Audit.NET

USAGE | OUTPUT | CUSTOMIZATION | DATA PROVIDERS | CREATION POLICY | CONFIGURATION | EXTENSIONS

Gitter     issues-open issues-closed

An extensible framework to audit executing operations in .NET including support for .NET Framework ≥ 4.5 and NetCore ≥ 1.0 (NetStandard 1.3).

Generate audit logs with evidence for reconstruction and examination of activities that have affected specific operations or procedures.

With Audit.NET you can generate tracking information about operations being executed. It gathers environmental information such as the caller user id, machine name, method name, exceptions, including execution time and duration, and exposing an extensible mechanism to enrich the logs and handle the audit output.

Output extensions are provided to log to JSON Files, Event Log, SQL, MySQL, PostgreSQL, MongoDB, AzureBlob, DocumentDB, Redis, Elasticsearch and DynamoDB.

Also extensions to audit different systems are provided, such as Entity Framework, MVC, WebAPI, WCF and SignalR.

NuGet

NuGet Status NuGet Count

To install the package run the following command on the Package Manager Console:

PM> Install-Package Audit.NET

Changelog

Check the CHANELOG.md file.

Usage

The Audit Scope is the central object of this framework. It encapsulates an audit event, controlling its life cycle. The Audit Event is an extensible information container of an audited operation. See the audit scope statechart.

Create an Audit Scope by calling the static AuditScope.Create method.

Suppose you have the following code to cancel an order that you want to audit:

Order order = Db.GetOrder(orderId);
order.Status = -1;
order.OrderItems = null;
order = Db.OrderUpdate(order);

To audit this operation, you can surround the code with a using block that creates an AuditScope, indicating a target object to track:

Order order = Db.GetOrder(orderId);
using (AuditScope.Create("Order:Update", () => order))
{
    order.Status = -1;
    order.OrderItems = null;
    order = Db.OrderUpdate(order);
}

It is not mandatory to use a using block, but it simplifies the syntax when the code to audit is on a single block, allowing to detect exceptions and calculate the duration by implicitly saving the event on disposal.

The first parameter of the Create method is an event type name intended to identify and group the events. The second is the delegate to obtain the object to track (target object). This object is passed as a Func<object> to allow the library inspect the value at the beggining and at the disposal of the scope. It is not mandatory to supply a target object, pass null when you don't want to track a specific object.

There is also a unified overload of the Create method that accepts an instance of AuditScopeOptions. Use this class to configure any of the available options for the scope:

var options = new AuditScopeOptions()
{
    EventType = "MyEvent",
    CreationPolicy = EventCreationPolicy.Manual,
    ExtraFields = new { Action = this.Action },
    AuditEvent = new MyCustomAuditEvent()
};
using (var scope = AuditScope.Create(options))
{
    // ...
}

Simple logging

If you are not tracking an object, nor the duration of an event, you can use the CreateAndSave shortcut method that logs an event immediately. For example:

AuditScope.CreateAndSave("Event Type", new { ExtraField = "extra value" });

Manual Saving

You can control the creation and saving logic, by creating a manual AuditScope. For example to log a pair of Start/End method calls as a single event:

public class SomethingThatStartsAndEnds
{
    private AuditScope auditScope;

    public int Status { get; set; }

    public void Start()
    {
        // Create a manual scope
        auditScope = AuditScope.Create("MyEvent", () => Status, EventCreationPolicy.Manual);
    }

    public void End()
    {
        // Save the event
        auditScope.Save();
        // Discard to avoid further saving
        auditScope.Discard();
    }
}

For more information about the EventCreationPolicy please see Event Creation Policy section.

Asynchronous operations

Asynchronous versions of the operations that saves audit logs are also provided. For example:

public async Task SaveOrderAsync(Order order)
{
    AuditScope auditScope = null;
    try
    {
        // async scope creation
        auditScope = await AuditScope.CreateAsync("order", () => order);

        // async manual saving
        await auditScope.SaveAsync();
    }
    finally
    {
        // async disposal
        await auditScope.DisposeAsync();
    }
}

Note: Inside async methods, if you create the scope within a using statement, the event saving could take place when the scope is disposed, but the Dispose method is synchronous. As a workaround you can explicitly call the DisposeAsync() method, or use combination of SaveAsync() and Discard().

