Non-Glasses Pages

Link to the main program: placemat.ps

Links to documentation: ▶︎ Introduction, and a first placemat  ▶︎ Fonts and glass decoration  ▶︎ Compound Strings and non‑ASCII characters  ▶︎ Page‑level controls  ▶︎ Arrangement of glasses on the page  ▷︎ Non‑Glasses Pages  ▶︎ Document‑level controls  ▶︎ Type sizes  ▶︎ Translations  ▶︎ Code injection  ▶︎ Bitmap images  ▶︎ Debugging


Introduction

There are multiple types of printable page.

  • /Glasses: labels glass positions;
  • /TastingNotes: for those who record TNs with a pen on paper.
  • /PlaceName: At a large formal tasting it is appropriate to label each person’s place-setting, so everybody knows who everybody else is.
  • /PrePour: to help with the pre-pouring of portions — necessary at at tastings with many people.
  • /VoteRecorder: to record the votes for Wine Of The Night, and to record guesses of blinded wines.
  • /DecantingNotes: observations of those doing the decanting.
  • /Accounts: tawdry financial matters, organised.
  • /CorkDisplay as described.
  • /NeckTags: to label de-capsuled bottles when decanting; also around the neck of a wrapped bottle at blind tastings.
  • /DecanterLabels: cut; paste to back of old business cards; allow to dry; punch holes; hang on decanters; fill decanters; wait; drink.
  • /BottleWrap: at a blind tasting, to which bottles rather than decanters are being brought, bottles should be wrapped in pages that match everything else.
  • /StickyLabels: at a tasting with more wines than glasses, these can be attached to the foot of a glass to show both owner and current contents. Larger stickies also useful on bottles.
  • /OneCircle: to make a GIF animation of the circles.

To make the glasses pages required information about wines, about people, and about formatting. That information is reused to make the other pages.

Each of the non-glasses pages has a few controls, but only a few, as described below.

TastingNotes

By default there are also tasting-note pages. These have a few parameters which might want changing, and others which are almost never changed.

Worthwhile

Page size is TastingNotesPaperType, which North Americans should change from the default of /A4 to /USL = 8½″×11″.

Which wines appear on which TN pages is controlled by GlassesOnTastingNotePages, a depth-two array of the same structure as GlassesOnSheets. E.g., a possible non-default value might be /GlassesOnTastingNotePages [ [0 2 4 6 8 10] [1 3 5 7 9 11] ] def, which puts alternate wines over two pages.

The glasses page uses arrays Circlearrays and Titles. The tasting-note pages use CirclearraysTastingNotes and TitlesTastingNotes, which by default equal Circlearrays and Titles respectively. Why? Consider a vertical, so multiple years of one house. Space is tight in the glasses circles, so the Titles might well be two-digit years. There is much more space on the tasting-note pages, so TitlesTastingNotes could hold four-digit years. Indeed, it is quite usual to generate this automatically, as in the following code fragment, which repays study.

/Circlearrays [
	[ (1927) (Niepoort) ]
	[ (1931) (Niepoort) ]
	[ (1945) (Niepoort) ]
	[ (1955) (Niepoort) ]
	[ (1963) (Niepoort) ]
] def
/TitlesTastingNotes [ Circlearrays {0 get} forall ] def  % (1927) (1931) ...
/Titles [ TitlesTastingNotes {2 2 getinterval} forall ] def  % (27) (31) ...

The glasses page also has arrays Abovetitles, Belowtitles, Overtitles. Some of the other page types, including the tasting-note pages, have only one additional array, SubtitlesTastingNotes. The complicated default picks, one element at a time, the first non-empty from Overtitles, then Belowtitles, then Abovetitles.

Optionally, there can be a row of stars: circle to score. This can nudge those not prone to scoring into doing so. But different people use different scoring systems, so the parameter TastingNotesStarsNameColsRowsArrangement determines things by elements of Names.

