BigSense

Full Documentation: BigSense.io

BigSense is a web services designed to ingest and aggregate data from sensor networks. It can be used with its companion client LtSense to gather and store data from temperature, humidity and other environmental sensors.

Installation / Quick Start Guide

Database

You'll need to setup a database. BigSense supports most recently versions of mysql, postgres and mssql. Refer to your Linux distributions documentation for creating a database and create a database, user and password to be used later. Alternatively, you can run both your database and BigSense from a docker container which is covered below.

Debian, Ubuntu, Devuan, etc.

Start by importing the BigSense repository key

curl https://repo.bigsense.io/bigsense.io.key | sudo apt-key add -

Then add the appropriate repository based on the init system used in your distribution:

# Upstart (Ubuntu 14.04 Trusty, Ubuntu 14.10 Utopic, etc.)

sudo add-apt-repository 'deb https://repo.bigsense.io/debs upstart stable'

# systemv (Debian 7 Wheezy, Devuan, etc.)

sudo add-apt-repository 'deb https://repo.bigsense.io/debs systemv stable'

# systemd (Debian 8+, Ubuntu 15+, most current distributions)

sudo add-apt-repository 'deb https://repo.bigsense.io/debs systemd stable'

Then install OpenJDK and BigSense:

sudo apt-get update
sudo apt-get install openjdk-7-jre-headless bigsense

openSUSE, CentOS, and other RPM based distributions

Start by importing the BigSense repository key

sudo curl https://repo.bigsense.io/bigsense.io.key --create-dirs -o /etc/pki/rpm-gpg/RPM-GPG-KEY-BigSense
sudo rpm --import /etc/pki/rpm-gpg/RPM-GPG-KEY-BigSense

Next, create the BigSense.repo file

• CentOS: /etc/yum.repos.d/BigSense.repo
• OpenSuse: /etc/zypp/repos.d/BigSense.repo

[BigSense]
name=BigSense Repository for RPM
baseurl=https://repo.bigsense.io/rpms/stable
enabled=1
gpgcheck=1
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-BigSense

Then install OpenJDK and BigSense:

# CentOS

sudo yum install java-1.8.0-openjdk-headless bigsense

# OpenSUSE

sudo zypper install java-1_8_0-openjdk-headless bigsense

Docker

You'll want to pair BigSense with a database container. The following commands will create a network, mysql container and BigSense container.

docker network create -d bridge bigsense

docker run -d --name bigsense-mysql --network bigsense \
  -v bigsense-mysql-data:/var/lib/mysql \
  -e MYSQL_ROOT_PASSWORD=mysq1adm1n \
  -e MYSQL_DATABASE=bigsense mysql:5

docker run -d --name bigsense-web --network bigsense -p 8080:8080 \
   -e DB_HOSTNAME=bigsense-mysql \
   -e DB_PORT=3306 \
   -e DB_DATABASE=bigsense \
   -e DB_USER=bigsense \
   -e DB_PASS=s0mePa33w0rd \
   -e DBO_USER=root \
   -e DBO_PASS=mysq1adm1n \
   -e SECURITY_MANAGER=Disabled \
   -e DBMS=mysql \
   -e HTTP_PORT=8080 bigsense/bigsense:0.4.0

Docker Environment Variables

Variable	Description
DB_HOSTNAME	hostname or ip address for database server
DB_DATABASE	database name
DB_PORT	database port
DB_USER	user for non-DDL operations
DB_PASS	password for standard db user
DBO_USER	user for DDL/schema operations
DBO_PASS	password for dbo user
SECURITY_MANAGER	Can be Signature or Disabled
DBMS	Can be pgsql, mysql or mssql for Postgres, MySQL and MS Sql respectively
HTTP_PORT	post for BigSense to listen on for http requests

Configuration (non-docker)

Create /etc/bigsense/bigsense.conf with the following:

dbms=pgsql
dbHostname=localhost
dbPort=3456
dbDatabase=bigsense
dbUser=db_bigsense
dbPass=bigsense
dboUser=db_bigsense_ddl
dboPass=bigsenseDDL
securityManager=Disabled
httpPort=8080
server=tomcat

• dbms can be either pgsql, mysql or mssql for Postgres, MySQL and Microsoft SQL respectively
• dbHostname, dbPort and dbDatabase are database connection parameters
• dbUser/dbPass and dboUser/dboPass specify the two database users
  • The DBO user can update the schema and is only used upon startup of BigSense
  • The non-DBO user is used for all further connections when reading from/writing to the database
• securityManager can be used to verify all incoming sensor data. Currently can be set to Disabled or Signature.
• httpPort the port the web service will run on
• server can be either jetty or tomcat

Once configured, restart the service using systemctl restart bigsense.service on a systemd distribution or /etc/init.d/bigsense restart on others.

Sending Sensor Data

You can test out sending data to the webservice using curl:

curl -X POST localhost:8080/Sensor.sense.json --data '[
  {"id": "MyRelayID", "timestamp": "1549670382708",
  "gps": {"location": {"longitude": 13.0, "latitude": -12.0, "altitude": 5.0}},
  "sensors": [{"id": "Temp001", "type": "Temperature", "units": "C", "data": "34"},
  {"id": "Humidity001", "type": "Humdity", "units": "%", "data": "30"}]}]'

Pulling Data

You can then pull that data using the same webservice API:

curl localhost:8080/Query/Latest/100.txt
