refactor(experimental): pre-build the byte array before encoding with codecs

[lorisleiva]

Note this is a draft PR focusing on codecs-core to gather feedback, I will continue to update the other libraries afterwards.

This PR updates the codecs API such that both encoding and decoding function have access to the entire byte array. Let’s first see the change this PR introduce and then see why this is a valuable change.

API Changes

• Encode: The Encoder type contains a new function write. Contrary to the encode function which creates a new Uint8Array and returns it directly, the write function updates the provided bytes argument at the provided offset. It then returns the next offset that should be written to.

  // Before
  type Encoder<T> = {
    encode: (value: T) => Uint8Array;
    // ...
  };

  // After
  type Encoder<T> = {
    encode: (value: T) => Uint8Array;
    write: (value: T, bytes: Uint8Array, offset: Offset) => Offset;
    // ...
  };

  A new createEncoder function was provided to automatically fill the encode function from the write function.

  const myU8Encoder = createEncoder({
    fixedSize: 1,
    write: (value: number, bytes: Uint8Array, offset: Offset) {
      bytes.set(value, offset);
      return offset + 1;
    };
  });

• Decode: The decode function already following a similar approach by using offsets. The newly added function read takes over this responsibility. The only difference is we now make the offset a mandatory argument to stay consistent with the write function. The decode function now becomes syntactic sugar for accessing the value directly.

  // Before
  type Decoder<T> = {
    decode: (bytes: Uint8Array, offset?: Offset) => [T, Offset];
    // ...
  };

  // After
  type Decoder<T> = {
    decode: (bytes: Uint8Array, offset?: Offset) => T;
    read: (bytes: Uint8Array, offset: Offset) => [T, Offset];
    // ...
  };

  Similarly to the Encoder changes, a new createDecoder function is provided to fill the decode function using the read function.

  const myU8Decoder = createDecoder({
    fixedSize: 1,
    read: (bytes: Uint8Array, offset: Offset) {
      return [bytes[offset], offset + 1];
    };
  });

• Sizes: Because we now need to pre-build the entire byte array that will be encoded, we need a way to find the variable size of a given value. We introduce a new variableSize function and narrow the types so that it can only be provided when fixedSize is null.

  // Before
  type Encoder<T> = {
    fixedSize: number | null;
    maxSize: number | null;
  }

  // After
  type Encoder<T> = { ... } & (
    | { fixedSize: number; }
    | { fixedSize: null; variableSize: (value: T) => number; maxSize?: number }
  )

  We do something similar the Decoder except that this one doesn’t need to know about the variable size (it would make no sense as the type parameter T for decoder refers to the decoded type and not the type to encode).

  // Before
  type Decoder<T> = {
    fixedSize: number | null;
    maxSize: number | null;
  }

  // After
  type Decoder<T> = { ... } & (
    | { fixedSize: number; }
    | { fixedSize: null; maxSize?: number }
  )

• Description: This PR takes this refactoring opportunity to remove the description attribute from the codecs API which brings little value to the end-user.

Why?

• Consistent API: The implementation of the encode / decode and write / read functions are now consistent with each other. Before one was using offsets to navigate through an entire byte array and the other was returning and merge byte arrays together. Now they both use offsets to navigate the byte array to encode or decode.

• Performant API: By pre-building the byte array once, we’re avoiding creating multiple instance of byte arrays and merging them together.

• Non-linear serialisation: The main reason why it’s important for the encode method to have access to the entire encoded byte array is that it allows us to offer more complex codec primitives that are able to jump back and forth within the buffer. Without it, we are locking ourselves to only supporting serialisation strategies that are read linearly which isn’t always the case. For instance, imagine we have the size of an array being stored at the very beginning of the account whereas the items themselves are being stored at the end. Because we now have the full byte array when encoding, we can push the size at the beginning whilst inserting all items at the requested offset. We could even offer a getOffsetCodec (or similar) that allows us to shift the offset forward or backward to compose more complex, non-linear data structures. This would be simply impossible with the current format of the encode function.