/TastingNotesStarsNameColsRowsArrangement
[
	(Julian)   5 1 /Upright
	(Alice)    5 1 /Sideways
	(Benedict) 5 1 /Alternating
] def

This is an array of length a multiple of 4. The first of each set of four is the text of the name of the person to whom this applies (before comparing the code removes non-text). The second is a number of columns; the third a number of rows. The fourth of each set of four is one of:

  • /Upright = Upright
  • /Sideways = Sideways
  • /Alternating = Alternating

Sometimes, too small a table is going to be a squeeze. When so, it is helpful to be able to fold the TN sheets, so they use less physical space, and can be rested on a smaller morsel of table. TastingNotes_NumVerticalSections defaults to 1, and for a tight table could be set to 2, allowing a TN page to be folded vertically, and perhaps after horizontally, for easier manipulation. TastingNotes_NumVerticalSections ≥ 2 suppresses the column headings, suppresses the column-separating lines, and suppresses the effect of TastingNotesCirclesBehind.

Superfluous

The elements of TitlesTastingNotes are shown at a size not exceeding TastingNotesTitlesFontSizeMax, and the elements of SubtitlesTastingNotes are shown at TastingNotesSubtitleFontSizeProportionTitles times the size of the TitlesTastingNotes. The vertical separation between the CirclearraysTastingNotes and TitlesTastingNotes, and between the TitlesTastingNotes and SubtitlesTastingNotes, is TastingNotesLineGap.

The tasting-note pages are lightly divided into columns, the number of columns and the column headings being determined by the array TastingNotesColumnHeadings, by default this being [ (Times) (Eye) (Nose) (Mouth) (Score) ], the first of these being intended to hold times of decanting and sampling. These column headings are rendered in the font HeaderFont at size TastingNotesColumnHeadingsFontSize. The columns have widths proportionate to TastingNotesColumnRelativeWidths, an array of the same length as TastingNotesColumnHeadings. TastingNotesColumnStrokeCode formats and strokes the lines that separate the columns.

The decorative boolean TastingNotesCirclesBehind repeats the elements from the glasses pages, faded by a factor of either TastingNotesCirclesBehindFadingFactorIfAnyGrey or TastingNotesCirclesBehindFadingFactorIfAllBlack, according to whether ColourSchemeTitles is ever /MidGrey. By default TastingNotesCirclesBehind is true if distilling with Distiller, false otherwise (because of an awkward technical interaction between Mac Preview and GhostScript). The circles are in a straight line, the x position at the top being TastingNotesCirclesBehindTopX (0 ⇒ left, 1 ⇒ right), and at the bottom is TastingNotesCirclesBehindBottomX. The complication of the default values causes, over multiple TN pages, some variation to the visual effect. The boolean TastingNotesCirclesBehindFitAndCentreInRow controls whether the circles fit between the horizontal lines made by the Circlearrays (true), or whether they are as large as possible (false).

There has been discussion of printing A6 booklets to hold the tasting-note pages, one wine per page. To aid this it is possible to replace the names with page numbers via TastingNotesReplaceNameWithPageNum, the page-number string being defined in TastingNotesPageNumCompoundString, and being shown in a font size reduced by a factor of TastingNotesPageNumFontSizeFactor. This feature has never been used.

Side-by-side Glasses

If having a mini tasting of only three wines, one might wish to print everything on one sheet, especially if everything must be squeezed onto a small round bar table. For right handers the three glasses would be on the left of the tasting-notes; for lefties, glasses to the right — as in the images on the right. This small-tasting layout is enabled by setting the boolean constant SideBySideGlassesTastingNotes to true.

Superfluous

Some parameters are almost never changed.

Between the two sides of the paper is a gutter, an internal margin, of size SideBySideGlassesTastingNotesWidthGutter; the proportion of the page occupied by the glasses (from the edge of the paper to the middle of the gutter) being SideBySideGlassesTastingNotesProportionPageGlasses. The people are right-handed unless present in the array LeftHanders, which is also used to determine whether water boxes are on the right or the left.

When SideBySideGlassesTastingNotes is true several of the tasting-note parameters are ignored, action being determined by the glasses equivalent. Ignored parameters include TastingNotesPaperType and TastingNotesOrientation; PageOrderingTastingNotePages; and MirrorPagesTastingNotePages.

Place names

At a large formal tasting a tented label for each person’s place-setting helps everybody knows who everybody else is, even late in the tasting. Pages require three folds. First, fold in half; then fold and press hard along the faint dashed lines, thereby preventing the corners curling. The side with the small-writing header and footer should face the named person; the side without should face away.

