DISCONTINUATION OF PROJECT.

This project will no longer be maintained by Intel.

This project has been identified as having known security escapes.

Intel has ceased development and contributions including, but not limited to, maintenance, bug fixes, new releases, or updates, to this project.

Intel no longer accepts patches to this project.

Workload Consolidation - Industrial Edge to Cloud Demo

This repo hosts demo code designed to showcase the workload consolidation feature of Project ACRN on edge devices.

Demo Video

Getting ready on Edge and Cloud

The demo has been containerized as two deployments for edge and cloud respectively. Before the deployment, here are some prerequisites.

1. Clone this repository locally: git clone https://github.com/intel/acrn-workload-consolidation
2. Make sure Docker is running: sudo systemctl start docker. If you have not installed Docker yet, please refer to the installation guide to set up docker
3. Follow these on-line instructions: Docker Compose installation and have docker-compose installed
4. Put yourself in the cloned folder: cd acrn-workload-consolidation

Set up services on edge

There are four services running on the edge device: stream-web, stream-buffer, redis and mosquitto. Here are the steps to start the deployment:

1. Setup proxy in docker-compose.yml file if you are behind a network proxy and build service images:

sudo docker-compose -f docker-compose.yml build

Alternatively, the images could be pulled by Dockerhub:

sudo docker pull xshan1/industrial-edge-demo_stream-buffer:latest
sudo docker pull xshan1/industrial-edge-demo_stream-web:latest
sudo docker tag xshan1/industrial-edge-demo_stream-buffer:latest industrial-edge-demo_stream-buffer:latest
sudo docker tag xshan1/industrial-edge-demo_stream-web:latest industrial-edge-demo_stream-web:latest

2. Set-up the IP camera following the online User Guides
3. Configure the IP camera video url by setting CAMERA_SRC=http://ip_cam_hostname:port/xxx in docker-compose.yml If you are using a usb web camera, set CAMERA_SRC=<device id> and uncomment the lines below.

  #devices:
     #- "/dev/video0:/dev/video0"

Update the device id by your actual device id. eg. set CAMERA_SRC=1 and devices: - "/dev/video1:/dev/video1"

4. Start the services and all the services are running in the background.

sudo /usr/local/bin/docker-compose up -d

Check the logs:

sudo /usr/local/bin/docker-compose logs

Check container status:

sudo /usr/local/bin/docker-compose ps -a

5. Tear down the services

sudo /usr/local/bin/docker-compose down

Set up services on the Cloud:

There are seven services running on the Cloud: mongo, redis, mongosetup, mongo-express, rest-api, video-compressor, dashboard. Here are the steps to start the deployment:

1. Setup proxy in docker-compose-cloud.yml file if you are behind a network proxy and build service images:

cd acrn-workload-consolidation
sudo docker-compose -f docker-compose-cloud.yml build

Or the images could be pulled from Dockerhub:

sudo docker pull xshan1/industrial-edge-demo_dashboard:latest
sudo docker pull xshan1/industrial-edge-demo_rest-api:latest
sudo docker pull xshan1/industrial-edge-demo_mongosetup:latest
sudo docker pull xshan1/industrial-edge-demo_video-compressor:latest
sudo docker tag xshan1/industrial-edge-demo_dashboard:latest industrial-edge-demo_dashboard:latest
sudo docker tag xshan1/industrial-edge-demo_rest-api:latest industrial-edge-demo_rest-api:latest
sudo docker tag xshan1/industrial-edge-demo_mongosetup:latest industrial-edge-demo_mongosetup:latest
sudo docker tag xshan1/industrial-edge-demo_video-compressor:latest industrial-edge-demo_video-compressor:latest

2. Create two directories on the host for mongodb and video files respectively:

sudo mkdir -p /data
sudo mkdir -p /video

3. Configure MOSQUITTO_HOST and REDIS_HOST for the video-compressor service:

video-compressor:
    ...
    command: ["/usr/bin/python3", "-u", "video_compressor.py"]
    environment:
      - "REDIS_HOST=<ip addr of edge device>"
      - "MOSQUITTO_HOST=<ip addr of edge device>"
      - "REST_API=rest-api"

4. Configure REST_API, WS_SERVER, TIMEZONE, GEO_LAT and GEO_LON for dashboard; Open file vue-table/src/config.js and update content as below:

export const CONFIG = Object.freeze({
    REST_API: "http://<ip addr of cloud device>:3000",
    WS_SERVER: "ws://<ip addr of edge device>:9001"
    TIMEZONE: "Asia/Shanghai",
    GEO_LAT: 47.413220,
    GEO_LON: -1.219482,
});

Replace both <ip addr of cloud device> and <ip addr of edge device> with the actual Cloud and Edge device IP addresses (respectively). Update the timezone and geo-location accordingly as well. If you are uncertain about your timezone name, you may refer to this list.

5. Start all the services in the background

sudo docker-compose -f docker-compose-cloud.yml up -d

6. Browse the dashboard: http://<cloud-host-ip>:8080

Set up cyclic test agent on ACRN service OS

The agent watches the real-time changes on the cyclic test log file and sends the accumulated result to the Cloud by mosquitto service.

1. Checkout the repo on the SOS

git clone https://github.com/intel/acrn-workload-consolidation
cd acrn-workload-consolidation

2. Make sure that Python >= 3.5 has been installed as well as the python dependencies

pip3 install pyinotify paho-mqtt

3. Start the agent

./cyclic_test_agent.py <path/to/zephyr.log> -s <ip addr mqtt_host> -p <ip addr mqtt_port> -d

You may check cyclic_test_agent.py -h for help in details.
