Sara Brumfield edited this page Oct 17, 2022 · 18 revisions

FromThePage is an open-source tool that allows volunteers to collaborate to transcribe handwritten documents.

FromThePage Diagram

Features

  • Wiki-style Editing: Users add or edit transcriptions using simple, wiki-style syntax on one side of the screen while viewing a scanned image of the manuscript page on the other side.
  • Version Control: Changes to each page transcription are recorded and may be viewed to follow the edit history of a page.
  • Wikilinks: Subjects mentioned within the document may are indexed via simple wikilinks within the transcription. Users can annotate subjects with full subject articles.
  • Presentation: Readers can view transcriptions in a multi-page format or alongside page images. They can also read all the pages that mention a subject
  • Automatic Markup: FromThePage can suggest wikilinks to editors by mining previously edited transcriptions. This helps insure editorial consistency and vastly reduces the amount of effort involved in markup.
  • Internet Archive integration: FromThePage can be pointed at manuscripts hosted on Archive.org. It will import the page structure and any printed page titles into its native format for transcription, while serving page images from the Internet Archive.
  • Translation: FromThePage supports foreign language material which can be transcribed in full UTF-8. A translator’s workflow allows creation of parallel texts.
  • OCR Correction: Not just for handwritten materials, FromThePage can import OCR alongside the original image for users to correct and edit.

License

FromThePage is currently issued under the Affero GPL. This license remains controversial, however, so we are trying to preserve the option to dual-license the code.

Platform

We recommend you run FromThePage on a Linux operating system. It currently requires Ruby on Rails version 4.2.1 and the RMagick, hpricot, will_paginate, and OAI gems.

Installation

Install required packages & gems

Install Ruby, RubyGems, Bundler, ImageMagick, MySQL and Git

Install pandoc 2.13 or later.

sudo apt-get install texlive-generic-extra texlive-math-extra

Install ImageMagick

sudo apt-get install libmagickwand-dev imagemagick
sudo apt-get install libmagickcore-dev

dev libraries:
sudo apt-get install libmysqlclient-dev libmysqlclient20 ruby-dev

Install Graphviz

apt-get install graphviz (or see the graphviz documentation at http://www.graphviz.org/)

If you wish to use latex formulas in your transcriptions, you’ll need to install “pdflatex” and “pdfcrop”.
You can usually install them by typing:
sudo apt-get install texlive-latex-base texlive-extra-utils

Configure MySQL

Create a database and user account for FromThePage to use.

Install FromThePage

Clone the repository

git clone git://github.com/benwbrum/fromthepage.git

Install required gems

bundle install

Configure MySQL

Create a database and user account for FromThePage to use.

Then update the config/database.yml file to point to the MySQL user account and database you created above.

Run
rake db:migrate
to load the schema definition into the database account.

Modify the configuration parameters in config/initializers/01fromthepage.rb.

Modify the config/environments/production.rb (or development.rb) file to configure your mailer. (Search for “action_mailer”.)

Finally, start the application

rails server

Docker

Alternatively, Ryan Baumann has created a docker image for FromThePage that may be a good starting point.
https://github.com/ryanfb/docker_fromthepage

Configuration

After installing you’ll want to configure FromThePage for your environment.