Pages to facilitate this are produced using the Boolean PlaceNames parameter. Typically, this is the only of these parameters that is touched.

There can be multiple copies of the place names, with different names, so NamesPlaceNames is an array of arrays of names, by default containing just one sub-array, Names. Why the multiple sets of names? The intention is that one set is the Names, and there can also be one set per food course, holding the names of the courses. When the food is about to arrive, switch them, so that waiters and waitresses see which plates go where. That done, switch back. This might be achieved with parameters resembling:

/Names [ (Julian) (Alice) (Ben) (Caroline) (Derek) (Elizabeth) ] def
/NamesPlaceNames [
	Names  % People
	[
		(Steak & kidney pie)   % Julian
		(Roast beef, lots)     % Alice
		(Fillet, blue)         % Ben
		(Fillet, medium-rare)  % Caroline
		(Low-salt diet salad)  % Derek
		(Burger & chips)       % Elizabeth
	]  % Foods, and food-free foods
] def  % /NamesPlaceNames

Superfluous

There is also the parameter PlaceNamesShowNameAsFooter, an array of Booleans the same length as NamesPlaceNames, controlling whether the relevant element of Names is to be shown as a footer. If the big writing says “Low-salt diet salad”, it can simplify set-up to have a very small “Derek” written on the page.

These place-name pages are set on pages of size PlaceNamesPaperType (defaulting to TastingNotesPaperType), and orientation PlaceNamesOrientation (default /Landscape). The lines marking the anti-curling folds are a distance PlaceNamesFirstAndThirdFoldsFromEdge away from the top and bottom edges, defaulting to 36 = ½″ = 12.7mm, which should be changed to 0 if printing to stiff card. The Names are set in font PlaceNamesFont (defaulting to NamesFont, though sometimes TitlesFont would be more appropriate), at the largest size that fits subject to an upper bound of PlaceNamesMaxFontSizeAbsolute (defaulting to 192). The colour scheme used is ColourSchemePlaceNames, this functioning in the same manner as ColourSchemeTitles. Because these names are usually larger than the Titles, various details such as line-widths are set larger by a factor of PlaceNamesDetailsScalingFactor; but, messily, this parameter is used partly in the code, and partly in the default values of other parameters.

Caution: if used with FillTitles distillation is excruciatingly slow. Distillation over the web will almost certainly time out: use local conversion.

PrePour

If a tasting is attended by six people, decanters can circulate and people help themselves. But at a tasting for fourteen people the portion size is a mere 5cl (75cl bottle, less the angels’ share, less a little loss during decanting, ÷ 14). So wine must be pre-poured. This could be a source of confusion: “What did you pour into these fourteen glasses?”, “Err, I think …”. Instead glasses are arranged on or close to a page that labels them. Then the pourer knows what to pour; and those moving the glasses to the table know what has been poured.

PrePour

The number of copies of these pre-pour sheets is PrePourNumCopies, the default being 1 if the length of Names is ≥12, otherwise 0. In an awkward working space /PrePourNumCopies 2 def might be useful.

In a typical vertical tasting, the oldest wines come first in the list, so as to be top-left of the sheet. But decanting is in the reverse order, youngest to oldest, so it is convenient to reverse the order of the pre-pour sheets. This is controlled by PrePourReverseOrder, which defaults to true.

PrePourShowBackgroundTexts and PrePourShowDroplets control whether the background texts and droplets, present on the glasses pages, appear on the pre-pour pages. These parameters are re-used, with same meaning, on the one-circle pages.

Superfluous

The other parameters are changed rarely.

Collation of multiple copies is controlled by the Boolean PrePourCollate: if true then PrePourNumCopies is outside SheetNum and WithinPage/WithinTitles; if false then PrePourNumCopies is inside.

There are also obvious parameters PrePourPaperType and PrePourOrientation.

For some layouts, it may be desirable for a specific bottle to appear on more than one glasses sheet (e.g. when using overlapping sheets). The consequent duplication of pre-pour sheets is removed by PrePourRemoveDuplicatesByWithinTitles being true, its default value. The guillotine-and-overlap trick also messes with the order of the pre-pour sheets, sometimes fixable with PrePourSortByWithinTitles.

