README.md

Dowse logo

A digital rod for local area network rabdomancy

software by Dyne.org

Updates: http://dowse.eu

Whitepaper: https://files.dyne.org/dowse/dowse_whitepaper.pdf

Build Status

Dowse project stats

Introduction

Dowse is a transparent proxy facilitating the awareness of ingoing and outgoing connections, from, to, and within a local area network.

Dowse provides a central point of soft control for all local traffic: from ARP traffic (layer 2) to TCP/IP (layers 3 and 4) as well as application space, by chaining a firewall setup to a trasparent proxy setup. A core feature for Dowse is that of hiding all the complexity of such a setup.

Dowse is also a highly extensible platform: interoperability between modules is available using Socks4/5, UNIX pipes, local TCP/IP sockets and port redirection, conforming to specific daemon implementations. At the core of Dowse is a very portable shell script codebase implementing a modular plugin architecture that isolates processes and supports any executable written in any language: Shell, C, Perl, Python etc.

Dowse is an ongoing development effort rapidly gaining momentum for its simplicity and usefulness. Here a recent backstage video:

The making of Dowse

Features

Dowse takes control of a LAN by becoming its DHCP server and thereby assigning itself as main gateway and DNS server for all clients. It keeps tracks of assigned leases by MAC Address. DNSMasq is the DHCP and DNS daemon.

All network traffic is passed through NAT rules for masquerading. HTTP traffic (TCP port 80) can be filtered through a transparent proxy using an application layer chain of Squid2 and Privoxy.

All IP traffic is filtered using configurable blocklists to keep out malware, spyware and known bad peers, using Peerguardian2 and Iptables.

All DNS traffic (UDP port 53) is filtered through Dnscap and analysed to render a graphical representation of traffic. It is also possible to tunnel it via DNSCrypt-proxy, encrypting all traffic (AES/SHA256) before sending it to DNSCrypt.eu or other configurable servers supporting this protocol.

In the future, traffic of all kinds may be transparently proxied for monitoring, filtering, and transformation by other applications loaded on the Dowse device.

All daemons are running as a unique non-privileged UID. The future plan is to separate them using a different UID for each daemon.

Installation

Installation and activation takes a few steps, only make install needs root:

  1. Download dowse on a GNU/Linux box (we use Devuan Jessie)

    git clone https://github.com/dyne/dowse dowse-src git submodule update --init

  2. Install all requirements, here below the list of packages. To avoid installing more than needed, consider using the --no-install-recommends flag in APT or similar for other package managers.

zsh iptables ebtables sqlite3 procps gettext-base net-tools autoconf automake libssl-dev libbind-dev libpcap-dev unzip wget gcc g++ make cmake libtool liblo-dev libnetfilter-conntrack3 libnetfilter-queue-dev libsqlite3-dev libjemalloc-dev libseccomp2 libsodium-dev libhiredis-dev libkmod-dev bind9-host bison gawk libevent-dev libjansson-dev asciidoc libldns-dev  libreadline5 libpcre3 libaio1 libfile-mimeinfo-perl libmariadb-client-lgpl-dev cproto xmlstarlet nmap libaprutil1-dev libltdl-dev patch libb64-dev uuid-dev python-redis python-hiredis dnsutils valgrind build-essential libmysqld-dev libapr1 libapr1-dev libaprutil1-dev curl
  1. Choose which user should be running dowse: your own is fine, or eventually create one just for that to separate filesystem permissions.

  2. As the user of choice, run make inside the dowse source

  3. As root, run make install

  4. If necessary edit the files in the /etc/dowse folder, especially settings where it should be indicated the address for the local network you like to create.

  5. As the dowse user of choice and inside the source, fire up the startup script ./start.sh

Dowse is now running with a web interface on port 80.

To interact with dowse there is also a console with commands prefixed with dowse- (tab completion available). To enter it run zsh without extensions and source the main script: first type zsh -f and press enter, then type source /usr/local/dowse/zshrc and press enter.

If you like the dowse user to have an interactive console every time it logs in, then do ln -s /usr/local/dowse/zshrc $HOME/.zshrc.

