transformed complex clips should be nerfed

[Gankra]

The boundary of the clipped content can't be clipped by anything, escaping parent stacking contexts and even overlapping the chrome.

pls nerf

Here's a slightly scaled and rotated div with border-radius inside an overflow:hidden parent div:

As you can see, the edge of the inner div has escape the parent, clippable by no mortal.

I've reduced this to the following capture, but need to call it a day:

scene.yaml

(
    root_pipeline_id: Some((1, 12)),
    pipelines: {
        (1, 12): (
            pipeline_id: (1, 12),
            viewport_size: (3205, 1830),
            content_size: (3205, 1830),
            background_color: None,
            display_list: [
                (
                    item: PushStackingContext((
                        stacking_context: (
                            scroll_policy: Scrollable,
                            transform: None,
                            transform_style: Flat,
                            perspective: None,
                            mix_blend_mode: Normal,
                            reference_frame_id: None,
                            clip_node_id: None,
                            glyph_raster_space: Screen,
                        ),
                    ), [
                    ]),
                    clip_and_scroll: (
                        scroll_node_id: Clip(1, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (0, 0)),
                        clip_rect: ((0, 0), (0, 0)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [0]
                (
                    item: Rectangle((
                        color: (
                            r: 1,
                            g: 1,
                            b: 1,
                            a: 1,
                        ),
                    )),
                    clip_and_scroll: (
                        scroll_node_id: Clip(1, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [1]
                (
                    item: Rectangle((
                        color: (
                            r: 0,
                            g: 0,
                            b: 0,
                            a: 0,
                        ),
                    )),
                    clip_and_scroll: (
                        scroll_node_id: Clip(1, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: Some((0, 1)),
                    ),
                ),// [2]
                (
                    item: Clip((
                        id: Clip(2, (1, 12)),
                        image_mask: None,
                    ), [
                    ]),
                    clip_and_scroll: (
                        scroll_node_id: Clip(1, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [3]
                (
                    item: ScrollFrame((
                        clip_id: Clip(3, (1, 12)),
                        scroll_frame_id: Clip(4, (1, 12)),
                        external_id: Some((2, (1, 12))),
                        image_mask: None,
                        scroll_sensitivity: Script,
                    ), [
                    ]),
                    clip_and_scroll: (
                        scroll_node_id: Clip(2, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [4]
                (
                    item: Rectangle((
                        color: (
                            r: 0,
                            g: 0,
                            b: 0,
                            a: 0,
                        ),
                    )),
                    clip_and_scroll: (
                        scroll_node_id: Clip(4, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: Some((2, 1)),
                    ),
                ),// [5]
                (
                    item: Clip((
                        id: Clip(5, (1, 12)),
                        image_mask: None,
                    ), [
                    ]),
                    clip_and_scroll: (
                        scroll_node_id: Clip(4, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [6]
                (
                    item: Rectangle((
                        color: (
                            r: 0,
                            g: 0,
                            b: 0,
                            a: 0,
                        ),
                    )),
                    clip_and_scroll: (
                        scroll_node_id: Clip(5, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: Some((2, 1)),
                    ),
                ),// [7]
                (
                    item: Rectangle((
                        color: (
                            r: 1,
                            g: 1,
                            b: 1,
                            a: 1,
                        ),
                    )),
                    clip_and_scroll: (
                        scroll_node_id: Clip(5, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (3205, 1830)),
                        clip_rect: ((0, 0), (3205, 1830)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [8]
                (
                    item: Clip((
                        id: Clip(6, (1, 12)),
                        image_mask: None,
                    ), [
                    ]),
                    clip_and_scroll: (
                        scroll_node_id: Clip(4, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((20, 20), (2400, 900)),
                        clip_rect: ((20, 20), (2400, 900)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [9]
                (
                    item: PushStackingContext((
                        stacking_context: (
                            scroll_policy: Scrollable,
                            transform: Some(Value((1.0249937772750854, 0.003577917581424117, 0, 0, -0.003577917581424117, 1.0249937772750854, 0, 0, 0, 0, 1, 0, -28.3824462890625, -15.540679931640625, 0, 1))),
                            transform_style: Flat,
                            perspective: None,
                            mix_blend_mode: Normal,
                            reference_frame_id: Some(Clip(7, (1, 12))),
                            clip_node_id: None,
                            glyph_raster_space: Screen,
                        ),
                    ), [
                    ]),
                    clip_and_scroll: (
                        scroll_node_id: Clip(6, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((20, 20), (0, 0)),
                        clip_rect: ((20, 20), (0, 0)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [10]
                (
                    item: Rectangle((
                        color: (
                            r: 0,
                            g: 0,
                            b: 0,
                            a: 0,
                        ),
                    )),
                    clip_and_scroll: (
                        scroll_node_id: Clip(6, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (2400, 900)),
                        clip_rect: ((0, 0), (2400, 900)),
                        is_backface_visible: true,
                        tag: Some((2, 1)),
                    ),
                ),// [11]
                (
                    item: Clip((
                        id: Clip(8, (1, 12)),
                        image_mask: None,
                    ), [
                        (
                            rect: ((0, 0), (2400, 900)),
                            radii: (
                                top_left: (5, 5),
                                top_right: (5, 5),
                                bottom_left: (5, 5),
                                bottom_right: (5, 5),
                            ),
                            mode: Clip,
                        ),// [0]
                    ]),
                    clip_and_scroll: (
                        scroll_node_id: Clip(6, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (2400, 900)),
                        clip_rect: ((0, 0), (2400, 900)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [12]
                (
                    item: Rectangle((
                        color: (
                            r: 0,
                            g: 0,
                            b: 0,
                            a: 1,
                        ),
                    )),
                    clip_and_scroll: (
                        scroll_node_id: Clip(8, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (2400, 900)),
                        clip_rect: ((0, 0), (2400, 900)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [13]
                (
                    item: PopStackingContext,
                    clip_and_scroll: (
                        scroll_node_id: Clip(6, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (0, 0)),
                        clip_rect: ((0, 0), (0, 0)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [14]
                (
                    item: PopStackingContext,
                    clip_and_scroll: (
                        scroll_node_id: Clip(1, (1, 12)),
                        clip_node_id: None,
                    ),
                    info: (
                        rect: ((0, 0), (0, 0)),
                        clip_rect: ((0, 0), (0, 0)),
                        is_backface_visible: true,
                        tag: None,
                    ),
                ),// [15]
            ],
        ),
    },
    pipeline_epochs: {
        (1, 12): (3),
    },
)

