- Transcript: https://github.com/data-umbrella/event-transcripts/blob/main/2020/15-emma-gouillart-plotly.md
- Meetup Event: https://www.meetup.com/data-umbrella/events/272683860/
- Video: https://youtu.be/BxIoQ0gsxzA
- Jupyter notebook: plotly-code
- GitHub repo: not applicable
- Transcriber: ? [needs a transcriber]
welcome to data umbrella um i'm going to just go over the agenda of how the webinar is going to go i'm going to do a brief introduction emmanuelle um will do her presentation on plotly and you can ask questions on the q a tab and so we'll sort of check questions when it's a good time to stop um but not to worry your questions will get answered some of them might be at the end but we will answer all questions and this webinar is being recorded a little bit about myself i'm a statistician data scientist i'm the founder of data umbrella and i'm also an organizer for the new york city chapter of pi ladies you can find me on twitter github and linkedin as reishmas data umbrella is our mission is to provide inclusive and welcoming space for underrepresented persons in data science machine learning and ai and we are an all volunteer run organization pi ladies is an international group there are over 125 active chapters around the world and it's for women and gender minorities of all levels of programming um and this is our website yeah you can also um you know go to our website and we have links to all of our linkedin and slack and more information i want to cover the code of conduct briefly we're very strict with our code of conduct we're dedicated to providing harassment free experience for everyone we ask that you make this a professional and respectful environment and this applies to the chat as well and um it's been a great experience so far and thank you everyone in the community for uh keeping it up i want to share a new feature of data umbrella which is a job board the url is jobs.dataumbrella.org i'll also in in just a couple of minutes i'll put it in the chat um but you can check it out to see what jobs are posted and you can also there's a weekly digest that you can subscribe to if you are um in the job market we have the highlighted job of the week which is farfetch farfetch is a um i know they do work with fashion uh you can read more about the um job on our website and they're new york city based and they're looking for a lead data scientist on our website which is dataumbrella.org there are a number of resources there there are resources for accessibility and inclusivity there are resources for open source about social impact of policy about scikit-learn so um you know on your when you have some time uh check out the website um there's a lot of helpful information there for data umbrella the best place to find out about upcoming events is meetup.com nyc data umbrella uh the website has resources we're on twitter feel free to tweet about it and pretty much we're on all social media platforms data umbrella and now i am going to hand it off to emmanuel um and uh just that you know if we could if we could clap emanuel is joining all the way from france paris and i started in particular contributing to psychic image which is a python image processing toolkit since i was using it for my research and one year and a half ago i decided to contribute more to open source and this is why i joined blockley full time and during this time at plotley i've been lucky to receive a grant from the chance working bag initiative which is a foundation which has funded a project uh bloodly to work on interactive image processing i talk about it at the end of the presentation so the subject of my talk is a bloody graphing library so uh what is plot g maybe um most of you know about it and i'll try to share a little just so that you can vote for your preferred visualization tool you don't have to say it's bloodline it's just interesting for me to see which tool people are using so i just put solutions well just put answers in writing because this is the language i know the most uh but so plotly is an interactive web native visualization library and since it is developed for visualization in the browser it is written in javascript but it also has apis for languages more familiar to data scientists so python are and more recently julia as well the the python flavor of plotly also has a high level expressive api which is called bloody express and which is particularly suitable for working with spender's data frames like seabourn for mad bloodly and for python plottings in fact the most downloaded visualization library uh which is interactive that is uh web-based and very interactive matplotlib is more than loaded but then it's not as interactive and it's not based plotly is open source it's mighty licensed and during this presentation we'll see that it has a large variety of traces and is very customizable and it has a strong focus on interactivity in the sense that charts figures are very interactive but also they send events which can be listened to by other libraries for even more interactivity so in order to illustrate the capabilities of properly i'll focus here on three different use cases of bloody during this talk first of all we'll see how to explore data by visualizing them which is something you can do in a jupiter notebook for example then i'll switch to a slightly more advanced use case where you want your visualizations to interact with other elements or to publish them as a dashboard and finally i'll combine the two first aspects to show tools we've been developing recently for interactive image annotation and processing so let me start with the first use case which is interactive exploration of data and for this we'll work in a notebook so i guess most of you are familiar with a jupyter notebook so it's a development environment which mixes code cells and the outputs um so i'll be using it uh during this presentation i hope the the fonts are big enough i can