README.md

Haikanko Build Status Code Climate

Haikanko is a management tool of fluentd cluster


Why we need Haikanko?

Fluentd achieves a feature by cooperating with lots of fluentd nodes. The configuration of each fluentd node must be consistent in terms of both a sender and a receiver. However, it is difficult to keep the consistency of this kinds of complicated, entwined cluster architecture by hand.

Haikanko resolves such issues, and enables to manage a fluentd cluster easily.

What Haikanko can do?

With Haikanko, you can

  • Manage fluend cluster feature configuration on Web UI
  • Generate fluend configuration files for each node achieving the specified fluend cluster feature
  • Deploy these configuration files by one-click

Currently, Haikanko supports below fluentd cluster features

  • Notifier: Watch log files and notifies via IRC or Email if watching keyword is detected
  • Visualizer: Visualize metrics obtained from log files

Dependencies

Tested on CentOS 5.8, 6.2.

Haikanko (Mandatory)

Install belows for Haikanko:

Ruby

TIPS: I don't really recommend, but you can avoid error: error setting certificate verify locations: error of git clone by

sudo git config --system http.sslverify false

rbenv with ruby-2.0.0-p0 or later and the bundler gem installed

git clone https://github.com/sstephenson/rbenv.git ~/.rbenv
echo 'export PATH="$HOME/.rbenv/bin:$PATH"' >> ~/.bashrc
echo 'eval "$(rbenv init -)"' >> ~/.bashrc
exec $SHELL -l
mkdir -p ~/.rbenv/plugins
git clone https://github.com/sstephenson/ruby-build.git ~/.rbenv/plugins/ruby-build
git clone https://github.com/sstephenson/rbenv-vars.git ~/.rbenv/plugins/rbenv-vars
rbenv install 2.0.0-p0
## Mac OSX
# brew install openssl
# brew install readline
# CC=/usr/bin/gcc-4.2 RUBY_CONFIGURE_OPTS="--with-readline-dir=`brew --prefix readline` --with-openssl-dir=`brew --prefix openssl`" rbenv install 2.0.0-p0
# chmod 600 /Users/seo.naotoshi/.gem/credentials
rbenv rehash

MongoDB

Used as a Haikanko Web Data Store:

i386

cat << EOT | sudo tee /etc/yum.repos.d/10gen.repo
[10gen]
name=10gen Repository
baseurl=http://downloads-distro.mongodb.org/repo/redhat/os/i686
gpgcheck=0
enabled=0
EOT

x86_64

cat << EOT | sudo tee /etc/yum.repos.d/10gen.repo
[10gen]
name=10gen Repository
baseurl=http://downloads-distro.mongodb.org/repo/redhat/os/x86_64
gpgcheck=0
enabled=0
EOT

Install and start

sudo yum install -y --enablerepo=10gen mongo-10gen mongo-10gen-server
sudo /sbin/chkconfig --add mongod
sudo /etc/init.d/mongod start

Try

$ mongo
mongo> show dbs
mongo> use [dbname]
mongo> show collections
mongo> db.help()
mongo> db.[collection_name].find()

Fluentd Worker (Mandatory)

daemontools

Haikanko is currently taking a fluentd cluster architecture drawn as below:


To utilize the CPU resource of worker servers, multiple worker processes should be invoked at a host (typically, the number of processes equals to the number of cores of CPU) with different port numbers. Haikanko uses daemontools to do it.

Install daemontools to your fluentd worker hosts

# yum install daemontools daemontools-toaster
# echo "SV:12345:respawn:/usr/local/bin/svscanboot" >> /etc/inittab
# kill -HUP 1

Fluentd Agent

Requires nothing. Haikanko takes care of them.

Visualizer (Optional)

Install belows if you want to use Haikanko's Visualizer feature:

GrowthForecast

sudo yum groupinstall "Development Tools"
sudo yum install pkgconfig glib2-devel gettext libxml2-devel pango-devel cairo-devel

perlbrew + cpanm

curl -kL http://install.perlbrew.pl | bash
echo '[[ -s "$HOME/perl5/perlbrew/etc/bashrc" ]] && source "$HOME/perl5/perlbrew/etc/bashrc"' >> .bashrc
source "$HOME/perl5/perlbrew/etc/bashrc"
perlbrew install perl-5.16.2
perlbrew switch perl-5.16.2
perlbrew install-cpanm

growthforecast

git clone https://github.com/kazeburo/GrowthForecast.git
cd GrowthForecast
cpanm --installdeps .

Run (I use daemontools to daemonize growthforecast actually)

perl growthforecast.pl --port 5125

Notifier (Optional)

Install belows if you want to use Haikanko's Notifier feature:

postfix

Used for sending e-mail. Install if you need a smtp server.

sudo yum install postfix
sudo /etc/init.d/postfix restart

ircd

IRC server. Install if you need an IRC server.

sudo yum --enablerepo=epel install ircd-hybrid
sudo cp -irp /usr/share/doc/ircd-hybrid-7.2.3/simple.conf /etc/ircd/ircd.conf
echo "--- /usr/share/doc/ircd-hybrid-7.2.3/simple.conf 2007-02-28 13:17:53.000000000 +0900
+++ /etc/ircd/ircd.conf 2012-10-09 12:09:41.000000000 +0900
@@ -12,7 +12,7 @@

 serverinfo {
    name = "irc.example.com";
-   sid = "_CHANGE_ME_";
+   sid = "1AB";
    description = "Test IRC Server";
    hub = no;
 };" | sudo patch /etc/ircd/ircd.conf
sudo /etc/init.d/ircd start

ikachan

Used as an agent for sending message to IRC.

Install perl

curl -kL http://install.perlbrew.pl | bash
echo '[[ -s "$HOME/perl5/perlbrew/etc/bashrc" ]] && source "$HOME/perl5/perlbrew/etc/bashrc"' >> .bashrc
source "$HOME/perl5/perlbrew/etc/bashrc"
perlbrew install perl-5.16.0
perlbrew switch perl-5.16.0
perlbrew install-cpanm

Install ikachan

perlbrew switch perl-5.16.0
cpanm App::Ikachan
ikachan -S 127.0.0.1 -N ikachan

Try

curl -F channel=#fluentd-warn http://127.0.0.1:4979/join
curl -F channel=#fluentd-warn -F message="Hello Haikanko!" http://127.0.0.1:4979/notice

Development

Setup

git clone https://github.com/sonots/haikanko
cd haikanko
sudo yum install -y libxslt-devel libxml2-devel
rbenv local 2.0.0-p0
rbenv rehash
gem install bundler
rbenv rehash
bundle install

Run the Haikanko

bundle exec foreman start

You should be able to access Haikanko Web UI via http://your-host:10080. Have a fun with it!

Run the test suite

bundle exec rspec

Configuration

Edit the config/haikanko.yml, config/fluentd.yml, and config/mongoid.yml.

Deployments and CLI

Haikanko provides a Web UI interfaces, but it does not provide all functions which Haikanko have. See CLI.md.

Contributing

  1. Fork it
  2. Create your feature branch (git checkout -b my-new-feature)
  3. Commit your changes (git commit -am 'Add some feature')
  4. Push to the branch (git push origin my-new-feature)
  5. Create new Pull Request

Copyright

Copyright (c) 2013 Naotoshi SEO. See LICENSE for details.
