Data Mining Train Project

Repository for the data mining project at the ULB 2023-Fall

Installation

The virtual environment assumes python 3.11. Create your virtual environment and activate it using:

# Creates the virtual environment
python3.11 -m venv train_env
#activates the virtual environment
source train_env/bin/activate

Install the dependencies used by using

pip install -r requirements.txt

If you need to update the requirements, i.e. you added a new library, add it to the requirements using

pip freeze > requirements.txt

To deactivate the virtual environment, open a new terminal or run the command

deactivate

Fix-Lint Autopep8

We use autopep8 to fix the format of the code. Run the following command before pushing to the branch.

sh fix-lint.sh

Data

Please add the file ar41_for_ulb.csv to the data folder so that all scripts are consistent.

Order of running the scripts

Please run in order

python src/scripts/make_parquet_from_csv.py
python src/scripts/clean_location.py
python src/scripts/clean_outliers.py
python src/scripts/mark_stop_track.py
python src/scripts/add_weather.py
python src/scripts/dump_load_pickle.py -kmeans_k 5 -kmeans_percentile 95 -dbscan_eps 0.5 -dbscan_min_samples 20 -if_contamination 0.05 -svm_nu 0.05
python src/scripts/make_small_subsample.py

For reference about the meteorological data please consult this link

Cluster

Columns explanation:

1. k_cluster: The cluster the point belongs to(0,1,2,3...) calculated by kmeans

2. k_anomaly: Whether it's an anomaly, detected by threshold(-1,1)

3. db_cluster: The cluster the point belongs to(-1,0,1,2...) calculated by dbscan

4. if_cluster: The cluster the point belongs to(-1,1) calculated by isolation forest

5. svm_cluster: The cluster the point belongs to(-1,1) calculated by svm one class

Dashboard

For the dashboard please set up docker first using

docker compose up -d

Afterwards upload the data to TimescaleDB using

python src/scripts/upload_data_to_timescaledb.py

It should take around 5 minutes to upload.

Now you can go to http://localhost:3000/dashboards and a selection of dashboards should appear. The user is gabriel and the password is gabriel.

To stream data you can use

python src/scripts/stream_data.py