increase them a bit so um plotly is open source you can paper install it and so we'll start by importing it and in particular we'll import a set package called graph objects for it's like a collection of graphical objects and it's commonly imported as go and the first object we'll be creating is called a figure so when we execute this in a notebook we get a figure but then it's an empty figure so not very interesting but so we'll populate this figure object in an object-oriented manner by adding first a trace which will be a scatter trace with x and y coordinates [Music] okay and we'll show it so here the first race and we'll add more elements by adding for example a bar plot so a second trace [Music] and let's say we don't so traces are data points which you are visualizing in some specific ways and um here we also want to add more elements in particular let's say we want to add a title so a title is a part of what's called the layout in a closely figure and so we call the update layout method my first figure this will be my text okay so here is our first figure object but what it is uh what is it exactly to know what is this figure object we'll just print it to show its structure calling its representation so we see that this figure object contains an object which looks like a dictionary a dictionary with two keys one of them is the data which is a list of traces and the other one is a layout and so each trace or the layout is itself a dictionary which is a dictionary of dictionaries so it has a nested hierarchy structure with the different properties and attributes of the visual elements and this object is in fact passed to the javascript library as a json string since it has this json-like hierarchy so it's in fact a very simple object which is just past as it is to uh the javascript part of the library and once you have understood this nested hierarchical structure then you can modify it like for example if i want my first trace which is the scatter trace i want to modify its x coordinate not 0 1 2 but 1 2 3. i can modify it this way you see it has shifted the x data points or i can also modify my title [Music] uh like this equals 30. okay but um so instead of writing all those dots it's actually nicer to call this high level methods of the figure objects which are archways or update traces update layout and also instead of writing all these dots you see here this underscore which is exactly uh the same as uh putting a dot here so if i want to modify the title font size here i can write it like this so using this underscores called magic underscores a way to navigate down the hierarchy of attributes of the the plotly figure there you go okay so this was for a crash course introduction to the structure of bloody figures you can create figures in this informative way where you define the traces you modify the layout and you create a figure but sometimes it's much nicer to uh use a high level api and this is uh what the bloody express um package does so now i'll introduce bloody express you usually import it as px and uh so it's probably express why express it's uh in order to create a function figures fast but also uh to also to create figures in an expressive way so it's both fast and expressive and so px comes with a set of built-in data sets so we'll use one of them which is called the gapminder [Music] so what it is it's it's a painless data frame where each line is a pair of country in year and there are other columns for values such as the life expectancy or the population of the country for this year so to to start with we'll limit our data sets to the most recent year here using some typical pandas syntax with a query and we'll start by asking ourselves what is the distribution of life expectancies through the countries of the world so we'll call the plotly express or px that a histogram function in order to plot a histogram so the syntax is you have the data frame and then you give the variable on which you want you to plot the distribution so here i'm interested in the distribution of life expectancy there you go so you've got this figure which is [Music] quite interactive you can see in particular that i can see for each binder the count corresponding to the number of countries with life expectancy in a given bin what's interesting is that you can see that this histogram is quite bi-modal it's not just one peak um you can see that uh a few countries have a very low life expectancy all those very high so can we know more about which countries are in which to pin for this we can add more visual elements but first i'd like to show you that this figure created by the plotliexpress core the plot express function is not very different from uh the figures we've been using uh in the examples just before with graphical object so we'll print the figure and you can see that so it's still a figure object with a data key corresponding here to one trace this trace is a histogram so it's a graphical object trace it has some x data and also it has a layout which is populated with some values in particular the the the title of uh the the access is already [Music] specified you don't have to to give it yourself so bloody express is here a fast way to to produce a figure which is not completely camera ready but uh has already a lot of useful elements but it's exactly the same structure as a plotline figure created with graph objects and so i was saying what if we want to know more about which countries are in each bin then we can add facets for a marginal view of the countries so we add this rock plot where each of these small bars correspond to one country um but we don't know the name of the countries so we'll map the name the country column of the data set to the hover name so that it appears in the hover [Music] what uh i'm i'm doing here is mapping columns of my data set to visual elements and i can go further in this direction by adding a different color for different