Output

The library will generate an output (AuditEvent) for each operation, including:

  • Tracked object's state before and after the operation.
  • Execution time and duration.
  • Environment information such as user, machine, domain, locale, etc.
  • Comments and Custom Fields provided.

An example of the output in JSON:

{
    "EventType": "Order:Update",
    "Environment": {
        "UserName": "Federico",
        "MachineName": "HP",
        "DomainName": "HP",
        "CallingMethodName": "Audit.UnitTest.AuditTests.TestUpdate()",
        "Exception": null,
        "Culture": "en-GB"
    },
    "StartDate": "2016-08-23T11:33:14.653191-05:00",
    "EndDate": "2016-08-23T11:33:23.1820786-05:00",
    "Duration": 8529,
    "Target": {
        "Type": "Order",
        "Old": {
            "OrderId": "39dc0d86-d5fc-4d2e-b918-fb1a97710c99",
            "Status": 2,
            "OrderItems": [{
                "Sku": "1002",
                "Quantity": 3.0
            }]
        },
        "New": {
            "OrderId": "39dc0d86-d5fc-4d2e-b918-fb1a97710c99",
            "Status": -1,
            "OrderItems": null
        }
    }
}

Output details

The following tables describes the output fields:

Field Name Type Description
EventType string User-defined string to group the events
Environment Environment Contains information about the execution environment
StartDate DateTime Date and time when the event has started
EndDate DateTime Date and time when the event has ended
Duration integer Duration of the event in milliseconds
Target Target User-defined tracked object
Comments Array of strings User-defined comments
CustomFields Dictionary User-defined custom fields
Field Name Type Description
UserName string Current logged user name
MachineName string Executing machine name
DomainName string Current user domain
CallingMethodName string Calling method signature information
Exception string Indicates if an Exception has been detected (NULL if no exception has been thrown)
Culture string Current culture identifier
Field Name Type Description
Type string Tracked object type name
Old Object Value of the tracked object at the beginning of the event
New Object Value of the tracked object at the end of the event

Custom Fields and Comments

The AuditScope object provides two methods to extend the event output.

  • Use SetCustomField() method to add any object as an extra field to the event.
  • Use Comment() to add textual comments to the event's Comments array.

For example:

Order order = Db.GetOrder(orderId);
using (var audit = AuditScope.Create("Order:Update", () => order))
{
    audit.SetCustomField("ReferenceId", orderId);
    order.Status = -1;
    order = Db.OrderUpdate(order);
    audit.Comment("Status Updated to Cancelled");
}

You can also set Custom Fields when creating the AuditScope, by passing an anonymous object with the properties you want as extra fields. For example:

using (var audit = AuditScope.Create("Order:Update", () => order, new { ReferenceId = orderId }))
{
    order.Status = -1;
    order = Db.OrderUpdate(order);
    audit.Comment("Status Updated to Cancelled");
}

You can also access the Custom Fields directly from Event.CustomFields property of the scope. For example:

using (var audit = AuditScope.Create("Order:Update", () => order, new { ReferenceId = orderId }))
{
    audit.Event.CustomFields["ReferenceId"] = orderId;
}

Custom fields are not limited to single properties, you can store any object as well, by default they will be JSON serialized.

