- Multiplayer 3D Game with Babylon.js
- Videos
- The team
- Goal
- How to play the game
- History, Details and Difficulties of the Development
- Perspectives
- Launch the Game Locally
- Used Libraries/Frameworks
| FISSORE Davide | BERNIGAUD Noé |
|---|---|
 |
 |
We are students at the University of Côte d'Azur.
- FISSORE Davide was in charge of the menus and UI, the structure of the project, DevOps pipelines and deployment.
- BERNIGAUD Noé was taking care of the rust server, the islands creation, the models and their animations, the game physics, gameplay and sounds.
However, despite our specialization that occurred during the project, we always stayed polyvalent and were able to help each other out whenever someone had a block.
A third student, VENTURELLI Antoine, was originally included in the project and participated in the early versions of the game's logic and physics. Unfortunately, he left the computing science field as well as the project during the first iterations.
The goal of this project was the creation of a 3D Multiplayer Survival game with Babylon.js in Spring of 2023 for the Game on Web 2023 contest. The theme was "To Be Green".
First of all, you can launch the game simply by clicking this link. You will be asked to enter a name for your character and you're good to go !
Because of humanity's greed and avidity, the planet ran out of resources and society collapsed. Your are a survivor who took refuge on an archipelago and have nothing but your will and body to defend yourself. Your goal is to survive the hostile environment and, in particular, monsters that will spawn at night.
This is a multiplayer game, so you might not be the only survivor on the archipelago. Other players live and die by the same rules as you, so choose to cooperate with them in order to become stronger as a group. Or, you could also attack them to make the archipelago your own...
Z: walk forwardZ + SHIFT: run forwardS: walk backwardQ: rotate leftD: rotate rightMove Mouse: rotateLeft Mouse Click: AttackRight Mouse Click: Throw attackSPACE: jumpSPACE(while falling): deploy gliderENTER: open the in-game chat
When we look at what the game look like now, it might come as a surprise to know how it started: a glorified mini-chat. We wanted to learn how to program a server since it would be fun to be able to play and test the game we were developing together. At this stage, we didn't even precisely know what the game would be like, but we wanted to make a server first to better understand how it works and be able to picture how we could make a multiplayer game.
We decided to realize the server with the Rust programming language. None of us knew how to program in Rust, but we were interested to learn more about it due to its growing reputation to be a good server language with a high control, security and performance.
Once the mini-chat was done, we made a rudimentary BabylonJS world where players were able to log in with a custom name. This frontend would connect to the server, which was now able to receive, store and broadcast players' position.
A fun issue we got to experience during our testing was injection attack: we could send special characters, HTML tag, or even code in the mini-chat to try to crash the server or even make the server interpret it! It was a rather easy fix but also something amusing to experiment.
Another issue with the server was the update per second. We couldn't ask the server to update all players positions for all clients
An interesting choice for the server we had to debate early on was to choose between a dumb server (smart client) or a smart server (dumb client). The first correspond to how we would develop a solo game, where the client handle the game's logic and the server serves mainly as a place to centralize and broadcast any information. In the case of the smart server, it is the server that handles the game logic, and the client's job is to capture inputs from the player and display results from the server. The latter is actually the main way to make multiplayer games as it is much easier to prevent cheats this way. However, we decided not to implement it for two reasons:
- We want to make the server run for free and therefore it needs to work on very low resources.
- Cheating is not a main concern for our game as it is non-competitive and doesn't have a large audience.
That said, we will see later in this readme that there is a part of smart server in our server.
Once we had our strong base, it was time to move forward and for that we needed to know more precisely what we wanted to do. A lot of ideas were proposed, such as RPG directions, but we ended up choosing to make a survival multiplayer game. We liked the idea of spawning the player on an archipelago of islands with different biomes where they would be attacked by a variety of monsters. Moreover, we wanted to strongly link the game with the theme "To Be Green" by including management and respect of the archipelago's resources.
In the end we did respect the overall direction of our original idea, but could not follow on every aspects of its ambitions. The scope and complexity of our ideas were way too large and complex, so we had to refocus on what was important to our game.
One choice we made very early in the development was not use the whole BabylonJS's physics engine. We didn't need its most powerful features as we intended to keep the physic of our game rather simple. Therefore, we chose to create our own physics to have a more lightweight engine.
Gravity's interactions were quite tricky to implement. We assigned to the player a variable representing his current acceleration vector. It is then easy at first to implement the gravity or other kind of propulsion such as jumps. However, gravity created difficulties when combined with collisions with the ground. If we always applied gravity the player would glide over even the smoother slope as we wanted something lighter than friction forces. To solve this problem, we opted to cast an invisible laser below the player that once detect an intersection with the ground will not apply the gravity force on the player. We can adjust the size of the laser to change the maximum degree of slope the player can climb.