[Gankra]

bugzilled: https://bugzilla.mozilla.org/show_bug.cgi?id=1455839

(contains the html version of this testcase)

[glennw]

@mrobinson Have you got cycles to take a look at this one?

[mrobinson]

@glennw Sure. I'm happy to take a look at this one.

@gankro Can you comment on what I should expect from the output of this test case? Changing the size of the scroll frame seems to clip the interior black rectangle just fine, but perhaps I'm missing something...

[Gankra]

@mrobinson check out https://bug1455839.bmoattachments.org/attachment.cgi?id=8971412 in vanilla firefox

[Gankra]

tl;dr: you should just see a solid black rect.

[mrobinson]

Here's some wrench yaml showing a reduced test case

---
root:
  items:
    - type: clip
      bounds: [100, 100, 100, 100]
      id: 2
    -
      type: stacking-context
      clip-and-scroll: 2
      transform: rotate(0.25)
      items:
       - type: clip
         bounds: [0, 0, 2400, 900]
         id: 3
         complex:
           - rect: [ 0, 0, 2400, 900 ]
             radius: 50
       - type: rect
         color: [0, 255, 0, 1]
         bounds: [0, 0, 2400, 900]
         clip-and-scroll: 3

There should be a single green 100x100 rectangle at 100x100. Instead an area the size of the radius of the interior clip shows up surrounding the 100x100 rectangle. This seems to be a bad interaction between the rotation and a clip with a radius. The rotation suggests that it's an issue that involves complex clips that span coordinate systems.
