Overview

Shield by Openfort is a secure service dedicated to the protection of sensitive data. It ensures the confidentiality and security of data management by offering a robust framework for storing secrets and encryption parameters.

---

Understanding Shares, Projects, and Encryption

1. Shares

A share is a crucial part of a user's private key. Shares can be stored in different ways based on their entropy:

• Plain (Entropy: None): The share is stored directly without encryption.
• Encrypted by User (Entropy: User): The share is externaly encrypted and its parameters can be stored:
  • Salt: A string used to introduce randomness into the encryption process.
  • Iterations: The number of iterations used in the encryption algorithm.
  • Length: The length of the resulting encrypted data.
  • Digest: The hashing algorithm used (e.g., SHA-256).
• Encrypted by Project (Entropy: Project): The share is encrypted using a project-wide encryption key. This key is split into two parts:
  • Part 1: Stored securely in the database.
  • Part 2 (Encryption Part): Provided to the client via the API when a project is created or when the endpoint to generate it is called.

2. Projects

A project serves as a container for a group of users and its shares and authentication methids. Projects are identified by an API Key and secured by an API Secret. The project handles encryption in a consistent manner for all its shares:

• Project Encryption Key: Projects can generate an encryption key in two ways:
  • During Creation: Using the GenerateEncryptionKey field in the CreateProject request.
  • After Creation: By calling the /project/encryption-key endpoint. This endpoint not only generates an encryption key but also encrypts all stored shares with "None" entropy.

3. Handling Encryption with Shares

Project Entropy: When a project encrypts shares, the following happens:

• A random encryption key is generated and split into two parts:
  • Part 1: Stored in the database.
  • Part 2 (Encryption Part): Provided through the API and required for any operation involving the share (except deletion).

Providing the Encryption Part: There are two ways to provide this encryption part when interacting with shares:

1. Direct Provision:

• Register/Update Share: Include the encryption_part field in the request body.
• Get Share: Use the X-Encryption-Part header.

2. Using an Encryption Session:

• Session Creation: Call the /project/encryption-session endpoint with the encryption_part to create a session. This session is one-time use and returns a session_id.
• Register/Update Share: Use the encryption_session field in the request body.
• Get Share: Use the X-Encryption-Session header.

4. User Authentication and Providers

Users are automatically associated with a project based on the provided API key. To authenticate users (using access tokens), the project must register a provider. There are two types of providers:

1. Openfort Provider:

• The project integrates with Openfort to validate user credentials.
• When using this provider:
  • Specify X-Auth-Provider: openfort in the request.
  • If Openfort authentication is using Third Party provide X-Openfort-Provider and X-Openfort-Token-Type headers for user authentication details.

2. Custom Provider:

• The project provides OIDC-compatible information, such as a JWK URL or a PEM certificate and key type.
• When using this provider:
  • Specify X-Auth-Provider: custom in the request.

Important Notes:

• The X-Auth-Provider header is mandatory for the Shares API to specify which authentication method is being used.
• For Openfort, X-Openfort-Provider and X-Openfort-Token-Type are required headers to detail the specific authentication context.

Endpoints

1. Share API Endpoints

1.1 Register Share

• Endpoint: POST /shares

• Request:

  • Type: RegisterShareRequest
    • Mandatory header Authorization with access token and X-API-Key with project's api key
    • Mandatory header X-Auth-Provider and optional X-Openfort-Provider and X-Openfort-Token-Type for user authentication
    • Optional headers X-Encryption-Part and X-Encryption-Session to specify encryption details.
  • Example:

    {
      "secret": "some_secret_value",
      "entropy": "user",
      "salt": "some_salt_value",
      "iterations": 1000,
      "length": 256,
      "digest": "sha256",
      "encryption_part": "part_value",
      "encryption_session": "session_value"
    }

• Response:

  • Success: HTTP 201 Created with no body content.
  • Failure:
    • 400 Bad Request if the request body is invalid.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a RegisterShareRequest JSON payload.
  • The handler reads and validates the request data.
  • If valid, the handler registers the share using the ShareApplication service and returns 201 Created. This endpoint can also be called with API Key, API Secret, and an extra header X-User-ID to register a share in name of a user.

