How to correctly parse the contents of the HTML files generated by SingleFileZ #4

Closed
nuthrash opened this issue Oct 20, 2022 · 27 comments
Closed

How to correctly parse the contents of the HTML files generated by SingleFileZ #4

nuthrash opened this issue Oct 20, 2022 · 27 comments
Assignees
@nuthrash
Labels
help wanted Extra attention is needed

Comments

@nuthrash
Copy link
Owner

    > I have some questions:

1. Is the "SingleFileZ" web extension necessary? I opened a xxx.zip.html in Opera, it shows the same message. (NOTE: the Obsidian is based on [Electron](https://www.electronjs.org/), which embedded a Chromium browser)

It is unfortunately necessary to install SingleFileZ to view pages from the filesystem in Chromium-based browsers because they don't allow to run fetch("") (in order to retrieve the displayed page in binary) when the page is opened from the filesystem. It looks like the same limitation is applied in Obsidian.

2. How to detect a .html file made by "SingleFileZ"?

The file can be unzipped and it contains an index.html file in the root folder or the first folder of the zip file (for MAFF files). In addition, for self-extracting pages, the <html> tag contains the attribute data-sfz.

3. Is there a npm package to convert/decode SingleFileZ's .html content to standard HTML string?

The function extractPage in the code below (heavily inspired from this gist) should help you.

import { extract } from "https://raw.githubusercontent.com/gildas-lormeau/SingleFileZ/master/src/single-file/processors/compression/compression-extract.js";
import * as zip from "https://raw.githubusercontent.com/gildas-lormeau/zip.js/master/index.js";
globalThis.zip = zip;

async function extractPage(zipBlob) {
  const { docContent } = await extract(zipBlob, { noBlobURL: true });
  return docContent;
}

You can also use local imports instead of retrieving scripts from raw.githubusercontent.com by importing single-filez-core and zip.js from NPM, and replacing "https://raw.githubusercontent.com/gildas-lormeau/SingleFileZ/master/src/single-file" with "single-filez-core" and "https://raw.githubusercontent.com/gildas-lormeau/zip.js/master/index.js" with "@zip.js/zip.js".

Originally posted by @gildas-lormeau in #1 (comment)
@nuthrash
Copy link
Owner Author

nuthrash commented Oct 20, 2022 •
edited

You can also use local imports instead of retrieving scripts from raw.githubusercontent.com by importing single-filez-core and zip.js from NPM, and replacing "https://raw.githubusercontent.com/gildas-lormeau/SingleFileZ/master/src/single-file" with "single-filez-core" and "https://raw.githubusercontent.com/gildas-lormeau/zip.js/master/index.js" with "@zip.js/zip.js".

@gildas-lormeau
I am trying to convert the HTML files generated by SingleFileZ.

My workaround code is

import { extract } from "single-filez-core/processors/compression/compression-extract.js";
import * as zip from  '@zip.js/zip.js';

...

export class HtmlView extends FileView {
    async onLoadFile(file: TFile): Promise<void> {
        // whole HTML file strings
        const contents = await this.app.vault.read(file);

        globalThis.zip = zip;
        const { sfzContents } = await extract(contents, { noBlobURL: true });
        this.contentEl.insertAdjacentHTML("beforeend", sfzContents );

        ...
    }
}

When I open a xxx.zip.html generated by SingleFileZ, the Obsidian throw an exception Failed to fetch.
I tried to trace the function call flow, I found the exception was thrown by async* getEntriesGenerator(). The Call Stack is

getEntriesGenerator (plugin:obsidian-html-plugin:8457)
await in getEntriesGenerator (async)
getEntries (plugin:obsidian-html-plugin:8614)
extract (plugin:obsidian-html-plugin:71)
onLoadFile (plugin:obsidian-html-plugin:10336)
await in onLoadFile (async)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
m (app.js:1)
t.loadFile (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
m (app.js:1)
t.setState (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
a (app.js:1)
Promise.then (async)
l (app.js:1)
a (app.js:1)
Promise.then (async)
l (app.js:1)
(anonymous) (app.js:1)
m (app.js:1)
t.setViewState (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
m (app.js:1)
t.openFile (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
(anonymous) (app.js:1)
m (app.js:1)
t.onFileClick (app.js:1)
s (enhance.js:1)

Because the source code of original getEntriesGenerator() cannot match exactly with generated javascript code, I am not sure what's going on. The generated javascript version where getEntriesGenerator() thrown exception:

  async *getEntriesGenerator(options = {}) {
    const zipReader = this;
    let { reader } = zipReader;
    const { config: config2 } = zipReader;
    await initStream(reader);
    if (reader.size === UNDEFINED_VALUE || !reader.readUint8Array) {
      reader = new BlobReader(await new Response(reader.readable).blob()); // throw exception: Failed to fetch
      await initStream(reader);
    }
    if (reader.size < END_OF_CENTRAL_DIR_LENGTH) {
      throw new Error(ERR_BAD_FORMAT);
    }
    ...

Installed packages versions:

"@zip.js/zip.js": "^2.6.50",
"single-filez-core": "^1.0.20"

@nuthrash nuthrash self-assigned this Oct 20, 2022
@nuthrash nuthrash added the help wanted Extra attention is needed label Oct 20, 2022
@gildas-lormeau
Copy link

gildas-lormeau commented Oct 20, 2022 •
edited

I'm not sure this is the cause of the issue but it looks like this.app.vault.read(file) does not return a Blob object but a string instead. Maybe replacing await extract(contents, { noBlobURL: true }); with await extract(new Blob([contents]), { noBlobURL: true }); would help. Also, const { sfzContents } won't work. You must write const { docContent } instead.

Edit: new Blob([contents]) won't probabbly work. You need to get the page content in a binary format from the Obsidian API
Edit 2: readBinary should help, see https://marcus.se.net/obsidian-plugin-docs/reference/typescript/classes/Vault#readbinary, you'll need to call await extract(new Blob([new Uint8Array(contents)]), { noBlobURL: true });

@nuthrash
Copy link
Owner Author

Edit 2: readBinary should help, see https://marcus.se.net/obsidian-plugin-docs/reference/typescript/classes/Vault#readbinary, you'll need to call await extract(new Blob([new Uint8Array(contents)]), { noBlobURL: true });

OK, it works. My code is:

import { extract } from "single-filez-core/processors/compression/compression-extract.js";
import * as zip from  '@zip.js/zip.js';

...

export class HtmlView extends FileView {
    async onLoadFile(file: TFile): Promise<void> {
        // whole HTML file ArrayBuffer
        const contents = await this.app.vault.readBinary(file);

        globalThis.zip = zip;
        const { docContents } = await extract(new Blob([new Uint8Array(contents)]), { noBlobURL: true });
        this.contentEl.insertAdjacentHTML("beforeend", docContents);

        ...
    }
}

Thank you very much!! 👍

By the way, at Developer Console, there is a Content Security Policy red warning:

- The Content Security Policy 'default-src 'none'; font-src 'self' data: blob:; img-src 'self' data: blob:; style-src 'self' 'unsafe-inline' data: blob:; frame-src 'self' data: blob:; media-src 'self' data: blob:; script-src 'self' 'unsafe-inline' data: blob:;  object-src 'self' data: blob:;' was delivered via a <meta> element outside the document's <head>, which is disallowed. The policy has been ignored.

It seems a potential XSS attack. After I applied HTML Sanitization, some HTML elements were sanitized out.

Fig1. Before apply HTML Sanitization

s1 - before HTML Sanitization

Fig2. After apply HTML Sanitization
s2 - after HTML Sanitization

This situation never happened when open the HTML files which were made by SingleFile.