Extending AuditEvent

Another way to enrich the event output is to create a class inheriting from the AuditEvent class, then you can pass an instance of your class to the AuditScope.Create method. For example:

public class YourAuditEvent : AuditEvent
{
    public Guid ReferenceId { get; set; } = Guid.NewGuid();
}

using (var scope = AuditScope.Create(new AuditScopeOptions { AuditEvent = new YourAuditEvent() }))
{
    //...
}

The output of the previous examples would be:

{
    "EventType": "Order:Update",
    "Environment": {
        "UserName": "Federico",
        "MachineName": "HP",
        "DomainName": "HP",
        "CallingMethodName": "Audit.UnitTest.AuditTests.TestUpdate()",
        "Exception": null,
        "Culture": "en-GB"
    },
    "Target": {
        "Type": "Order",
        "Old": {
            "OrderId": "39dc0d86-d5fc-4d2e-b918-fb1a97710c99",
            "Status": 2,

        },
        "New": {
            "OrderId": "39dc0d86-d5fc-4d2e-b918-fb1a97710c99",
            "Status": -1,

        }
    },
    "ReferenceId": "39dc0d86-d5fc-4d2e-b918-fb1a97710c99",           // <-- Custom Field
    "Comments": ["Status Updated to Cancelled"],                     // <-- Comments
    "StartDate": "2016-08-23T11:34:44.656101-05:00",
    "EndDate": "2016-08-23T11:34:55.1810821-05:00",
    "Duration": 8531
}

Discard option

The AuditScope object has a Discard() method to allow the user to discard an event. Discarding an event means it won't be saved.

For example, if you want to avoid saving the audit event under certain condition:

using (var scope = AuditScope.Create("SomeEvent", () => someTarget))
{
    try
    {
        //some operation
        Critical.Operation();
    }
    catch (Exception ex)
    {
        //If an exception is thrown, discard the audit event
        scope.Discard();
    }
}

Data providers

A data provider (or storage sink) contains the logic to handle the audit event output, where you define what to do with the audit logs.

You can use one of the data providers included or inject your own mechanism by creating a class that inherits from AuditDataProvider and overrides its methods:

  • InsertEvent: should store the event and return a unique ID for it.
  • ReplaceEvent: should update an event given its ID. This method is only called for Creation Policies Manual or InsertOnStartReplaceOnEnd.

If your data provider will support asynchronous operations, you must also implement the following methods:

  • InsertEventAsync: Asynchoronous implementation of the InsertEvent method.
  • ReplaceEventAsync: Asynchoronous implementation of the ReplaceEvent method.

Also, if your data provider will support event retrieval, you should implement the methods:

  • GetEvent: Retrieves an event by id.
  • GetEventAsync: Asynchoronous implementation of the GetEvent method.

For example:

public class MyCustomDataProvider : AuditDataProvider
{
    public override object InsertEvent(AuditEvent auditEvent)
    {
        var fileName = $"Log{Guid.NewGuid()}.json";
        File.WriteAllText(fileName, auditEvent.ToJson());
        return fileName;
    }
    public override void ReplaceEvent(object eventId, AuditEvent auditEvent)
    {
        var fileName = eventId.ToString();
        File.WriteAllText(fileName, auditEvent.ToJson());
    }
    public override T GetEvent<T>(object eventId)
    {
        var fileName = eventId.ToString();
        return JsonConvert.DeserializeObject<T>(File.ReadAllText(fileName));
    }
    // async implementation:
    public override async Task<object> InsertEventAsync(AuditEvent auditEvent)
    {
        var fileName = $"Log{Guid.NewGuid()}.json";
        await File.WriteAllTextAsync(fileName, auditEvent.ToJson());
        return fileName;
    }
    public override async Task ReplaceEventAsync(object eventId, AuditEvent auditEvent)
    {
        var fileName = eventId.ToString();
        await File.WriteAllTextAsync(fileName, auditEvent.ToJson());
    }
    public override async Task<T> GetEventAsync<T>(object eventId)
    {
        var fileName = eventId.ToString();
        return await GetFromFileAsync<T>(fileName);
    }
}

You can set a global data provider assigning the DataProvider property on the static Configuration object. For example:

Audit.Core.Configuration.DataProvider = new MyCustomDataProvider();

Or using the fluent API UseCustomProvider method:

Audit.Core.Configuration.Setup()
	.UseCustomProvider(new MyCustomDataProvider());

NOTE: If you don't specify a data provider, it will default to a FileDataProvider logging events as .json files into the current working directory.