continents color equals continent [Music] so here you've got this different stacked histograms each one of them corresponds to a different continent one interesting things also is this legend which is interactive like if i want to select only um asian country oops i should double click on it or i can select or remove one of these continents so the the legend is uh quite quite useful um so this was for a histogram but in this histogram each country has the same weight whereas we know that some countries are much more populated than others so if you want a different view what we can do is instead to plot a bar plot with this time [Music] the x corresponding to the the continent and the y to the population and you get this bar plot and um where the height of each bar corresponds to to the population and this time since i've got a different x location for each continent i can save the color for a different colon of my data set which is life expectancy so that it will be color coded color coding the life expectancy and you get this nice hues for the life expectancy with a color bar here so this chart is interesting but what if i want to be able to select one continent and to do some drill down in my data set for this i can switch from a bar plot to a more hierarchical plot and i will show you this by just looking through the plotly documentation just to show you an example of uh how to look for stuff in the plotley documentation so this is the main plotly documentation and let's say you're looking for a hierarchical plot so you see that on the left column you have the documentation results for different tutorials and here is a figure reference result so it's more the api so you see that the first results are treemap and some burst charts so which are the two kinds of hierarchical traces which we have in bloodley so if you go to one of these pages you have actually quite a large number of examples for each chart you you can see that there is a property express sunburst function that its arguments are pass for the hierarchy of levels values is what you want to represent the equivalent of the y in the bar chart uh you have more examples with scholars and and so on and so forth so we try to have quite a thorough documentation for plotly and it's also an area where we get a lot of help from the community of users with a lot of community pro requests about improving the documentation which is absolutely great and i hope we continue to have a lot of great contributions from the community in the future but so if i go back to my code cell here if i want to plot a sunburst here instead i have to use a bus with continent and then country [Music] and my values will be the population and color life expectancy so i get this um circular diagram where i can drill down in one country and you can see that in more details the different countries of africa and you can go back one level up by double clicking exploring uh another continent so this is a small example of the entire activity which you you get with bloody and by the way the sunburst and tree map charts are even more useful when you have a large number of levels like uh three or four rather than two um so this was for a short introduction uh to the plotly visualization library um one little thing which i can also show is um how to yeah how to map different columns uh to um not a two to facets that is two different subplots this is something which is very very useful so i could do like a live [Music] equals continent [Music] it's why okay so in this visualization i get one one facet per continent and i could also make different colors um for just two [Music] yeah this is better so it's uh also a way to map the values of your columns this time to a different subplots and this is a very powerful way of creating subplots and populating them because if you had to write all this yourself it's actually a bit more verbose you would have to loop through the different uh facets you can do it of course it's easy to write loose with python but uh this high-level way of making multi-faceted plots is quite nice so this was for the short not so short maybe introduction to uh plotline and if you want to learn more i recommend going to the documentation website which has several tutorials covering what i've been describing and in particular how to create figures their structure plotly express and you can also see in the documentation that there is a very large number of charts of course uh usual basic charts like pie charts bar charts but also statistical charts uh heat maps geographical charts 3d visualization is also quite interesting so check it out if you're interested so very nice flats a lot of different traces but what if you want to have more interaction than just user interaction in one figure for example if you want to have two figures which interact together so um this is something which you can do with uh plotline because plotting figures in fact emit some events which can be captured by other javascript tools and in particular you can capture these events using dash so i spent just a few minutes explaining what is dash which is another open source library developed by plotly also mighty license so dash is a web framework to write what we call analytical apps in python we'll see examples of analytical apps which are basically dashboards for science and data science it's a user interface toolkit so written in javascript but with a python api so that you can write your java your dashboards uh in pure python with no javascript required this is really the promise of dash it has a large variety of interactive components and so we will see uh first a few examples just to introduce dash and then we'll see how plot integrates with dash so we've got this first hello world uh script for dash uh where you import some dash modules and then you create your first dash app and you declare the layout of the app with several elements so one of them