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 21, 2022 •
edited

I think the error is normal because I guess you're actually trying to inject the whole saved page within another page. You have to ensure that you don't insert the child tags of the <head> tag (of the saved page) in a <body> tag (of the host page which displays the saved page). Although, I find it's a bit strange you don't have this issue with pages saved with SingleFile because they also include a CSP in a <meta> tag. The CSP is a bit stricter in SingleFile though. FYI, the role of these policies is to block network requests that might be sent by a saved page. It should never happen though and it can be considered as a bug in SingleFile/SingleFileZ if it happens.

@nuthrash
Copy link
Owner Author

nuthrash commented Oct 22, 2022 •
edited

You have to ensure that you don't insert the child tags of the <head> tag (of the saved page) in a <body> tag (of the host page which displays the saved page).

I have to do something like that because of Obsidian's constraint. This plugin is hosted on one page/tab of Obsidian, and the only way to convert HTML strings to HTML DOM object is using DOMPurify. An important option is:

// return entire document including <html> tags (default is false)
var clean = DOMPurify.sanitize(dirty, {WHOLE_DOCUMENT: true})

If WHOLE_DOCUMENT set to false, the HTML files made by SingleFile would look like Fig2 instead Fig1.

EDIT1:

  • The XPath of the original <html> of Fig1 inserted into Obsidian:
/html/body/div[2]/div[1]/div/div[3]/div/div[2]/div/div/div[2]/html
  • The XPath of the HTML file made by SingleFile inserted into Obsidian with {WHOLE_DOCUMENT: false}:
/html/body/div[2]/div[1]/div/div[3]/div/div[2]/div/div/div[2]/body

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 22, 2022 •
edited

Thank you for the details. From my point of view, you can ignore the warning and set WHOLE_DOCUMENT to true. Additionally, you could also fix the warning by removing the offending <meta> tag and running something like dirty.replace(/<meta http-equiv="?content-security-policy"? content="[^"]+">/, "") before calling sanitize().

@nuthrash
Copy link
Owner Author

Thank you for the details. From my point of view, you can ignore the warning and set WHOLE_DOCUMENT to true. Additionally, you could also fix the warning by removing the offending <meta> tag and running something like dirty.replace(/<meta http-equiv="?content-security-policy"? content="[^"]+">/, "") before calling sanitize().

I got the key point, it is caused by the href of CSS contents of link tag were removed. You are right, that CSP warning is not the key point.
The SingleFile and SingleFileZ take different skills to handle the content of <link rel="stylesheet" href="xxxx.css">. The SingleFile would embed the contents of external CSS files into HTML files with raw text format, but the SingleFileZ would convert them to base64 strings then set the result to href attribute of <link> tags. The default HTML sanitization configuration of DOMPurify would sanitize <link rel="stylesheet" href="data:text/css;charset=utf-8;base64,Lm13LW........."> as <link rel="stylesheet">, so many CSS effects lost.
I have tried and got the working DOMPurify configuration to keep href attribute of <link>.
However, I wonder will <link rel="stylesheet" href="data:text/css;charset=utf-8;base64,Lm13LW........."> cause a XSS attack?

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 22, 2022 •
edited

Does it work if you run DOMPurify.sanitize(dirty, { WHOLE_DOCUMENT: true, ADD_DATA_URI_TAGS: ["link"] });? (see https://github.com/cure53/DOMPurify#can-i-configure-dompurify)

@nuthrash
Copy link
Owner Author

Does it work if you run DOMPurify.sanitize(dirty, { WHOLE_DOCUMENT: true, ADD_DATA_URI_TAGS: ["link"] });? (see https://github.com/cure53/DOMPurify#can-i-configure-dompurify)

Hmm, more settings need, my testing configuration is

const purifyConfig = {
			RETURN_DOM: true, // return DOM HTMLBodyElement
			WHOLE_DOCUMENT: true,

			// Default TAGs ATTRIBUTEs allow list & blocklist https://github.com/cure53/DOMPurify/wiki/Default-TAGs-ATTRIBUTEs-allow-list-&-blocklist
			// allowed tags https://github.com/cure53/DOMPurify/blob/main/src/tags.js
			ADD_TAGS: ['link'],
			// allowed attributes https://github.com/cure53/DOMPurify/blob/main/src/attrs.js

			ADD_DATA_URI_TAGS: ['a', 'area', 'img', 'link'],
		};

And I will try to find out which tags are safe to be added to ADD_DATA_URI_TAGS.

By the way, I forget to tell you. The note tag <single-file-note> used by SingleFile and SingleFileZ would be sanitized out by Obsidian, it seems that Obsidian disallow non-HTML5 tags.

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 23, 2022 •
edited

By the way, I forget to tell you. The note tag <single-file-note> used by SingleFile and SingleFileZ would be sanitized out by Obsidian, it seems that Obsidian disallow non-HTML5 tags.

You have to add 'single-file-note' into ADD_TAGS if you want to support it.

@nuthrash
Copy link
Owner Author

nuthrash commented Oct 23, 2022 •
edited

You have to add single-file-note into ADD_TAGS if you want to support it.

No, even I add it, the tag still would be removed by Obsidian.

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 23, 2022 •
edited

Do you see an empty <single-file-note> tag or no tag at all in the debugger when the page is displayed in Obsidian? If you see an empty tag, the issue would be probably related to the shadow root deserialization instead.

@nuthrash
Copy link
Owner Author

Do you see an empty <single-file-note> tag or no tag at all in the debugger when the page is displayed in Obsidian? If you see an empty tag, the issue would be probably related to the shadow root deserialization instead.

Hmm, It seems that the <single-file-note> still existed, I am sorry for my misunderstanding.

Before insertAdjacentHTML()


AfterinsertAdjacentHTML()


I can find the <single-file-note> by the Elements panel of Developer Console, but it is invisible on the screen.

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 23, 2022 •
edited

JavasScript is required to deserialize the shadow root, i.e. put the content of <template shadowroot=open> in the shadow root of <single-file-note>, but only in Firefox (and maybe Safari). The purpose of the shadow root is to avoid conflicts between the css from the notes and the css from the saved page. This script is inserted by SingleFileZ at the end of the saved page and I guess Obsidian removes it. Do you confirm you are not using a Chromium-based browser?

@nuthrash
Copy link
Owner Author

nuthrash commented Oct 23, 2022 •
edited

The Obsidian's appVersion: '5.0 (Windows NT 10.0; Win64; x64) AppleWebKit/537.36 (KHTML, like Gecko) obsidian/1.0.0 Chrome/100.0.4896.160 Electron/18.3.5 Safari/537.36'. Obviously, the Obsidian 1.0.0 is a Chromium-based browser. And I am building another plugin project about <ruby> tags for Obsidian, I want to take <rtc> as translated HTML code, but Obsidian is not support it. According the rtc document, the Chrome is not support <rtc> tags.

