schmetterling

schmetterling

Debug running clojure processes from the browser!

Usage

To enable a process to be debugged by Schmetterling you must open a dt_socket with the following compiler option:

-agentlib:jdwp=transport=dt_socket,server=y,suspend=n

So with leiningen, in your project.clj add the following line:

:jvm-opts ["-agentlib:jdwp=transport=dt_socket,server=y,suspend=n"]

When the process starts up, something like the following will appear in its console output:

Listening for transport dt_socket at address: 54330

Note the five digit port number (in this case 54330).

To run Schmetterling, clone the repo and simply

lein cljsbuild once
lein run

in the Schmetterling root. Browse to the Schmetterling frontend at localhost:16461, then connect to an existing process by providing its dt_socket port. Schmetterling is now waiting for exceptions to occur in this process. When an exception arises in the observed process it will break and control will be passed to Schmetterling.

A stacktrace will appear and provide an interactive repl for each frame in the stacktrace. Click the triangle next to the frame to open the repl. There will be a view of the source with the questionable line highlighted, and under that a list of available locals. Type expressions at the prompt and hit enter to evaluate them in the context of the frozen process. You can navigate your expression history with the up and down arrows. When you are done you can click the white "continue" button to resume the frozen process.

stacktrace

Triggering Schmetterling Manually

If you add Schmetterling as a dependency, you can trigger the debugger from your code.

Add the dependency in your project.clj:

[schmetterling "0.0.7"]

Then from your code:

(ns bad.code
  (:use [schmetterling.core :only (debugger)]))

(defn destroy-everything
  []
  (let [a 0 b 1]
    (debugger)  ;; <-- This will trigger Schmetterling
    (/ b a)))

The stacktrace will appear in your Schmetterling tab, and hopefully you can fix this egregious violation of universal law.

Caveats

Schmetterling uses java debugging tools, so you must have the JDK installed, not just the JRE. Also, it seems on Java 7 this jar is no longer in the classpath. If you get an exception like:

Exception in thread "main" java.lang.ClassNotFoundException: com.sun.jdi.Bootstrap

you will have to set an environment variable that points Schmetterling at the current location of your tools.jar:

export JAVA_TOOLS_JAR=/path/to/tools/jar/on/your/system/tools.jar

Also, if you trigger an exception in the process being debugged (by a mistyping a local or just a compounding error) this creates a paradox in spacetime where it cannot resolve the exception since you are already paused for an exception (I call this act "exinception"). If this happens you will have to restart Schmetterling, and possibly the frozen process as well.

If you find a way around this let me know, but as far as I can tell don't do this.

License

Copyright © 2013 Ryan Spangler

Distributed under the Eclipse Public License, the same as Clojure.
