Fix clang submodules #1982

aacirino · 2022-01-17T19:02:53Z

I made this pull request due to build failures with submodules and clang 13. I've tested it with the project xmake/tests/projects/c++/modules/submodules and it runs as expected.

…mefix

waruqi · 2022-01-17T23:46:31Z

xmake/rules/c++/modules/build_modules/module_parser.lua

-                local moduleinfo = data.moduleinfo
-                moduledeps = moduledeps or {}
-                moduledeps[moduleinfo.name] = moduleinfo
+                if data.moduleinfo then


and

local moduleinfo = data.moduleinfo if moduleinfo then moduledeps = moduledeps or {} moduledeps[moduleinfo.name] = moduleinfo end

waruqi · 2022-01-17T23:47:16Z

xmake/rules/c++/modules/build_modules/clang.lua

@@ -100,6 +100,14 @@ function build_with_batchjobs(target, batchjobs, sourcebatch, opt)
            opt2.objectfile = modulefiles[i]
            opt2.dependfile = target:dependfile(opt2.objectfile)
            opt2.sourcekind = assert(sourcebatch.sourcekind, "%s: sourcekind not found!", sourcefile)
+            if moduledep["deps"] then


use moduledep.deps moduledep.name

waruqi · 2022-01-17T23:48:22Z

xmake/rules/c++/modules/build_modules/clang.lua

+                    if found == nil then
+                        target:add("cxxflags", "-fmodule-file=" .. modulefile, {force = true})
+                    end
+                end


why? The code below will add it

xmake/xmake/rules/c++/modules/build_modules/clang.lua

Lines 122 to 129 in 1b2a5da

count = count + 1

if count == sourcefiles_total then

target:add("cxxflags", modulesflag, "-fmodules-cache-path=" .. cachedir, {force = true})

-- FIXME It is invalid for the module implementation unit

--target:add("cxxflags", "-fimplicit-modules", "-fimplicit-module-maps", "-fprebuilt-module-path=" .. cachedir, {force = true})

for _, modulefile in ipairs(modulefiles) do

target:add("cxxflags", "-fmodule-file=" .. modulefile, {force = true})

end

The code above doesn't add the pcm file to the compilation.

We've turned on -fimplicit-modules and module cache, clang should find submodules without explicitly setting -fmodule-file.

The root cause of it is that the module files for cache/module1.pcm are not named correctly, in case of submodules, it should be cache/main_module.module1.pcm so that clang can find them correctly.

I have tested your demo project and confirmed that it can be fixed successfully.

waruqi · 2022-01-18T01:16:53Z

I can't reproduce it, It work fine here

xmake f --toolchain=clang-13 -cvD;xmake -r
checking for platform ... linux
checking for architecture ... x86_64
checking for clang-13 ... /usr/bin/clang-13
configure
{
    ndk_stdcxx = true
    ccache = true
    arch = x86_64
    mode = release
    buildir = build
    toolchain = clang-13
    clean = true
    plat = linux
    host = linux
    kind = static
}
[ 14%]: ccache compiling.release src/math.math1.mpp
[ 14%]: ccache compiling.release src/math.math2.mpp
[ 42%]: ccache compiling.release src/math.mpp
[ 57%]: ccache compiling.release src/main.cpp
[ 71%]: linking.release math
[100%]: build ok!

Can you give a reproducible example? or provide your error output?

aacirino · 2022-01-18T13:09:04Z

This is the complete flow that led to the error and the build with my patches

[~/git/modfix]$ tree
.
├── build
│   └── linux
│       └── x86_64
│           └── release
├── p.lua
├── src
│   ├── main.cpp
│   ├── main_module.mpp
│   ├── module1.cpp
│   ├── module1.mpp
│   ├── module2.cpp
│   └── module2.mpp
└── xmake.lua

5 directories, 8 files
[~/git/modfix]$ cat src/main.cpp
import main_module;

int main(int argc, char** argv) {
  hello1();
  hello2();
  return 0;
}
[~/git/modfix]$ cat src/main_module.mpp
export module main_module;

export import main_module.module1;
export import main_module.module2;

export void hello() {
  hello1();
  hello2();
}
[~/git/modfix]$ cat src/module1.mpp
export module main_module.module1;

export void hello1(void);
[~/git/modfix]$ cat src/module1.cpp
module main_module.module1;

import <iostream>;

void hello1(void) {
  std::cout << "Hello One\n";
}
[~/git/modfix]$ cat src/module2.mpp
export module main_module.module2;