See Configuration section for more information.

You can also set the data provider per-scope, by using an appropriate overload of the AuditScope.Create method. For example:

AuditScope.Create("Order:Update", () => order, EventCreationPolicy.Manual, new MyCustomDataProvider());

Or:

AuditScope.Create(new AuditScopeOptions { DataProvider = new MyCustomDataProvider() });

Dynamic data providers

As an alternative to creating a data provider class, you can define the mechanism at run time by using the DynamicDataProvider or DynamicAsyncDataProvider classes. For example:

var dataProvider = new DynamicDataProvider();
// Attach an action for insert
dataProvider.AttachOnInsert(ev => Console.Write(ev.ToJson()));
Audit.Core.Configuration.DataProvider = dataProvider;

Or by using the fluent API:

Audit.Core.Configuration.Setup()
	.UseDynamicProvider(config => config
		.OnInsert(ev => Console.Write(ev.ToJson())));

For async operations you should use the DynamicAsyncDataProvider, for example:

var dataProvider = new DynamicAsyncDataProvider();
dataProvider.AttachOnInsert(async ev => await File.WriteAllTextAsync(filePath, ev.ToJson()));
Audit.Core.Configuration.DataProvider = dataProvider;

Or by using the fluent API:

Audit.Core.Configuration.Setup()
    .UseDynamicAsyncProvider(config => config
        .OnInsert(async ev => await File.WriteAllTextAsync(filePath, ev.ToJson())));

Data providers included

The Data Providers included are summarized in the following table:

Data Provider Package Description Configuration API
FileDataProvider Audit.NET Store the audit logs as files. Dynamically configure the directory and path. .UseFileLogProvider()
EventLogDataProvider Audit.NET Write the audit logs to the Windows EventLog. .UseEventLogProvider()
DynamicDataProvider / DynamicAsyncDataProvider Audit.NET Dynamically change the behavior at run-time. Define Insert and a Replace actions with lambda expressions. .UseDynamicProvider() / .UseDynamicAsyncProvider()
SqlDataProvider Audit.NET.SqlServer Store the events as rows in a MS SQL Table, in JSON format. .UseSqlServer()
MySqlDataProvider Audit.NET.MySql Store the events as rows in a MySQL database table, in JSON format. .UseMySql()
PostgreSqlDataProvider Audit.NET.PostgreSql Store the events as rows in a PostgreSQL database table, in JSON format. .UsePostgreSql()
MongoDataProvider Audit.NET.MongoDB Store the events in a Mongo DB collection, in BSON format. .UseMongoDB()
AzureDbDataProvider Audit.NET.AzureDocumentDB Store the events in an Azure Document DB collection, in JSON format. .UseAzureDocumentDB()
AzureBlobDataProvider Audit.NET.AzureStorage Store the events in an Azure Blob Storage container, in JSON format. .UseAzureBlobStorage()
AzureTableDataProvider Audit.NET.AzureStorage Store the events in an Azure Table. .UseAzureTableStorage()
UdpDataProvider Audit.NET.Udp Send Audit Logs as UDP datagrams to a network. .UseUdp()
RedisDataProvider Audit.NET.Redis Store audit logs in Redis as Strings, Lists, SortedSets, Hashes or publish to a PubSub channel. .UseRedis()
Log4netDataProvider Audit.NET.log4net Store the audit events using Apache log4net™. .UseLog4net()
EntityFrameworkDataProvider Audit.EntityFramework Store EntityFramework audit events in the same EF context. .UseEntityFramework()
ElasticsearchDataProvider Audit.NET.Elasticsearch Store audit events in Elasticsearch indices. .UseElasticsearch()
DynamoDataProvider Audit.NET.DynamoDB Store audit events in Amazon DynamoDB™ tables. .UseDynamoDB()

Event Creation Policy

The audit scope can be configured to call its data provider in different ways:

  • Insert on End: (default) The audit event is inserted when the scope is disposed.

