Adds maliput profiler #538
Changes from all commits
448f86b
5097cab
9b9fed9
bd04adf
65bb428
37c9d05
9b96910
2bf6ce2
22ff1d8
209cc9d
File filter
Filter by extension
Conversations
Jump to
Diff view
Diff view
There are no files selected for viewing
Original file line number | Diff line number | Diff line change |
---|---|---|
@@ -0,0 +1,79 @@ | ||
// BSD 3-Clause License | ||
// | ||
// Copyright (c) 2023, Woven Planet. | ||
// All rights reserved. | ||
// | ||
// Redistribution and use in source and binary forms, with or without | ||
// modification, are permitted provided that the following conditions are met: | ||
// | ||
// * Redistributions of source code must retain the above copyright notice, this | ||
// list of conditions and the following disclaimer. | ||
// | ||
// * Redistributions in binary form must reproduce the above copyright notice, | ||
// this list of conditions and the following disclaimer in the documentation | ||
// and/or other materials provided with the distribution. | ||
// | ||
// * Neither the name of the copyright holder nor the names of its | ||
// contributors may be used to endorse or promote products derived from | ||
// this software without specific prior written permission. | ||
// | ||
// THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" | ||
// AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE | ||
// IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE | ||
// DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE | ||
// FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL | ||
// DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR | ||
// SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER | ||
// CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, | ||
// OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE | ||
// OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. | ||
#pragma once | ||
|
||
/// @file Wraps ignition common's profiler behind maliput macros. | ||
/// This allows us to enable/disable profiling at compile time and avoid adding a dependency on ignition common. | ||
|
||
#ifndef MALIPUT_PROFILER_ENABLE | ||
/// Always set this variable to some value | ||
#define MALIPUT_PROFILER_ENABLE 0 | ||
#endif | ||
|
||
#if MALIPUT_PROFILER_ENABLE | ||
|
||
#define IGN_PROFILER_ENABLE 1 | ||
#include <ignition/common/Profiler.hh> | ||
|
||
/// \brief Set name of profiled thread | ||
#define MALIPUT_PROFILE_THREAD_NAME(name) IGN_PROFILE_THREAD_NAME(name) | ||
/// \brief Log profiling text, if supported by implementation | ||
#define MALIPUT_PROFILE_LOG_TEXT(name) IGN_PROFILE_LOG_TEXT(name) | ||
/// \brief Being profiling sample | ||
#define MALIPUT_PROFILE_BEGIN(name) IGN_PROFILE_BEGIN(name) | ||
/// \brief End profiling sample | ||
#define MALIPUT_PROFILE_END() IGN_PROFILE_END() | ||
|
||
/// \brief Convenience wrapper for scoped profiling sample. Use MALIPUT_PROFILE | ||
#define MALIPUT_PROFILE_L(name, line) IGN_PROFILE_L(name, line) | ||
/// \brief Scoped profiling sample. Sample will stop at end of scope. | ||
#define MALIPUT_PROFILE(name) IGN_PROFILE(name) | ||
Comment on lines
+54
to
+57
There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more. Is it possible to use That will allow to reduce the cost to implement the profiling everywhere, meaning that we don't need to review spelling mistakes and so on and the compiler will do it for us. There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more. Maybe we could create a new macro like #define MALIPUT_PROFILE_FUNC() IGN_PROFILE(__FUNCTION__)
Finally, we are using the profiler for analyzing entire method execution, however, it could be used por different part of a method. For example, check this usecase in gz-sim::simulationrunner There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more. I like the macro There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more. What about also adding the option with pretty_function? Check 22ff1d8 In the api I am still using the There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more. I think it is OK, but I would use it everywhere we are using the name of the function only to avoid spelling mistakes. Also, the macro could be (I hope the compiler shakes my right hand): #define MALIPUT_PROFILE_FUNC() IGN_PROFILE(__FUNCTION__)
#define MALIPUT_PROFILE_FUNC_MSG(msg) IGN_PROFILE(__FUNCTION_": "#msg) There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more. Out of curiosity, are these There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more.
Good question, There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more.
The issue with
There is an alternative of concatenating as a string and converting to const char * but making this conversion/operation every time that the method is called isn't ideal. I replaced all the occurrences with There was a problem hiding this comment. Choose a reason for hiding this commentThe reason will be displayed to describe this comment to others. Learn more. Good catch. Let's keep it as is then. |
||
/// \brief Scoped profiling sample as MALIPUT_PROFILE. | ||
/// __FUNCTION__ is used as the sample name. | ||
#define MALIPUT_PROFILE_FUNC() IGN_PROFILE(__FUNCTION__) | ||
/// \brief Scoped profiling sample as MALIPUT_PROFILE. | ||
/// __PRETTY_FUNCTION__ is used as the sample name. | ||
#define MALIPUT_PROFILE_PRETTY_FUNC() IGN_PROFILE(__PRETTY_FUNCTION__) | ||
|
||
/// \brief Macro to determine if profiler is enabled and has an implementation. | ||
#define MALIPUT_PROFILER_VALID IGN_PROFILER_VALID | ||
#else | ||
|
||
#define MALIPUT_PROFILE_THREAD_NAME(name) ((void)name) | ||
#define MALIPUT_PROFILE_LOG_TEXT(name) ((void)name) | ||
#define MALIPUT_PROFILE_BEGIN(name) ((void)name) | ||
#define MALIPUT_PROFILE_END() ((void)0) | ||
#define MALIPUT_PROFILE_L(name, line) ((void)name) | ||
#define MALIPUT_PROFILE(name) ((void)name) | ||
#define MALIPUT_PROFILE_FUNC() ((void)0) | ||
#define MALIPUT_PROFILE_PRETTY_FUNC() ((void)0) | ||
#define MALIPUT_PROFILER_VALID MALIPUT_PROFILER_ENABLE | ||
|
||
#endif // MALIPUT_PROFILER_ENABLE |
There was a problem hiding this comment.
Choose a reason for hiding this comment
The reason will be displayed to describe this comment to others. Learn more.
We should use @def MALIPUT_PROFILER_ENABLE ....
Which value should we use?
There was a problem hiding this comment.
Choose a reason for hiding this comment
The reason will be displayed to describe this comment to others. Learn more.
This states that if the
MALIPUT_PROFILER_ENABLE
is not defined then set it to zero. (as it is done in the very line below)And the define is expected to bet set via preprocessor : cmake-ars --> compile definition