export void hello2(void);
[~/git/modfix]$ cat src/module2.cpp
module main_module.module2;

import <iostream>;

void hello2(void) {
  std::cout << "Hello Two\n";
}
[~/git/modfix]$ cat xmake.lua
add_rules("mode.debug", "mode.release")

target("modfix")
    set_kind("binary")
    add_files("src/*.cpp", "src/*.mpp")
    add_includedirs(
      "/usr/local/include",
      "$(shell brew --prefix)/include",
      "$(shell brew --prefix)/opt/llvm/include"
    )
    add_cxxflags(
      "-march=native",
      "-std=c++20",
      "-isystem $LLVM_DIR/include/c++/v1/include",
      "-stdlib=libc++"
    )
    add_ldflags(
      "-fuse-ld=mold"
    )
    add_links("c++")
target_end()
[~/git/modfix]$ which xmake
/home/linuxbrew/.linuxbrew/bin/xmake
[~/git/modfix]$ xmake clean && clear && xmake -b -v -j 6
generating.moduledeps src/module1.mpp
generating.moduledeps src/module2.mpp
generating.moduledeps src/main_module.mpp
[ 11%]: ccache compiling.release src/module1.mpp
/home/linuxbrew/.linuxbrew/bin/ccache /home/linuxbrew/.linuxbrew/opt/llvm/bin/clang -c -Qunused-arguments -m64 -fvisibility=hidden -fvisibility-inlines-hidden -O3 -I/usr/local/include -I/home/linuxbrew/.linuxbrew/include -I/home/linuxbrew/.linuxbrew/opt/llvm/include -march=native -std=c++20 -isystem $LLVM_DIR/include/c++/v1/include -stdlib=libc++ -DNDEBUG -fmodules -fimplicit-modules -fimplicit-module-maps -fprebuilt-module-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache --precompile -x c++-module -fmodules-cache-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache -o build/.gens/modfix/linux/x86_64/release/rules/modules/cache/module1.pcm src/module1.mpp
[ 11%]: ccache compiling.release src/module2.mpp
/home/linuxbrew/.linuxbrew/bin/ccache /home/linuxbrew/.linuxbrew/opt/llvm/bin/clang -c -Qunused-arguments -m64 -fvisibility=hidden -fvisibility-inlines-hidden -O3 -I/usr/local/include -I/home/linuxbrew/.linuxbrew/include -I/home/linuxbrew/.linuxbrew/opt/llvm/include -march=native -std=c++20 -isystem $LLVM_DIR/include/c++/v1/include -stdlib=libc++ -DNDEBUG -fmodules -fimplicit-modules -fimplicit-module-maps -fprebuilt-module-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache --precompile -x c++-module -fmodules-cache-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache -o build/.gens/modfix/linux/x86_64/release/rules/modules/cache/module2.pcm src/module2.mpp
/home/linuxbrew/.linuxbrew/bin/ccache /home/linuxbrew/.linuxbrew/opt/llvm/bin/clang -c -Qunused-arguments -m64 -fvisibility=hidden -fvisibility-inlines-hidden -O3 -I/usr/local/include -I/home/linuxbrew/.linuxbrew/include -I/home/linuxbrew/.linuxbrew/opt/llvm/include -march=native -std=c++20 -isystem $LLVM_DIR/include/c++/v1/include -stdlib=libc++ -DNDEBUG -fmodules -fmodules-cache-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache -fimplicit-modules -fimplicit-module-maps -fprebuilt-module-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache -o build/.objs/modfix/linux/x86_64/release/src/module1.mpp.o build/.gens/modfix/linux/x86_64/release/rules/modules/cache/module1.pcm
/home/linuxbrew/.linuxbrew/bin/ccache /home/linuxbrew/.linuxbrew/opt/llvm/bin/clang -c -Qunused-arguments -m64 -fvisibility=hidden -fvisibility-inlines-hidden -O3 -I/usr/local/include -I/home/linuxbrew/.linuxbrew/include -I/home/linuxbrew/.linuxbrew/opt/llvm/include -march=native -std=c++20 -isystem $LLVM_DIR/include/c++/v1/include -stdlib=libc++ -DNDEBUG -fmodules -fmodules-cache-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache -fimplicit-modules -fimplicit-module-maps -fprebuilt-module-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache -o build/.objs/modfix/linux/x86_64/release/src/module2.mpp.o build/.gens/modfix/linux/x86_64/release/rules/modules/cache/module2.pcm
[ 33%]: ccache compiling.release src/main_module.mpp
/home/linuxbrew/.linuxbrew/bin/ccache /home/linuxbrew/.linuxbrew/opt/llvm/bin/clang -c -Qunused-arguments -m64 -fvisibility=hidden -fvisibility-inlines-hidden -O3 -I/usr/local/include -I/home/linuxbrew/.linuxbrew/include -I/home/linuxbrew/.linuxbrew/opt/llvm/include -march=native -std=c++20 -isystem $LLVM_DIR/include/c++/v1/include -stdlib=libc++ -DNDEBUG -fmodules -fimplicit-modules -fimplicit-module-maps -fprebuilt-module-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache --precompile -x c++-module -fmodules-cache-path=build/.gens/modfix/linux/x86_64/release/rules/modules/cache -o build/.gens/modfix/linux/x86_64/release/rules/modules/cache/main_module.pcm src/main_module.mpp
error: src/main_module.mpp:3:15: fatal error: module 'main_module.module1' not found
export import main_module.module1;
       ~~~~~~~^~~~~~~~~~~
1 error generated.
[~/git/modfix]$ /usr/local/bin/xmake.new clean && /usr/local/bin/xmake.new -b -j 6
[ 11%]: ccache compiling.release src/module1.mpp
[ 11%]: ccache compiling.release src/module2.mpp
[ 33%]: ccache compiling.release src/main_module.mpp
[ 44%]: ccache compiling.release src/module2.cpp
[ 44%]: ccache compiling.release src/module1.cpp
[ 44%]: ccache compiling.release src/main.cpp
[ 77%]: linking.release modfix
[100%]: build ok!
[~/git/modfix]$ /usr/local/bin/xmake.new r
Hello One
Hello Two