Before insertAdjacentHTML()

<script data-template-shadow-root>(() => { document.currentScript.remove(); const processNode = node => { node.querySelectorAll("template[shadowroot]").forEach(element=>{ let shadowRoot = getShadowRoot(element.parentElement); if (!shadowRoot) { try { shadowRoot = element.parentElement.attachShadow({mode:element.getAttribute("shadowroot")}); shadowRoot.innerHTML = element.innerHTML; element.remove(); } catch (error) {} if (shadowRoot) { processNode(shadowRoot); } } }) }; const FORBIDDEN_TAG_NAMES = ["a","area","audio","base","br","col","command","embed","hr","img","iframe","input","keygen","link","meta","param","source","track","video","wbr"]; const NOTE_TAGNAME = "single-file-note"; const NOTE_CLASS = "note"; const NOTE_ANCHORED_CLASS = "note-anchored"; const NOTE_SELECTED_CLASS = "note-selected"; const NOTE_MOVING_CLASS = "note-moving"; const NOTE_MASK_MOVING_CLASS = "note-mask-moving"; const MASK_CLASS = "single-file-mask"; const HIGHLIGHT_CLASS = "single-file-highlight"; const NOTES_WEB_STYLESHEET = ".note { all: initial; display: flex; flex-direction: column; height: 150px; width: 150px; position: absolute; top: 10px; left: 10px; border: 1px solid rgb(191, 191, 191); z-index: 2147483646; box-shadow: 3px 3px 3px rgba(33, 33, 33, .7); min-height: 100px; min-width: 100px; } .note-selected { z-index: 2147483647; } .note-hidden { display: none; } .note-collapsed { min-height: 30px; max-height: 30px; overflow: hidden; } .note textarea { all: initial; white-space: break-spaces; font-family: Arial, Helvetica, sans-serif; font-size: 14px; padding: 3px; height: 100%; border: 1px solid transparent; resize: none; color: black; } .note textarea:focus { border: 1px dotted rgb(160, 160, 160); } .note header { all: initial; min-height: 30px; cursor: grab; user-select: none; } .note .note-remove { all: initial; position: absolute; right: 0px; top: 2px; padding: 5px; opacity: .5; cursor: pointer; user-select: none; width: 16px; height: 16px; } .note .note-anchor { all: initial; position: absolute; left: 0px; top: 2px; padding: 5px; opacity: .25; cursor: pointer; width: 16px; height: 16px; } .note .note-resize { all: initial; position: absolute; bottom: -5px; right: -5px; height: 15px; width: 15px; cursor: nwse-resize; user-select: none; } .note .note-remove:hover { opacity: 1; } .note .note-anchor:hover { opacity: .5; } .note-anchored .note-anchor { opacity: .5; } .note-anchored .note-anchor:hover { opacity: 1; } .note-moving { opacity: .75; box-shadow: 6px 6px 3px rgba(33, 33, 33, .7); } .note-moving * { cursor: grabbing; } .note-yellow header { background-color: #f5f545; } .note-yellow textarea { background-color: #ffff7c; } .note-pink header { background-color: #ffa59f; } .note-pink textarea { background-color: #ffbbb6; } .note-blue header { background-color: #84c8ff; } .note-blue textarea { background-color: #95d0ff; } .note-green header { background-color: #93ef8d; } .note-green textarea { background-color: #9cff95; }"; const MASK_WEB_STYLESHEET = ".note-mask { all: initial; position: fixed; z-index: 2147483645; pointer-events: none; background-color: transparent; transition: background-color 125ms; } .note-mask-moving.note-yellow { background-color: rgba(255, 255, 124, .3); } .note-mask-moving.note-pink { background-color: rgba(255, 187, 182, .3); } .note-mask-moving.note-blue { background-color: rgba(149, 208, 255, .3); } .note-mask-moving.note-green { background-color: rgba(156, 255, 149, .3); } .page-mask { all: initial; position: fixed; top: 0; left: 0; width: 0; height: 0; z-index: 2147483646; } .page-mask-active { width: 100vw; height: 100vh; }"; const NOTE_HEADER_HEIGHT = 25; const PAGE_MASK_ACTIVE_CLASS = "page-mask-active"; const REMOVED_CONTENT_CLASS = "single-file-removed"; const reflowNotes = function reflowNotes() { document.querySelectorAll(NOTE_TAGNAME).forEach(containerElement => { const noteElement = containerElement.shadowRoot.querySelector("." + NOTE_CLASS); const noteBoundingRect = noteElement.getBoundingClientRect(); const anchorElement = getAnchorElement(containerElement); const anchorBoundingRect = anchorElement.getBoundingClientRect(); const maxX = anchorBoundingRect.x + Math.max(0, anchorBoundingRect.width - noteBoundingRect.width); const minX = anchorBoundingRect.x; const maxY = anchorBoundingRect.y + Math.max(0, anchorBoundingRect.height - NOTE_HEADER_HEIGHT); const minY = anchorBoundingRect.y; let left = parseInt(noteElement.style.getPropertyValue("left")); let top = parseInt(noteElement.style.getPropertyValue("top")); if (noteBoundingRect.x > maxX) { left -= noteBoundingRect.x - maxX; } if (noteBoundingRect.x < minX) { left += minX - noteBoundingRect.x; } if (noteBoundingRect.y > maxY) { top -= noteBoundingRect.y - maxY; } if (noteBoundingRect.y < minY) { top += minY - noteBoundingRect.y; } noteElement.style.setProperty("position", "absolute"); noteElement.style.setProperty("left", left + "px"); noteElement.style.setProperty("top", top + "px"); }); }; const addNoteRef = function addNoteRef(anchorElement, noteId) { const noteRefs = getNoteRefs(anchorElement); noteRefs.push(noteId); setNoteRefs(anchorElement, noteRefs); }; const deleteNoteRef = function deleteNoteRef(containerElement, noteId) { const anchorElement = getAnchorElement(containerElement); const noteRefs = getNoteRefs(anchorElement).filter(noteRefs => noteRefs != noteId); if (noteRefs.length) { setNoteRefs(anchorElement, noteRefs); } else { delete anchorElement.dataset.singleFileNoteRefs; } }; const getNoteRefs = function getNoteRefs(anchorElement) { return JSON.parse("[" + (anchorElement.dataset.singleFileNoteRefs || "") + "]"); }; const setNoteRefs = function setNoteRefs(anchorElement, noteRefs) { anchorElement.dataset.singleFileNoteRefs = noteRefs.toString(); }; const getAnchorElement = function getAnchorElement(containerElement) { return document.querySelector("[data-single-file-note-refs^=" + JSON.stringify(containerElement.dataset.noteId) + "], [data-single-file-note-refs$=" + JSON.stringify(containerElement.dataset.noteId) + "], [data-single-file-note-refs*=" + JSON.stringify("," + containerElement.dataset.noteId + ",") + "]") || document.documentElement; }; const getMaskElement = function getMaskElement(className, containerClassName) { let maskElement = document.documentElement.querySelector("." + className); if (!maskElement) { maskElement = document.createElement("div"); const maskContainerElement = document.createElement("div"); if (containerClassName) { maskContainerElement.classList.add(containerClassName); } maskContainerElement.classList.add(MASK_CLASS); const firstNote = document.querySelector(NOTE_TAGNAME); if (firstNote && firstNote.parentElement == document.documentElement) { document.documentElement.insertBefore(maskContainerElement, firstNote); } else { document.documentElement.appendChild(maskContainerElement); } maskElement.classList.add(className); const maskShadow = maskContainerElement.attachShadow({ mode: "open" }); maskShadow.appendChild(getStyleElement(MASK_WEB_STYLESHEET)); maskShadow.appendChild(maskElement); return maskElement; } }; const getStyleElement = function getStyleElement(stylesheet) { const linkElement = document.createElement("style"); linkElement.textContent = stylesheet; return linkElement; }; const attachNoteListeners = function attachNoteListeners(containerElement, editable = false) { const SELECT_PX_THRESHOLD = 4; const COLLAPSING_NOTE_DELAY = 750; const noteShadow = containerElement.shadowRoot; const noteElement = noteShadow.childNodes[1]; const headerElement = noteShadow.querySelector("header"); const mainElement = noteShadow.querySelector("textarea"); const noteId = containerElement.dataset.noteId; const resizeElement = noteShadow.querySelector(".note-resize"); const anchorIconElement = noteShadow.querySelector(".note-anchor"); const removeNoteElement = noteShadow.querySelector(".note-remove"); mainElement.readOnly = !editable; if (!editable) { anchorIconElement.style.setProperty("display", "none", "important"); } else { anchorIconElement.style.removeProperty("display"); } headerElement.ontouchstart = headerElement.onmousedown = event => { if (event.target == headerElement) { collapseNoteTimeout = setTimeout(() => { noteElement.classList.toggle("note-collapsed"); hideMaskNote(); }, COLLAPSING_NOTE_DELAY); event.preventDefault(); const position = getPosition(event); const clientX = position.clientX; const clientY = position.clientY; const boundingRect = noteElement.getBoundingClientRect(); const deltaX = clientX - boundingRect.left; const deltaY = clientY - boundingRect.top; maskPageElement.classList.add(PAGE_MASK_ACTIVE_CLASS); document.documentElement.style.setProperty("user-select", "none", "important"); anchorElement = getAnchorElement(containerElement); displayMaskNote(); selectNote(noteElement); moveNote(event, deltaX, deltaY); movingNoteMode = { event, deltaX, deltaY }; document.documentElement.ontouchmove = document.documentElement.onmousemove = event => { clearTimeout(collapseNoteTimeout); if (!movingNoteMode) { movingNoteMode = { deltaX, deltaY }; } movingNoteMode.event = event; moveNote(event, deltaX, deltaY); }; } }; resizeElement.ontouchstart = resizeElement.onmousedown = event => { event.preventDefault(); resizingNoteMode = true; selectNote(noteElement); maskPageElement.classList.add(PAGE_MASK_ACTIVE_CLASS); document.documentElement.style.setProperty("user-select", "none", "important"); document.documentElement.ontouchmove = document.documentElement.onmousemove = event => { event.preventDefault(); const { clientX, clientY } = getPosition(event); const boundingRectNote = noteElement.getBoundingClientRect(); noteElement.style.width = clientX - boundingRectNote.left + "px"; noteElement.style.height = clientY - boundingRectNote.top + "px"; }; }; anchorIconElement.ontouchend = anchorIconElement.onclick = event => { event.preventDefault(); noteElement.classList.toggle(NOTE_ANCHORED_CLASS); if (!noteElement.classList.contains(NOTE_ANCHORED_CLASS)) { deleteNoteRef(containerElement, noteId); addNoteRef(document.documentElement, noteId); } onUpdate(false); }; removeNoteElement.ontouchend = removeNoteElement.onclick = event => { event.preventDefault(); deleteNoteRef(containerElement, noteId); containerElement.remove(); }; noteElement.onmousedown = () => { selectNote(noteElement); }; function moveNote(event, deltaX, deltaY) { event.preventDefault(); const { clientX, clientY } = getPosition(event); noteElement.classList.add(NOTE_MOVING_CLASS); if (editable) { if (noteElement.classList.contains(NOTE_ANCHORED_CLASS)) { deleteNoteRef(containerElement, noteId); anchorElement = getTarget(clientX, clientY) || document.documentElement; addNoteRef(anchorElement, noteId); } else { anchorElement = document.documentElement; } } document.documentElement.insertBefore(containerElement, maskPageElement.getRootNode().host); noteElement.style.setProperty("left", (clientX - deltaX) + "px"); noteElement.style.setProperty("top", (clientY - deltaY) + "px"); noteElement.style.setProperty("position", "fixed"); displayMaskNote(); } function displayMaskNote() { if (anchorElement == document.documentElement || anchorElement == document.documentElement) { hideMaskNote(); } else { const boundingRectAnchor = anchorElement.getBoundingClientRect(); maskNoteElement.classList.add(NOTE_MASK_MOVING_CLASS); if (selectedNote) { maskNoteElement.classList.add(selectedNote.dataset.color); } maskNoteElement.style.setProperty("top", (boundingRectAnchor.y - 3) + "px"); maskNoteElement.style.setProperty("left", (boundingRectAnchor.x - 3) + "px"); maskNoteElement.style.setProperty("width", (boundingRectAnchor.width + 3) + "px"); maskNoteElement.style.setProperty("height", (boundingRectAnchor.height + 3) + "px"); } } function hideMaskNote() { maskNoteElement.classList.remove(NOTE_MASK_MOVING_CLASS); if (selectedNote) { maskNoteElement.classList.remove(selectedNote.dataset.color); } } function selectNote(noteElement) { if (selectedNote) { selectedNote.classList.remove(NOTE_SELECTED_CLASS); maskNoteElement.classList.remove(selectedNote.dataset.color); } noteElement.classList.add(NOTE_SELECTED_CLASS); noteElement.classList.add(noteElement.dataset.color); selectedNote = noteElement; } function getTarget(clientX, clientY) { const targets = Array.from(document.elementsFromPoint(clientX, clientY)).filter(element => element.matches("html *:not(" + NOTE_TAGNAME + "):not(." + MASK_CLASS + ")")); if (!targets.includes(document.documentElement)) { targets.push(document.documentElement); } let newTarget, target = targets[0], boundingRect = target.getBoundingClientRect(); newTarget = determineTargetElement("floor", target, clientX - boundingRect.left, getMatchedParents(target, "left")); if (newTarget == target) { newTarget = determineTargetElement("ceil", target, boundingRect.left + boundingRect.width - clientX, getMatchedParents(target, "right")); } if (newTarget == target) { newTarget = determineTargetElement("floor", target, clientY - boundingRect.top, getMatchedParents(target, "top")); } if (newTarget == target) { newTarget = determineTargetElement("ceil", target, boundingRect.top + boundingRect.height - clientY, getMatchedParents(target, "bottom")); } target = newTarget; while (boundingRect = target && target.getBoundingClientRect(), boundingRect && boundingRect.width <= SELECT_PX_THRESHOLD && boundingRect.height <= SELECT_PX_THRESHOLD) { target = target.parentElement; } return target; } function getMatchedParents(target, property) { let element = target, matchedParent, parents = []; do { const boundingRect = element.getBoundingClientRect(); if (element.parentElement && !element.parentElement.tagName.toLowerCase() != NOTE_TAGNAME && !element.classList.contains(MASK_CLASS)) { const parentBoundingRect = element.parentElement.getBoundingClientRect(); matchedParent = Math.abs(parentBoundingRect[property] - boundingRect[property]) <= SELECT_PX_THRESHOLD; if (matchedParent) { if (element.parentElement.clientWidth > SELECT_PX_THRESHOLD && element.parentElement.clientHeight > SELECT_PX_THRESHOLD && ((element.parentElement.clientWidth - element.clientWidth > SELECT_PX_THRESHOLD) || (element.parentElement.clientHeight - element.clientHeight > SELECT_PX_THRESHOLD))) { parents.push(element.parentElement); } element = element.parentElement; } } else { matchedParent = false; } } while (matchedParent && element); return parents; } function determineTargetElement(roundingMethod, target, widthDistance, parents) { if (Math[roundingMethod](widthDistance / SELECT_PX_THRESHOLD) <= parents.length) { target = parents[parents.length - Math[roundingMethod](widthDistance / SELECT_PX_THRESHOLD) - 1]; } return target; } }; const anchorNote = function anchorNote(event, noteElement, deltaX, deltaY) { event.preventDefault(); const { clientX, clientY } = getPosition(event); document.documentElement.style.removeProperty("user-select"); noteElement.classList.remove(NOTE_MOVING_CLASS); maskNoteElement.classList.remove(NOTE_MASK_MOVING_CLASS); maskPageElement.classList.remove(PAGE_MASK_ACTIVE_CLASS); maskNoteElement.classList.remove(noteElement.dataset.color); const headerElement = noteElement.querySelector("header"); headerElement.ontouchmove = document.documentElement.onmousemove = null; let currentElement = anchorElement; let positionedElement; while (currentElement.parentElement && !positionedElement) { if (!FORBIDDEN_TAG_NAMES.includes(currentElement.tagName.toLowerCase())) { const currentElementStyle = getComputedStyle(currentElement); if (currentElementStyle.position != "static") { positionedElement = currentElement; } } currentElement = currentElement.parentElement; } if (!positionedElement) { positionedElement = document.documentElement; } const containerElement = noteElement.getRootNode().host; if (positionedElement == document.documentElement) { const firstMaskElement = document.querySelector("." + MASK_CLASS); firstMaskElement.parentElement.insertBefore(containerElement, firstMaskElement); } else { positionedElement.appendChild(containerElement); } const boundingRectPositionedElement = positionedElement.getBoundingClientRect(); const stylePositionedElement = window.getComputedStyle(positionedElement); const borderX = parseInt(stylePositionedElement.getPropertyValue("border-left-width")); const borderY = parseInt(stylePositionedElement.getPropertyValue("border-top-width")); noteElement.style.setProperty("position", "absolute"); noteElement.style.setProperty("left", (clientX - boundingRectPositionedElement.x - deltaX - borderX) + "px"); noteElement.style.setProperty("top", (clientY - boundingRectPositionedElement.y - deltaY - borderY) + "px"); }; const getPosition = function getPosition(event) { if (event.touches && event.touches.length) { const touch = event.touches[0]; return touch; } else { return event; } }; const onMouseUp = function onMouseUp(event) { if (highlightSelectionMode) { highlightSelection(); onUpdate(false); } if (removeHighlightMode) { let element = event.target, done; while (element && !done) { if (element.classList.contains(HIGHLIGHT_CLASS)) { document.querySelectorAll("." + HIGHLIGHT_CLASS + "[data-singlefile-highlight-id=" + JSON.stringify(element.dataset.singlefileHighlightId) + "]").forEach(highlightedElement => { resetHighlightedElement(highlightedElement); onUpdate(false); }); done = true; } element = element.parentElement; } } if (resizingNoteMode) { resizingNoteMode = false; document.documentElement.style.removeProperty("user-select"); maskPageElement.classList.remove(PAGE_MASK_ACTIVE_CLASS); document.documentElement.ontouchmove = document.documentElement.onmousemove = null; onUpdate(false); } if (movingNoteMode) { anchorNote(movingNoteMode.event || event, selectedNote, movingNoteMode.deltaX, movingNoteMode.deltaY); movingNoteMode = null; document.documentElement.ontouchmove = document.documentElement.onmousemove = null; onUpdate(false); } if (collapseNoteTimeout) { clearTimeout(collapseNoteTimeout); collapseNoteTimeout = null; } if ((cuttingMode || cuttingOuterMode) && cuttingPath) { if (event.ctrlKey) { const element = cuttingPath[cuttingPathIndex]; element.classList.toggle(cuttingMode ? CUT_SELECTED_CLASS : CUT_OUTER_SELECTED_CLASS); } else { validateCutElement(event.shiftKey); } } }; const getShadowRoot = function getShadowRoot(element) { const chrome = window.chrome; if (element.openOrClosedShadowRoot) { return element.openOrClosedShadowRoot; } else if (chrome && chrome.dom && chrome.dom.openOrClosedShadowRoot) { try { return chrome.dom.openOrClosedShadowRoot(element); } catch (error) { return element.shadowRoot; } } else { return element.shadowRoot; } }; const maskNoteElement = getMaskElement("note-mask"); const maskPageElement = getMaskElement("page-mask", "single-file-page-mask"); let selectedNote, highlightSelectionMode, removeHighlightMode, resizingNoteMode, movingNoteMode, collapseNoteTimeout, cuttingMode, cuttingOuterMode; window.onresize = reflowNotes; window.onUpdate = () => {}; document.documentElement.onmouseup = document.documentElement.ontouchend = onMouseUp; window.addEventListener("DOMContentLoaded", () => { processNode(document); reflowNotes(); document.querySelectorAll("single-file-note").forEach(noteElement => attachNoteListeners(noteElement)); }); })()</script>

