Pymrio: Multi-Regional Input-Output Analysis in Python.





Documentation Status




What is it

Pymrio is an open source tool for analysing global environmentally extended multi-regional input-output tables (EE MRIOs). Pymrio aims to provide a high-level abstraction layer for global EE MRIO databases in order to simplify common EE MRIO data tasks. Pymrio includes automatic download functions and parsers for available EE MRIO databases like EXIOBASE, WIOD and EORA26. It automatically checks parsed EE MRIOs for missing data necessary for calculating standard EE MRIO accounts (such as footprint, territorial, impacts embodied in trade) and calculates all missing tables. Various data report and visualization methods help to explore the dataset by comparing the different accounts across countries.

Further functions include:

  • analysis methods to identify where certain impacts occur
  • modifying region/sector classification
  • restructuring extensions
  • export to various formats
  • visualization routines and
  • automated report generation

Where to get it

The full source code is available on Github at:

Pymrio is registered at PyPI and on the Anaconda Cloud. Install it by:

pip install pymrio --upgrade

or when using conda install it by

conda install -c conda-forge pymrio

or update to the latest version by

conda update -c conda-forge pymrio

The source-code of Pymrio available at the GitHub repo:

The master branch in that repo is supposed to be ready for use and might be ahead of the official releases. To install directly from the master branch use:

pip install git+


A small test mrio is included in the package.

To use it call

import pymrio
test_mrio = pymrio.load_test()

The test mrio consists of six regions and eight sectors:


The test mrio includes tables flow tables and some satellite accounts. To show these:


However, some tables necessary for calculating footprints (like test_mrio.A or test_mrio.emissions.S) are missing. pymrio automatically identifies which tables are missing and calculates them:


Now, all accounts are calculated, including footprints and emissions embodied in trade:


To visualize the accounts:

import matplotlib as plt

Everything can be saved with


See the documentation , tutorials and Stadler 2021 for further examples.


The documentation includes information about how to use pymrio for automatic downloading and parsing of the EE MRIOs EXIOBASE, WIOD, OECD and EORA26 as well as tutorials for the handling, aggregating and analysis of these databases.


If you use Pymrio in your research, citing the article describing the package (Stadler 2021) is very much appreciated.

For the full bibtex key see CITATION file.


Want to contribute? Great! Please check CONTRIBUTING.rst if you want to help to improve Pymrio.

Communication, issues, bugs and enhancements

Please use the issue tracker for documenting bugs, proposing enhancements and all other communication related to pymrio.

You can follow me on twitter to get the latest news about all my open-source and research projects (and occasionally some random retweets).