[lorisleiva]

Current dependencies on/for this PR:

• master
  • PR refactor(experimental): rename codec options to codec config #1856
    • PR refactor(experimental): pre-build the byte array before encoding with codecs #1865 👈
      • PR refactor(experimental): add FixedSizeCodec and VariableSizeCodec types #1883
        • PR refactor(experimental): add read write functions to codecs-numbers #1884
          • PR refactor(experimental): add read write functions to codecs-strings #1885
            • PR refactor(experimental): rename variableSize to getSizeFromValue in codecs #1901
              • PR refactor(experimental): remove { fixedSize: null } from variable size codecs #1903
                • PR refactor(experimental): add size type param to fixed-size codecs #1909
                  • PR refactor(experimental): add read and write functions to codecs-data-structures #1910
                  • PR refactor(experimental): rename isFixedSize and isVariableSize type guards #1919
                  • PR refactor(experimental): add read write functions to option codecs #1920
                  • PR refactor(experimental) update codecs in other packages #1922
                  • PR refactor(experimental): add accounts package #1855

This stack of pull requests is managed by Graphite.

[mcintyre94]

Just a clarifying question, when you say "offer more complex codec primitives that are able to jump back and forth within the buffer" do we have a use case for that more complex implementation now? Or is it just something you've recognised as a limitation of the current ones?

Also am I right in thinking the performance improvement would increase based on how much encoders/decoders are composed? I think that's potentially a really important motivation too because things like the transaction decoder are pretty complex

[mcintyre94]

I think my only concern would be that encode and decode are really generic terms for us to be exporting into people's apps, where stuff like getTransactionEncoder is less likely to clash with anything they're doing
They're definitely the right names to use for this though, so not really suggesting any change there!

[lorisleiva]

Thanks for the review Callum!

Regarding the encode and decode functions: I agree they are pretty generic. I’d love to keep the codec.encode and codec.decode API which we could. It just comes with its own set of challenges as codecs will now need to provide 4 functions such that two of them are just delegating to the other two. On the plus side, we no longer have that annoying [0] suffix on the main API.

Regarding offering more complex primitives: The main issue here is that the current encode and decode logic are not symmetrical. Meaning there are things we can do with decode that we cannot do with encode because we do not have access to the entire buffer. I do have some examples of that. For instance, imagine an offsetCodec(codec, relativeOffset) helper that, given a codec, shifts its position on the buffer by the given relative offset. We can do that right now with Decoders but it’s impossible to do with Encoders because they use a different mechanism that rely on linear serialisation only. An example of why we would we need something like an offsetCodec helper is any array such that its size does not immediately prefix the items.

Regarding performance improvements: The decoding logic should stay pretty much the same because it already uses a single buffer but the encoding logic should drastically use less instances of Uint8Array which I believe will be a big performance boost.

[buffalojoec]

Another way to achieve the same thing but keep the previous encoder.encode(value) API is to introduce a new set of low-level methods such as write and read on the Encoder and Decoder types respectively. However, this means every single Encoder and Decoder needs to implement the same encode and decode helper method over and over again. It also makes it easy for people to misuse it and use the encode method instead of the write method when chaining encoders together.

I think this sounds like a better approach to me. This API aligns with borsh in Rust (not that we care to align with borsh necessarily) so it's not unfamiliar, and I would really hate to see any partial destruction of the simple TS/JS syntax that is:

const bytes: UInt8Array = getStructCodec(..).encode(myObject);

If the intention is to provide better low-level functionality, better to do that with write and let people still get the slick API of encode.

I wouldn't even hate just adding offset to the return type of encode, but that's tripped me up with decode before, too. I'd probably rather see the offset removed from decode to match encode, and instead used in read.

• Performant API: By pre-building the byte array once, we’re avoiding creating multiple instance of byte arrays and merging them together.

I understand you're also going for performance here, and you're right the current implementation does degrade performance/memory, however, I think having a simple, user-friendly API alongside a lower-level performant one is more than enough.

[lorisleiva]

Thanks Joe! I agree, it would make me sad loosing the getStructCodec(..).encode(myObject) API.

I also like the alternative API, it's just a little bit more of a pain to write codecs with this API. That being said, I can offer helper methods like createEncoder and createDecoder that accepts an Encoder or Decoder with write and read function and provide the encode and decode function for you.