Most of the design is exactly copied from the glasses pages. But the text in the outermost box comes from CirclearraysPrePour, which has differed from Circlearrays only once (08 Oct 2024, 1970s, Undisturbed and Others).

If RotationTitlesAboveBelowOverCirclearray ≠ 0, then small arrows appear on the pre-pour sheets indicating the correct orientation.

VoteRecorder

At the end of a tasting there is typically a vote for the Wine Of The Night (WOTN), and for large tastings there might also be a vote after each flight or page. The vote-recorder design records public votes; it is not a ballot paper. To assist the ‘returning officer’ there is paper on which votes can be recorded. For WOTN it is the points that should be recorded, rather than the ranks, as doing so simplifies the addition of the totals. (There is also benefit in there being agreement as to what is recorded: if you record, but I retain the vote-recorder sheet and enter it into a description of the tasting, it is useful that “3” be unambiguously ‘first place three points’.)

(At ThePortForum tastings, the rule is that each person has 6 points to allocate, not more than 3 points going to any one wine, and scores must be integer multiples of ½. So the fifty-eight valid vote partitions include the usual 3+2+1, and 3+3, 3+2½+½, 3+2+½+½, 3+1½+1½, 3+1½+1+½, 3+1+1+1, 2½+2½+1, 2½+2½+½+½, 2½+2+1½, 2½+2+1+½, 2½+1½+1+1, 2+2+2, 2+2+1½+½, 2+2+1+1, 2+1½+1½+1, 1½+1½+1½+1½, and others with many smaller scores.)

Vote recorder sheets can also be used to hold, in a blind tasting, guesstimates of which is what.

Worthwhile

These sheets are enabled by setting VoteRecorders to true. There are then conceptually two levels of loops. Pages are specified, except the question in the top text. Then each of these pages can be re-used with multiple top texts.

VoteRecorderTopTexts is a double-depth array holding the questions. Its inner arrays hold the one or multiple top-texts to be used with each item of GlassesClusteredOnVoteRecorders.

/VoteRecorderTopTexts [
	[ (Wine Of The Night?)  /questiondown ]
	[ (What is it?) ]
] def

Scores are always totalled by wine. For WOTN, they are not by person. But for guesses of wines served blind, they are totalled also by person.

There is a blind-tasting mischief in adding control guesses, as a discipline on those attending. This could be a constant guess — the first few times this was done by ThePortForum crowd, the ‘Monkey’ always guessed Dow 1970. Or somebody not present could be asked to guess. The appearance of the monkey column is controlled by VoteRecorderMonkeyWhenShowTotalRow, and the name of the Monkey is /VoteRecorderMonkeyName. The monkey’s guess is VoteRecorderMonkeyVote (or can be handwritten at the event).

The array VoteRecorderShowTotalRow is of the same length as VoteRecorderTopTexts, and holds Booleans, defaulting to [ false true ], which almost always suffices.

GlassesClusteredOnVoteRecorders is a triple-depth array, the same length as VoteRecorderTopTexts and VoteRecorderShowTotalRow, and can remain at its default value except for the largest tastings. The outermost array is one per vote-recorder page: voting on separate days, with different people or wines, or different total-column-row flags, should be recorded on separate sheets. Within this are ‘clusters’, intended to align with tasting-note pages. Within this are integers pointing to wines (except that a negative integer is blank, not shown). The default value is empty if GlassesOnTastingNotePages is empty, otherwise [GlassesOnTastingNotePages], so the cluster divisions (25% grey backgrounding) on the vote recorder are page divisions between the tasting-note pages.

The most complicated definition of /GlassesClusteredOnVoteRecorders has been:

/GlassesClusteredOnVoteRecorders
[
	GlassesOnTastingNotePages 0 3 getinterval
	GlassesOnTastingNotePages 3 3 getinterval
	GlassesOnTastingNotePages 6 3 getinterval
	GlassesOnTastingNotePages
] def

Then there is the complicated VoteRecorderCrossedBox. Obviously, I am not to guess the wine I know. It is elegant for that box to be crossed. So VoteRecorderCrossedBox is code returning a Boolean, it usually accessing internal variables such as WithinTitles and ThisName, as well as VoteRecorderShowTotalRow. (VoteRecorderCrossedBox is not intuitive to use: please suggest improvements in issue 80.)