Something else we had fun experimenting with was fall damage. The simplest implementation was to use the previously created acceleration vector and assign fall damage proportional to it. However, this created some frustrating and unintuitive behavior where the player would die after gently gliding in a slope. We managed to assign fairer fall damage by giving to the player variables representing his height position and time when he last touched the ground. If, after a fall, the difference of height was to high and the difference of time was too low, that would mean the player made a large and hard fall, and they would take fall damage. This implementation created a much more consistent behavior.
Once we started to create our world map, we wanted to realize stunning map: one of the most important goal we want to achieve. The execution of our game on a browser limits a lot the graphical performances in comparison to more classic games. Despite this, we still wanted to get a wow out of the player when they load the game.
All blender, a 3D modeling software. None of us was experienced with it and it has a quite steep learning curve, so this step took a lot of time. Moreover, we had to endure very long loading times as generating high-quality terrain or textures could take from tens of minutes to hours. Therefore, we had to really find the good settings before testing.
After a lot of experimentation, we managed to create satisfying terrain models using the ANT (Another Noise Tool) landscape extension on Blender. By tuning the noise's parameters, we could create the different biomes' height map. This tool also allowed us to texture the terrain. Despite this, the forest terrain results were not good enough, so for this specific case we made the texture of the terrain by using a shader assigning textures based on rules, in our case the inclination of the terrain. We also made a lot of effort in optimizing the complexity of our terrains' models.
We created the water out of simple plan to which we gave the very convenient WaterMaterial found in the BabylonJS library with parameters adjusted to our needs. We also implemented a tide that rhythm the accessibility of the different islands. When under the water plan, the player enter a swimming state and can drown if they stay for too long. Under the water plan, a sand ground is there, with varying heights to create paths between the islands depending on the tide.
Finally, we wanted to have a Day/Night cycle that would make the landscape more varied and would rhythm the gameplay. We instantiated animation on the lightning and sky, which contains a lot of parameters in its material to simulate a real sky. While it was quite a long job to animate all the different needed details for the lights and colors of the sky for different hours of the day, it was well worth it as we feel it was the final touch that finally brought the "wow" we were looking for.
BabylonJS offers some interesting options for cameras, however our specific needs called for addition onto them. For a third person game, a FollowCamera is the best choice, but we had problems where the camera could go under/behind the ground when the player would turn his back on a slope. Our islands having quite a lot of relief, we had to modify the camera - we added a front and back laser to the camera to know its position in relation to the ground. This way, the camera will get closer to the player when needed to avoid going under the ground, all the while trying to position itself as close to its normal distance to the player at all time. The player also becomes semi-transparent if the camera gets too close, which is a classic technique used in games to avoid the player obstructing the view when the camera gets too close.
All in all, the game is overall not performance-hungry thanks to our work on the physic, as each player only needs to calculate his own movements and not the ones of the other players or monsters, which are transmitted by the server. However, the introduction of the forest made performance much tighter. Because of the high number of trees, the number of frames per seconds dropped really low. To improve that issue, we implemented an LoD (Level of Detail) on trees so that we don't have to display high-quality details from afar. We create the trees as instances of the model, for which we freeze the coordinates to lower the computation as much as possible. After working on that, we managed to get back to a good amount of frame per seconds.
Another important part of performance is that we avoid using collision on complex models (player's model, trees...), and instead link objects to a simple hitbox corresponding to the shape of the model, often a cylinder.
It is also interesting to notice that the game physic does not depend on the performance. We use the time between each frame to scale the movements made during physic calculations, so that a player with less frame per seconds will still go at the same speed as others.
With our approach on the dumb server issue, we had difficulties on how to implement the monster's artificial intelligence and movements. Here are the options that were considered:
- One client chosen as the host for the game, which means the monster's calculations would be made on his side for everyone. Not only this option could create wrong behaviors and large inconveniences if the host doesn't have a performant enough computer, this would also create difficult to handle cases when the host disconnects.
- Each client spawn a few monsters and handles them. This is a rather elegant solution, however it introduces a lot of problems on players disconnection as any monster could disappear.
- The server, when launched, instantiate a special "server-side client", which is a windowless BabylonJS process containing a minimalist version of the game charged of the monster's intelligence and movements. This is the option we ended up choosing as it is a lot more straightforward to implement and we were more limited in resources on the client-side than on the server-side.
For the deployment, we chose to use Heroku for the server and Github Pages for the client. We already had experience with both, and those are free resources. However, our complex implementation of the server, which needed a Rust and a javascript environment, made the deployment of the server much more complicated than we hoped. We also had problems with the size of the project: it was too large for most hebergement websites.
