Zenscroll

Demo         Download         About         Install         How to use         License

One JavaScript to Smooth-Scroll Them All

Smooth animated scrolling. Move elements into view, or scroll to any vertical position.

1.4 kilobyte of vanilla JavaScript. No dependencies.

About

Zenscroll is a vanilla JavaScript library that enables animated vertical scrolling to an element or position within your document or within a scrollable element (DIV, etc.). It can also automatically smooth all scrolling within the same page.

Features:

  • Smooth animated vertical scrolling.
  • Automatic smooth-scrolling on links within the same page, including back and forward navigation (Chrome, Firefox, Opera, Safari Technology Preview).
  • Scroll to the top of a specific element.
  • Scrolling an element into view, making sure both top & bottom are visible, if possible.
  • Scroll to an element and center it on the screen.
  • Specify the spacing between the element and the edge of the screen (e.g., for fixed navigation bars and footers).
  • Customize the duration of the individual scroll operations.
  • Callback when the scrolling is done.
  • Can use new browser’s built-in smooth-behavior if it’s enabled.
  • Just 1.4 kilobyte minimized & gzipped.
  • No dependencies.

Full support tested and works under:

  • Android Browser 2.2+
  • Chrome for Android
  • Chrome 14+ (probably earlier too)
  • Edge
  • Firefox 9+
  • Internet Explorer 9+
  • iOS Safari 4+
  • Opera 10.6+ (probably earlier too)
  • Safari 4+
  • Windows Phone 8.1
  • Yandex 14.12

Limited support (programmatic animated scroll in document) tested and works under:

  • Firefox 3+
  • Internet Explorer 6+
  • iOS Safari 3+

Getting Started

Installing Zenscroll

Download Zenscroll and include it into your page. A good place is at the very bottom, just before the closing </body> tag. For example:

    ...
    <script src="zenscroll-min.js"></script>
</body>

Zenscroll will also work if you reference it in the <head> but it is not recommended for performance reasons. Important: You can only call Zenscroll when document.body is already available, so don’t try to call Zenscroll functions from the <head>.

You can also get Zenscroll via npm:

npm install zenscroll

Enabling native smooth-scrolling in the browser

If you want to leverage the native smooth-scrolling by the browser (currently available in Firefox 36+ and Chrome 49+) then set the scroll-behavior CSS property to smooth on the body and on the elements you want to scroll. E.g.,

body, .smooth-container { scroll-behavior: smooth }

If this is set, Zenscroll will use built-in smooth-scrolling in capable browsers while still animating the scroll in older browsers. However, note that if you use the native smooth-scrolling then you loose the finer control options that Zenscroll offers: the speed settings of the animation, and the edge offset for links within the page. Only set this CSS property on the body or on the elements if you don’t need this level of control.

Disabling automatic smoothing on local links

If you want to use Zenscroll programmatically but you don’t need the automatic smoothing on local links then set window.noZensmooth to a non-falsy value. In this case the event handler for automatic smoothing is not installed but you can still use everything, like zenscroll.intoView(), etc.

It’s important to set this value before Zenscroll is executed, otherwise the handlers will be installed. So make sure the setting comes before the loading of the script. For example:

    ...
    <script>window.noZensmooth = true</script>
    <script src="zenscroll-min.js"></script>
</body>

(I consider the disabling of the automatic smooth-scrolling a rather rare scenario that’s why I install the event handlers by default.)

How to use

1. Automatic smooth-scroll to links within the page

If Zenscroll is included in your page it will automatically animate the vertical scrolling to anchors on the same page. No further setting is required. (Note that it can be disabled, see 1.5.)

Automatic smooth-scrolling works also with content you dynamically load via AJAX, as Zenscroll uses a generic click handler. Since the automatic smooth-scrolling is implemented a progressive enhancement, internal links work in older browsers as well.

1.1. Automatic edge offset adjustment on load

Zenscroll automatically adds the configured edge offset when the page is loaded with a hash suffix. For example, if you navigate to "http://yoursite.com/#about" then the scroll position will be not cut sharply at the top edge of the element with id="above". Instead, Zenscroll automatically adds the configured edge offset (which is 9 pixels by default, unless you changed it).

No automatic adjustment happens in the following cases:

  • If automatic smooth-scroll is disabled via noZensmooth or the native smooth-scrolling (see 1.5)
  • If edge offset was set to zero (e.g., zenscroll.setup(null, 0)).