is an html title and the other one is taken from this dashboard com components library dcc which is for elements to be modified by the user and here it's a text input so what happens if i execute this writing script we'll go back to the notebook just in a few minutes but just i show you the vanilla classical way of defining uh of dash apps so when you run the app uh under the hood there's a flask server running and you can go to a url where you have created your web page with this title you defined in layout and also a text input so far so good but we don't have interaction in this app so for interaction we need to add what's called a callback uh so a callback is a this function decorated here which links together two components the here it takes as input the the text input when it's changed the callback will be triggered and as output uh the content of my title so what if i run this time this new app this will this should reload my app and now when i write hello every time i type a keystroke then the values are sent to the python server the callback is executed and the new value for the title is sent back to the javascript layer in my browser and if you want to take a look at the graph of callbacks in my uh in my dash app you can see that here there is one callback linking together the input and the title components okay so how can we integrate this with platygraphs so for this i first show you an example of what is it it's here which is an example from the dash gallery so in this dcc dash core components package you have a component called dcc.graph which is a wrapper around the plotly figure and for example this is here a bloody figure you can see here it's modbar it's a different kind of trace which is here a cover plate so it's one of this geographical uh map and so when you change the sliders this will modify your map because there's a callback taking as input as a slider and as outputs a bloody figure the callback creates a new plot refigure and sends it to the browser however uh this is only one way of interacting and the other way works as well like if i make a selection like this lasting selection here in my figure this will send a specific event called a selected event in to a callback listening to this kind of event and this will modify a histogram here so the plotline figure can be interacted with really both ways in a dash app you can modify it with a callback but it can also trigger events and callbacks and if you want to know more about the kind of events which you can listen to i encourage you to take a look at the the interactive visualizations tutorial of the dash documentation where you have this app with one callback for every kind of event so hover over data which is the events triggered when you hover click data when you click selected data and so on and so forth and the layout data is when you change one element of the layout so for example here if i zoom i will trigger a layout data event changing the range of the two axis or if i click i trigger also a click data event so this is how you can connect bloody figures to other parts of a dash app so this was for a very short demonstration demo of how you can use your plotter figures in an interactive way with other elements in an app like a dash app and in the last part of my talk i'll show you how to combine platy express with the with dash for image processing so image processing is uh what's the topic which uh maybe interests me the most in data science in uh in scientific writing it's the task of processing your image data in order to extract information from them it's something which is done in a very large variety of domains in science like in biology where you want to count cells and measure the properties satellite imaging it will be very useful also in a self-driving cars or in image classification like in google images for example and um last year i i've been working on this project funded by sensody in order to develop more tools for interactive image processing using several mainstream tools from scientific python the first one is psychic image which is the image processing toolkit for python so i'm a maintainer also psyched image which is a collection of image processing algorithms with a functional api you call functions on images and the idea of this project is to combine the algorithms of site image with the capabilities of plotting dash to use plotly in order to visualize image data in a dash to trigger to trigger callbacks when you annotate images within plotline dash to call some algorithms from psychic image like if you draw a rough contour like here of this organ you want a psychic image to segment in a very good way uh it's exact contour so the idea is to have uh powerful tools to build interactive image passing apps so how how have we been doing this uh let me go back to my notebook a first step has been to extend the bloody express api so that it had image visualization capabilities because we used to have limited capabilities for image visualization so i'll start by just importing an image data set from plotly from psychic image so sorry by calling one of the built-in image data sets which is the cat and [Music] there is one trace which is called image trace and which is meant to represent images [Music] i forgot to import plotly that's a demo effect [Music] so there you go you've got this image visualization here in this figure where you've got some information in the hover in particular the the value of each pixel is represented as z here this is quite useful and so that's a low level uh go api but we've also introduced the corresponding property express function and we've got a px dot in show [Music] function [Music] and um [Music] which is calling um an image trace under the hood so this the first step of the project was to uh implement this interactive image visualization function where you can zoom you can select some parts and now we can build our first image