SyntaxMatrix: A customizable framework for Python AI assistant projects.
DEMO:
Demo Video |
Tutorial Video |
syntaxmatrix is a full-stack Python library that lets you build interactive chat-style front-ends for AI apps without diving into a full web framework. It provides:
- Rapid widget registration (text inputs, buttons, file uploaders)
- Dynamic theme toggling and multiple UI modes
- Built-in PDF ingestion & chunking
- Stylized feedback (success, error, warning, info)
- Admin panel, session management, and more
Ideal for Retrieval-Augmented Generation (RAG), data explorers, or any AI assistant interface.
pip install syntaxmatrix
- Rapid UI Creation: One-line calls to register
text_input,button,file_uploader, etc. - Built-in Chat Loop:
user_query(text input),submit_query(send button),user_pdfs(PDF uploader + chunking).
- Custom Widgets: Register any keys you like—just provide matching handler logic.
- PDF Ingestion:
load_pdf_chunks(directory)Domain data that augments LLM's knowledge/ and returns a{filename: [chunks,…]}map. - Session File Uploads:
get_user_chunks(), for per-session user files. - Dynamic Themes:
enable_theme_toggle(),set_theme(), pluslist_themes(). - Multiple UI Modes:
set_ui_mode()supportsdefault,bubble,card,smxandlist_ui_modes(). - Rich Output:
markdown(),latex(),plt_plot(),plotly_plot(), pluserror(),warning(),success(),info(). - Branding Helpers:
set_user_icon(),set_bot_icon(),set_site_icon(),set_site_logo(),set_site_title(),set_project_title(). - Session Management: Named chat sessions with rename/delete; session IDs via
get_session_id().
pip install syntaxmatrixor if upgrading
pip install --upgrade syntaxmatrixThis minimal example uses the built-in chat flow (no custom keys required):
import syntaxmatrix as smx
from syntaxmatrix.plottings import figure, plotly
import os
from openai import OpenAI
from dotenv import load_dotenv
load_dotenv(override=False, verbose=False)
OPENAI_API_KEY = os.getenv("OPENAI_API_KEY")
DEEPSEEK_API_KEY = os.getenv("DEEPSEEK_API_KEY")
XAI_API_KEY = os.getenv("XAI_API_KEY")
GEMINI_API_KEY = os.getenv("GEMINI_API_KEY")
PROFILE = os.getenv("PROFILE")
LLMs = {
"gpt": OpenAI(api_key=OPENAI_API_KEY),
"deepseek": OpenAI(api_key=DEEPSEEK_API_KEY, base_url="https://api.deepseek.com"),
"grok": OpenAI(api_key=XAI_API_KEY, base_url="https://api.x.ai/v1"),
"gemini": OpenAI(api_key=GEMINI_API_KEY, base_url="https://generativelanguage.googleapis.com/v1beta/openai/"),
}
MODELs = {
"gpt":["gpt-4o-mini"],
"deepseek":["deepseek-chat"],
"grok":["grok-2-latest"],
"gemini":["gemini-2.0-flash-lite", "gemini-2.0-flash"]
}
llm = LLMs["gpt"]
model = MODELs["gpt"][0]
smx.set_ui_mode("bubble") # [default, card, bubble, smx]
smx.set_theme("chark", "chark")
smx.set_project_title("RAG System")
smx.set_site_logo("SMX")
smx.set_site_title("smx")
smx.set_user_icon("😸")
smx.set_bot_icon("💀")
smx.set_site_icon("👃")
# smx.enable_theme_toggle()
sys_chunks = smx.load_sys_chunks()
def process_query(query, history, context):
INSTRUCTION = """Generate a response to the given query based on the given content. Use the chat history to stay in context. Refer to your training knowledge if content lacks sufficient knowledge to generate a response.