1.2. Limited support for smooth back & forward navigation

The scroll is also animated when the browser’s back and forward buttons or the relevant key combinations are used (or even if the navigation is invoked from JavaScript). Note that although Zenscroll remembers the vertical scroll position, it cannot calculate changes caused by browser window resizing or collapsing/expanding elements, etc.

This functionality requires browser support for history.scrollRestoration which is available for example in Chrome 46+, Firefox 46+, and Safari Technology Preview.

1.3. Limited support for the hashchange event and the CSS pseudo :target

The automatic smooth-scroll on local links can also trigger the standard hashchange event and the CSS pseudo-class :target but only if you set the edge offset to 0. I had to introduce this limitation because otherwise the scrolling isn’t smooth.

So if you need hashchange or :target then make sure you execute zenscroll.setup(null, 0).

1.4. No support for automatic scroll to elements inside scrollable elements

Zenscroll wants to be a lightweight solution for animated vertical scrolling, that works in most browsers. The automatic link-scrolling is even more focused on anchors that are directly inside the page body. Unfortunately it won’t scroll accurately to elements that are inside other scrollable elements (e.g., overflow: auto; max-height: 100px). Don’t expect Zenscroll to re-implement the full functionality of the browser, with the recursive logic of traversing the nested scrollable elements.

So, how to deal with a situation like this? Try one of the following methods:

  • Exclude the problematic links from the automatic smooth-scrolling (see 1.6.).
  • Or implement the special logic programatically (see 7. Scroll inside a scrollable DIV).
  • Or don’t use Zenscroll at all. Instead, rely on the browser’s built-in scrolling, and enable the native smooth-scrolling (via body { scroll-behavior: smooth }) which works in new browsers.

1.5. Disable the automatic smooth-scrolling

The automatic smooth-scrolling is completely disabled in the following cases:

  1. If you set window.noZensmooth to a non-falsy value (see above).
  2. In new browsers if the scroll-behavior CSS property is set to smooth on the body (see above). In this case Zenscroll will only enable automatic smooth-scrolling in browsers which don’t support this feature yet (e.g., Internet Explorer).

1.6. Exclude a link from the automatic smooth-scrolling

If you want only some of the links to be excluded from the automatic smoothing then do one of the following:

  1. Add the class noZensmooth to the anchor element, for example <a href="#about" class="noZensmooth">
  2. Alternatively, start with the path of the page. E.g., instead of writing <a href="#about"> use <a href="/#about"> or <a href="index.html#about">.

2. Scroll to the top of an element

var about = document.getElementById("about")
zenscroll.to(about)

Note that Zenscroll intentionally leaves a few pixels (by default 9px) from the edges of the screen or scrolling container. If you have a fixed navigation bar or footer bar then you probably need more than that. Or you may want to set it to zero. You can globally override the default value by calling zenscroll.setup() (see below), or by providing the edgeOffset parameter when you create a scroller for a DIV, e.g., zenscroll.createScroller(myDiv, null, 20)

3. Scroll to a specific vertical position

zenscroll.toY(50)

4. Scroll an element into view

If the element is already fully visible, with the edge offset at the top and bottom, then no scroll is performed. Otherwise Zenscroll will try to make both top & bottom of element visible, if possible. If the element is higher than the visible viewport then it will simply scroll to the top of the element, including the edge offset.

zenscroll.intoView(image1)

Tip: If you resize an element with a transition of 500ms, you can postpone calling zenscroll with that amount of time:

image.classList.remove("is-small")
setTimeout(function () {
    zenscroll.intoView(image2)
}, 500)

5. Scrolls the element to the center of the screen

zenscroll.center(image2)

If you want you can also define an offset. The top of the element will be upwards from the center of the screen by this amount of pixels. (By default offset is the half of the element’s height.)

var duration = 500 // milliseconds
var offset = 200 // pixels
zenscroll.center(image2, duration, offset)

Note that a zero value for offset is ignored. You can work around this by using zenscroll.toY().

6. Set the duration of the scroll

The default duration is 999 which is ~1 second. The duration is automatically reduced for elements that are very close. You can specifically set the duration for each scroll function via an optional second parameter. If you pass a value of zero then the scroll happends immediately, without smoothing.