1.2 Update Share

• Endpoint: PUT /shares

• Request:

  • Mandatory header Authorization with access token and X-API-Key with project's api key
  • Mandatory header X-Auth-Provider and optional X-Openfort-Provider and X-Openfort-Token-Type for user authentication
  • Optional headers X-Encryption-Part and X-Encryption-Session to specify encryption details.
  • Type: UpdateShareRequest
  • Example:

    {
      "secret": "updated_secret_value",
      "entropy": "project",
      "salt": "updated_salt_value",
      "iterations": 2000,
      "length": 512,
      "digest": "sha512",
      "encryption_part": "updated_part_value",
      "encryption_session": "updated_session_value"
    }

• Response:

  • Type: UpdateShareResponse
  • Example:

    {
      "secret": "updated_secret_value",
      "entropy": "project",
      "salt": "updated_salt_value",
      "iterations": 2000,
      "length": 512,
      "digest": "sha512",
      "encryption_part": "updated_part_value",
      "encryption_session": "updated_session_value"
    }

  • Success: HTTP 200 OK with the updated share details.
  • Failure:
    • 400 Bad Request if the request body is invalid.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends an UpdateShareRequest JSON payload.
  • The handler updates the share using the provided data.
  • Upon successful update, the handler returns the updated share details.

1.3 Delete Share

• Endpoint: DELETE /shares

• Request:

  • No request body required.
  • Mandatory header Authorization with access token and X-API-Key with project's api key
  • Mandatory header X-Auth-Provider and optional X-Openfort-Provider and X-Openfort-Token-Type for user authentication
  • Optional headers X-Encryption-Part and X-Encryption-Session to specify encryption details.

• Response:

  • Success: HTTP 204 No Content indicating the share was successfully deleted.
  • Failure:
    • 404 Not Found if the share does not exist.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a request to delete the share.
  • The handler calls the ShareApplication service to delete the share.
  • If the deletion is successful, it returns 204 No Content.

1.4 Get Share

• Endpoint: GET /shares

• Request:

  • No request body required.
  • Mandatory header Authorization with access token and X-API-Key with project's api key
  • Mandatory header X-Auth-Provider and optional X-Openfort-Provider and X-Openfort-Token-Type for user authentication
  • Optional headers X-Encryption-Part and X-Encryption-Session to specify encryption details.

• Response:

  • Type: GetShareResponse
  • Example:

    {
      "secret": "some_secret_value",
      "entropy": "user",
      "salt": "some_salt_value",
      "iterations": 1000,
      "length": 256,
      "digest": "sha256",
      "encryption_part": "part_value",
      "encryption_session": "session_value"
    }

  • Success: HTTP 200 OK with the share details.
  • Failure:
    • 404 Not Found if the share is not found.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a request to retrieve share details.
  • The handler fetches and returns the share details in the response.

2. Project API Endpoints

2.1 Create Project

• Endpoint: POST /register

• Request:

  • Type: CreateProjectRequest
  • Example:

    {
      "name": "My Project",
      "generate_encryption_key": true
    }

• Response:

  • Type: CreateProjectResponse
  • Example:

    {
      "id": "project_id",
      "name": "My Project",
      "api_key": "generated_api_key",
      "api_secret": "generated_api_secret",
      "encryption_part": "generated_encryption_part"
    }

  • Success: HTTP 201 Created with the project details.
  • Failure:
    • 400 Bad Request if the request body is invalid.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a CreateProjectRequest JSON payload.
  • The handler processes the request to create a new project.
  • The project details, including API keys and optionally an encryption part, are returned in the response.

2.2 Get Project

• Endpoint: GET /project

• Request:

  • No request body required.
  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret

• Response:

  • Type: GetProjectResponse
  • Example:

    {
      "id": "project_id",
      "name": "My Project"
    }

  • Success: HTTP 200 OK with the project details.
  • Failure:
    • 404 Not Found if the project is not found.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a request to retrieve the project details.
  • The handler fetches and returns the project information in the response.