Superfluous

VoteRecorderNamesOrientation controls the orientation of the NamesVoteRecorder, with allowed values /Horizontal, /Vertical, or the default value of /Either.

VoteRecorderShowTotalCol is like VoteRecorderShowTotalRow, defaulting to an array of true.

And the self-explnatory parameters VoteRecorderPaperType and VoteRecorderOrientation; and VoteRecorderTitlesFontSizeMax and VoteRecorderSubtitleFontSizeProportionTitles (a positive number or /Automatic). The ‘Total’ strings are VoteRecorderTotalColTitle, VoteRecorderTotalRowTitle: there might be changes for Kernning or different languages.

The arrays used are NamesVoteRecorder, CirclearraysVoteRecorder, TitlesVoteRecorder, and SubtitlesVoteRecorder.

DecantingNotes

If decanting is done centrally, those decanting should record the time each bottle is decanted, as well as the condition of the cork and perhaps the qualities of the sediment. Pages to hold these notes are activated by setting DecantingNotesNumCopies to ≥ 1.

Superfluous

There are some further parameters, all of which work as on the other page types.

Arrays used are CirclearraysDecantingNotes, TitlesDecantingNotes, and SubtitlesDecantingNotes.

The text at the top of the page is DecantingNotesTopText, the two columns being titled DecantingNotesColumnHeadingTimes and DecantingNotesColumnHeadingNotes.

GlassesClusteredOnDecantingNotes has the same structure as GlassesClusteredOnVoteRecorders.

And the self-explnatory parameters DecantingNotesPaperType and DecantingNotesOrientation; and DecantingNotesTitlesFontSizeMax and DecantingNotesSubtitleFontSizeProportionTitles (a positive number or /Automatic).

Accounts

Of course, any financial rebalancing will have been computed in advance, audited in accordance with the 1844 Companies Act, and settled using a system designated under the The Financial Markets and Insolvency (Settlement Finality) Regulations 1999. Of course.

Except that it rarely works like that. At the last moment extra bottles are added, perhaps an extra attendee, and the food bill itself is not known until late in the evening, after much drinking. An Accounts page can assist those doing the computations.

Accounts

The page is activated by setting AccountsNumCopies to more than zero.

Superfluous

Columns are organised into groups, with titles for the groups and for the individual columns. AccountsColumnGroupHeadings contains the groups’ headings. AccountsSubColumnHeadings is of the same length as AccountsColumnGroupHeadings, but AccountsSubColumnHeadings contains arrays of the sub-columns’ headings. The relative widths of the sub-columns are in AccountsColumnRelativeWidths, the length of which is the sum of the lengths of AccountsSubColumnHeadings’ elements. There is one row per NamesAccounts (by default equalling Names), and a few extra rows as in AccountsExtraRows. There are also the obvious parameters AccountsTopText, AccountsColumnHeadingsFontSize, AccountsPaperType, and AccountsOrientation.

CorkDisplay

Cork display

Bottles having been decanted, corks should be put on display, for which pages are activated by setting CorkDisplayNumCopies to be positive.

Superfluous

Each rectangle is at least CorkDisplayMinWidth wide, and at least CorkDisplayMinHeight high; and the corks shown are in GlassesClusteredOnCorkDisplay, a triple-depth array resembling GlassesClusteredOnVoteRecorders.

Within each page the nesting order is determined by PackingNestingColumnMajor which is described with PackingStyles.

Pages are titled with CorkDisplayTopText, defaulting to (The Corks). The paper type is CorkDisplayPaperType; the orientation being chosen automatically.

The TitlesCorkDisplay are shown at a font size that is ≤ CorkDisplayTitleFontSizeMax.

NeckTags

There are several way to label bottles. Decanter labels could be made, but that entails some advance faffing with glue and string. Sticky labels could be printed, if whoever is doing the printing has the required labels. Neck tags are the easiest to prepare, though too small for decanters.

Neck tags are enabled by setting NeckTagsNumCopies to positive.

Superfluous

NeckTagsMinWidth, NeckTagsMaxWidth, NeckTagsMinHeight, and NeckTagsMaxHeight constrain the size of each tag. The circle to be cut is of radius NeckTagsHoleRadius, defaulting to 54pt ⇒ diameter of 108pt = 1½″ ≈ 38mm.

