Planar Bridge

Planar Bridge downloads and maintains a local library of high-quality card scans from Magic: the Gathering.

Scans come from Scryfall, and the bulk set and card metadata that drives the downloads comes from MTGJSON.

Planar Bridge also upgrades resolution over time. If a scan stored locally is low-res and Scryfall later publishes a high-res version, for instance once a newly spoiled set gets rescanned, Planar Bridge replaces the old file.

Installation

Planar Bridge runs on Linux and macOS. Windows should work too, though it hasn't been tested there yet. It requires Python 3.13 or later, so check your installed version if you're unsure:

$ python3 -V
Python 3.13.0

(note that lines in code blocks beginning with $ mean this line is used as a user-executed command)

To install Planar Bridge, start by cloning this repository.

$ git clone --depth=1 https://github.com/van-riper/planar-bridge.git

Then set up the environment with uv, which installs the runtime and development dependencies into a local virtual environment:

$ uv sync

Usage

To run Planar Bridge, use the planar-bridge console script (or the equivalent module form, uv run python -m planar_bridge):

$ uv run planar-bridge
[12:34:56] INFO: Comparing local & source files...
...

Planar Bridge then begins the download process. Downloading every card scan can take several hours, even on a fast connection, but you can kill the program at any point and start it later. It resumes exactly where it left off.

MTGJSON's bulk database is pinned to a specific version. If your locally cached copy has drifted from that version, Planar Bridge asks you to confirm before continuing; pass -y to skip that prompt.

Useful flags:

$ uv run planar-bridge --set LEA --set LEB   # restrict the run to these sets
$ uv run planar-bridge --dry-run             # report what would download, write nothing
$ uv run planar-bridge --language de         # override the configured card language
$ uv run planar-bridge -y                    # skip the MTGJSON version-drift prompt

Data directory

Planar Bridge stores all card scans, bulk data, and its catalog database outside the repo, in a data directory it creates on first run. Resolution order:

1. $PLANAR_BRIDGE_DIR, if set
2. $HOME/.local/share/planar-bridge (Linux/macOS) or %APPDATA%/planar-bridge (Windows)

This reads $HOME and %APPDATA% directly; it does not check $XDG_DATA_HOME.

Here is an example layout of that directory with some example set codes and phony UUIDs:

planar-bridge/                 (the data directory)
├─ .mtgjson/
│  ├─ AllPrintings.sqlite
│  └─ Meta.json
├─ catalog.sqlite
├─ planar-bridge.toml
├─ LEA/
│  ├─ tokens/
│  │  ├─ 01234567-89ab-cdef-0123-456789abcdef.jpg
│  │  └─ ...
│  ├─ 01234567-89ab-cdef-fedc-ba9876543210.jpg
│  ├─ fedcba98-7654-3210-0123-456789abcdef.jpg
│  └─ ...
├─ LEB/
│  └─ ...
└─ ...

Planar Bridge names card image files after that card's UUID from MTGJSON's database. Cards that share a single image across two faces (split, flip, adventure, aftermath layouts) are named by joining both UUIDs with _. At this time, there is no way to name a card file according to that card's name.

.mtgjson/ holds the MTGJSON bulk database (AllPrintings.sqlite) and its metadata (Meta.json), fetched once and reused on later runs. catalog.sqlite is a small SQLite database recording each downloaded card's resolution; it's what lets a killed run resume from exactly where it left off. Do not modify or delete it, since it drives both resuming and resolution upgrades.

Development

Planar Bridge is developed with uv. After uv sync, the dev tooling runs through uv run:

$ uv run pytest                    # run the test suite
$ uv run ruff check src tests      # lint
$ uv run ruff format src tests     # format
$ uv run ty check                  # type-check

Configuration

If you want to configure Planar Bridge, copy planar-bridge.example.toml from this repo to planar-bridge.toml inside your data directory (see Data directory above).

Configuration options let you enable reprints, set a preferred card language, and choose which sets, set types, and promo types to exclude from the download process. For more information on set and promo types, visit MTGJSON.

Configuration is limited for now. If you have a suggestion for more options, feel free to open an issue.

Terms of Use

By downloading and running this program, you agree to Wizards of the Coast's Fan Content Policy as well as Scryfall's Terms of Service. If you have any questions about what you can or cannot do under these policies, read the linked terms and FAQs carefully.

This program respects the 50 - 100 millisecond request rate limit that Scryfall states on its website:

We kindly ask that you insert 50 – 100 milliseconds of delay between the requests you send to the server at api.scryfall.com. (i.e., 10 requests per second on average).

Submitting excessive requests to the server may result in a HTTP 429 Too Many Requests status code. Overloading the API after this point may result in a temporary or permanent ban of your IP address. Applications that continously recieve rate limit warnings over a longer period may also be blocked.

- Scryfall's API homepage (Sep 2024)

Do not modify or remove this program's built-in rate limiter, which keeps every request to Scryfall under that limit. If you remove it, your IP address will likely get blocked, either temporarily or permanently.

With that said, Planar Bridge and its developers accept no responsibility for incidents that breach WotC's, Scryfall's, and/or Planar Bridge's terms and conditions.

Credits

Logo based on the 'Portal' design by Lorc.

License

This project is under the MIT License. See LICENSE for details.