processing dash app for this i'll reuse some code so that you don't have to see me copy pasting so let's say i want to [Music] visualize the histogram of some parts in my image and i want the user to select interactively uh some interesting parts um so for for this since we are in the notebook i'd be using um a recent let me let me use a new notebook we'll be using a new package called jupiter dash [Music] which we've been um releasing and oh i forgot to kill my my old app so i need to um use in a new port so [Music] so jupiter dash is a way to display your uh well to to write and visualize your dash apps in the notebook so it's very convenient if you're used to working in the notebook because you can start just creating your bloody figures in the notebook and then adding some interactivity with the jupiter dash app so here i've got two figures one of them is my image here and the other one is a histogram and i want to be able to make a selection and to see what happens what is the histogram of my my my selected vision and so when you do this usually what i start doing is that i i listen to the selected data event and i look at uh the structure of this this events and i see that it looks like this so i know the syntax of um what i should be calling i use print quite a lot in the dash apps and so this will be like my next uh [Music] my next callback let me update it i see that i'm running out of time so i will try to be fast and just updating this [Music] so this time when i select a small region then the the graph is updated and if i select like the nose for example it's very red so i can explore some parts of my my image like this the white part is very bright and so on and so forth but um so with selection i can have some interactivity but selections are quite short-lived and we wanted to have something which uh was more persistent in user annotations which you could use for a longer time in the plotlife and this is why we introduced shapes shapes uh so shapes which you can draw shapes have been parts of the plotline layout for a long time so a shape for example is this rectangle and um in the most recent versions of broadly you can draw shapes yourself like for example you can draw a rectangle you can draw a circle and each time you do this this triggers a layout event you can also modify them just by clicking modifying some of them and you can listen to the corresponding we layout data events uh in your your dash apps so i just stopped the presentation by showing you a small example of a more advanced dash app we've been writing using this annotation so this shape annotations we've got one figure here which would like to segment that is to separate the different parts of the image in different classes and here when i'm selecting the different colors a callback is updating the new shape properties of my platfigure so that the the color is changed i will do this i can also modify it switch which is another property of this new shapes and and so on and so i have all my shapes which are persistent more than selections and then when i click on this show segmentation a callback uses cyclone to compute well cyclotron and features corresponding on local neighborhoods to compute labels for the remaining pixels so this is an example combining these plotly annotations uh in an interactive figure where you can also zoom for example you can fan and look at the details and also the power of scientific writing libraries like psychic image for image processing or psychic learn for machine learning um so i'm running a bit out of time so conclude here by just hoping that this presentation was interesting for you i hope there will be questions in the chat i hope you will be in touch either on twitter or also we have this discourse community forum where a lot of questions about flatly and dash are asked and answered too so thank you very much and i hope we'll now have a nice q a session thank you so let me go back to the chat okay so i guess it's it's your time to work and to ask questions in the chat so the next question is uh is image processing the same as neural networks or a different process so neural networks are a possible tools for image processing because image processing is this generic class of tasks where you want to extract information from images and there are several ways of doing that uh you can either do somewhere operations on uh pixel values which is a more traditional way of doing image processing or you can build a neural net to perform some image processing tasks by uh learning some structure out of your images or you can also use uh more traditional tools uh for machine learning like uh the the app i showed at the end was you using a random forest classifier for example so this is not a neural net but this is still using machine learning so i'd say neural net is one of the possible tools for image posting and nowadays it's also the state of the art for a lot of image processing tasks like image classification or segmentation or some objects next question um how is the app recognizing the classes after you indicate the classes this is some kind of cnn or other machine learning algorithm so i went very quickly on this app because i was running out of time so um let me go back to the app so here um for each pixel um we call a circuit image function co computing a vector features for each pixel so features are based on the local intensity the local standard deviation and texture in different neighborhoods with different signals so we've got this uh vector features for each pixel and after we call uh random forest classifier uh from cyclic learn so it starts using cnn but the features are defined um in um in a more specific way but of course it would be also possible to use a pre-trained uh neural nets here uh which could give very good results maybe even better that's actually some extension i've been wanting to to do to this ab it's to try it out with uh with the