Volumetric Isosurface Rendering with Deep Learning-Based Super-Resolution (TVCG 2019)

Sebastian Weiss, Mengyu Chu, Nils Thuerey, Ruediger Westermann, Technical University of Munich

License

This software, excluding third party libraries, is distributed under the MIT open source license. See LICENSE for details.

Resources

• Project page
• TVCG 2019 Paper
• Preprint (PDF)

Requirements

The code was written under Windows 10 with Visual Studio and CUDA 10.0 and Python 3.6. For the python requirements, see SuperresolutioNetwork\Requirements.txt. The network will run (probably) platform-independently but the isosurface renderer is most likely fixed to Windows. Use it on other platforms on your own risk.

Note: for the sake of a smaller repository, we only added the third-party libraries for a release build and excluded the debug build.

Project structure

The project contains the following sub-project

• CopyLibraries: utility that copies dlls from the third-party folders to the binary folder
• CPURenderer: cpu isosurface renderer, callable from command line or interactive over streans
• GPURenderer: cuda isosurface renderer, callable from command line or interactive over streans
• GPURendererDirect: cuda isosurface renderer, but build as a shared library to be included directly in Python
• DataGenerator: python projects with scripts to generate the training data
• SuperresolutionNetwork: the python project with the network specification, dataset generation and loading, training and interactive inference. All files prefixed with main are executable python scripts.
  • mainVideo.py: training code for the Shaded network
  • mainVideoUnshaded.py: training code for the unshaded networks (networks on the geometry/normals with shading in post-process)
  • mainDatasetViewer.py: simple GUI to view the dataset
  • mainGUI.py: interactive GUI to explore the datasets and different networks. Depends on GPURendererDirect
  • mainComparisonImages.py / mainComparisonVideo1,2,3.py: scripted benchmarks and video creation
  • mainPSNR1,2,3,4.py: scripts used to create the statistics reported in the paper

How to use it

The mainGUI.py can be directly launched without command line arguments. It opens a window and allows you to select the volume to render and the networks to use.

mainVideoUnshaded.py is the main training code. All network and training parameters are specified via command line. For example, these are the arguments used to train our best performing network:

python3 mainVideoUnshaded.py \
	--dataset cloud-video \
	--inputPathUnshaded "...../all_ejecta.txt" \
	--numberOfImages -1 \
	--model EnhanceNet \
	--losses l1:mask:1,l1:ao:1,l1:normal:10,l1:depth:10,temp-l2:color:0.1 \
	--lossAO 0.0 \
	--lossAmbient 0.1 \
	--lossDiffuse 0.9 \
	--initialImage zero \
	--samples 5000 \
	--batchSize 16 \
	--testBatchSize 16 \
	--nEpochs 1000 \
	--lr 0.0001 \
	--lrStep 100 \
	--logdir "./logdir_video_2/" \
	--modeldir "./modeldir_video_2/" \
	--pretrained "./pretrained/gen_l1normalDepth_2.pth" \
	--cuda

Datasets and binary releases

Volume datasets, prerendered data for the training and pretrained networks can be found under Releases

Citation

If you find this source code or the paper useful in your research, please cite our work as follows:

@ARTICLE{weiss2019isosuperres,
author={S. {Weiss} and M. {Chu} and N. {Thuerey} and R. {Westermann}},
journal={IEEE Transactions on Visualization and Computer Graphics},
title={Volumetric Isosurface Rendering with Deep Learning-Based Super-Resolution},
year={2019},
volume={},
number={},
pages={1-1},
keywords={Isosurfaces;Image reconstruction;Spatial resolution;Signal resolution;Rendering (computer graphics);Training;Machine Learning;Extraction of Surfaces (Isosurfaces, Material Boundaries);Volume Rendering},
doi={10.1109/TVCG.2019.2956697},
ISSN={2160-9306},
month={},}

Supplemental Material