To be able to control our server's environment, we therefore used Docker to make a containerize the game. Once Dockerized, heberging the container is a lot easier and more controlled than trying to directly heberge our backend code. Using Docker also allowed us to only heberge the file needed.
The process of building the frontend and the backend code, creating the docker container, pushing onto our repository, and updating the backend on Heroku was very long and tedious. In order to make our workflow easier and faster, and constantly update wrt our online version, we set up a continuous integration pipeline. In this way, a simple push on the game repository would automatically do all the tasks described above. This was a huge quality of life improvement for us and we'll be sure to incorporate it from the start in our future projects.
With the biggest stepping stone now done, it was time to enter the finalization stage of the game. We had a lot of small bugs to fix and improvements to make so that our game become more of a finalized project and less of a early concept.
First of all we had to use proper character models and animate them. We tried a lot of models but animating them was difficult and time consuming, but after some research we stubbled onto Mixamo, a free website that allows us to download models and attach animation to them. Using Blender once again, we were able to combine many animations into a models. Once imported, we still had a lot of issues regarding the way to import models, but after working on a refactor we manage to get everything to work as we wanted. All characters now have a variable representing their state, such as:
- "walking"
- "dying"
- "swimming"
- "gliding"
- And many more...
The model's animation are activated according to a state machine using these state and their transitions. We also enabled blending for our models' animation so that we get smooth transitions between all animations.
We used postPrecessing to add a vignette when the player is under water to make the player really feel like he's under water. We used the same technique combined with a fading animation to create a red effect on the camera when the player takes damage.
It is also important in a game to have a pleasing soundscape so that it does not feel dull. While we kept things quite calm to not distract the player too much, we added the necessary sounds to make the world feel more alive.
The game at this stage was working as we wanted but it lacked some meaningful activity to do during the day and a reason to explore the world. Therefore, we added helpful fruit plants that could be hit by the player so that they gain back some of their lost health. The plant then is destroyed and will reappear only 100 second later. Not only this make it very useful to explore as you get to know the different fruit plant spots, it also introduces some drawback to always sticking as a groupe of player and could encourage some hostile behavior between players as the resource is quite limited, which in our opinion makes the game more interesting as there are incentives both to cooperate or to defend your ground against others.
Finally, what is a third person action game without a glider? A lot of the major game releases that looks anything alike our game have a glider in it, and for good reasons - it's just that fun! This is one of the final touches that gave a little extra to the game, and with the work on the scenery, a glider felt like the perfect addition to get a better view while having a funnier way to move around. Moreover, it was a rather easy addition as we just needed to give the player a constant vertical force and prevent the gravity to accelerate them while they glide. We added a laser below the player to check if they have enough space to glide before allowing them to do so, so go jump from the tallest cliff you can find and spring your wings!
During the development of this project, we learned a lot about the lower-levels of game development. Indeed, we had to do a lot of work to program some of the physics ourselves, as well as creating a server from scratch. The deployment was also an interesting and challenging part, and learning how to set up Docker and the continuous integration proved very useful. We also made a lot of effort in the visual area and we're very happy with the results.
Doing a multiplayer game in particular created a lot of specific difficulties, as some things usually manageable such as a simple AI chasing the player could become very complicated in order to get the synchronization working. That said, overcoming these challenges was well worth the time as being able to play a game with others is a complete different experience in comparison to a solo game, and is especially convenient in the case of a game you do not even need to download and can play directly in your browser.
We hope that you will enjoy your time on the game as much as we enjoyed developing it !
While the project is deployed on heroku and playable simply by clicking on this link, it is also possible to launch it locally after having imported the source code. In the project's root, open two terminal and enter the following command:
- cargo run to launch the rust server.
- npm run client to launch the javascript client
Note: To run the project, you will need to install cargo and nodejs to respectively execute the server (coded in rust) and the client (coded in javascript)
For the development of the game we used the following libraries/frameworks
- BabylonJs (v. 5.17.1) to render the 3D part of the game
- ReactJs (v. 16.13.1) to structure and easily maintain our frontend
- Bootstrap (v. 5.2.3) to customize our welcome page with standard css styles
- Docker (v. 24.0.2) to containerize the project
- GitHub workflow to:
- build the dockerized version of the server and push it on Heroku
- compile the sources of the client and push them on a dedicated branch (called branch-client) of github
- Github pages to automatically push branch-client on github.io
Programming languages:
- Typescript (the typed version of javascript) to implement the game
- Rust to implement the server
Hosts the game:
- github.io for the client side
- heroku for the server side
