Tutorial: Building Secure & Decentralized Global Applications on Kubernetes with NATS

KubeCon 2020: NATS Tutorial

NATS is a simple, secure and performant communications system for digital systems, services and devices. NATS is a hosted project in the Cloud Native Computing Foundation (CNCF). NATS has over 30 client language implementations, and the NATS Server can run on-premise, in the cloud, at the edge, and even on a Raspberry Pi. NATS can secure and simplify design and operation of modern distributed systems.

Learn how to build applications that span across more than one Kubernetes region by using a NATS based global communications network. In this talk, it will be covered how to setup a globally available NATS cluster using multiple Kubernetes regions using NATS gateways and leafnode connections, as well as how to create applications that take advantage of the NATS decentralized authorization model by showing how to implement a simple Slack-like clone that runs under your terminal.

You can watch the tutorial by clicking on the image below:

Checkout the repo

Follow along with this repo: https://github.com/wallyqs/kubecon2020

git clone https://github.com/wallyqs/kubecon2020

Setup decentralized auth

Installing NSC

curl -LO https://raw.githubusercontent.com/nats-io/nsc/master/install.sh
less install.sh
sh ./install.sh

Initialize NSC

curl -fSl https://nats-io.github.io/k8s/setup/nsc-setup.sh | sh

Inspect NSC objects

tree nsc/ | less
nsc describe jwt -f nsc/accounts/nats/KO/KO.jwt

Creating the KUBECON account

• We need 3 users at least:
  • Chat Credentials Requestor
  • Credentials Provisioner

  Chat User

  Will be dynamically generated

nsc add account --name KUBECON
nsc list accounts
nsc describe jwt -f ./nsc/accounts/nats/KO/accounts/KUBECON/KUBECON.jwt

Add a new signing key for KUBECON account

This is needed to be able to create users dynamically by the credentials provisioner.

nsc generate nkey --account --store
nsc edit account --sk ACUIKNKJIAPABWJSIJM4GFYLQLL7RUWEBI2BIZYUINPWV5432ZOAEDV4
nsc describe jwt -f ./nsc/accounts/nats/KO/accounts/KUBECON/KUBECON.jwt

Create user for the credentials provisioner

nsc add user chat-access \
   -K $NKEYS_PATH/keys/A/AO/AAOEOFBQCJKEJ7XZLLSHKVCERH34OPZOIJMOUUVW7QKESQ2KT33JZDRI.nk \
   --allow-sub 'chat.req.access' \
   --allow-pubsub '_INBOX.>' \
   --allow-pubsub '_R_' \
   --allow-pubsub '_R_.>'

nsc describe jwt -f $NKEYS_PATH/creds/KO/KUBECON/chat-access.creds

Create user for the credentials request

nsc add user chat-creds-request \
   -K $NKEYS_PATH/keys/A/AO/AAOEOFBQCJKEJ7XZLLSHKVCERH34OPZOIJMOUUVW7QKESQ2KT33JZDRI.nk \
   --allow-pub 'chat.req.access' \
   --allow-pubsub '_INBOX.>' \
   --allow-pubsub '_R_' \
   --allow-pubsub '_R_.>'

nsc describe jwt -f $NKEYS_PATH/creds/KO/KUBECON/chat-creds-request.creds

Confirm setup locally

Generate the NATS configuration.

source .nsc.env
nsc list accounts
nsc generate config --mem-resolver --sys-account SYS
nsc generate config --mem-resolver --sys-account SYS > conf/resolver.conf

Start the NATS Server:

nats-server -c conf/resolver.conf

Try to make a request:

nats-req -creds nsc/nkeys/creds/KO/KUBECON/chat-creds-request.creds chat.req.access example

Create a mock responder:

nats-rply -creds nsc/nkeys/creds/KO/KUBECON/chat-access.creds chat.req.access example

Using the Chat Application

Running the provisioner

cd chat-access
go run main.go --acc $NSC_HOME/nats/KO/accounts/KUBECON/KUBECON.jwt \
    --sk $NKEYS_PATH/keys/A/AO/AAOEOFBQCJKEJ7XZLLSHKVCERH34OPZOIJMOUUVW7QKESQ2KT33JZDRI.nk \
    --creds $NKEYS_PATH/creds/KO/KUBECON/chat-access.creds

Getting some credentials and starting the app

cd chat
nats-req -creds nsc/nkeys/creds/KO/KUBECON/chat-creds-request.creds chat.req.access wallyqs 2> my.creds
go build ./...
./chat -creds my.creds