neural net um does the next question is does bloodley dash work well with 3d volumetric images both for visualization and image analysis so plotline has a variety of traces for 3d visualization i can show here the section of the documentation on the uh 3d uh plots like is it has a surface plots uh which it has uh 3d scatter plots and and so on and so forth uh the performance of these traces depends uh on the size of your data sets like if for example you want to compute a nicer surface of several millions of points it can take quite a lot of time and it can even freeze your browser so um usually you want to limit uh the number of data points uh which you you feed the browser since the browsers are not very good with very large objects but for medium sized data sets you've got all this nice traces which you can use so for image processing in 3d in particular you can use slices or maybe i can show this up dash playground it's a recent app which we've been writing so it's not using here a 3d uh trace but it's using uh just slices through a 3d volume so it's a it's an mri data set here so this is just a broadly image where here i'm navigating through the the different slices and so here in in this interactive dash app we want to segment here a lesion which is a part of the brain where there was a problem and so the segmentation is done so you can see that this slicing and dicing through the volume works quite well so this is something you can do with splatling and you also have a 3d view here of the brain where you you have here the the lesion which has been segmented in 3d and the contour of the brain so this is a typical example of what you've been doing in 3d with splatly so that was for the vince and as for the image analysis so plotli does not include image processing algorithms but uh if you're calling uh its python api then you can use uh other packages such as psycat image uh for example so that uh you can write callbacks which are just a few lines uh calling uh second image functions and this is what we've been doing in this since that project if you're interested i forgot to mention that we've got a blog which is uh you can see it from my twitter i've tweeted a few blog posts with some examples uh describing how to use plotly dash and circuit image together for uh image processing and one of the next posts will be on the 3d visualization in image processing um so i think i went through the whole list of questions uh i don't know if we still have time for one or two questions it's also possible of course to reach out after the webinar but the nice thing here is that other people can see the questions and hear the answers oh we can take a look also at the at the results of the poll uh but there is uh one more question uh oh which is basically a story of my life could you share your career trajectory from your phd in physics to working on open source development full time so during this year's in research i've been doing experiments where my main source of scientific data was images and i needed to extract some numbers some scientific data from this large sets of images which i was acquiring at the synchrotrons and so and for for this this is how i started contributing to psychic image because when i started doing image phosing a second image was actually just starting and i i got more and more involved because uh well first of all the scientific writing is community is a very nice one very welcoming and i felt very welcomed so i wanted to to spend more time in this community and also i realized the importance of having open source tools uh available to a large community because this was something i was directly using for my my research work so i i tried to spend some time on open source development but as a hobby and at some point i thought hey why don't you try to turn this hobby into a job and this is how i joined plotley which is this open core company uh developing nice open source tools used by very large number of users with also a commercial offering but i've been working on the the open source tools and so at the end of uh this grant i'm going back to to research but uh it's been really great navigating uh between research and software because uh um so for the research the software tools are just essential you you need them to do your science but also when you're developing uh software it's very useful to have ids about what users can do and having my background in research having also collaborations and contacts students doing research has been very useful when developing software because it helps developing the right tools something which you think will be really used so um i would encourage really people in research trying to spend more time developing open source software but also people developing software also trying to be in the shoes of their users and also to to work on applications so basically doing more multidisciplinary work so thank you for for this question and for all the questions thank you thank you so much emma um i think that is the most successful live coding demo i have seen which is really great because you never know how these things well yeah only a few bucks it was really great um thank you so much um and for our um you know for people who are joining i'm gonna you know sort of um put a video up within the next few days and for sharing the notebook it won't be today because it's midnight in paris so bear with me in wait until tomorrow please yeah we'll definitely get that information out i'll probably add it as a link to the youtube video just so it's readily available for whoever watches versus an email or something so yeah i think that'll be great thank you very much to everybody it's been really fun uh giving this presentation and especially answering the question saying thanks for having a lot of questions and if you have more please reach out and on twitter or on the plotline community forum so see you there thanks a lot