So for instance, if I wanted to create a number encoder. instead of this:

const myEncoder: Encoder<number> = {
  fixedSize: 1,
  encode(value, bytes, offset): Offset {
    bytes.set(value, offset);
    return offset + 1;
  }
}

I'd be doing this:

const myEncoder: Encoder<number> = createEncoder({
  fixedSize: 1,
  write(value, bytes, offset): Offset {
    bytes.set(value, offset);
    return offset + 1;
  }
})

// `createEncoder` basically just adds the `encode` function for us:
myEncoder.encode(42); // <- Uint8Array.

What do you think?

[buffalojoec]

Thanks Joe! I agree, it would make me sad loosing the getStructCodec(..).encode(myObject) API.

I also like the alternative API, it's just a little bit more of a pain to write codecs with this API. That being said, I can offer helper methods like createEncoder and createDecoder that accepts an Encoder or Decoder with write and read function and provide the encode and decode function for you.

So for instance, if I wanted to create a number encoder. instead of this:

const myEncoder: Encoder<number> = {
  fixedSize: 1,
  encode(value, bytes, offset): Offset {
    bytes.set(value, offset);
    return offset + 1;
  }
}

I'd be doing this:

const myEncoder: Encoder<number> = createEncoder({
  fixedSize: 1,
  write(value, bytes, offset): Offset {
    bytes.set(value, offset);
    return offset + 1;
  }
})

// `createEncoder` basically just adds the `encode` function for us:
myEncoder.encode(42); // <- Uint8Array.

What do you think?

Yep, I think that's great! Lgtm 💪🏼

[mcintyre94]

Agreed, that looks like a really nice API to me. Only question is how easy is it to compose eg a struct encoder using that? Would you be internally using eg the write function of the nested fields, and the encode function is just the external API?

[lorisleiva]

Agreed, that looks like a really nice API to me. Only question is how easy is it to compose eg a struct encoder using that? Would you be internally using eg the write function of the nested fields, and the encode function is just the external API?

That's right, codecs that are composed from other codecs should only use the write and read functions internally. The encode and decode functions are syntactic sugar for the end-user.

[lorisleiva]

I've updated the PR and its description.

[steveluscher]

[steveluscher]

Is there any reason to make this context-y with this?

Suggested change

	write: (value: string, bytes, offset) => {
	const charCodes = [...value.slice(0, 32)].map(char => Math.min(char.charCodeAt(0), 255));
	bytes.set(new Uint8Array(charCodes));
	return bytes;
	bytes.set(charCodes, offset);
	return offset + 32;
	},
	write(value: string, bytes, offset) {
	const length = this.fixedSize;
	const charCodes = [...value.slice(0, length)].map(char => Math.min(char.charCodeAt(0), 255));
	bytes.set(charCodes, offset);
	return offset + length;
	},

[steveluscher]

You could achieve the context-y suggestion above by doing something like this:

Suggested change

	readonly write: (value: T, bytes: Uint8Array, offset: Offset) => Offset;
	readonly write: (
	this: Readonly<{fixedSize: number | null}>,
	value: T,
	bytes: Uint8Array, offset: Offset,
	) => Offset;

Then something like this later:

const context = {fixedSize};
return {
  // ...
  write(...args) { return encoder.write.apply(context, args); },
}

[lorisleiva]

Hmm I don't know that I like this tbh. It's making me implement codecs thinking: "it's possible that a parent codec is going to inject a different size and therefore mess up with this implementation". 🤔

[buffalojoec]

Looking slick! One question from me popped up.

[mcintyre94]

This looks good to me now! I think the createEncoder and createDecoder and keeping the encode/decode is much nicer too.

[lorisleiva]

Merge activity

• Dec 1, 10:16 AM: @lorisleiva started a stack merge that includes this pull request via Graphite.
• Dec 1, 10:17 AM: @lorisleiva merged this pull request with Graphite.

[github-actions]

Because there has been no activity on this PR for 14 days since it was merged, it has been automatically locked. Please open a new issue if it requires a follow up.