The width of the dashed line is NeckTagsHoleLineWidth which defaults to 0.12pt = 1 pixel on a 600 d.p.i. printer.

From the top of that hole to the top of the whole tag is NeckTagsSpaceAboveHole; between hole and top of the Title/Abovetitle/etc is at least NeckTagsSpaceAboveTitlesEtc; and between bottom of the Title/Belowtitle/etc and the inside of the bordering text (an element of CirclearraysNeckTags) is at least NeckTagsSpaceBelowTitlesEtc.

If there are BackgroundTextsGlasses then whether those background texts appear in the neck tags is controlled by NeckTagsShowBackgroundTexts. Likewise for OutlineTitles, by NeckTagsShowOutlineTitles; and for CrossHatchingInside, by NeckTagsShowCrossHatchingInside.

The tags are on paper NeckTagsPaperType.

DecanterLabels

Decanter labels are enabled by setting DecanterLabelsNumCopies to positive. Having two sets of decanter labels, pasted to both sides of the business cards, sometimes allows those sitting ‘behind’ the labels a clue as to contents.

Decanter labels are to fit within a rectangle of size DecanterLabelsMaxSmallerDimension × DecanterLabelsMaxLargerDimension, which should be the size of business cards less a small margin.

Superfluous

Orientation, of labels not page, is controlled by DecanterLabelsOrientation, with allowed values /Landscape, /Portrait, and /Automatic. The Boolean parameter DecanterLabelsGuillotineMarks controls whether small cut marks are shown: useful if guillotining. The decanter label pages include instructions of DecanterLabelsTopText, defaulting to “Decanter labels: cut; paste to business cards; allow to dry; punch holes; hang on decanters; fill decanters; wait; drink.”

If there are BackgroundTextsGlasses then whether those background texts appear in the decanter labels is controlled by BackgroundTextsDecanterLabels. Likewise for OutlineTitles, by DecanterLabelsShowOutlineTitles; and for CrossHatchingInside, by DecanterLabelsShowCrossHatchingInside.

The decanter labels are on paper DecanterLabelsPaperType.

OneCircle

Nice to post online can be a GIF animation of all the glass circles. (Examples: 07 Feb 2023, 28 Feb, 28 Mar, 24 Apr, 12 Sep, 14 Oct, 26 Mar 2024, 01 July, 24 Sep, 08 Oct.)

The natural way to proceed is to have the software make single-glass pages. For each page, width = height = 2 × radius, with the circle centred. GIFing is then easy, such as via GraphicConverter’s File > New > Animation using all Pages of the multipage Document (TIFF,PDF).

This is done by setting OneCircles to true. By default that activates OneCircleSuppressOtherPageTypes, which suppresses all other pages.

The parameters PrePourShowBackgroundTexts and PrePourShowDroplets also apply to the one-circle pages.

For this page type there isn’t a PaperType: the size of each page is determined by the size of its circle.

BottleWrap

At a blind tasting, particularly of wines served cold and undecanted, it is natural to bring the wine in its original bottle, wrapped in anonymising paper.

There’s a quirk. Usually most of the paperwork is printed centrally. But these pages need to be printed, and wrapped around bottles, before arriving at the central location. So if the main control, BottleWrapNumCopies, is not 0, then BottleWrapSuppressOtherPageTypes becomes true, and all non-bottle-wrap pages are suppressed. Then this BottleWrap PDF should be made available separately, and people encouraged to print their page(s) at home.

Superfluous

The parameter BottleWrapPadding is the empty space around the graphic that is the bottle centre. And BottleWrapScalingMin is the target size of this graphic, as a proportion of that on the Glasses pages, which is used to determine the number of rows.

Most other parameters function as for pre-pour pages: BottleWrapReverseOrder, BottleWrapCollate, BottleWrapRemoveDuplicatesByWithinTitles, BottleWrapSortByWithinTitles, BottleWrapPaperType, BottleWrapOrientation.

StickyLabels

Sticky labels

Sticky labels can be intricate to use. But before that, what is their purpose that isn’t handled by the decanter labels? There are two.