waruqi · 2022-01-18T13:14:10Z

can you upload your demo project?

aacirino · 2022-01-18T14:31:52Z

The zip file is attached modfix.zip <https://drive.google.com/file/d/1nSYd-79nsJKSkJQaiAg7TzvQ5fuQdx1_/view?usp=drivesdk> Em ter., 18 de jan. de 2022 10:14, ruki ***@***.***> escreveu:

…

can you upload your demo project? — Reply to this email directly, view it on GitHub <#1982 (comment)>, or unsubscribe <https://github.com/notifications/unsubscribe-auth/AARARENZQEEA3HBCJHGOO5LUWVRS3ANCNFSM5MFMM3MA> . You are receiving this because you authored the thread.Message ID: ***@***.***>

waruqi · 2022-01-18T14:34:56Z

thanks, I will look at it in these days

waruqi · 2022-01-19T00:58:57Z

The zip file is attached modfix.zip https://drive.google.com/file/d/1nSYd-79nsJKSkJQaiAg7TzvQ5fuQdx1_/view?usp=drivesdk Em ter., 18 de jan. de 2022 10:14, ruki @.> escreveu:
…
can you upload your demo project? — Reply to this email directly, view it on GitHub <#1982 (comment)>, or unsubscribe https://github.com/notifications/unsubscribe-auth/AARARENZQEEA3HBCJHGOO5LUWVRS3ANCNFSM5MFMM3MA . You are receiving this because you authored the thread.Message ID: @.>

I cannot downlload it, can you upload it to github issues attachment?

waruqi · 2022-01-19T02:21:40Z

I added your demo project as test. https://github.com/xmake-io/xmake/tree/dev/tests/projects/c%2B%2B/modules/submodules2

aacirino · 2022-01-19T12:08:13Z

Here follows the test project
modfix.zip

waruqi · 2022-01-19T12:14:34Z

Does it work for this patch now?

aacirino · 2022-01-19T14:42:32Z

Yes, I merged the latest master commits and it is working fine. Thanx

aacirino added 7 commits July 15, 2021 23:23

Merge remote-tracking branch 'upstream/master'

81ad292

Merge branch 'master' of https://github.com/xmake-io/xmake

286ba62

Little modifications to modules build

885d00d

Merged from upstream/master

ed0c0c5

Merge branch 'master' of https://github.com/xmake-io/xmake into modna…

274244b

…mefix

Merge branch 'master' of https://github.com/xmake-io/xmake into modna…

92978c6

…mefix

Solved building submodules with clang

1b2a5da

waruqi reviewed Jan 17, 2022

View reviewed changes

waruqi added 2 commits January 19, 2022 09:55

Update clang.lua

cc30e77

Update module_parser.lua

f4056be

waruqi merged commit 093fcdb into xmake-io:dev Jan 19, 2022
