What is it?

Phantom Camera is a Godot 4 plugin designed to provide and simplify common behaviors for the built-in Camera2D and Camera3D nodes - heavily inspired by a Unity package called Cinemachine.

It allows for simple behaviours such as following and looking at specific nodes, with an optional smooth/dampened movement, to more advance logic like reframing itself to keep multiple nodes in view and dynamically animate between specific camera positions, i.e. other PhantomCamera nodes, on demand.

Feature.Examples.mp4
Documentation & Guides Roadmap

Showcases

GameFromScratch's Youtube Overview Bissash's Youtube Video

(English)

Phantom Camera For Godot Is Awesome!
GameFromScratch

(Spanish)

Mejores cΓ‘maras con Phantom Camera
Bissash

ClΓ©cio Espindola GameDev's Youtube Video ClΓ©cio Espindola GameDev's Youtube Video

(Portuguese)

CΓ‚MERA mais DINΓ‚MICA com Phanton Camera
ClΓ©cio Espindola GameDev

(English)

The 4 MUST Have ADDONS for Godot 4
DevWorm

Features

Determines which PhantomCamera should be active with the Camera2D/Camera3D.

When a new camera recieves a higher priority than currently active PhantomCamera the Camera2D/Camera3D will seamlessly transition to the new one.


Define how the Camera2D/Camera3D should follow, or reposition based on, its target(s).

Sticks to its target.


Follows the target with an optional offset and damping.


2D

3D
2D-Follow-Simple.mp4
3D-Follow-Simple.mp4

Follows the centre of a collection of targets.


2D

3D
2D-Follow-Group.mp4
3D-Follow-Group.mp4

Follows a target while being positionally confined to a Path node.


2D

3D
2D-Follow-Path.mp4
3D-Follow-Path.mp4

Enables dynamic framing of a given target using dead zones. Dead zones enable the camera to remain still until the target moves far enough away from the camera's view. This is determined by the horizontal and vertical dead zone size in their respective properties within the inspector.


2D

3D
2D-Follow-Framed.mp4
3D-Follow-Framed.mp4

As the name implies, this mode is meant to be used for third person camera experiences.
It works by applying a SpringArm3D node as a parent, where its properties, such as Collison Mask, Spring Length and Margin, can be adjusted from the PhantomCamera node.


2D

3D
Not available in 2D
3D-Follow-Third-Person.mp4

Define the Zoom level for the Camera2D.


2D

3D
2D-Zoom.mp4
Not available in 3D

Defines where the Camera3D should be lookingβ€”adjusting its rotational value.


Copies the rotational value of its target.



Looks At the target with an optional offset.


2D

3D
Not available in 2D
3D_Look_At_Simple.mp4

Looks at the centre of a collection of targets.


2D

3D
Not available in 2D
3D-LookAt-Group.mp4

Tweak how the Camera2d/Camera3D tweens to a newly active PhantomCamera.


2D

3D
2D-Tweening.mp4
3D-Tweening.mp4

Viewfinder.mp4

Preview what the Camera2D / Camera3D sees when attached to a PhantomCamera. Accessible from the bottom panel labelled Phantom Camera. The viewfinder rendering of the scene will only work when the combination of a Camera, PhantomCameraHost and PhantomCamera are present in the scene.


πŸͺ€ Example Scenes

A 2D and 3D example scenes can be found inside res://addons/phantom_camera/examples.

πŸ’Ύ Installation

Asset Library (Recommended - Stable)

  1. In Godot, open the AssetLib tab.
  2. Search for and select "Phantom Camera".
  3. Download then install the plugin (be sure to only select the phantom_camera directory).
  4. Enable the plugin inside Project/Project Settings/Plugins.

Github Releases (Recommended - Stable)

  1. Download a release build.
  2. Extract the zip file and move the addons/phantom_camera directory into the project root location.
  3. Enable the plugin inside Project/Project Settings/Plugins.

Github Main (Latest - Unstable)

  1. Download the latest main branch.
  2. Extract the zip file and move the addons/phantom_camera directory into project's root location.
  3. Enable the plugin inside Project/Project Settings/Plugins.

For more help, see Godot's official documentation

πŸ“– Roadmap

See the project page for upcoming features.

FAQ

See the FAQ page on the documentation site.

Contribution

See the contribution guidelines on the documentation site.

Credits

MIT License