Deploying to K8S: Infra setup

Creating K8S clusters for NATS

You can find info here:

https://docs.nats.io/nats-on-kubernetes/super-cluster-on-digital-ocean

Let’s create 3 clusters in Digital Ocean:

doctl kubernetes cluster create nats-k8s-sfo2 --count 3 --region sfo2
doctl kubernetes cluster create nats-k8s-sgp1 --count 3 --region sgp1
doctl kubernetes cluster create nats-k8s-ams3 --count 3 --region ams3

Open up the firewall for the required ports

• 4222 is the client port
• 7422 is the port for leafnodes
• 7522 is the port for gateway connections (cluster of clusters)

for firewall in `doctl compute firewall list | tail -n 3 | awk '{print $1}'`; do
  doctl compute firewall add-rules $firewall --inbound-rules protocol:tcp,ports:4222,address:0.0.0.0/0
  doctl compute firewall add-rules $firewall --inbound-rules protocol:tcp,ports:7422,address:0.0.0.0/0
  doctl compute firewall add-rules $firewall --inbound-rules protocol:tcp,ports:7522,address:0.0.0.0/0
done

Deploying NATS to a K8S Cluster

Add Helm NATS repos

brew install helm
helm repo add nats https://nats-io.github.io/k8s/helm/charts/
helm repo update

Upload the memory resolver with the NATS accounts

for ctx in do-ams3-nats-k8s-ams3 do-sfo2-nats-k8s-sfo2 do-sgp1-nats-k8s-sgp1; do
  kubectl --context $ctx create cm nats-accounts --from-file conf/resolver.conf
  # kubectl --context $ctx delete cm nats-accounts
done

Configure gateway connections

Using explicit URL endpoints though we could use external-dns instead for this:

for ctx in do-ams3-nats-k8s-ams3 do-sgp1-nats-k8s-sgp1 do-sfo2-nats-k8s-sfo2; do
  echo "    - name: $ctx"
  echo "      urls:"
  for externalIP in `kubectl --context $ctx get nodes -o jsonpath='{.items[*].status.addresses[?(@.type=="ExternalIP")].address}'`; do
    echo "        - nats://$externalIP:7522";
  done
  echo
done

- name: do-ams3-nats-k8s-ams3
  urls:
    - nats://164.90.192.194:7522
    - nats://164.90.192.226:7522
    - nats://164.90.192.80:7522

- name: do-sgp1-nats-k8s-sgp1
  urls:
    - nats://188.166.236.158:7522
    - nats://188.166.232.25:7522
    - nats://188.166.236.155:7522

- name: do-sfo2-nats-k8s-sfo2
  urls:
    - nats://64.227.50.254:7522
    - nats://64.227.54.26:7522
    - nats://138.197.219.203:7522

Super Cluster YAML

nats:
  image: nats:alpine

  # Bind a host port from the host for each one of the pods.
  externalAccess: true

  logging:
    debug: false
    trace: false

cluster:
  enabled: true

auth:
  enabled: true

  resolver:
    ############################
    #                          #
    # Memory resolver settings #
    #                          #
    ##############################
    type: memory

    #
    # Use a configmap reference which will be mounted
    # into the container.
    #
    configMap:
      name: nats-accounts
      key: resolver.conf

gateway:
  enabled: true

  # NOTE: defined via --set gateway.name="$ctx"
  # name: $ctx

  gateways:
    - name: do-ams3-nats-k8s-ams3
      urls:
        - nats://164.90.192.194:7522
        - nats://164.90.192.226:7522
        - nats://164.90.192.80:7522

    - name: do-sgp1-nats-k8s-sgp1
      urls:
        - nats://188.166.236.158:7522
        - nats://188.166.232.25:7522
        - nats://188.166.236.155:7522

    - name: do-sfo2-nats-k8s-sfo2
      urls:
        - nats://64.227.50.254:7522
        - nats://64.227.54.26:7522
        - nats://138.197.219.203:7522

natsbox:
  enabled: true

for ctx in do-ams3-nats-k8s-ams3  do-sfo2-nats-k8s-sfo2 do-sgp1-nats-k8s-sgp1; do
  helm --kube-context $ctx install nats nats/nats -f conf/super-cluster.yaml --set gateway.name=$ctx
  # helm --kube-context $ctx delete nats
done

Confirm the setup

• Peek at the connect_urls and confirm that the routes are present.

telnet 188.166.232.25 4222

Try to make a request from SF:

nats-req -s 138.197.219.203 -creds nsc/nkeys/creds/KO/KUBECON/chat-creds-request.creds chat.req.access example

Create a mock responder in AMS:

nats-rply -s 164.90.192.226 -creds nsc/nkeys/creds/KO/KUBECON/chat-access.creds chat.req.access example

Using the System account

nats-sub -s 188.166.236.158 -creds ./nsc/nkeys/creds/KO/SYS/sys.creds '>'