Examples:

zenscroll.toY(50, 100) // 100ms == 0.1 second
zenscroll.to(about, 500) // 500ms == half a second
zenscroll.center(image2, 2000) // 2 seconds
zenscroll.to(about, 0) // 0 milliseconds == no smoothing

7. Scroll inside a scrollable DIV

Anything you can do within the document you can also do inside a scrollable DIV or other element. You just need to instantiate a new scroller for that element. I will also fall back by default to the native browser smooth-scrolling if available (which can be overridden via setup()).

Important: the container DIV must have its position CSS property set to relative, absolute or fixed. If you want to keep it in the normal document flow, just assign position: relative to it via a class or a style attribute, like in the example below:

<div id="container" style="position: relative">
  <div id="item1">ITEM 1</div>
  <div id="item2">ITEM 2</div>
  <div id="item3">ITEM 3</div>
  <div id="item4">ITEM 4</div>
  <div id="item5">ITEM 5</div>
  <div id="item6">ITEM 6</div>
  <div id="item7">ITEM 7</div>
</div>

<script>
  var defaultDuration = 500
  var edgeOffset = 30
  var myDiv = document.getElementById("container")
  var myScroller = zenscroll.createScroller(myDiv, defaultDuration, edgeOffset)
  var target = document.getElementById("item4")
  myScroller.center(target)
</script>

Obviously you can use all other scroll functions and parameters with the scrollable container. Two more examples:

myScroller.toY(500)
myScroller.intoView(target)

8. Execute something when the scrolling is done

You can provide a callback function to all four scroll functions, which is executed when the scroll operation is finished. For example, you change some UI elements but first you want to make sure that the relevant elements are visible.

Note that the callback is immediately invoked if the native scroll-smoothing is enabled (see above).

If you look at the source code of the examples under Scroll inside a scrollable DIV they are actually implemented like this:

// Last line of example 1:
zenscroll.intoView(container, 100, function () { myScroller.center(target) })

// Example 2:
zenscroll.intoView(container, 100, function () { myScroller.toY(35) })

// Example 3:
zenscroll.intoView(container, 100, function () { myScroller.intoView(target) })

So first the container (with ITEM 1 to ITEM 7) is scrolled into view if necessary, and then the scrolling inside the container is performed. Try scrolling out the above container and then hit one of the ‘Play’ buttons above to see how it works.

This works with all four scrolling functions. The onDone parameter is always the last parameter:

  1. to(element, duration, onDone)
  2. toY(y, duration, onDone)
  3. intoView(element, duration, onDone)
  4. center(element, duration, offset, onDone)

9. Change settings

It’s easy to change the basic parameters of scrolling:

  • You can set the default value for duration. This will be valid for internal scrolls and all your direct scroll calls where you don’t specify a duration.
  • Change the edge offset (the spacing between the element and the screen edge). If you have a fixed navigation bar or footer bar then set the offset to their height.
var defaultDuration = 777 // ms
var edgeOffset = 42 // px
zenscroll.setup(defaultDuration, edgeOffset)

You can change custom scrollers similarly:

myScroller.setup(500, 10)

If you don’t want to change a value just omit the parameter or pass null. For example, the line below sets the default duration, while leaving other settings unchanged:

zenscroll.setup(777) // only updates defaultDuration to 777

Sets the the spacing between the edge of the screen (or a DIV) and the target element you are scrolling to, while leaving the default duration unchanged:

zenscroll.setup(null, 42) // only updates edgeOffset to 42

The function always returns the current values in an object, so even if no parameters are passed you can obtain the current settings:

var currentSettings = zenscroll.setup()
var dd = currentSettings.defaultDuration
var eo = currentSettings.edgeOffset

10. Additional functions

To check whether a scroll is being performed right now:

var isScrolling = zenscroll.moving()

To stop the current scrolling:

zenscroll.stop()

To get the current vertical scrolling position:

var bodyY = zenscroll.getY()

var myDivY = myDivScroller.getY()

To get the top position of an element within the body or a scroller:

var myElemY = zenscroll.getTopOf(myElem)

var relativeTopOfElem = myDivScroller.getTopOf(anElemInMyDiv)

Impotant: the returned value is without edge offset, and without recurcursively calculating nested scrollable containers.

License

Public Domain. You can do with it whatever you want and I am not responsible for anything.
