Development Tools'
sudo apt-get install cmake	sudo yum install cmake
sudo apt-get install libgmp3-dev	sudo yum install gmp-devel
sudo apt-get install golang-go	sudo yum install golang

1. Globally install Microsoft SEAL 3.2.0:

wget https://github.com/microsoft/SEAL/archive/refs/tags/v3.2.0.tar.gz
tar -xvf v3.2.0.tar.gz
cd SEAL-3.2.0/native/src
cmake .
make
sudo make install

2. Compile the SealPIR library in adveil/C/:

cd C/
cmake .
make -j

3. Run the desired experiment! (See next section)

Running experiments

1. On the Broker machine:

bash run_targeting.sh
    --port 8000 \
    --numprocs 1

2. On the client machine:

bash run_client.sh --brokerhost localhost --brokerport 8000 --trials 10 --autoclose

or cycle through all experiments at once:

bash clicycle.sh --brokerhost localhost --brokerport 8000 --trials 10 --autoclose

The client triggers the start of the experiment on the server. The targeting_params.sh script iterates through a parameters and initializes the server with the params. Each client run starts a new experiment under the specified parameters and saves it to a JSON file. Therefore, to cycle through all experiments, we re-run the client many times (e.g., 100); this is done automatically using clicycle.sh. Resulting experiment summary will be saved in the adveil/results directory.

Converting the generated files

All results as saved as .json files (one per experiment) in the adveil/results`` directory. Use concat.pyto merge multiple files into one.json``` array file.

python concat.py --dir ../results --out ../results/targeting.json

Issues with running on MacOS

While the code has been tested on MacOS (Big Sur), there is a bug in the cgo interface. On Linux, uint64_t is cast as C.ulong in the Go code which does not work on Mac (seems to be a bug?) The compiler will handle switching between two instances of sealpir.go to work around this issue.

Evaluating accuracy of the targeting data structure

Please see AdVeil Accuracy for instructions on reproducing the ANN accuracy experiments.

Acknowledgements

• Part of the anonymous token code was obtained from the Privacy Pass implementation.

Important Warning

This implementation of AdVeil is intended as a proof-of-concept prototype only! The code was implemented for research purposes and has not been vetted by security experts. As such, no portion of the code should be used in any real-world or production setting!