"""
prompt = [
{"role": "system", "content": PROFILE},
{"role": "user", "content": INSTRUCTION},
{"role": "assistant", "content": f"Query: {query}\n\nContext: {context}\n\nHistory: {history}\n\nAnswer: "}
]
try:
response = llm.chat.completions.create(
model=model,
messages=prompt,
temperature=0.3,
max_tokens=500
)
answer = response.choices[0].message.content
except Exception as e:
answer = f"Error: {str(e)}"
return answer
def create_conversation():
chat_history = smx.get_chat_history()
sid = smx.get_session_id()
# Get any user-uploaded files and process them
personal_chunks = smx.get_user_chunks(sid) or []
context = list(sys_chunks.values())
# Augment the Domain data wit the user data
if personal_chunks:
for p_ch in personal_chunks:
context.append(p_ch)
query = smx.get_text_input_value("user_query").strip()
# Handle the "Enter" keyboard key if pressed when the text input is empty.
if not query:
smx.warning("Enter a query.")
return
# Consider only the last n=10 chat cycles in the chat history
trimmed_history = chat_history[-10:] if len(chat_history) > 10 else chat_history
answer = process_query(query, trimmed_history, context)
chat_history.append(("User", query))
chat_history.append(("Bot", answer))
smx.set_chat_history(chat_history)
smx.clear_text_input_value("user_query")
# Activate System Widgets
smx.text_input("user_query", "Enter query:", placeholder="Type your query here...")
smx.button("submit_query", "Submit", callback=create_conversation)
smx.file_uploader("user_pdfs", "Upload PDF files:", accept_multiple_files=True)
# Register Custom Widgets
def clear_chat():
smx.clear_chat_history()
smx.button("clear_chat", "Clear Chat", callback=clear_chat)
if __name__ == "__main__":
smx.run()Note: If you register different keys, you must also adapt your handlers and/or the request-processing logic to match those names.
You’re not limited to the three defaults. Example:
# Custom keys:
smx.text_input("query_box", "Your query…")
smx.button("ask_btn", "Ask", callback=my_ask_handler)
smx.file_uploader(
"pdf_docs",
"Attach Documents",
accept_multiple_files=True,
callback=my_upload_handler
)Then your my_ask_handler() must read from smx.get_text_input_value("query_box"), and you’ll need to implement or wrap the chat loop yourself if you deviate from the built-ins.
| Function | Description |
|---|---|
run() |
Launches the Flask server and opens a browser window |
set_site_title(title: str) |
Sets the navbar site title |
set_project_title(title: str) |
Sets the main project heading |
set_user_icon(icon: str) |
Emoji/text for user messages |
set_bot_icon(icon: str) |
Emoji/text for bot messages |
set_site_icon(icon: str) |
Small icon in the browser tab |
set_site_logo(logo: str) |
Text/logo in the navbar |
| Function | Description |
|---|---|
enable_theme_toggle() |
Show a light/dark toggle link in the navbar |
disable_theme_toggle() |
Hide the theme toggle |
set_theme(name: str, theme_dict?: dict) |
Switch or define a custom theme |
list_themes() -> List[str] |
Get all available theme names |
set_ui_mode(mode: str) |
Choose layout: default, bubble, card, smx |
list_ui_modes() -> Tuple[str,…] |
Available UI modes |
| Function | Description |
|---|---|
text_input(key, label, placeholder="") |
Register a text box. For built-in chat use key=user_query. |
button(key, label, callback=None) |
Register a button. For built-in chat use key=submit_query. |
file_uploader(key, label, accept_multiple_files=False, callback=None) |
Register a file upload. For PDF chunking use key=user_pdfs. |
get_text_input_value(key) |
Read current text in a box |
clear_text_input_value(key) |
Clear the text box |
get_file_upload_value(key) |
Access raw file objects uploaded |
| Function | Description |
|---|---|
load_pdf_chunks(directory: str = "uploads/sys") |
Ingest all system PDFs → split into chunks → cache → return {file:[chunks]} |
get_session_id() -> str |
Current chat session UUID |
add_user_chunks(sess_id: str, chunks: List[str]) |
Store user-uploaded text chunks |
get_user_chunks(sess_id: str) -> List[str] |
Retrieve stored user chunks |
clear_user_chunks(sess_id: str) |
Remove all user chunks for session |
| Function | Description |
|---|---|
write(content: str) |
Append raw HTML/text to system-output buffer |
markdown(md_text: str) |
Render Markdown via Python-Markdown |
latex(math_text: str) |
Render LaTeX math via MathJax |
error(msg: str) |
Output red-styled error message |
warning(msg: str) |
Output orange-styled warning |
success(msg: str) |
Output green-styled success |
info(msg: str) |
Output blue-styled info |
plt_plot(fig: matplotlib.figure.Figure) |
Embed a Matplotlib figure |
plotly_plot(fig: plotly.Figure) |
Embed a Plotly figure |
MIT © Bob Bobga Nti
