Day 7 (190916)

• Filled the triangles.

Filling Triangles (2)

1. The First Attempt

Suppose I have a point abp that moves on line t0-t2. Suppose there is a point bbp that moves on boundary B, that is, on line segments t0t1 and t1t2. If bbp has the same y value as abp, I can move the y coordinate of abp from t0 to t2 and draw a line with the corresponding bbp to fill the triangle.

Vec2i bbp;

for (abp.y = t0.y; abp.y <= t1.y; abp.y++) {
    abp.x = boundary_x(t0, t2, abp.y);
    bbp = Vec2i(boundary_x(t0, t1, abp.y), abp.y);
    line(abp, bbp, image, white);
}

for (abp.y = t1.y; abp.y <= t2.y; abp.y++) {
    abp.x = boundary_x(t0, t2, abp.y);
    bbp = Vec2i(boundary_x(t1, t2, abp.y), abp.y);
    line(abp, bbp, image, white);
}

2. Problems that I've met today.

-
For the first, when I runned this code, it made non-fully-filled triangles.

void line(Vec2i p0, Vec2i p1, TGAImage &image, TGAColor color) {
    bool steep = false;
    if (std::abs(p0.x-p1.x)<std::abs(p0.y-p1.y)) {
        std::swap(p0.x, p0.y);
        std::swap(p1.x, p1.y);
        steep = true;
    }
    if (p0.x>p1.x) {
        std::swap(p0, p1);
    }

    for (int x=p0.x; x<=p1.x; x++) {
        float t = (x-p0.x)/(float)(p1.x-p0.x);
        int y = p0.y*(1.-t) + p1.y*t;
        if (steep) {
            image.set(y, x, color);
        } else {
            image.set(x, y, color);
        }
    }
}

void triangle(Vec2i t0, Vec2i t1, Vec2i t2, TGAImage &image) {
    if (t0.y > t1.y) {
        std::swap(t0.x, t1.x);
        std::swap(t0.y, t1.y);
    }
    if (t0.y > t2.y) {
        std::swap(t0.x, t2.x);
        std::swap(t0.y, t2.y);
    }
    if (t1.y > t2.y) {
        std::swap(t1.x, t2.x);
        std::swap(t1.y, t2.y);
    }

    Vec2i abp = Vec2i(boundary_x(t0, t2, t1.y), t1.y);  // (the boundary) A boundary point

    Vec2i bbp;

    if (t1.x < abp.x) {
    side = eSideType::Left;

    for (abp.y = t0.y; abp.y <= t1.y; abp.y++) {
        abp.x = boundary_x(t0, t2, abp.y);
        bbp = Vec2i(boundary_x(t0, t1, abp.y), abp.y);
        line(abp, bbp, image, white);
    }

    for (abp.y = t1.y; abp.y <= t2.y; abp.y++) {
        abp.x = boundary_x(t0, t2, abp.y);
        bbp = Vec2i(boundary_x(t1, t2, abp.y), abp.y);
        line(abp, bbp, image, white);
    }

    } else {
        side = eSideType::Right;

        for (abp.y = t0.y; abp.y <= t1.y; abp.y++) {
            abp.x = boundary_x(t0, t2, abp.y);
            bbp = Vec2i(boundary_x(t0, t1, abp.y), abp.y);
            line(abp, bbp, image, white);
        }

        for (abp.y = t1.y; abp.y <= t2.y; abp.y++) {
            abp.x = boundary_x(t0, t2, abp.y);
            bbp = Vec2i(boundary_x(t1, t2, abp.y), abp.y);
            line(abp, bbp, image, white);
        }
    }
}

Like these: So to find this reason, I put some couts.