  1. At the start of decanting, some bottles will be clearly labelled. Others might have little more than a capsule, so after opening, could be entirely unlabelled. Confusion can be prevented by a sticky label, or by a neck tag, or by a decanter label.

  2. Some tastings have many more wines than glasses. At such an event it can help to stick to the foot of the glass (always foot; never bowl) a small sticky label identifying the current contents and the glass’s owner.

Specifying either of these requires describing the sheet of labels. The defaults specify the sizes for sheets of sticky labels readily available in the UK. If the defaults should know of other standard sizes, please raise an issue to that effect.

Sticky labels appear if StickyLabelsNumCopies exceeds zero.

To allow both bottle and glass labels, the sticky labels can be of multiple types, as contained in the array StickyLabelsTypes. This does very little: the sticky label code is run with StickyLabelsTypeThis set to each element of this in turn. The other parameters might choose to access the current value of StickyLabelsTypeThis.

  • With StickyLabelsTypeThis equalling 0 the default parameters fit Ryman product 0220013460 (containing 25 sheets, or equivalently to the 100-sheet pack 0220023460), having on each A4 sheet eight labels, each 99mm×68mm.
  • With StickyLabelsTypeThis equalling 1 the default parameters fit Avery J8651, each sheet of which has 65 labels, each 38.1mm×21.2mm.

Hence 0 or 1 in StickyLabelsTypes chooses a label size, or sizes.

Superfluous

If the labels are for bottles, there is one per wine; if for glasses, there is one per wine per element of NamesStickyLabels, as controlled by StickyLabelsByNameWhichReplaceCirclearrays.

If there is one label per wine per person, then the element of CirclearraysStickyLabels is replaced with the element of NamesStickyLabels and StickyLabelsNamesChangeFaster controls the ordering of the loops. When there are labels by name, it is convenient for cutting if each person’s labels are in a convenient rectangular block, enforced by StickyLabelsAvoidAcrossColumnsOrRows, and not spilling over page boundaries, enforced by StickyLabelsAvoidAcrossPages.

If not using a default, the user must change the specification of the label layout. For all the following it is assumed that the page is portrait.

  • StickyLabelsWithPagePortraitNumRows is the number of rows whilst holding the page portrait.
  • StickyLabelsWithPagePortraitNumCols is the number of columns.
  • StickyLabelsColumnsChangeFaster controls the ordering of the row and column loops: true ⇒ columns change faster; false ⇒ rows change faster.
  • StickyLabelsWithPagePortraitGapBetweenRows is the gap between the rows of labels; and StickyLabelsWithPagePortraitGapBetweenCols is the gap between the columns of labels. Either of these could be zero; neither may be negative.
  • StickyLabelsWithPagePortraitGapL is the margin on the left of the page, that is, the gap between the edge of the page and the left edge of the leftmost column of labels. Mutatis mutandis, StickyLabelsWithPagePortraitGapR, StickyLabelsWithPagePortraitGapT, and StickyLabelsWithPagePortraitGapB.
  • StickyLabelsPaperType is the paper type of the sticky labels, accepting values such as /A4 or /USL, and defaulting to /A4.
  • Printing is not to the edge of the labels: a little spare space should left on the inside of the edges of the label, this being specified by StickyLabelsPaddingWithPagePortraitTB (top and bottom) and StickyLabelsPaddingWithPagePortraitRL (right and left).
  • StickyLabelsOrientation is the desired orientation of the labels. That is not necessarily the same as the orientation of the page: if, with the page held portrait, labels are wider than they are high, it will be the opposite. Allowed values are /Landscape, /Portrait, and /Automatic. If /Automatic then the orientation is chosen automatically, the code choosing /Landscape unless switching to /Portrait would increase the linear size of the text by ≥∜2.
  • If one has a part-used sheet of labels, it can help to specify the where on the first page of sticky labels to start, as if StickyLabelsFirstPageStartPosition labels have already been used.

To make sticky labels for wines not appearing on a glasses sheet, see GlassesNumCopies.

There are also settings StickyLabelsReverseOrder, StickyLabelsRemoveDuplicatesByWithinTitles, StickyLabelsSortByWithinTitles, StickyLabelsShowBackgroundTexts, StickyLabelsShowDroplets, and StickyLabelsShowCirclearraysInCircle (as well as in the straight lines top and bottom).