After insertAdjacentHTML()

<script data-template-shadow-root="">(() => { document.currentScript.remove(); const processNode = node => { node.querySelectorAll("template[shadowroot]").forEach(element=>{ let shadowRoot = getShadowRoot(element.parentElement); if (!shadowRoot) { try { shadowRoot = element.parentElement.attachShadow({mode:element.getAttribute("shadowroot")}); shadowRoot.innerHTML = element.innerHTML; element.remove(); } catch (error) {} if (shadowRoot) { processNode(shadowRoot); } } }) }; const FORBIDDEN_TAG_NAMES = ["a","area","audio","base","br","col","command","embed","hr","img","iframe","input","keygen","link","meta","param","source","track","video","wbr"]; const NOTE_TAGNAME = "single-file-note"; const NOTE_CLASS = "note"; const NOTE_ANCHORED_CLASS = "note-anchored"; const NOTE_SELECTED_CLASS = "note-selected"; const NOTE_MOVING_CLASS = "note-moving"; const NOTE_MASK_MOVING_CLASS = "note-mask-moving"; const MASK_CLASS = "single-file-mask"; const HIGHLIGHT_CLASS = "single-file-highlight"; const NOTES_WEB_STYLESHEET = ".note { all: initial; display: flex; flex-direction: column; height: 150px; width: 150px; position: absolute; top: 10px; left: 10px; border: 1px solid rgb(191, 191, 191); z-index: 2147483646; box-shadow: 3px 3px 3px rgba(33, 33, 33, .7); min-height: 100px; min-width: 100px; } .note-selected { z-index: 2147483647; } .note-hidden { display: none; } .note-collapsed { min-height: 30px; max-height: 30px; overflow: hidden; } .note textarea { all: initial; white-space: break-spaces; font-family: Arial, Helvetica, sans-serif; font-size: 14px; padding: 3px; height: 100%; border: 1px solid transparent; resize: none; color: black; } .note textarea:focus { border: 1px dotted rgb(160, 160, 160); } .note header { all: initial; min-height: 30px; cursor: grab; user-select: none; } .note .note-remove { all: initial; position: absolute; right: 0px; top: 2px; padding: 5px; opacity: .5; cursor: pointer; user-select: none; width: 16px; height: 16px; } .note .note-anchor { all: initial; position: absolute; left: 0px; top: 2px; padding: 5px; opacity: .25; cursor: pointer; width: 16px; height: 16px; } .note .note-resize { all: initial; position: absolute; bottom: -5px; right: -5px; height: 15px; width: 15px; cursor: nwse-resize; user-select: none; } .note .note-remove:hover { opacity: 1; } .note .note-anchor:hover { opacity: .5; } .note-anchored .note-anchor { opacity: .5; } .note-anchored .note-anchor:hover { opacity: 1; } .note-moving { opacity: .75; box-shadow: 6px 6px 3px rgba(33, 33, 33, .7); } .note-moving * { cursor: grabbing; } .note-yellow header { background-color: #f5f545; } .note-yellow textarea { background-color: #ffff7c; } .note-pink header { background-color: #ffa59f; } .note-pink textarea { background-color: #ffbbb6; } .note-blue header { background-color: #84c8ff; } .note-blue textarea { background-color: #95d0ff; } .note-green header { background-color: #93ef8d; } .note-green textarea { background-color: #9cff95; }"; const MASK_WEB_STYLESHEET = ".note-mask { all: initial; position: fixed; z-index: 2147483645; pointer-events: none; background-color: transparent; transition: background-color 125ms; } .note-mask-moving.note-yellow { background-color: rgba(255, 255, 124, .3); } .note-mask-moving.note-pink { background-color: rgba(255, 187, 182, .3); } .note-mask-moving.note-blue { background-color: rgba(149, 208, 255, .3); } .note-mask-moving.note-green { background-color: rgba(156, 255, 149, .3); } .page-mask { all: initial; position: fixed; top: 0; left: 0; width: 0; height: 0; z-index: 2147483646; } .page-mask-active { width: 100vw; height: 100vh; }"; const NOTE_HEADER_HEIGHT = 25; const PAGE_MASK_ACTIVE_CLASS = "page-mask-active"; const REMOVED_CONTENT_CLASS = "single-file-removed"; const reflowNotes = function reflowNotes() { document.querySelectorAll(NOTE_TAGNAME).forEach(containerElement => { const noteElement = containerElement.shadowRoot.querySelector("." + NOTE_CLASS); const noteBoundingRect = noteElement.getBoundingClientRect(); const anchorElement = getAnchorElement(containerElement); const anchorBoundingRect = anchorElement.getBoundingClientRect(); const maxX = anchorBoundingRect.x + Math.max(0, anchorBoundingRect.width - noteBoundingRect.width); const minX = anchorBoundingRect.x; const maxY = anchorBoundingRect.y + Math.max(0, anchorBoundingRect.height - NOTE_HEADER_HEIGHT); const minY = anchorBoundingRect.y; let left = parseInt(noteElement.style.getPropertyValue("left")); let top = parseInt(noteElement.style.getPropertyValue("top")); if (noteBoundingRect.x > maxX) { left -= noteBoundingRect.x - maxX; } if (noteBoundingRect.x < minX) { left += minX - noteBoundingRect.x; } if (noteBoundingRect.y > maxY) { top -= noteBoundingRect.y - maxY; } if (noteBoundingRect.y < minY) { top += minY - noteBoundingRect.y; } noteElement.style.setProperty("position", "absolute"); noteElement.style.setProperty("left", left + "px"); noteElement.style.setProperty("top", top + "px"); }); }; const addNoteRef = function addNoteRef(anchorElement, noteId) { const noteRefs = getNoteRefs(anchorElement); noteRefs.push(noteId); setNoteRefs(anchorElement, noteRefs); }; const deleteNoteRef = function deleteNoteRef(containerElement, noteId) { const anchorElement = getAnchorElement(containerElement); const noteRefs = getNoteRefs(anchorElement).filter(noteRefs => noteRefs != noteId); if (noteRefs.length) { setNoteRefs(anchorElement, noteRefs); } else { delete anchorElement.dataset.singleFileNoteRefs; } }; const getNoteRefs = function getNoteRefs(anchorElement) { return JSON.parse("[" + (anchorElement.dataset.singleFileNoteRefs || "") + "]"); }; const setNoteRefs = function setNoteRefs(anchorElement, noteRefs) { anchorElement.dataset.singleFileNoteRefs = noteRefs.toString(); }; const getAnchorElement = function getAnchorElement(containerElement) { return document.querySelector("[data-single-file-note-refs^=" + JSON.stringify(containerElement.dataset.noteId) + "], [data-single-file-note-refs$=" + JSON.stringify(containerElement.dataset.noteId) + "], [data-single-file-note-refs*=" + JSON.stringify("," + containerElement.dataset.noteId + ",") + "]") || document.documentElement; }; const getMaskElement = function getMaskElement(className, containerClassName) { let maskElement = document.documentElement.querySelector("." + className); if (!maskElement) { maskElement = document.createElement("div"); const