If all went well now one should be able to connect any device to the internet as you did before, via Dowse.

Embedded ARM devices

Using https://www.devuan.org just compile and install Dowse following the procedure above. Images are available for a several popular ARM devices including RaspberryPI2 and 3, BananaPI, Cubieboard etc.

Starting Dowse

Here below an example start script launching all services in Dowse. Some can be commented / expunged ad-hoc depending from use cases, since the only vital functions are redis-server, dhcpd and dnscrypt-proxy.

#/usr/bin/env zsh

source /etc/dowse/settings
source /usr/local/dowse/zshrc

    notice "Starting Dowse"

    # start the redis daemon (core k/v service)
    start redis-server

	notice "Starting all daemons in Dowse"

    # launch the dhcp daemon
    start dhcpd

    # start the dns encrypted tunneling
    start dnscrypt-proxy

    # start the sql database
    start mysqld

    # start web interface
    start webui

	# start the mqtt/websocket hub
	start mosquitto

    # netdata dashboard for the technical status
    start netdata

	# nodejs/node-red
	start node-red

	# start the cronjob handler (with resolution to seconds)
	start seccrond

    notice "Dowse succesfully started"

}

Adding the following line one can set up an open network, what we call it "party mode":

echo "set party-mode ON" | redis-cli

As a good practice, such a script can be launched from /etc/rc.local for user dowse using setuidgid from the daemontools package.

The next is an example on how to stop dowse, for instance from a stop.sh script:

#/usr/bin/env zsh

source /usr/local/dowse/zshrc

	notice "Stopping all daemons in Dowse"

	stop seccrond

	stop mosquitto

    stop webui

    stop mysqld

	# stop nodejs/node-red
	stop node-red

    # stop the dashboard
    stop netdata

    # stop the dns crypto tunnel
    stop dnscrypt-proxy

    # stop the dhcp server
    stop dhcpd

    # remove the layer 2 firewall rules
    ebtables-stop

    # remove the layer 3 firewall rules
    iptables-snat-off
    iptables-stop

    # restore backup if present
    # [[ -r /etc/resolv.conf.dowse-backup ]] &&  {
    #     mv /etc/resolv.conf.dowse-backup /etc/resolv.conf
    # }

    stop redis-server

    notice "Dowse has stopped running."

The scripts above are found in dowse source as start.sh and stop.sh and can be customised and called from the system at boot. It is also possible to run an interactive console with completion where dowse commands are available using the console.sh script. Once in the console all the above start/stop commands and even more internals will be available to be launched interactively.

Visualization

The DNS visualization is produced in a custom format which can be easily processed by gource. This is the best way to "see dowse running": if you are running it locally, then install gource and do:

dowse-to-gource | gource --log-format custom -

or from remote:

ssh dowse@dowse.it -- dowse-to-gource | gource --log-format custom -

Sidenote: dowse-to-gource must be in the user's $PATH. To achieve this, as mentioned above, you can change the user's shell to zsh and do: ln -sf /usr/local/dowse/zshrc $HOME/.zshrc.

This will live render all the DNS activity occurring on your computer or local network, with the sort of animation that is also showcased on our website.

One can also experiment with gource arguments and render all the output of dowse-to-gource into a video file.

Experimentation

Open Sound Control (OSC) messaging is implemented to interface low-latency devices that are running on the same network. To start it one must know the IP address of the device, then do:

dowse-to-osc osc.udp://10.0.0.2:999

This will start sending OSC messages over UDP to IP 10.0.0.2 port 999

Development

The main development repository is on https://github.com/dyne/dowse

Inside the ops directory an Ansible recipe is found along a ready to use Vagrant configuration to build two virtual machines (leader and client) that simulate a LAN to do further testing of Dowse.

cd ops
vagrant up

Plus the usual vagrant commands. The devops in Dowse is based on http://Devuan.org and will run two virtual machines connected to each other, one "leader" running Dowse and serving DHCP, one "client" connected to it and to the Internet via the leader.

Help with development is welcome, manuals on how to write new modules and daemons are in the making and there is a sister project to categorize all domains used by Internet's conglomerates which also welcomes contributions: https://github.com/dyne/domain-list
