SoftScope

A software based Oscilloscope / Vectorscope

SoftScope is an attempt to mimic the functionality of a two channel oscilloscope, where each channel is fed from an stereo audio source. The result, when used with the appropriate audio source, is a vector drawing machine:

SoftScope v0.3

Click here to see this sample as a video with audio

SoftScope v0.4

Screenshot of SoftScope v0.4 with the new wave form and spectrum panels.

SoftScope v1.0b

Screenshot of SoftScope v1.0b while playing a WAV file.

For best results, try using one of these files and play it using SoftScope 1.0b (or newer):