maskContainerElement = document.createElement("div"); if (containerClassName) { maskContainerElement.classList.add(containerClassName); } maskContainerElement.classList.add(MASK_CLASS); const firstNote = document.querySelector(NOTE_TAGNAME); if (firstNote && firstNote.parentElement == document.documentElement) { document.documentElement.insertBefore(maskContainerElement, firstNote); } else { document.documentElement.appendChild(maskContainerElement); } maskElement.classList.add(className); const maskShadow = maskContainerElement.attachShadow({ mode: "open" }); maskShadow.appendChild(getStyleElement(MASK_WEB_STYLESHEET)); maskShadow.appendChild(maskElement); return maskElement; } }; const getStyleElement = function getStyleElement(stylesheet) { const linkElement = document.createElement("style"); linkElement.textContent = stylesheet; return linkElement; }; const attachNoteListeners = function attachNoteListeners(containerElement, editable = false) { const SELECT_PX_THRESHOLD = 4; const COLLAPSING_NOTE_DELAY = 750; const noteShadow = containerElement.shadowRoot; const noteElement = noteShadow.childNodes[1]; const headerElement = noteShadow.querySelector("header"); const mainElement = noteShadow.querySelector("textarea"); const noteId = containerElement.dataset.noteId; const resizeElement = noteShadow.querySelector(".note-resize"); const anchorIconElement = noteShadow.querySelector(".note-anchor"); const removeNoteElement = noteShadow.querySelector(".note-remove"); mainElement.readOnly = !editable; if (!editable) { anchorIconElement.style.setProperty("display", "none", "important"); } else { anchorIconElement.style.removeProperty("display"); } headerElement.ontouchstart = headerElement.onmousedown = event => { if (event.target == headerElement) { collapseNoteTimeout = setTimeout(() => { noteElement.classList.toggle("note-collapsed"); hideMaskNote(); }, COLLAPSING_NOTE_DELAY); event.preventDefault(); const position = getPosition(event); const clientX = position.clientX; const clientY = position.clientY; const boundingRect = noteElement.getBoundingClientRect(); const deltaX = clientX - boundingRect.left; const deltaY = clientY - boundingRect.top; maskPageElement.classList.add(PAGE_MASK_ACTIVE_CLASS); document.documentElement.style.setProperty("user-select", "none", "important"); anchorElement = getAnchorElement(containerElement); displayMaskNote(); selectNote(noteElement); moveNote(event, deltaX, deltaY); movingNoteMode = { event, deltaX, deltaY }; document.documentElement.ontouchmove = document.documentElement.onmousemove = event => { clearTimeout(collapseNoteTimeout); if (!movingNoteMode) { movingNoteMode = { deltaX, deltaY }; } movingNoteMode.event = event; moveNote(event, deltaX, deltaY); }; } }; resizeElement.ontouchstart = resizeElement.onmousedown = event => { event.preventDefault(); resizingNoteMode = true; selectNote(noteElement); maskPageElement.classList.add(PAGE_MASK_ACTIVE_CLASS); document.documentElement.style.setProperty("user-select", "none", "important"); document.documentElement.ontouchmove = document.documentElement.onmousemove = event => { event.preventDefault(); const { clientX, clientY } = getPosition(event); const boundingRectNote = noteElement.getBoundingClientRect(); noteElement.style.width = clientX - boundingRectNote.left + "px"; noteElement.style.height = clientY - boundingRectNote.top + "px"; }; }; anchorIconElement.ontouchend = anchorIconElement.onclick = event => { event.preventDefault(); noteElement.classList.toggle(NOTE_ANCHORED_CLASS); if (!noteElement.classList.contains(NOTE_ANCHORED_CLASS)) { deleteNoteRef(containerElement, noteId); addNoteRef(document.documentElement, noteId); } onUpdate(false); }; removeNoteElement.ontouchend = removeNoteElement.onclick = event => { event.preventDefault(); deleteNoteRef(containerElement, noteId); containerElement.remove(); }; noteElement.onmousedown = () => { selectNote(noteElement); }; function moveNote(event, deltaX, deltaY) { event.preventDefault(); const { clientX, clientY } = getPosition(event); noteElement.classList.add(NOTE_MOVING_CLASS); if (editable) { if (noteElement.classList.contains(NOTE_ANCHORED_CLASS)) { deleteNoteRef(containerElement, noteId); anchorElement = getTarget(clientX, clientY) || document.documentElement; addNoteRef(anchorElement, noteId); } else { anchorElement = document.documentElement; } } document.documentElement.insertBefore(containerElement, maskPageElement.getRootNode().host); noteElement.style.setProperty("left", (clientX - deltaX) + "px"); noteElement.style.setProperty("top", (clientY - deltaY) + "px"); noteElement.style.setProperty("position", "fixed"); displayMaskNote(); } function displayMaskNote() { if (anchorElement == document.documentElement || anchorElement == document.documentElement) { hideMaskNote(); } else { const boundingRectAnchor = anchorElement.getBoundingClientRect(); maskNoteElement.classList.add(NOTE_MASK_MOVING_CLASS); if (selectedNote) { maskNoteElement.classList.add(selectedNote.dataset.color); } maskNoteElement.style.setProperty("top", (boundingRectAnchor.y - 3) + "px"); maskNoteElement.style.setProperty("left", (boundingRectAnchor.x - 3) + "px"); maskNoteElement.style.setProperty("width", (boundingRectAnchor.width + 3) + "px"); maskNoteElement.style.setProperty("height", (boundingRectAnchor.height + 3) + "px"); } } function hideMaskNote() { maskNoteElement.classList.remove(NOTE_MASK_MOVING_CLASS); if (selectedNote) { maskNoteElement.classList.remove(selectedNote.dataset.color); } } function selectNote(noteElement) { if (selectedNote) { selectedNote.classList.remove(NOTE_SELECTED_CLASS); maskNoteElement.classList.remove(selectedNote.dataset.color); } noteElement.classList.add(NOTE_SELECTED_CLASS); noteElement.classList.add(noteElement.dataset.color); selectedNote = noteElement; } function getTarget(clientX, clientY) { const targets = Array.from(document.elementsFromPoint(clientX, clientY)).filter(element => element.matches("html *:not(" + NOTE_TAGNAME + "):not(." + MASK_CLASS + ")")); if (!targets.includes(document.documentElement)) { targets.push(document.documentElement); } let newTarget, target = targets[0], boundingRect = target.getBoundingClientRect(); newTarget = determineTargetElement("floor", target, clientX - boundingRect.left, getMatchedParents(target, "left")); if (newTarget == target) { newTarget = determineTargetElement("ceil", target, boundingRect.left + boundingRect.width - clientX, getMatchedParents(target, "right")); } if (newTarget == target) { newTarget = determineTargetElement("floor", target, clientY - boundingRect.top, getMatchedParents(target, "top")); } if (newTarget == target) { newTarget = determineTargetElement("ceil", target, boundingRect.top + boundingRect.height - clientY, getMatchedParents(target, "bottom")); } target = newTarget; while (boundingRect = target && target.getBoundingClientRect(), boundingRect && boundingRect.width <= SELECT_PX_THRESHOLD && boundingRect.height <= SELECT_PX_THRESHOLD) { target = target.parentElement; } return target; } function getMatchedParents(target, property) { let element = target, matchedParent, parents = []; do { const boundingRect = element.getBoundingClientRect(); if (element.parentElement && !element.parentElement.tagName.toLowerCase() != NOTE_TAGNAME && !element.classList.contains(MASK_CLASS)) { const parentBoundingRect = element.parentElement.getBoundingClientRect(); matchedParent = Math.abs(parentBoundingRect[property] - boundingRect[property]) <= SELECT_PX_THRESHOLD; if (matchedParent) { if (element.parentElement.clientWidth > SELECT_PX_THRESHOLD && element.parentElement.clientHeight > SELECT_PX_THRESHOLD && ((element.parentElement.clientWidth - element.clientWidth > SELECT_PX_THRESHOLD) || (element.parentElement.clientHeight - element.clientHeight > SELECT_PX_THRESHOLD))) { parents.push(element.parentElement); } element = element.parentElement; } } else { matchedParent = false; } } while (matchedParent && element); return parents; } function determineTargetElement(roundingMethod, target, widthDistance, parents) { if (Math[roundingMethod](widthDistance / SELECT_PX_THRESHOLD) <= parents.length) { target = parents[parents.length - Math[roundingMethod](widthDistance / SELECT_PX_THRESHOLD) - 1]; } return target; } }; const anchorNote = function anchorNote(event, noteElement, deltaX, deltaY) { event.preventDefault(); const { clientX, clientY } = getPosition(event); document.documentElement.style.removeProperty("user-select"); noteElement.classList.remove(NOTE_MOVING_CLASS); maskNoteElement.classList.remove(NOTE_MASK_MOVING_CLASS); maskPageElement.classList.remove(PAGE_MASK_ACTIVE_CLASS); maskNoteElement.classList.remove(noteElement.dataset.color); const headerElement = noteElement.querySelector("header"); headerElement.ontouchmove = document.documentElement.onmousemove = null; let currentElement = anchorElement; let positionedElement; while (currentElement.parentElement && !positionedElement) { if (!FORBIDDEN_TAG_NAMES.includes(currentElement.tagName.toLowerCase())) { const currentElementStyle = getComputedStyle(currentElement); if (currentElementStyle.position != "static") { positionedElement = currentElement; } } currentElement = currentElement.parentElement; } if (!positionedElement) { positionedElement = document.documentElement; } const containerElement = noteElement.getRootNode().host; if (positionedElement == document.documentElement) { const firstMaskElement = document.querySelector("." + MASK_CLASS); firstMaskElement.parentElement.insertBefore(containerElement, firstMaskElement); } else { positionedElement.appendChild(containerElement); } const boundingRectPositionedElement = positionedElement.getBoundingClientRect(); const stylePositionedElement = window.getComputedStyle(positionedElement); const borderX = parseInt(stylePositionedElement.getPropertyValue("border-left-width")); const borderY = parseInt(stylePositionedElement.getPropertyValue("border-top-width")); noteElement.style.setProperty("position", "absolute"); noteElement.style.setProperty("left", (clientX - boundingRectPositionedElement.x - deltaX - borderX) + "px"); noteElement.style.setProperty("top", (clientY - boundingRectPositionedElement.y - deltaY - borderY) + "px"); }; const getPosition = function getPosition(event) { if (event.touches && event.touches.length) { const touch = event.touches[0]; return touch; } else { return event; } }; const onMouseUp = function onMouseUp(event) { if (highlightSelectionMode) { highlightSelection(); onUpdate(false); } if (removeHighlightMode) { let element = event.target, done; while (element && !done) { if (element.classList.contains(HIGHLIGHT_CLASS)) { document.querySelectorAll("." + HIGHLIGHT_CLASS + "[data-singlefile-highlight-id=" + JSON.stringify(element.dataset.singlefileHighlightId) + "]").forEach(highlightedElement => { resetHighlightedElement(highlightedElement); onUpdate(false); }); done = true; } element = element.parentElement; } } if (resizingNoteMode) { resizingNoteMode = false; document.documentElement.style.removeProperty("user-select"); maskPageElement.classList.remove(PAGE_MASK_ACTIVE_CLASS); document.documentElement.ontouchmove = document.documentElement.onmousemove = null; onUpdate(false); } if (movingNoteMode) { anchorNote(movingNoteMode.event || event, selectedNote, movingNoteMode.deltaX, movingNoteMode.deltaY); movingNoteMode = null; document.documentElement.ontouchmove = document.documentElement.onmousemove = null; onUpdate(false); } if (collapseNoteTimeout) { clearTimeout(collapseNoteTimeout); collapseNoteTimeout = null; } if ((cuttingMode || cuttingOuterMode) && cuttingPath) { if (event.ctrlKey) { const element = cuttingPath[cuttingPathIndex]; element.classList.toggle(cuttingMode ? CUT_SELECTED_CLASS : CUT_OUTER_SELECTED_CLASS); } else { validateCutElement(event.shiftKey); } } }; const getShadowRoot = function getShadowRoot(element) { const chrome = window.chrome; if (element.openOrClosedShadowRoot) { return element.openOrClosedShadowRoot; } else if (chrome && chrome.dom && chrome.dom.openOrClosedShadowRoot) { try { return chrome.dom.openOrClosedShadowRoot(element); } catch (error) { return element.shadowRoot; } } else { return element.shadowRoot; } }; const maskNoteElement = getMaskElement("note-mask"); const maskPageElement = getMaskElement("page-mask", "single-file-page-mask"); let selectedNote, highlightSelectionMode, removeHighlightMode, resizingNoteMode, movingNoteMode, collapseNoteTimeout, cuttingMode, cuttingOuterMode; window.onresize = reflowNotes; window.onUpdate = () => {}; document.documentElement.onmouseup = document.documentElement.ontouchend = onMouseUp; window.addEventListener("DOMContentLoaded", () => { processNode(document); reflowNotes(); document.querySelectorAll("single-file-note").forEach(noteElement => attachNoteListeners(noteElement)); }); })()</script>