  • Insert on Start, Replace on End: The event (on its initial state) is inserted when the scope is created, and then the complete event information is replaced when the scope is disposed.

  • Insert on Start, Insert on End: Two versions of the event are inserted, the initial when the scope is created, and the final when the scope is disposed.

  • Manual: The event saving (insert/replace) should be explicitly invoked by calling the Save() method on the AuditScope.

You can set the Creation Policy per-scope, for example to explicitly set the Creation Policy to Manual:

using (var scope = AuditScope.Create(new AuditScopeOptions { CreationPolicy = EventCreationPolicy.Manual }))
{
    //...
    scope.Save();
}

If you don't provide a Creation Policy, the default Creation Policy configured will be used (see the configuration section).

AuditScope statechart

The following is the internal state machine representation of the AuditScope object:

AuditScope statecart

Configuration

Data provider

To change the default data provider, set the static property DataProvider on Audit.Core.Configuration class. This should be done prior to the AuditScope creation, i.e. during application startup.

For example, to set your own provider as the default data provider:

Audit.Core.Configuration.DataProvider = new MyCustomDataProvider();

If you don't specify a Data Provider, a default FileDataProvider will be used to write the events as .json files into the current working directory.

Creation Policy

To change the default creation policy, set the static property SetCreationPolicy on Audit.Core.Configuration class. This should be done prior to the AuditScope creation, i.e. during application startup.

For example, to set the default creation policy to Manual:

Audit.Core.Configuration.CreationPolicy = EventCreationPolicy.Manual;

If you don't specify a Creation Policy, the default Insert on End will be used.

Custom Actions

You can configure Custom Actions that are executed for all the Audit Scopes in your application. This allows to globally change the behavior and data, intercepting the scopes after they are created or before they are saved.

Call the static AddCustomAction() method on Audit.Core.Configuration class to attach a custom action.

For example, to globally discard the events under a certain condition:

Audit.Core.Configuration.AddCustomAction(ActionType.OnScopeCreated, scope =>
{
    if (DateTime.Now.Hour == 17) // Tea time
    {
        scope.Discard();
    }
});

Or to add custom fields / comments globally to all scopes:

Audit.Core.Configuration.AddCustomAction(ActionType.OnEventSaving, scope =>
{
    if (scope.Event.Environment.Exception != null)
    {
        scope.SetCustomField("Oops", true);
    }
    scope.Comment("Saved at " + DateTime.Now);
});

The ActionType indicates when to perform the action. The allowed values are:

  • OnScopeCreated: When the Audit Scope is being created, before any saving. This is executed once per Audit Scope.
  • OnEventSaving: When an Audit Scope's Event is about to be saved.
  • OnEventSaved: After an Audit Scope's Event is saved.

Global switch off

You can disable audit logging by setting the static property Configuration.AuditDisabled to true. The audit events are globally ignored while this flag is set. For example to disable the audits on certain environment:

if (environment.IsDevelopment())
{
    Audit.Core.Configuration.AuditDisabled = true;
}

Global serialization settings

Most of the data providers serializes audit events in JSON format. You can change the default settings used for this serialization via the static property Configuration.JsonSettings. For example:

Audit.Core.Configuration.JsonSettings = new JsonSerializerSettings()
{
    NullValueHandling = NullValueHandling.Ignore,
    TypeNameAssemblyFormatHandling = TypeNameAssemblyFormatHandling.Full,
    Converters = new List<JsonConverter>() { new MyStreamConverter() }
};

Configuration Fluent API

Alternatively to the properties/methods mentioned before, you can configure the library using a convenient Fluent API provided by the method Audit.Core.Configuration.Setup(), this is the most straightforward way to configure the library.