2.3 Add Providers

• Endpoint: POST /project/providers

• Request:

  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret
  • Type: AddProvidersRequest
  • Example:

    {
      "providers": {
        "openfort": {
          "publishable_key": "openfort_publishable_key"
        },
        "custom": {
          "jwk": "custom_jwk",
          "pem": "custom_pem",
          "key_type": "rsa"
        }
      }
    }

• Response:

  • Type: AddProvidersResponse
  • Example:

    {
      "providers": [
        {
          "provider_id": "openfort_provider_id",
          "type": "openfort"
        },
        {
          "provider_id": "custom_provider_id",
          "type": "custom"
        }
      ]
    }

  • Success: HTTP 200 OK with the list of added providers.
  • Failure:
    • 400 Bad Request if the request body is invalid.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends an AddProvidersRequest JSON payload.
  • The handler processes the request to add providers to the project.
  • The response includes details of the added providers.

2.4 Get Providers

• Endpoint: GET /project/providers

• Request:

  • No request body required.
  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret

• Response:

  • Type: GetProvidersResponse
  • Example:

    {
      "providers": [
        {
          "provider_id": "openfort_provider_id",
          "type": "openfort"
        },
        {
          "provider_id": "custom_provider_id",
          "type": "custom"
        }
      ]
    }

  • Success: HTTP 200 OK with the list of providers.
  • Failure:
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a request to retrieve all providers associated with the project.
  • The handler fetches and returns the list of providers in the response.

2.5 Get Provider

• Endpoint: GET /project/providers/{provider}

• Request:

  • No request body required.
  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret

• Response:

  • Type: GetProviderResponse
  • Example:

    {
      "provider_id": "custom_provider_id",
      "type": "custom",
      "jwk": "custom_jwk",
      "pem": "custom_pem",
      "key_type": "rsa"
    }

  • Success: HTTP 200 OK with the provider details.
  • Failure:
    • 404 Not Found if the provider is not found.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a request to retrieve details of a specific provider by its ID.
  • The handler fetches and returns the provider details.

2.6 Update Provider

• Endpoint: PUT /project/providers/{provider}

• Request:

  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret
  • Type: UpdateProviderRequest
  • Example:

    {
      "publishable_key": "new_publishable_key",
      "jwk": "new_jwk",
      "pem": "new_pem",
      "key_type": "ecdsa"
    }

• Response:

  • Success: HTTP 200 OK indicating the provider was updated successfully.
  • Failure:
    • 400 Bad Request if the request body is invalid.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends an UpdateProviderRequest JSON payload with updated details for the provider.
  • The handler processes the request to update the provider’s configuration.
  • If successful, the handler returns a 200 OK.

2.7 Delete Provider

• Endpoint: DELETE /project/providers/{provider}

• Request:

  • No request body required.
  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret

• Response:

  • Success: HTTP 200 OK indicating the provider was successfully deleted.
  • Failure:
    • 404 Not Found if the provider does not exist.
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a request to delete a provider by its ID.
  • The handler calls the ProjectApplication service to remove the provider from the project.
  • Upon successful deletion, it returns 200 OK.

2.8 Encrypt Project Shares

• Endpoint: POST /project/encrypt

• Request:

  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret
  • Type: EncryptBodyRequest
  • Example:

    {
      "encryption_part": "encryption_part_value"
    }

• Response:

  • Success: HTTP 200 OK indicating the shares were successfully encrypted.
  • Failure:
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends an EncryptBodyRequest JSON payload to encrypt all project shares.
  • The handler processes the request and returns 200 OK if encryption is successful.

2.9 Register Encryption Session

• Endpoint: POST /project/encryption-session

• Request:

  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret
  • Type: RegisterEncryptionSessionRequest
  • Example:

    {
      "encryption_part": "encryption_part_value"
    }

• Response:

  • Type: RegisterEncryptionSessionResponse
  • Example:

    {
      "session_id": "generated_session_id"
    }

  • Success: HTTP 200 OK with the session ID.
  • Failure:
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a RegisterEncryptionSessionRequest JSON payload to register a session.
  • The handler processes the request and returns the generated session ID.

2.10 Register Encryption Key

• Endpoint: POST /project/encryption-key

• Request:

  • No request body required.
  • Mandatory headers X-API-Key with project's api key and X-API-Secret with project's api secret

• Response:

  • Type: RegisterEncryptionKeyResponse
  • Example:

    {
      "encryption_part": "generated_encryption_part"
    }

  • Success: HTTP 200 OK with the registered encryption part.
  • Failure:
    • 500 Internal Server Error for any server-side issues.

• How it Works:

  • The client sends a request to register a new encryption key for the project.
  • The handler processes the request and returns the generated encryption part.