void line(Vec2i p0, Vec2i p1, TGAImage &image, TGAColor color) {
    bool steep = false;
    if (std::abs(p0.x-p1.x)<std::abs(p0.y-p1.y)) {
        std::swap(p0.x, p0.y);
        std::swap(p1.x, p1.y);
        steep = true;
    }
    if (p0.x>p1.x) {
        std::swap(p0, p1);
    }

    for (int x=p0.x; x<=p1.x; x++) {
        float t = (x-p0.x)/(float)(p1.x-p0.x);
        int y = p0.y*(1.-t) + p1.y*t;
        std::cout << p0.y*(1.-t) << "+" << p1.y*t << "=" << p0.y*(1.-t) + p1.y*t << std::endl;  // *
        if (steep) {
            image.set(y, x, color);
            std::cout << x << " " << y << std::endl;  // *
        } else {
            image.set(x, y, color);
            std::cout << x << " " << y << std::endl;  // *
        }
    }
}

void triangle(Vec2i t0, Vec2i t1, Vec2i t2, TGAImage &image) {
    if (t0.y > t1.y) {
        std::swap(t0.x, t1.x);
        std::swap(t0.y, t1.y);
    }
    if (t0.y > t2.y) {
        std::swap(t0.x, t2.x);
        std::swap(t0.y, t2.y);
    }
    if (t1.y > t2.y) {
        std::swap(t1.x, t2.x);
        std::swap(t1.y, t2.y);
    }

    Vec2i abp = Vec2i(boundary_x(t0, t2, t1.y), t1.y);  // (the boundary) A boundary point

    std::cout << t1.x << " " << abp.x << std::endl;  // *

    Vec2i bbp;

    if (t1.x < abp.x) {
        side = eSideType::Left;

        for (abp.y = t0.y; abp.y <= t1.y; abp.y++) {
            abp.x = boundary_x(t0, t2, abp.y);
            bbp = Vec2i(boundary_x(t0, t1, abp.y), abp.y);
            line(abp, bbp, image, white);
            std::cout << abp << bbp << std::endl;  // *
        }

        for (abp.y = t1.y; abp.y <= t2.y; abp.y++) {
            abp.x = boundary_x(t0, t2, abp.y);
            bbp = Vec2i(boundary_x(t1, t2, abp.y), abp.y);
            line(abp, bbp, image, white);
            std::cout << abp << bbp << std::endl;  // *
        }

    } else {
        side = eSideType::Right;

        for (abp.y = t0.y; abp.y <= t1.y; abp.y++) {
            abp.x = boundary_x(t0, t2, abp.y);
            bbp = Vec2i(boundary_x(t0, t1, abp.y), abp.y);
            line(abp, bbp, image, white);
            std::cout << abp << bbp << std::endl;  // *
        }

        for (abp.y = t1.y; abp.y <= t2.y; abp.y++) {
            abp.x = boundary_x(t0, t2, abp.y);
            bbp = Vec2i(boundary_x(t1, t2, abp.y), abp.y);
            line(abp, bbp, image, white);
            std::cout << abp << bbp << std::endl;  // *
        }
    }
}

cout that I really need was like below.

std::cout << p0.y*(1.-t) << " + " << p1.y*t << " == " << p0.y*(1.-t) + p1.y*t << std::endl;
std::cout << y <<std::endl;

In the function line, while casting y to int, it was not rounding the float value. So to fix it, I had to plus 0.5 to y before cast it.

int y = p0.y*(1.-t) + p1.y*t + 0.5;

Then it works. But the vertices are blunt. I checked the logs, and found that the y value of vertices became nan. It was because the division by zero.

for (int x=p0.x; x<=p1.x; x++) {
    float t = (x-p0.x)/(float)(p1.x-p0.x);  // here
    int y = p0.y*(1.-t) + p1.y*t + 0.5;
    if (steep) {
        image.set(y, x, color);
    } else {
        image.set(x, y, color);
    }
}

For the case that p1.x and p0.x are the same, I had to make an exception handling.

if (p0.x != p1.x) {
    for (int x=p0.x; x<=p1.x; x++) {
        float t = (x-p0.x)/(float)(p1.x-p0.x);
        int y = p0.y*(1.-t) + p1.y*t + 0.5;
        if (steep) {
            image.set(y, x, color);
        } else {
            image.set(x, y, color);
        }
    }
} else {
    for (int y=p0.y; y<=p1.y; y++) {
    image.set(p0.x, y, color);
    }
}

After fixing it, the vertecies appeared.