@gildas-lormeau
Copy link

Actually, I did not even know Obsidian was a browser, I never used it. Maybe you need to enable this flag: about://flags/#enable-experimental-web-platform-features. FYI, the exact term of this feature is the "Declarative Shadow DOM", see https://web.dev/declarative-shadow-dom/.

@nuthrash
Copy link
Owner Author

nuthrash commented Oct 23, 2022 •
edited

Refer to "Parser only" section, if I insert the HTML string of the HTML file with single-file-note by insertAdjacentHTML(), the Developer Console would show a yellow message:

Found declarative shadowroot attribute on a template, but declarative Shadow DOM has not been enabled by includeShadowRoots.

The includeShadowRoots is used to pass to the standard DOMParser (Obsidian forbid the DOMParser).
I would not see this message while I using appendChild() to append the DOM object. (Of cause, I add the tag <single-file-note> and attribute shadowroot to DOMPurify configuration)
But the notes are still invisible.

After some try and errors, I still cannot find the way to ensure "Declarative Shadow DOM" feature is enabled in Obsidian. However, according to "Feature detection and browser support" section, the function HTMLTemplateElement.prototype.hasOwnProperty('shadowRoot'); return true at the Developer Console of Obsidian 1.0.0.
(NOTE: about://flags/#enable-experimental-web-platform-features cannot be directly navigated inside Obsidian and Electron platforms, they are not normal web browsers and lack many UI elements including address bar)

By the way, the Visual Studio Code is also based on the Electron framework, you can refer to https://www.electronjs.org/apps.

@gildas-lormeau
Copy link

Thank you for the additional information. From my point of view, it looks like it's a bug in Obsidian.

@nuthrash
Copy link
Owner Author

OK, thanks very much for your help. If I get something new about this bug, I will tell you.

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 24, 2022 •
edited

I forgot that there will be a limitation though. JavaScript is required to position the notes in the page when it's resized. This means that notes might be at the wrong place if the page is displayed for example in a frame with a smaller or larger width than the width of the page when the note was added.

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 24, 2022 •
edited

Here is a zip file containing an example of page (example.com) which illustrates the resizing issue. The note should be anchored to "More information..." but cannot, when resizing the window, because the page contains no script at all.
It can also be used as a test page for Obsidian because it relies only on the Declarative Shadow DOM and contains no script.

Example.zip

@nuthrash
Copy link
Owner Author

nuthrash commented Oct 25, 2022 •
edited

Finally, I found the way to bypass Obsidian's constraints.
The process to render HTML elements of Declarative Shadow DOM(DSD) correctly is

  1. Build DOM object by the standard DOMParser with {includeShadowRoots: true} option.
  2. Append the DOM object with appendChild(). (The related DSD elements shall inside <body> of the DOM object)

Fig3. Notes become visible
s3 - notes visible

Even all DSD HTML elements rendered by DOMPurify are existed in DOM object, they are still invalid for DSD. I think maybe I have to refactor all codes, or find the correct way to render DSD elements by DOMPurify.

@nuthrash
Copy link
Owner Author

nuthrash commented Oct 25, 2022 •
edited

Here is a zip file containing an example of page (example.com) which illustrates the resizing issue. The note should be anchored to "More information..." but cannot, when resizing the window, because the page contains no script at all. It can also be used as a test page for Obsidian because it relies only on the Declarative Shadow DOM and contains no script.

Example.zip

How a terrible Example.html, it would disarrange the whole layout of the Obsidian
Fig4. After open Example.html
d1 - after open Example html

I have questions.
The green note of Example.html is visible in Chrome, but invisible in Firefox. Why?
I make two similar .html files with notes by SingleFile in Chrome and Firefox. Their notes are visible in both Chrome and Firefox. What is the difference between them and Example.html?

I found the HTML files made by SingleFile or "Print Edit WE" by saving Example.com's content would cause the same situation of Fig4. So, this is a problem about Example.com's HTML content, I have to check more deeper.

@gildas-lormeau
Copy link

The green note is not visible in Firefox because it does not implement the Declarative Shadow DOM specification. The difference is that your pages contain a polyfill implementing the Declarative Shadow DOM specification.

I'm surprised this page is causing a bug in Obsidian though. The HTML is quite simple.

@nuthrash
Copy link
Owner Author

I'm surprised this page is causing a bug in Obsidian though. The HTML is quite simple.

That is my fault, I did not isolate the content of HTML file very well, and that cause CSS Style Pollution to make this situation. I had isolated them with a Shadow DOM element and a dummy transform property of its parent element.

The green note is not visible in Firefox because it does not implement the Declarative Shadow DOM specification. The difference is that your pages contain a polyfill implementing the Declarative Shadow DOM specification.

Hmm, I guess you use the Shadow DOM to wrap and implement the polyfill? I see there are some attachShadow() inside the script.

@gildas-lormeau
Copy link

gildas-lormeau commented Oct 26, 2022 •
edited

Hmm, I guess you use the Shadow DOM to wrap and implement the polyfill? I see there are some attachShadow() inside the script.

Yes, the purpose of the script is to create a shadow DOM tree in the parent element of each <template> tag, copy the content of the <template> tag in the tree, and delete the <template> tag.

@nuthrash
Copy link
Owner Author

nuthrash commented Nov 12, 2022 •
edited

Hi @scruel,
Sorry to let you know that late. By gildas-lormeau's packages and his heavy assist, I have made this plugin support reading the files generated by SingleFileZ. You can update to the latest version 1.0.4 to check if you can see the content of them.

Although this plugin can read the files produced by SingleFileZ with the option "create self extracting archives" unchecked, I think I still cannot declare this plugin support "Mozilla Archive Format". Because that format is not a HTML file format, it is a file container format. The working purpose of this plugin as its name showing is to assist users to read pure text HTML files in Obsidian, not become an "Universal Reader" to read any file with .html file extension.

Sign up for free to join this conversation on GitHub. Already have an account? Sign in to comment
Assignees

@nuthrash nuthrash

Labels
help wanted Extra attention is needed
Projects
None yet
Milestone
No milestone
Development

No branches or pull requests
2 participants
@gildas-lormeau @nuthrash