For example, to set the FileLog Provider with its default settings using a Manual creation policy:

Audit.Core.Configuration.Setup()
    .UseFileLogProvider()
    .WithCreationPolicy(EventCreationPolicy.Manual);

Configuration examples

File log provider with dynamic directory path and filename:
Audit.Core.Configuration.Setup()
    .UseFileLogProvider(config => config
        .DirectoryBuilder(_ => $@"C:\Logs\{DateTime.Now:yyyy-MM-dd}")
        .FilenameBuilder(auditEvent => $"{auditEvent.Environment.UserName}_{DateTime.Now.Ticks}.json"));
File log provider with an InsertOnStart-ReplaceOnEnd creation policy, and a global custom field set in a custom action:
Audit.Core.Configuration.Setup()
    .UseFileLogProvider(config => config
        .FilenamePrefix("Event_")
        .Directory(@"C:\AuditLogs\1"))
    .WithCreationPolicy(EventCreationPolicy.InsertOnStartReplaceOnEnd)
    .WithAction(x => x.OnScopeCreated(scope => scope.SetCustomField("ApplicationId", "MyApplication")));
Event log provider with an InsertOnEnd creation policy:
Audit.Core.Configuration.Setup()
    .UseEventLogProvider(config => config
        .SourcePath("My Audited Application")
        .LogName("Application"))
    .WithCreationPolicy(EventCreationPolicy.InsertOnEnd);
Dynamic provider to log to the console:
Audit.Core.Configuration.Setup()
    .UseDynamicProvider(config => config
        .OnInsert(ev => Console.WriteLine("{0}: {1}->{2}", ev.StartDate, ev.Environment.UserName, ev.EventType)));

Extensions

The following packages are extensions to log interactions with different systems such as MVC, WebApi, WCF and Entity Framework:

Package Description
icon Audit.WCF Generate detailed server-side audit logs for Windows Communication Foundation (WCF) service calls, by configuring a provided behavior.
icon Audit.EntityFramework Generate detailed audit logs for saving operations on Entity Framework, by inheriting from a provided DbContext or IdentityDbContext. Includes support for EF 6 and EF 7 (EF Core).
icon Audit.WebApi Generate detailed audit logs by decorating Web API Methods and Controllers with an action filter attribute, or by using a middleware. Includes support for ASP.NET Core.
icon Audit.MVC Generate detailed audit logs by decorating MVC Actions and Controllers with an action filter attribute. Includes support for ASP.NET Core MVC.
icon Audit.DynamicProxy Generate detailed audit logs for any class without changing its code by using a proxy.
icon Audit.FileSystem Generate audit logs by intercepting file system events via FileSystemWatcher.
icon Audit.SignalR Generate audit logs for SignalR invocations by intercepting the hub processing

Storage providers

Apart from the FileLog, EventLog and Dynamic event storage providers, there are others included in different packages:

Audit.NET Extensions

Package Description
icon Audit.NET.SqlServer Store the events as rows in a SQL Table, in JSON format.
icon Audit.NET.MySql Store the events as rows in MySQL database, in JSON format.
icon Audit.NET.PostgreSql Store the events as rows in a PostgreSQL database, in JSON format.
icon Audit.NET.MongoDB Store the events in a Mongo DB Collection, in BSON format.
icon Audit.NET.AzureDocumentDB Store the events in an Azure Document DB Collection, in JSON format.
icon Audit.NET.AzureStorage Store the events in an Azure Blob Storage container or an Azure Table.
icon Audit.NET.Udp Send Audit Logs as UDP datagrams to a network.
icon Audit.NET.Redis Store Audit Logs in a Redis database as String, List, Hash, Sorted Set or publishing to a Redis PubSub channel.
icon Audit.NET.log4net Store the audit events using Apache log4net™.
icon Audit.NET.Elasticsearch Store the audit events in Elasticsearch indices.
icon Audit.NET.DynamoDB Store the audit events in Amazon DynamoDB tables.

Change Log

For detailed information on changes in new release refer to the change log.

Contribute

If you like this project please contribute in any of the following ways:

  • Star this project on GitHub.
  • Request a new feature or expose any bug you found by creating a new issue.
  • Ask any questions about the library on StackOverflow.
  • Subscribe to and use the Gitter Audit.NET channel.
  • Spread the word by blogging about it, or sharing it on social networks:

Share this package on Facebook Tweet this package
